DutchWest 2467 Mounting instructions

INSTALLER / CONSUMER
SAFETY INFORMATION
30002008 7/04 Rev. 3
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROP-
ERTY DAMAGE, PERSONAL IN-
JURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Installation and service must be per-
formed by a qualified installer, service
agency or the gas suppler.
WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electric switch; do
not use any phone in your building.
•Immediately call your gas supplier
from your neighbor’s phone. Follow
the gas supplier’s instructions.
•If you cannot reach your gas supplier,
call the fire department.
DO NOT STORE OR USE GASO-
LINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER
APPLIANCE.
This appliance may be installed in an after
market permanently located manufac-
tured (mobile) home where not prohibited
by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases unless a certified kit is
used.
Dutchwest
Natural Vent Gas
Heater
Models: 2467, 2468
Homeowner’s Installation
and Operating Manual
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
CERTIFIED
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
CFM Specialty Home Products

22
Dutchwest Natural Vent Gas Heater
30002008
PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE.
Thank you and congratulations on your purchase of a Dutchwest stove.
IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these
instructions may result in a possible fire hazard and will void the warranty.
Table of Contents
Installation & Operating Instructions...........................................................................................3
Stove Dimensions ..............................................................................................................4
Clearance Requirements ...................................................................................................5
Alcove Minimum Dimensions .............................................................................................5
Hearth Requirements .........................................................................................................5
Gas Specifications .............................................................................................................6
Gas Inlet and Manifold Pressures ......................................................................................6
High Elevations ..................................................................................................................6
Venting Requirements........................................................................................................6
Vent Layout and Height Requirements ..............................................................................6
Passing Through a Combustible Wall or Ceiling................................................................7
Venting Requirements........................................................................................................7
Install the Optional Fan ......................................................................................................8
Venting System Assembly .................................................................................................9
Connect the Gas Supply Line ..........................................................................................10
Burner Information ...........................................................................................................11
Install ON/OFF Switch......................................................................................................11
Thermostat Connection....................................................................................................11
Install the Logset ..............................................................................................................11
Install Stove Front ............................................................................................................12
Operation
Your First Fire ..................................................................................................................13
Pilot and Burner Inspection ..............................................................................................13
Lighting and Operating Instructions .................................................................................14
Troubleshooting ...............................................................................................................15
Fuel Conversion Instructions............................................................................................16
Maintenance
Annual System Inspection................................................................................................19
Logset and Burner Cleaning and Inspection ....................................................................19
Care of Cast Iron..............................................................................................................19
Cleaning the Glass...........................................................................................................19
Glass Replacement..........................................................................................................19
Gasket Replacement........................................................................................................20
Inspect the Vent System Annually ...................................................................................20
Check the Gas Flame Regularly ......................................................................................20
Stove Disassembly...........................................................................................................20
Wiring Diagrams...............................................................................................................21
Replacement Parts.......................................................................................................................22
Optional Accessories ..................................................................................................................24
Warranty .......................................................................................................................................26

