Duracell Lithium/Manganese Dioxide Ultra 123 User manual

Lithium/Manganese Dioxide
Ultra 123
Li/MnO2
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
**
6/08
Duracell Ultra 123 Typical Performance
500 1000 1500 2000
ANSI Photo
35mm SLR Photo
35mm Point &
Shoot Camera
Pulse Cycles
1.2A, 3 sec on 7sec off,
to 1.7V @ 20°C
1.8A, 3 sec on 7sec off,
to 2.0V @ 20°C
0.9A, 3 sec on 27sec off,
to 1.55V @ 20°C
Dimensions shown are IEC/ANSI standards
( + )
17.0
16.0
9.6 mm
MAX
1.0 mm
MIN
( – )
34.5 mm
MAX
φmm
33.5 mm
MIN
0.9 mm
MAX
φ11.0 mm
MIN
Nominal Voltage: 3.0 V
Typical Voltage: 3.2-3.3 V
Nominal Internal
Impedance: 0.25 ohm @ 1kHz
Average Weight: 17.0 gm
Volume: 7.18 cm
3
Terminals: Flat, Recessed Negative
Terminal, Nickel Plated Steel
Operating Temperature
Range: -20
o
C to 75
o
C
(-4
o
F to 167
o
F)
ANSI:
IEC: 5018LC CR17345
Delivered Energy vs. Power Drain
@ Various Cutoff Voltage - Room Temperature
2.2
2
1.8
Energy (Wh)
2
4
11
Power (W)
4
2
0.5
0.2
2500

This data is subject to change. Performance information is typical. Contact Duracell for the latest information
6/08
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
**
Continuous Discharge
1
3
4
0.1 110 100 1000
Service (Hours)
Voltage (V)
10 mA
50 mA
100 mA
250 mA
500 mA
750 mA
1000 mA
RT to 1.55 Volts
10 mA
50 mA
100 mA
250 mA
500 mA
750 mA
1000 mA
0.9 Amp, 3 sec on/27 sec off
@ Various Temperatures
1.5
1.7
1.9
2.1
2.3
2.5
2.7
0 500 1000 1500 2000 2500
Pulses
Battery Voltage (V)
-10°C
-20°C
RT
1.2 Amp, 3 sec on/ 7 sec off
@ Various Temperatures
1.5
1.7
1.9
2.1
2.3
2.5
2.7
0 200 400 600 800 1000 1200 1400 1600
Pulses
Battery Voltage (V)
-10°C
-20°C
RT
1.8 Amp 3 sec on/ 7 sec off
@ Various Temperatures
1.5
1.7
1.9
2.1
2.3
2.5
2.7
0 100 200 300 400 500 600 700 800 900 1000
Pulses
-10°C
RT
Battery Voltage (V)
