M1030-2 MOTE DATASHEET DUST NETWORKS™
CONFIDENTIAL
Product Description
The SmartMesh-XT™ M1030-2 embedded wireless mote uses Time Synchronized Mesh Protocol (TSMP) to enable low-
power wireless sensors and actuators with highly reliable wireless mesh networking. The M1030-2 is tailored for use in
battery- and line-powered wireless devices for applications that demand proven performance, scalability, and reliability.
The M1030-2 uses a 900 MHz radio to achieve more than 200-meter communication distance outdoors, while consuming
down to 30 μA in a typical network deployment. The combination of extremely high reliability and low power consumption
enables applications that require very low installation cost and low-maintenance, long-term deployments.
The standard serial and discrete input/output interfaces of the M1030-2 give it flexibility to be used in a wide variety of
different applications, from industrial process control to security, to lighting. When integrated into a product, the M1030-2 acts
like a network interface card (NIC)—it takes a data packet and makes sure that it successfully traverses the network. By
isolating the wireless mesh networking protocols from the user, the M1030-2 simplifies the development process and reduces
development risk.
Key Features
Reliable Networking
•Uses Time Synchronized Mesh Protocol (TSMP) for
high reliability (>99.9% typical network reliability)
•Frequency hopping for interference rejection
•Mesh networking for built-in redundancy
•Every M1030-2 acts as both an endpoint and a router,
increasing network reliability: “mesh-to-the-edge™”
•Automatic self-organizing mesh is built in
Low Power Consumption
•Ultra-low power components for long battery life
•Network-wide coordination for efficient power usage
•Down to 30 μA typical power consumption
Efficient Radio
•2.5 mW (+4 dBm) RF output power
•–88 dBm receiver sensitivity
•Outdoor range >200 m typical
Predictable Integration
•Standard High-level Data Link Control (HDLC) serial
interface with flow control in the receive direction
•Discrete analog inputs and digital I/O for continuous or
event-based monitoring
•FCC modular certification
•Industrial temperature range –40 °C to +85 °C
•Supports socket or solder assembly
•Rugged design for Class I Division I environments
900 MHz Wireless Analo
g/
Di
g
ital
/
Serial Mot
e
M1030-2

2DUST NETWORKS™M1030-2 MOTE DATASHEET
Contents
1.0 Absolute Maximum Ratings ....................................................................................4
2.0 Normal Operating Conditions .................................................................................4
3.0 Electrical Specifications..........................................................................................5
3.1 Application Circuit .............................................................................................6
4.0 Radio......................................................................................................................7
4.1 Detailed Radio Specifications...............................................................................7
4.2 Antenna Specifications.......................................................................................7
5.0 Pinout.....................................................................................................................8
6.0 Mote Boot Up..........................................................................................................9
6.1 Power-on Sequence...........................................................................................9
6.2 Inrush Current..................................................................................................9
6.3 Serial Interface Boot Up................................................................................... 10
7.0 Interfaces............................................................................................................. 10
7.1 Status LED Signal............................................................................................ 10
7.2 Discrete Input/Output (I/O).............................................................................. 10
7.3 Deep Sleep..................................................................................................... 11
7.4 Serial Interface............................................................................................... 11
7.4.1 Serial Flow Control ................................................................................ 11
7.4.1.1 Serial Port................................................................................ 11
7.4.1.2 Serial Interface Timing Requirements .......................................... 12
7.4.2 Mote Command Data Types .................................................................... 13
7.4.3 Mote Commands ................................................................................... 13
7.4.3.1 Command 0x80 Serial Payload Sent to Mote Serial ........................ 14
7.4.3.2 Command 0x81 Unacknowledged Serial Payload
Received from Mote Serial.......................................................... 14
7.4.3.3 Command 0x82 Acknowledged Serial Payload
Received from Mote Serial.......................................................... 14
7.4.3.4 Command 0x84 Time/State Packet.............................................. 14
7.4.3.5 Commands 0x87 and 0x88 Set Parameter Request/Response.......... 15
7.4.3.6 Commands 0x89 and 0x8A Get Parameter Request/Response ......... 15
7.4.3.7 Command 0x8C Mote Information............................................... 16
7.4.3.8 Command 0x8D Reset Mote ....................................................... 16
7.4.4 Mote Get/Set Command Parameters ........................................................ 16
7.4.4.1 Error Codes.............................................................................. 17
7.4.4.2 Parameter Type 0x01 Network ID................................................ 17
7.4.4.3 Parameter Type 0x02 Mote State ................................................ 18
7.4.4.4 Parameter Type 0x03 Frame Length ............................................ 19
7.4.4.5 Parameter Type 0x04 Join Key.................................................... 20
7.4.4.6 Parameter Type 0x05 Time/State ................................................ 20
7.4.4.7 Parameter Type 0x07 Mote information........................................ 21
7.4.5 HDLC Packet Processing Examples........................................................... 22
8.0 Packaging Description.......................................................................................... 24
8.1 Mechanical Drawings........................................................................................ 24
8.2 Soldering Information ...................................................................................... 25
9.0 Regulatory and Standards Compliance .................................................................25
9.1 FCC Compliance.............................................................................................. 25
9.1.1 FCC Testing .......................................................................................... 25
9.1.2 FCC-approved Antennae......................................................................... 26
9.1.3 OEM Labeling Requirements.................................................................... 26
9.2 IC Compliance ................................................................................................ 26
9.2.1 IC Testing............................................................................................. 26
9.2.2 IC-approved Antennae ........................................................................... 26