3
Dutchwest Natural Vent Gas Heater
30002008
The Dutchwest Natural Vent Room Heater, Model Nos. 2467
and 2468, is a vented gas appliance listed to theANSI standard
Z21.88b-2001 and CSA-2.33b-2001 for Vented Room Heaters,
and CSA 2.17-M91, Gas-Fired Appliances For Use at High Alti-
tudes.
The installation of the Dutchwest Natural Vent Room Heater
must conform with local codes, or in the absence of local codes,
with National Fuel Gas Code, ANSI Z223.1/NFPA 54 — latest
edition and CSA B-149.1 Installation Code. (EXCEPTION: Do
not derate this appliance for altitude. Maintain the manifold pres-
sure at 3.5 inches w.c. for Natural Gas and 10 inches w.c. for LP
gas at maximum input.)
This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases unless a certified kit is used.
Installation and replacement of gas piping, gas utilization
equipment or accessories, and repair and servicing of
equipment shall be performed only by a qualified agency.
The term “qualified agency” means any individual, firm,
corporation, or company that either in person or through a
representative is engaged in and is responsible for (a)
installation or replacement of gas piping, or (b), the
connection, installation, repair, or servicing of equipment,
whoisexperiencedinsuchwork,familiarwithallprecautions
required, and has complied with all the requirements of the
authority having jurisdiction.
The Dutchwest Natural Vent Room Heater should be
inspected before use and at least annually by a qualified
service agency. It is imperative that control compartments,
burners,andcirculatingairpassagewaysoftheappliancebe
kept clean.
The Dutchwest Natural Vent Room Heater and its individual
shut-off valve must be disconnected from the gas supply piping
during any pressure testing of that system at test pressures in
excess of 1/2 psig (3.5 kPa).
The Dutchwest Natural Vent Room Heater must be isolated
fromthe gas supply pipingsystem by closingits individual manual
shutoff valve during any pressure testing of the gas supply pip-
ing system at test pressures equal to or less than 1/2 psig.
An accessible tap is located above the pilot/on-off knob for
checking the inlet pressure.
This appliance needs fresh air for safe operation and must be
installed so there are provisions for adequate combustion and
ventilation air.
This appliance must be properly connected to a listed 4”
(100mm) Type B venting system or to an approved masonry or
factory-built chimney system. In Canada, a complete reline of
ClassAchimneysisrequired.Thisheater isequippedwithavent
safety shutoff system.
This appliance must be properly connected to a venting
system. WARNING: Operation of this heater when not
connected to a properly installed and maintained venting
systemortamperingwiththeventsafetyshutoffsystem can
result in carbon monoxide (CO) poisoning and possible
death.
This appliance is approved for bedroom installations in the
U.S. and Canada.
This appliance may be installed in an aftermarket* manufac-
tured(mobile) home, wherenot prohibited by stateor local codes.
The Dutchwest Natural Vent Room Heater, when installed,
must be electrically grounded in accordance with local codes or,
in the absence of local codes, with the National Electrical Code
ANSI/NFPA70, (latest edition), or of the current Canadian Elec-
trical Code C22.1.
Duetohightemperaturesthisapplianceshouldbelocated
out of traffic and away from furniture and draperies.
WARNING: Thisapplianceis hotwhileinoperation. Keep
children, clothing, and furniture away. Contact may cause
burns or ignition of combustible materials.
Children and adults should be alerted to the hazards of
high surface temperatures and should stay away to avoid
burnsorclothingignition.Youngchildrenshouldbecarefully
supervisedwhentheyareinthesameroomastheappliance.
Clothing or other flammable materials should not be
placed on or near the appliance.
Any safety screen, glass or guard removed for servicing
an appliance must be replaced prior to operating the
appliance.
The appliance area must be kept clear and free from
combustiblematerials,gasoline,andotherflammablevapors
and liquids.
The flow of combustion and ventilation air must not be
obstructed. The installation must include adequate
accessibility and clearance for servicing and proper
operation.
WARNING: DonotoperatetheRoomHeaterwiththeglass
panel removed, cracked or broken. Replacement of the
panel should be done by a licensed or qualified service
person.
Donotusethisapplianceifanyparthasbeenunderwater.
Immediatelycallaqualifiedservicetechniciantoinspectthe
appliance and to replace any part of the control system and
any gas control which has been under water.
Do not burn wood, trash or any other material for which
thisappliancewasnotdesigned.Thisapplianceisdesigned
to burn either natural gas or propane only.
This gas appliance must not be connected to a chimney
flue serving a separate solid-fuel burning appliance.
CAUTION: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper and
dangerous operation.
Verify proper operation after servicing.
*Aftermarket: Completionofsale,norforpurposeofresale,
from the manufacturer.
Installation & Operating Instructions
Proposition 65 Warning: Fuels used in gas, woodburning or
oil fired appliances, and the products of combustion of such
fuels, contain chemicals known to the State of California to
cause cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6

