Durite 0-776-31 User manual

IP68 Fully Waterproof Monitor CCTV Kit
Part No. 0-776-31
0-776-31-LEAFwww.durite.co.uk
WARNINGS
Before using this unit please read these instructions carefully. Take special care to follow
the warnings and safety suggestions listed below. Keep these instructions for future refer -
ence. There are no user-serviceable parts within the unit, refer servicing to qualified service
personnel.
PRECAUTIONS
•Please ensure you are familiar and comply with local traffic and driving regulations.
•Connection - The camera should only be connected to a Durite cctv system.
•Heat - Do not install the camera near heat sources.
•Mounting - Ensure the camera is facing the desired direction before fixing the camera
base. If fixing to isolated return chassis the camera bracket should be isolated from the
vehicle chassis. The monitor should be mounted to a strong secure surface.
•Service - The user should not attempt to service these units beyond that described in these
instructions. All other servicing should be referred to an authorised service technician.
•Power Source - The monitor should be connected to a 12 - 24 volt dc power supply only.
•Replacement Parts - Use only manufacturers replacement specified parts. Unauthorised
substitutions may result in fire risk, electric shock or other hazards and will void the warran -
ty
•Screen Protective Film - Remove the LCD screen protective plastic cover before use.
GENERAL
The camera has a CCD image sensor which gives a high quality picture and its solid state
circuitry provides extremely long life. Compact size and single connection make it easy
to install. Automatic gain control (AGC) provides a clear image in both strong sunlight
and low light conditions, if lighting conditions fall below a set level the Infra-red LEDs will
illuminate.It is recommended that all camera lead connections are additionally sealed by ei -
ther wrapping with a suitable tape or application of heat shrink sleeving. It is recommend to
connect the system and test before fixing to ensure the correct field of view is displayed.
0-776-31-LEAFwww.durite.co.uk
C
M
C
-
+
Field of View:115°
Waterproof Monitor
CAM1(Black) Extension Cable waterproof connector
waterproof connector
CAM1 Reversing signal cable(white)
CAM2 Reversing signal cable(blue)
Car Power Input: DC11~32V
Camera
Camera
waterproof connector
waterproof connector Extension Cable
CAM2(Black)
SYSTEM CONNECTION
MONITOR DIMENSIONS
220.0
149.3
84.0
20mm
∮6mm∮6mm
20mm 20mm
∮6mm
∮6mm
∮6.5m m
R14
R20
CA M1
CA M2

MONITOR CONTROLS
① ② ③ ④ ⑤ ⑦⑥
①Power
②Left(Vol-)
③Right(Vol+)
④Menu
⑤Null
⑥Null
⑦CAM Switch
Color TFT-LCD Screen
Sun Visor
Bracket Screw
Bracket
Power Indicator
Red：Stand-by
MONITOR OPTIONS
50
BRIGHT
CAM1(NOR)
语言
中文
CAM1(NOR)
LANGUAGE
ENGLISH
CAM1(NOR)
ZOOM
16：9
CAM1(NOR)
50
CAM1(NOR)
CONTRAST 50
CAM1(NOR)
COLOR
DELAYTIME(V1)
10 S
CAM1(NOR)
10 S
CAM2(NOR)
DELAYTIME(V2)
4:3
CAM1(NOR)
ZOOM
Press MENU, monitor will display as follow:
Bright / Contrast / Color / Delay time / Language / Zoom / Mirror
1、Brightness, Contrast, Color
Press MENU to Brightness(50)/Contrast(50)/Color(50), Press left/right to adjust 1-100
2、Delay Time(V1) / (V2)
Press MENU to Delay time(V1)/(v2), Press left/right to adjust 1S-30S
In CAM1(NOR)/CAM2(NOR), press MENU to delay(V1) 10S/delay(V2) 10S, press left/right
to adjust the delay time between 0-30S, then when you disconnect the revers power, the
reverse image will keep the time you set.
3、Language
Eleven Language for Choose
Various language for choose: Chinese/English/French/German/Italian/
Spanish/Portuguese/Russian/Dansk/Polski/Nederlands.
4、ZOOM (Display Mode)
Two display mode 16:9 and 4:3
Press MENU to Mode 16:9, press left/right to switch to 4:3
SPECIFICATION
MONITOR
Product Type.................................7" High Resolution Waterproof Monitor
Power Supply...............................11-32VDC
Power Consumption.....................5W Max
Resolution....................................800 x RGB x 480
Active Area...................................153.60 x 86.64mm
View Angle...................................140 / 110
Contrast Ratio..............................500:1
Luminance (nits)..........................450
Response Time............................25(ms)
Dimensions..................................W 220mm x H 149mm x D 84mm
IP Rating......................................IP68
Operating Temperature............... .-20℃~+60℃
Weight..........................................1.100Kg
Shock Resistance........................8G
Certificate....................................CE, EMC R10
CAMERA
Pick up element...........................1/3" SHARP CCD image sensor
Sensitivity.....................................0 Lux with IR on
S/N ratio.......................................48 dB
Electronic shutter.........................Auto
Lens.............................................F2.9mm
Video output.................................1 Vpp, 75 Ω
AGC.............................................Auto
Power supply...............................12VDC
Power Consumption....................200mA
Weight.........................................360g
Dimensions .................................l 84 x w 76 x h 70mm
Operating temperature................-20˚C to +60˚C
IP Rating......................................IP66
Certificate.....................................CE, EMC R10
0-776-31-LEAFwww.durite.co.uk0-776-31-LEAFwww.durite.co.uk
-ve
Video
NC/sound
+ve 12v dc
Female Screw Plug 5、Reverse Modes
Four reverse modes: N-LR M-LR M-UD N-UD
Ch1 Normal Image
CAM1 NOR
( )
MIRROR(V1)
N-LR
CAM1 MIR
( )
MIRROR(V1)
M-LR
Ch1 Mirror Image Ch1 Up-Down Image Ch1 Up-Down Mirror Image
CAM1 NOR
( )
N-UD
MIRROR(V1)
CAM1 ( )
M-UD
MIR
MIRROR(V1)
In CAM1(NOR), press MENU to V1, then press left/right to set the 4 mode
N-LR M-LR U-UD M-UD. Image mirror, Character normal.
In CAM2(NOR), press MENU to V1, then press left/right to set the 4 mode
N-LR M-LR U-UD M-UD. Image mirror, Character normal.