-
M1030-2 MOTE DATASHEET DUST NETWORKS™3
9.2.3 OEM Labeling Requirements ....................................................................26
9.3 Industrial Environment Operation.......................................................................26
10.0 Ordering Information............................................................................................27

Absolute Maximum Ratings
4DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
1.0 Absolute Maximum Ratings
The absolute maximum ratings shown below should under no circumstances be violated. Permanent damage to the device may
be caused by exceeding one or more of these parameters.
The M1030-2 can withstand an electrostatic discharge of up to 2 kV Human Body Model (HBM) or 200 V
Machine Model (MM) applied to any header pin, except the antenna connector. The antenna input can withstand a
discharge of 50 V.
2.0 Normal Operating Conditions
Unless otherwise noted, Table 3 assumes Vcc is 3.0 V.
Table 1 Absolute Maximum Ratings
Parameter Min Typ Max Units Comments
Supply voltage (Vcc to GND) –0.3 3.6 V
Voltage on digital I/O pin –0.3 VCC + 0.3
up to 3.6
V
Input RF level 10 dBm Input power at antenna
connector
Storage temperature range –45 +85 °C
Lead temperature +230 °CFor 10 seconds
VSWR of antenna 3:1
* All voltages are referenced to GND
Table 2 Normal Operating Conditions
Parameter Min Typ Max Units Comments
Operational supply voltage range
(between Vcc and GND) 2.7 3.3 VIncluding noise and load regulation
Voltage on analog input pins 01.5 V
Voltage supply noise 10 mVp-p 50 Hz–2 GHz
Peak current 40
18 mA mA Tx, 14 ms maximum Rx, searching for
network, 60 minutes,
maximum
Average current 30 μAAssuming 80-byte
packets, 1 per minute,
data only mote, 3 V,
25 °C
Storage and operating temperatures –40 +85 °C
Maximum allowed temperature ramp 8°C/min –40 °C to +85 °C
Table 3 Current Consumption
Parameter Min Typ Max Units Comments
Transmit 28 40 mA
Receive 14 18 mA
Sleep 818 μA

Electrical Specifications
M1030-2 MOTE DATASHEET DUST NETWORKS™5
CONFIDENTIAL
3.0 Electrical Specifications
.
Unless otherwise noted, Vcc is 3.0 V and temperature is –40 °Cto +85 °C.
.
Table 4 Device Load
Parameter Min Typ Max Units Comments
Input capacitance (clamped) 24.2 μF
Input capacitance (unclamped) 15.1 μF
Table 5 Digital I/O
Digital signal Min Typ Max Units Comments
VIH (logical high input) 0.8 x Vcc Vcc Vcc + 0.3 V
VIL (logical low input) GND – 0.3 GND GND + 0.6 V
VOH (logical high output) 0.7 x Vcc Vcc Vcc V
VOL (logical low output) GND GND 0.25 x Vcc V
Digital current*
Output source (single pin) 0.6 mA VOH = 2.3 V, 25 °C
Output sink (single pin) 0.6 mA VOL = 0.5 V, 25 °C
Input leakage current 50 nA
*This current level guarantees that the output voltage meets VOL of 0.25 x Vcc and VOH of 0.7 x Vcc.
Table 6 Analog Inputs
Analog Signal Min Typ Max Units Comments
Vref
Source current 1mA
Output level 1.44 1.5 1.56 V
Analog input
Input impedance 2kΩ
Input capacitance* 40 pF
Input voltage 0Vref V
*In order to ensure that the input capacitance can charge quickly enough to get an accurate reading, the total input
impedance, including source, should be less than 75 kΩ.

