Duracell Inverter 3000 User manual

Owner's Guide
975-0444-01-01 REV. A Printed in China
t 1 408 987 6359
www.xantrex.com/support
INVERTER 3000

INVERTER 3000
Owner’s Guide
Dur_Inverter_3000_Owners_Guide.book Page i Tuesday, June 3, 2008 11:51 AM

About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with
products ranging from small mobile units to utility-scale systems for wind, solar, batteries, fuel cells,
microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex
products include inverters, battery chargers, programmable power supplies, and variable speed drives
that convert, supply, control, clean, and distribute electrical power.
Trademarks
DURACELL® is a registered trademark of The Gillette Company, used under license. All rights
reserved. XANTREX is a registered trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of their respective owners
and are used herein for identification purposes only.
Notice of Copyright
Duracell®Inverter 3000 Owner’s Guide © May 2008 Duracell. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREXTM”)
(A)MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR
OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(B)ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF
SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’SRISK; AND
(C)REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH
STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE ACCURACY CANNOT
BE GUARANTEED. APPROVED XANTREX CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE
VERSION WHICH IS POSTED AT WWW.XANTREX.COM.
Date and Revision
May 2008 Revision A
Part Number
975-0444-01-01
Product Number
813-3007
Contact Information
Telephone: [phone]
Website: www.xantrex.com/support
Dur_Inverter_3000_Owners_Guide.book Page ii Tuesday, June 3, 2008 11:51 AM

iii
About This Guide
Purpose
The purpose of this Owner’s Guide is to provide explanations and
procedures for operating, maintaining, and troubleshooting the Duracell
Inverter 3000.
Scope
The Guide provides safety guidelines, as well as information about
operating and troubleshooting the inverter. It does not provide details
about particular brands of batteries. You need to consult individual
battery manufacturers for this information.
This Guide does not provide installation instructions. Installation should
be handled by qualified installers including licensed technicians and
electricians. Qualified installers have knowledge and experience in
installing electrical equipment, knowledge of the applicable installation
codes, and awareness of the hazards involved in performing electrical
work and how to reduce those hazards.
Qualified installers are to use the Duracell Inverter 3000 Installation
Guide (doc. part number: 975-0445-01-01).
Audience
The Guide is intended for users and operators of the Duracell Inverter
3000.
Dur_Inverter_3000_Owners_Guide.book Page iii Tuesday, June 3, 2008 11:51 AM

About This Guide
iv 975-0444-01-01
Organization
This Guide is organized into four chapters and one appendix.
Chapter 1 describes the standard features of the Duracell Inverter 3000, as
well as its protection features.
Chapter 2 provides information on the different parts of the Duracell
Inverter 3000.
Chapter 3 describes the operational procedures for using the Duracell
Inverter 3000.
Chapter 4 contains information and procedures for troubleshooting the
Duracell Inverter 3000.
Appendix A contains physical and electrical specifications of the Duracell
Inverter 3000.
Conventions Used
The following conventions are used in this guide.
Related Information
You can find more information about Xantrex Technology Inc. as well as
its products and services at www.xantrex.com
WARNING
Warnings identify conditions that could result in personal injury or loss of life
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
Important: These notes describe things which are important for you to know,
but not as serious as a caution or warning.
Dur_Inverter_3000_Owners_Guide.book Page iv Tuesday, June 3, 2008 11:51 AM

