DURAG D-ISC 100 2 Series User manual

Operating manual
D-ISC 100 x xx2
Universal control unit
GmbH • Kollaustraße 105 • 22453 Hamburg • Germany • www.durag.com
Before starting any work please read the operating
manual!
Article no.:
4 019 392

Version: 10015849-21-04 Previous version: -/-
Production date: 06/11/2017
Volume: 212
Operating manual Universal control unit D‑ISC100
DURAG GmbH
Kollaustraße 105
22453 Hamburg
Germany
Telephone:
Fax:
Email:
Internet:
[phone] – 0
[phone]
[email protected]
www.durag.com
This manual...
●Generally relates to the entire equipment, even when individual program modules or (parts of)
devices were not purchased.
●Relates to the current device design version at the time this documentation was updated (see above
for production date);
●Contains illustrations which may differ from the actual appearance due to further technical develop-
ments or for reasons of clarity. Therefore, the existing illustrations do not make any claims for deliv-
ery of identical products.
●Must not be reproduced or transferred in any manner, language or medium, electronic or mechan-
ical, without the express permission of DURAGGmbH. The same applies to parts of the manual.
© DURAG GmbH 2017 All rights reserved.