Electrical Specifications
6DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
The voltage reference source Vref is powered on before taking analog readings and complies with the timing diagram below.
Figure 1 Vref Timing Diagram
3.1 Application Circuit
The following schematic shows how the M1030-2 mote can be used in a circuit.
Figure 2 M1030-2 Mote in Application Circuit

Radio
M1030-2 MOTE DATASHEET DUST NETWORKS™7
CONFIDENTIAL
4.0 Radio
4.1 Detailed Radio Specifications
4.2 Antenna Specifications
A MMCX-compatible male connector is provided on board for the antenna connection. The antenna must meet specifications
in Table 8. For a list of FCC-approved antennae see 9.1.2.
When the mote is placed inside an enclosure, the antenna should be mounted such that the radiating portion of the antenna
protrudes from the enclosure. The antenna should be connected using a MMCX connector on a coaxial cable. For optimum
performance, allow the antenna to be positioned vertically when installed.
Table 7 Radio Specifications
Parameter Min Typ Max Units Comments
Operating frequency 902 928 MHz
Number of channels 50
Channel separation 470 kHz
Channel bandwidth 170 kHz At –20 dBc
Modulation Binary FSK (NRZ)
Raw data rate 76.8 kbps
Receiver sensitivity
At 25 °C, –40 °C
At 85 °C –85 –83 –88 dBm dBm
At 10-3 BER, Vcc = 3 V
Output power (conducted)
At 25 °C, –40 °C
At 85 °C +3 +1 +4 +7 +7 dBm dBm
Vcc = 3 V
Range*
Indoor
Outdoor 80 200 m m
25 °C, 50% RH, 1 meter
above ground, +2 dBi
omni-directional antenna
* Actual RF range performance is subject to a number of installation-specific variables including, but not restricted to ambient
temperature, relative humidity, presence of active interference sources, line-of-sight obstacles, near-presence of objects
(for example, trees, walls, signage, and so on) that may induce multipath fading. As a result, actual performance varies for
each instance.
Table 8 Antenna Specifications
Parameter Value
Frequency range 902-928 MHz
Impedance 50 Ω
Gain +6 dBi maximum
Pattern Omni-directional
Maximum VSWR 3:1
Connector MMCX*
* The M1030-2 can accommodate the following RF mating connectors:
•MMCX straight connector such as Johnson 135-3402-001, or equivalent
•MMCX right angle connector such as Tyco 1408149-1, or equivalent

Pinout
8DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
5.0 Pinout
The M1030-2 has two 11-pin Samtec MTMM-111-04-S-S-175-3 (or equivalent) connectors on the bottom side for handling all
of the I/O. The third pin in each of the connectors is not populated, and serves as a key for alignment. The connectors are
mounted on opposite edges of the long axis of the M1030-2.
The M1030-2 serial interface (serial protocol is specified in 7.4.1) provides flow control in the receive direction only.
The RST input pin is internally pulled up, and is optional. When driven active low, the mote is hardware reset until the signal
is deasserted. Refer to section 6.1 for timing requirements on the RST pin. Note that the mote may also be reset using the mote
serial command (see section 7.4.3.8 ).
Table 9 M1030-2 Pin Functions
Pin
Number Name Mote I/O Direction Internal Pull Up/ Down
1GND In None
2VCC In None
3KEY (no pin) -None
4RX In None
5TX Out None
6LED Out None
7A1 In None
8CTS Out None
9D1 Out None
10 D2 In None
11 A2 In None
12 VRef Out None
13 No Connection -None
14 No Connection -None
15 No Connection -None
16 No Connection -None
17 No Connection -None
18 No Connection -None
19 No Connection -None
20 KEY (no pin) -None
21 No Connection -None
22 RST In 100 kΩpull up
Figure 3 M1030-2 Package with Pin Labels