v
Important Safety Instructions
IMPORTANT: Read and save this Owner’s Guide for
future reference.
This chapter contains important safety instructions for the Duracell
Inverter 3000.
1. Before using the Duracell Inverter 3000, READ ALL instructions and
cautionary markings on or provided with the Duracell Inverter 3000,
the batteries, and all appropriate sections of this guide.
2. DO NOT OPERATE this product unless it has been installed by a
qualified installer in accordance with the Duracell Inverter 3000
Installation Guide.
3. Do not expose the Duracell Inverter 3000 to rain, snow, spray, or
bilge water. To reduce risk of fire hazard, do not cover or obstruct the
ventilation openings. Overheating may result.
4. To avoid a risk of fire and electric shock, make sure that wiring is in
good condition, adequately rated, and not undersized. Do not operate
the Duracell Inverter 3000 with damaged or substandard wiring.
5. Do not operate the Duracell Inverter 3000 if it has received a sharp
blow, been dropped, or otherwise damaged in any way. If the
Duracell Inverter 3000 is damaged, see the Warranty section.
6. Do not disassemble the Duracell Inverter 3000. It contains no user-
serviceable parts. See Warranty for instructions on obtaining service.
Attempting to service the Duracell Inverter 3000 yourself may result
in a risk of electrical shock or fire. Internal capacitors remain charged
after all power is disconnected.
7. To reduce the risk of electrical shock, disconnect DC power from the
Duracell Inverter 3000 before attempting any maintenance or
cleaning or working on any circuits connected to the Duracell
Inverter 3000. Turning off controls will not reduce this risk.
WARNING: Shock, fire, and heat hazard. Risk of
injury to persons.
Dur_Inverter_3000_Owners_Guide.book Page v Tuesday, June 3, 2008 11:51 AM

Safety
vi 975-0444-01-01
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the
manufacturer of the equipment in which the battery is installed to
reduce the risk of battery explosion.
2. Working in the vicinity of lead-acid batteries is dangerous. Batteries
generate explosive gases during normal operation. Therefore, you
must read this guide and follow the instructions exactly before
installing or using your Duracell Inverter 3000.
3. This equipment contains components which tend to produce arcs or
sparks. To prevent fire or explosion, do not operate the Duracell
Inverter 3000 in compartments containing batteries or flammable
materials, or in locations that require ignition-protected equipment.
This includes any space containing gasoline-powered machinery, fuel
tanks, as well as joints, fittings, or other connections between
components of the fuel system.
4. Make sure the area around the battery is well ventilated.
5. Never smoke or allow a spark or flame near the engine or batteries.
6. Use caution to reduce the risk or dropping a metal tool on the battery.
It could spark or short circuit the battery or other electrical parts and
could cause an explosion.
7. If you need to remove a battery, always remove the ground terminal
from the battery first. Make sure all accessories are off so you don’t
cause a spark.
8. Remove all metal items, like rings, bracelets, and watches when
working with lead-acid batteries. Lead-acid batteries produce a short
circuit current high enough to weld metal to skin, causing a severe
burn.
9. Have someone within range of your voice or close enough to come to
your aid when you work near a lead-acid battery.
WARNING: Explosion or fire hazard
WARNING: Risk of personal injury due to burns or
battery acid
Dur_Inverter_3000_Owners_Guide.book Page vi Tuesday, June 3, 2008 11:51 AM

Safety
975-0444-01-01 vii
10. Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
11. Wear complete eye protection and clothing protection. Avoid
touching your eyes while working near batteries.
12. If battery acid contacts skin or clothing, wash immediately with soap
and water. If acid enters your eye, immediately flood it with running
cold water for at least twenty minutes and get medical attention
immediately.
Precautions for Using Rechargeable Appliances
Most rechargeable battery-operated equipment uses a separate charger or
transformer that is plugged into an AC receptacle and produces a low
voltage charging output.
Some chargers for small rechargeable batteries can be damaged if
connected to the Duracell Inverter 3000. Do not use the following with
the Duracell Inverter 3000:
• Small battery-operated appliances like flashlights, razors, and night
lights that can be plugged directly into an AC receptacle to recharge.
• Some chargers for battery packs used in power hand tools. These
affected chargers display a warning label stating that dangerous
voltages are present at the battery terminals.
CAUTION: Risk of equipment damage
The output of the Duracell Inverter 3000 is not sinusoidal and may not be
compatible with all loads. Follow the recommendations below.
Dur_Inverter_3000_Owners_Guide.book Page vii Tuesday, June 3, 2008 11:51 AM

viii
Dur_Inverter_3000_Owners_Guide.book Page viii Tuesday, June 3, 2008 11:51 AM