Mote Boot Up
M1030-2 MOTE DATASHEET DUST NETWORKS™9
CONFIDENTIAL
6.0 Mote Boot Up
6.1 Power-on Sequence
The M1030-2 mote has internal power on reset circuits that ensure that the mote will properly boot. However, for the power on
reset circuitry to function properly the external power supply must meet the timing shown in Figure 4 and specified in
Table 10.
Figure 4 External Power Supply Timing Requirements
The following reset sequence (shown in Figure 5 and specified in Table 10) is required for external power supplies that fail to
meet the requirements above.
Figure 5 Power-on Sequence
6.2 Inrush Current
During power on, the mote can be modeled as a lumped impedance of 1 Ωand 27 μF, as shown in Figure 6. With a source
impedance (Rsrc) of 1 Ω, the inrush current on the mote appears as shown in Figure 7.
Figure 6 M1030 Equivalent Series RC Circuit
Table 10 Power-on Sequence
Parameter Min Typ Max Units Comments
TVcc2RST 10 ms
TVccRv1v2 485 μs

Interfaces
10 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
Figure 7 Vcc Inrush Current
6.3 Serial Interface Boot Up
Upon mote power up, the CTS line is high (inactive). The mote serial interface boots within boot_delay (see Table 13) of the
mote powering up, at which time the mote transmits an HDLC Mote Information packet, as described in section 7.4.3.7.
Once the mote has established wireless network connection, it uses the CTS pin to signify availability to accept serial packets
for wireless transmission. At certain critical times during communication, the mote may bring CTS high. CTS remains high if
the mote does not have enough buffer space to accept another packet. It also remains high if the mote is not part of the
network. Sensor processors must check that the CTS pin is low before initiating each serial packet for wireless transmission.
Note that the mote may receive local serial packets at any time regardless of the CTS state.
7.0 Interfaces
7.1 Status LED Signal
The M1030-2 provides an output that can be used to drive a status LED. This signal indicates network connectivity
information which is useful during mote installation. Alternatively, the mote’s network status may be polled via serial using
the Get Parameter request (see 7.4.3.6) with the mote state parameter (see 7.4.4.3). See Figure 2 for an example application
circuit.
7.2 Discrete Input/Output (I/O)
The M1030-2 has the ability to perform discrete sensor sampling and digital output actuating.
The M1030-2 has two analog inputs (A1, A2), one digital input (D2), one digital output (D1), and a voltage reference (Vref)
output to allow for ratiometric sensors. Refer to section 3.0 for electrical specifications.
The mote buffers individual sensor readings and may perform the following functions:
•Concatenate individual readings into a report and send it into the network
•Summarize the readings into a report and send a it into the network
•Compare readings against threshold values and send a report into the network only if a limit is violated (event-based
monitoring)
•Compare readings against threshold values and locally actuate the digital output
Table 11 Status LED
LED Signal Behavior Mote State
High Off, or in sleep mode
Slow single blink (100 ms low, 900 ms high) On, and searching for potential network
Single blink (100 ms low, 400 ms high) On, and attempting to join network
Double blink (100 ms low, 100 ms high, 100 ms low, 700 ms
high) On, connected to network, attempting to establish redundant links
Low On, fully configured into network with redundant parents

Interfaces
M1030-2 MOTE DATASHEET DUST NETWORKS™11
CONFIDENTIAL
The TSMP 1.0 compliant wireless interface allows a remote monitoring/control application to configure the parameters (such
as sample rate, report rate, and thresholds), receive sensor data and to actuate the digital output. For details on integration with
remote applications, please refer to a Dust SmartMesh-XT Manager datasheet.
Figure 8 Discrete I/O
7.3 Deep Sleep
When the device is powered, the mote has the capability to go into deep sleep, which puts the mote into a non-functional,
lowest-power consumption state with current draw on the order of a few microamps. Deep sleep is ideal when the mote is
connected to its power source (power cannot be externally disconnected from the mote), but must be stored for extended
periods . To put a mote into deep sleep, assert RST active low while shorting the serial TX and RX pins. To wake a mote out of
deep sleep, simply assert RST active low with TX and RX no longer shorted.
The deep sleep detection algorithm relies upon actively driving a signal on the RX port and monitoring the TX port. To prevent
signal contention on the RX port of the mote, it is recommended that a 3.3 kΩresistor be placed in series, with the output of
the signal driving into the RX port unless the microprocessor (see Figure 9) is inactive on this port for the first 23 ms following
the negation of reset. To prevent unintentional detection of deep sleep, all systems incorporating the mote should place a 5 MΩ
pull-up resistor on the TX port of the mote. See the application circuit in Figure 2.
7.4 Serial Interface
The M1030-2 offers a well-defined serial interface that is optimized for low-powered embedded applications. This serial
interface offers a serial port comprised of the data pins (TX, RX) as well as the flow control pin, CTS. Through this port, the
M1030-2 provides a means of transmitting and receiving serial data through the wireless network, as well as a command
interface which provides synchronized time stamping, local configuration and diagnostics.
The following sections detail the Serial Interface Protocol, the Mote Command Interface, and the timestamping capability of
the M1030-2 serial interface.
7.4.1 Serial Flow Control
The Serial Interface Protocol provides for flow control of packets flowing into the M1030-2 serial interface. Packet delineation
and error control are handled separately.
7.4.1.1 Serial Port
The three-pin serial port is comprised of the data pins (TX, RX) as well as the CTS flow control pin used to prevent the
microprocessor from overflowing the mote. This port supports 4800 bps operation. The CTS signal is active low.
Table 12 Serial Parameters
Parameter Value
Bit rate 4800
Stop bit 1
Data bits 8
Parity None

Interfaces
12 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
The following diagram illustrates the pins used in the handshaking protocol:
Figure 9 Diagram of Pins Used in Handshaking Protocol
7.4.1.2 Serial Interface Timing Requirements
The following diagram shows interpacket timing.
Figure 10 Serial Interpacket Timing Diagram
Timout (T1) is the interpacket_delay for communications into the mote, and is defined as the minimum time after the mote
receives the last byte of a packet before it can start receiving the next packet (see Table 13 for values).
Table 13 Timing Values
Variable Meaning Min Max Unit
diag_ack_timeout The mote responds to all requests within this time. 125 ms
boot_delay The time between mote power up and serial interface
availability. 250 ms
interpacket_delay The sender of an HDLC packet must wait at least this amount
of time before sending another packet. 20 ms

Interfaces
M1030-2 MOTE DATASHEET DUST NETWORKS™13
CONFIDENTIAL
7.4.2 Mote Command Data Types
Table 14 defines the command data types used in the commands.
7.4.3 Mote Commands
The mote command interface provides a way to send and receive network packets, access local configuration and diagnostics,
and receive time stamps. All packets between the microprocessor and the mote are encapsulated in the HDLC format
(RFC 1662) and have the following structure (see Figure 11).
Figure 11 HDLC Packet Structure
The command type indicates which API message is contained in the message content. The message content for each command
type is described within the following sections.
FCS is calculated based on 16-bit FCS computation method (RFC 1662). The mote checks the FCS and drops packets that
have FCS errors. There is no mechanism for the mote to tell the microprocessor that a packet has been discarded, so the
applications layer must implement reliable delivery, if desired. All numerical fields in a packet are in big endian order (MSB
first), unless otherwise noted. Section 7.4.5 provides an example of HDLC packet construction and HDLC packet decoding.
Table 15 provides a summary of mote commands, which are described in detail in the following sections. For error handling,
all other packet types should be ignored. The Destination column indicates whether the packet is sent (or received) through the
network or processed locally by the mote.
Table 14 Command Data Types
Data Type Description
unsigned long 4 bytes
unsigned short 2 bytes
unsigned char 1 byte
Table 15 Mote Command Summary
Command Type (HEX) Direction Destination Description
0x80 Microprocessor to mote Network Packet destined for the network
0x81 Mote to microprocessor Network Unacknowledged packet received from the
network and destined for microprocessor
0x82 Mote to microprocessor Network Acknowledged packet received from the
network and destined for microprocessor
0x83 -- –Reserved
0x84 Mote to microprocessor Local Time and mote state information
0x85 -- –Reserved
0x86 -- –Reserved
0x87 Microprocessor to mote Local Set Parameter request
0x88 Mote to microprocessor Local Set Parameter response
0x89 Microprocessor to mote Local Get Parameter request
0x8A Mote to microprocessor Local Get Parameter response
Command
(Byte 1) (Bytes 2—n)
Command Type Message Content
Start Delimiter
(Byte 0) Data Frame (Bytes 1—n)Checksum (Bytes n + 1, n + 2) End Delimiter (Byte n + 3)
0x7E HDLC Packet payload FCS (2 Bytes) 0x7E