975-0444-01-01 ix
Important Safety Instructions
Precautions When Working With Batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vi
Precautions for Using Rechargeable Appliances - - - - - - - - - - - - - - - - - - - - - - - - - -vii
1 Introduction
Quality Power - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–1
Ease of Use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2
Comprehensive Protection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2
2 Features
AC Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
DC Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–4
Remote Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–5
3 Operation
Turning the Inverter On and Off - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–1
Operating Several Loads at Once - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Display Screen - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Operating Limits - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Power Output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Input Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Inverter Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
High Surge Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Trouble Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Routine Maintenance- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–5
Recharging Your Batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–5
Recycling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–5
Contents
Dur_Inverter_3000_Owners_Guide.book Page ix Tuesday, June 3, 2008 11:51 AM

Contents
x975-0444-01-01
4 Troubleshooting
Common Problems- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–1
Buzz in Audio Equipment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–1
Television Reception - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–1
Troubleshooting Reference - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–2
A Specifications
Electrical Performance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A–1
Physical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A–2
Accessory - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A–2
Warranty and Return Information - - - - - - - - - - - - - - - - - - - - - - - - - - - WA–1
Dur_Inverter_3000_Owners_Guide.book Page x Tuesday, June 3, 2008 11:51 AM

1–1
1Introduction
The Duracell Inverter 3000 has been designed to give you quality power,
ease of use, and reliability.
Please take a few moments to read this chapter to familiarize yourself
with the main performance features and protection features.
Quality Power
The Duracell Inverter 3000 is designed for use in recreational vehicles
(RVs), light and heavy duty truck applications, and other in-vehicle
applications.
• The inverter provides up to 2500 W of continuous power. It is
designed to handle loads such as microwaves, refrigerators, freezers,
circular saws, and small air compressors.
• The inverter’s high surge capability lets you handle many hard-to-
start loads, including large TVs, refrigerators, and freezers.
• The cooling fan in the inverter is thermally activated and comes on
when the inverter becomes warm. The fan turns off automatically
after the inverter has cooled.
Dur_Inverter_3000_Owners_Guide.book Page 1 Tuesday, June 3, 2008 11:51 AM

Introduction
1–2 975-0444-01-01
Ease of Use
Superior features and rugged durability have been combined with ease of
use:
• The inverter is compact, lightweight, and easy to operate.
• Loads can be powered directly from the AC outlets.
• Easy-to-read indicators on the front panel let you monitor system
performance at a glance.
• Remote On/Off switch (part number: 100-0864-01-01) lets you
control the inverter from a convenient location—up to 20 feet (6 m)
away—while the inverter itself is mounted out of sight.
Comprehensive Protection
The inverter is equipped with numerous protection features to guarantee
safe and trouble-free operation:
Low battery alarm Alerts you if the battery has become discharged to
11.0 V or lower.
Low battery voltage shutdown Shuts the inverter down automatically
if the battery voltage drops below 10.5 V. This feature will limit battery
discharge.
High battery voltage shutdown Shuts the inverter down automatically
if the input voltage rises to 15 V or more.
Overload and short-circuit shutdown Shuts the inverter down
automatically if a short-circuit is detected in the load connected to the
inverter’s output, or if the loads connected to the inverter exceed the
inverter’s operating limits.
Over-temperature shutdown Shuts the inverter down automatically if
its internal temperature rises above an acceptable level.
Dur_Inverter_3000_Owners_Guide.book Page 2 Tuesday, June 3, 2008 11:51 AM

2–1
2Features
Chapter 2, “Features” describes the main features of the Duracell Inverter
3000. Familiarize yourself with them before operating the inverter.
Dur_Inverter_3000_Owners_Guide.book Page 1 Tuesday, June 3, 2008 11:51 AM

Features
2–2 975-0444-01-01
AC Panel
Figure 2-1 AC Panel
Feature Description
1On/Off Switch turns the inverter’s control circuit on and off. This
switch is not a power disconnect switch. Disconnect AC and DC
power before working on any circuits connected to the inverter.
2Fault light (red): indicates the inverter has shut down due to
inverter overload or over-temperature.
3Power light (green): indicates the inverter is operating.
4Display Function Button Press this to display battery voltage,
battery current and AC output power.
5Status indicator lights: VOLTAGE, CURRENT, AC POWER
When lit, each light indicates which status is being displayed.
3
75
8
9
10
4
11 12
1
56
2
Dur_Inverter_3000_Owners_Guide.book Page 2 Tuesday, June 3, 2008 11:51 AM