Interfaces
14 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
7.4.3.1 Command 0x80 Serial Payload Sent to Mote Serial
Serial Data Packets going into the mote serial port use the command type 0x80. Upon reception of the packet, the mote
forwards it to the network. The format of the serial packet payload is transparent to the mote. The maximum length of the
payload is 80 bytes (excluding byte-stuffing bytes). There is no response by the mote upon reception of this command.
7.4.3.2 Command 0x81 Unacknowledged Serial Payload Received from Mote Serial
Unacknowledged serial data packets going out of the mote serial port use command type 0x81. The network uses this
command to send data out through the mote serial interface. Upon receiving this packet from the network, the mote forwards it
to the microprocessor without sending acknowledgement to Manager. The format of the serial packet payload is transparent to
the mote. The maximum length of the payload is 80 bytes (excluding byte-stuffing bytes).
7.4.3.3 Command 0x82 Acknowledged Serial Payload Received from Mote Serial
Acknowledged serial data packets going out of the mote use command type 0x82. The network uses this command to send
data out through the mote serial interface. Upon receiving this packet from the network, the mote forwards it to the
microprocessor and sends an acknowledgement back to Manager. The format of the serial packet payload is transparent to the
mote. The maximum length of the payload is 80 bytes (excluding byte-stuffing bytes). The microprocessor receives exactly
one copy of the message that was sent through the network.
0x8C Mote to microprocessor Local Mote information
0x8D Microprocessor to mote Local Reset mote
Table 16 Command 0x80 Serial Payload to Mote
Msg Byte Description Data Type Request (Sent to Mote)
1 Cmd type unsigned char 0x80
2(Transparent to mote) First byte of data
...2+n (Transparent to mote) Up to n–1 additional bytes of
data
Table 17 Command 0x81 Unacknowledged Serial Payload from Mote
Msg Byte Description Data Type Value
1 Cmd type unsigned char 0x81
2(Transparent to mote) First byte of data
...2+n (Transparent to mote) Up to n–1 additional bytes of
data
Table 18 Command 0x82 Acknowledged Serial Payload Downstream
Msg Byte Description Data Type Value
1 Cmd type unsigned char 0x82
2(Transparent to mote) First byte of data
...2+n (Transparent to mote) Up to n–1 additional bytes of
data
Table 15 Mote Command Summary
Command Type (HEX) Direction Destination Description

Interfaces
M1030-2 MOTE DATASHEET DUST NETWORKS™15
CONFIDENTIAL
7.4.3.4 Command 0x84 Time/State Packet
Time data packets use the command type 0x84. The time packet includes the network time and the current real time relative to
the Manager. The mote sends this response when it receives a Get Parameter request with time as the parameter (described
later).
7.4.3.5 Commands 0x87 and 0x88 Set Parameter Request/Response
The Set Parameter command allows the setting of a number of configuration parameters in the mote. When the Set Parameter
Request command is sent, the response to the request is sent within the diag_ack_timeout (see Table 13). The command
structure for individual Parameter Types and can be found in section 7.4.4. The length of payload (n) depends on the Parameter
Type and is specified in the Parameter Data Packet section of this document.
.
Table 19 Command 0x84 Time/State Packet
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x84
2-5 The sequential number of the
frame unsigned long Cycle
6-9 The offset from start of frame unsigned long Offset (μsec)
10-11 Frame length unsigned short Frame length (slots)
12-15 UTC time unsigned long Real time part 1 (sec)
16-19 UTC time unsigned long Real time part 2 (μsec)
20-23 Time from the last mote reset unsigned long Mote uptime (ms)
24 Mote state unsigned char Mote state (see Table 34)
25 Mote diagnostics status unsigned char Mote diagnostics status (see
Table 35)
Table 20 Command 0x87 Set Parameter Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x87
2unsigned char Parameter type
3Data First byte of data
...3+n Data Up to n–1 additional bytes of
data
Table 21 Command 0x88 Set Parameter Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x88
2unsigned char Parameter type
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x00

Interfaces
16 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
7.4.3.6 Commands 0x89 and 0x8A Get Parameter Request/Response
The Get Parameter command allows a number of configuration parameters in the mote to be read by serial. When a Get
Parameter Request command is sent, the response to the request is sent within the diag_ack_timeout (see Table 13). The
command structure for individual parameter types can be found in section 7.4.4. The length of payload (n) depends on the
parameter type and is specified in that section. If the error code is not equal to 0, then no data is returned in the response. Error
codes are described in Table 29.
7.4.3.7 Command 0x8C Mote Information
The mote sends this packet on bootup, supplying information about mote properties. For details on bootup, see section 6.3.
Table 22 Command 0x89 Get Parameter Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x89
2unsigned char Parameter type
3Data First byte of data
...3+n Data Up to n–1 additional bytes of
data
Table 23 Command 0x8A Get Parameter Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x8A
2unsigned char Parameter type
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char n
5Data First byte of data
...5+n Data Up to n–1 additional bytes of
data
Table 24 Command 0x8C – M1030-1 Information
Msg Byte Description Data Type Value
1 Cmd type unsigned char 0x8C
2-4 HW model Array of 3 unsigned char 00109
5-6 HW revision Array of 2 unsigned char HW revision
7-10 SW revision Array of 4 unsigned char SW revision
11-18 MAC address Array of 8 unsigned char MAC addr
19 Networking type unsigned char 1 = 900 MHz network
20-21 Network ID unsigned short Network ID
22-29 Datasheet ID Array of 8 unsigned char 000_0001
30-31 Mote ID unsigned short Mote ID
32 Reserved
33 Mote diagnostics status unsigned char Mote diagnostics status (see
Table 35)

Interfaces
M1030-2 MOTE DATASHEET DUST NETWORKS™17
CONFIDENTIAL
7.4.3.8 Command 0x8D Reset Mote
Upon receiving this command, the mote notifies its children about an upcoming reset, then proceeds to reset itself. The delay
to the actual reset depends on the network configuration.
7.4.4 Mote Get/Set Command Parameters
This section specifies the parameters that may be used with the Set and Get Commands. Table 26 provides an overview of the
these parameters.
All requests have the following structure:
All replies have the following structure:
Command Types, Parameter types, and error codes are discussed in the following sections. Data length is the number of bytes
of following data, set to 0 in case of non-zero error code.
7.4.4.1 Error Codes
Table 25 Command 0x8D Reset Mote
Msg Byte Description Data Type Value
1 Cmd type unsigned char 0x8D
Table 26 Set and Get Command Parameters
Parameter Type Set Parameter Get Parameter Description
0x01 XSet the mote’s network ID
0x02 XGet the mote’s current network connection state
0x03 XGet the network frame length
0x04 XSet the network join key on the mote
0x05 XGet the network time and mote state information
0x06 Reserved
0x07 XGet the mote’s properties
0x08 Reserved
0x09 Reserved
0x0A Reserved
Table 27 Request Structure for Parameter Data Packets
Command Type Parameter Type Data (Optional)
1 byte 1 byte Up to 33 bytes
Table 28 Reply Structure for Parameter Data Packets
Command Type Parameter Type Error Code Data Length Data (Optional)
1 byte 1 byte 1 byte 1 byte Up to 31 bytes
Table 29 Error Codes
Number Error Description
0DIAG_NO_ERR No Command-Specific Errors
1DIAG_EXE_ERR Mote unable to execute command
2DIAG_PARAM_ERR Illegal parameter in the request