975-0444-01-01 2–3
6Status Display: Shows Voltage, Current or AC Power.
VOLTAGE: Indicates battery power at the input terminal of the
inverter in volts (V).
CURRENT: Indicates current drawn from the battery by the inverter
in amps (A).
AC POWER: Indicates the output power from the inverter as a
percentage of total available watts (kW) being utilized.
7Two 15 A supplementary (overcurrent) protectors
83-Prong AC Outlets: Each outlet is protected by a 15-amp breaker.
9AC Knockout: For hardwiring the inverter.
10 Remote On/Off Connector Port: For connecting the Remote On/
Off Switch.
11 Mounting Flanges (front and rear) allow you to mount the inverter
permanently.
12 Ventilation Openings must not be obstructed for the proper
operation of the inverter. When the inverter is mounted, the
ventilation opening on the DC panel must not point up or down.
Feature Description
Dur_Inverter_3000_Owners_Guide.book Page 3 Tuesday, June 3, 2008 11:51 AM

Features
2–4 975-0444-01-01
DC Panel
Figure 2-2 DC Panel
Feature Description
1Chassis Ground Lug connects to vehicle chassis, DC grounding
bus or to engine’s negative bus.
2Ventilation Opening must not be obstructed for the proper
operation of the inverter. When the inverter is mounted, the
ventilation opening on the DC panel must not point up or down.
3Negative DC Cabling Terminal always connects to the cable
connected to the negative terminal of the battery.
4Positive DC Cabling Terminal always connects to the cable
connected to the positive terminal of the battery.
5Serial number of your inverter.
1
2
3
4
5
Dur_Inverter_3000_Owners_Guide.book Page 4 Tuesday, June 3, 2008 11:51 AM

975-0444-01-01 2–5
Remote Switch
Figure 2-3 Remote Switch
Feature Description
1Remote On/Off Switch turns the inverter’s control circuit on and
off. This switch is not a power disconnect switch. Disconnect DC
power before working on any circuits connected to the inverter.
2Communications Cable is 20 feet (6 m) long.
12
Dur_Inverter_3000_Owners_Guide.book Page 5 Tuesday, June 3, 2008 11:51 AM

2–6
Dur_Inverter_3000_Owners_Guide.book Page 6 Tuesday, June 3, 2008 11:51 AM

3–1
3Operation
Chapter 3 explains how to operate the inverter efficiently and effectively.
Specifically, this chapter:
• Gives procedures for operating the inverter from the front panel
• Discusses operating limits and inverter loads
• Discusses battery charging frequency
• Provides information about routine maintenance and recycling
Turning the Inverter On and Off
The On/Off switch on the inverter’s front panel turns the control circuit in
the inverter on and off.
To turn the inverter on and off from its front panel:
• Move the On/Off switch to the On position to turn the inverter on.
• Move the On/Off switch to the Off position to turn the inverter off.
When the switch is Off, the inverter draws a very low current from
the battery.
To turn the inverter on and off from the remote switch:
• Move the On/Off switch to the On position to turn the inverter on.
• Move the On/Off switch to the Off position to turn the inverter off.
When the switch is Off, the inverter draws a very low current from
the battery.
Important: TURNING THE INVERTER OFF WHEN NOT IN USE.
The inverter draws less than 600 mA from the battery with the On/Off switch
turned on and no load connected, but draws far less than this with the switch
turned off. If the switch is left on, even with no loads the inverter will eventually
discharge the battery.
To prevent unnecessary battery discharge, turn the inverter off when you are not
using it.
WARNING: Shock and energy hazard
The inverter’s On/Off switch (on the front panel and remote switch) does not
disconnect DC battery power from the inverter. You must disconnect DC power
before working on any circuits connected to the inverter.
Dur_Inverter_3000_Owners_Guide.book Page 1 Tuesday, June 3, 2008 11:51 AM