Interfaces
18 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
7.4.4.2 Parameter Type 0x01 Network ID
The network ID is the identification number used to distinguish different wireless networks. In order to join a specific network,
the mote must have the same network ID as the network Manager. This parameter is only valid for the Set Parameter
command. Upon receiving this request, the mote stores the new network ID in its persistent storage area, but continues to use
the existing network ID. The mote must be reset in order to begin using the new network ID.
The following packet is sent in response to a request to set the network ID.
7.4.4.3 Parameter Type 0x02 Mote State
This parameter is only valid for the Get Parameter command and is used to retrieve the mote’s current network connection
state (see Table 34).
The following packet is sent in response to a request to retrieve the mote’s current network connection state.
Table 30 Parameter Type 0x01 Network ID Set Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x87
2Parameter type unsigned char 0x01
3-4 Network ID unsigned short Network ID
Table 31 Parameter Type 0x01 Network ID Set Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x88
2Parameter type unsigned char 0x01
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x00
Table 32 Parameter Type 0x02 Mote State Get Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x89
2Parameter type unsigned char 0x02
Table 33 Parameter Type 0x02 Mote State Get Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x8A
2Parameter type unsigned char 0x02
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x02
5unsigned char Mote state
6Mote diagnostics status unsigned char Mote diagnostics status (see
Table 35)

Interfaces
M1030-2 MOTE DATASHEET DUST NETWORKS™19
CONFIDENTIAL
7.4.4.3.1 Configuration Change Flag (CCF)
The Configuration Change Flag (CCF) bit is set high when the network ID is changed. Note that when the network ID is
changed over the air (using the XML-API), the entire network synchronously changes over to the new network ID. There is no
delay between when the XML-API command is received and when motes change over to the new network ID. The CCF bit is
set high when the new network ID becomes active. The CCF bit is cleared when the mote receives a Mote Information Get
request (Command 0x07) or the mote is reset.
7.4.4.4 Parameter Type 0x03 Frame Length
This parameter is only valid for the Get Parameter command and is used to retrieve the frame length of the specified frame.
Table 34 Mote States
State # Description Details
1ACTIVE The mote has joined the network and is waiting to be
configured.
2JOINING The mote has sent a join request, waiting to be activated.
3ACT SEARCH The mote is actively searching for neighbors.
4–5 PASS SEARCH The mote is passively searching for neighbors.
6SYNCHRONIZED The mote is synchronized to a network, listening in active
search.
7–8 RESETTING The mote is going through the reset process.
9ONLINE1 The mote has joined a network and has been fully configured,
but has only one parent. The mote is ready to transmit data to
the network.
10 ONLINE2 The mote has joined a network, has been fully configured,
and has multiple parents. The mote is ready to transmit data
to the network.
Table 35 Diagnostics Status
Bit Name Details
7--- Reserved
6--- Reserved
5--- Reserved
4--- Reserved
3--- Reserved
2--- Reserved
1CCF Configuration change flag (see section 7.4.4.3.1)
0NV_ERR Non-volatile memory error
Table 36 Parameter Type 0x03 Frame Length Get Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x89
2Parameter type unsigned char 0x03
3unsigned char Frame ID

Interfaces
20 DUST NETWORKS™M1030-2 MOTE DATASHEET
CONFIDENTIAL
The following packet is sent in response to a request to retrieve the frame length.
7.4.4.5 Parameter Type 0x04 Join Key
The join key is needed to allow a mote on the network. The join key is specific for the network and used for data encryption.
This parameter is only valid for a Set Parameter command. Upon receiving this request, the mote stores the new join key in its
persistent storage. The mote must be reset in order to begin using the new join key.
The following packet is sent in response to a request to set the join key.
7.4.4.6 Parameter Type 0x05 Time/State
This parameter is only valid for the Get Parameter command and is used to request the network time and mote state
information. The response to this command returns the same information as Command 0x84 (Time/State Packet), with the
only difference being that this command can be solicited using a software Get command, rather than a hardware pin.
The following packet is sent in response to a request for the network time and mote state information.
Table 37 Parameter Type 0x03 Frame Length Get Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x8A
2Parameter type unsigned char 0x03
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x05
5unsigned char Frame ID
6-9 Frame length unsigned long Frame length (μs)
Table 38 Parameter Type 0x04 Join Key Set Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x87
2Parameter type unsigned char 0x04
3-18 New join key Array of 16 unsigned char New join key
Table 39 Parameter Type 0x04 Join Key Set Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x88
2Parameter type unsigned char 0x04
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x00
Table 40 Parameter Type 0x05 Time/State Get Request
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x89
2Parameter type unsigned char 0x05
Table 41 Parameter Type 0x05 Time/State Get Response
Msg Byte Description Data Type Value
1Cmd type unsigned char 0x8A
2Parameter type unsigned char 0x05
3Error code unsigned char Error code (see Table 29)
4Data length unsigned char 0x18