44
Dutchwest Natural Vent Gas Heater
30002008
C
L
Valve
Inlet
C
L
Valve Inlet
17"
(419mm)
23"
(584mm)
28³⁄₈"
(721mm)
4³⁄₈"
(111mm)
6³⁄₄"
(172mm)
12¹⁄₂"
(318mm)
24¹⁄₂"
(622mm)
See Page 5 for Flue Collar
Centerline Dimensions.
Fig. 1 Dutchwest dimensions.
Dutchwest Natural Vent Gas Heater Dimensions

5
Dutchwest Natural Vent Gas Heater
30002008
Clearance Requirements
Minimum Clearances to Combustible
Materials
Measure side clearances as shown in Figures 2
through 5 from the outer edge of the cast iron stove
top. Measure rear clearances from the outermost
surface of the sheet metal rear skirt.
The Dutchwest heater is approved for installation into
an alcove constructed of combustible materials to the
dimensions and clearances shown in Figure 5.
The same clearances apply in a standard parallel
installation.
Hearth Requirements
The Dutchwest Heater must be installed on rigid
flooring. When the heater is installed directly on any
combustible surface other than wood flooring, a metal
or wood panel extending the full width and depth of the
unit must be used as the hearth. There are no other
hearth requirements.
WARNING:
•Always maintain required
clearances (air spaces) to nearby
combustibles to prevent fire hazard. Do not
fill air spaces with insulation. All venting
components must maintain a 1" (25mm)
clearance to combustible materials. Maintain
a 6” (150mm) clearance when using single
wall pipe.
•The gas appliance and vent system must be
vented directly to the outside of the building
and never be attached to a chimney serving a
separate solid fuel or gas-burning appliance.
•Refer to the manufacturer's instructions
included with the venting system for
complete installation procedures.
Ceiling Clearances
ST774
Fig. 4 Minimum ceiling clearance; minimum alcove height.
72"
(1829mm)
45"
(1140mm)
Parallel Installation: Minimum Clearance
and Flue Centerline
Stove Clearances A: 5” (125mm)
B: 4” (102mm)
Pipe Centerlines C: 16” (406mm)
D: 9¹⁄₄” (235mm) ST128c
Fig. 2 Parallel installation requirements.
C
L
C
L
B
D
C
A
Corner Installation: Minimum
Clearance and Flue Centerline
Stove Clearance A: 4” (102mm)
Pipe Centerline B: 17” (432mm) ST129c
Fig. 3 Corner installation requirements.
A
A
B
B
Alcove Minimum Dimensions
A: 4” (102mm) B: 33” (838mm) C: 5” (125mm)
ST775
Fig. 5 The Dutchwest Natural Vent Stove is approved for
installation into alcoves built of combustible materials.
BA
A
C

66
Dutchwest Natural Vent Gas Heater
30002008
Venting Requirements and Options
The Dutchwest must be properly connected to a listed
4” (100mm) Type B venting system or to an approved
Class A masonry or factory-built chimney system. In
Canada, a complete relining of Class A chimney
systems is required.
The Dutchwest Natural Vent stove will accept decora-
tive 6” (150mm) stove pipe around the Type B venting
system, for aesthetic purposes.
Complete Type B vent systems are available from a
number of manufacturers, and your dealer can usually
supply one. Pipe sections from different makers are not
interchangeable; do not mix pipe or vent sections from
different makers. Follow the vent system
manufacturer’s instructions.
The vent system should conform to the specifications
of the National Fuel Gas Code, latest edition.
If connecting to a Class A chimney system, use 4”
(100mm) single wall or 4” Type B vent connector.
Single wall vent connector requires a minimum 6”
(150mm) clearance to combustible surfaces.
Exterior chimneys may be subject to flow reversal or
condensation. To lessen these conditions, enclose
Type B vents in an insulated chase, or reline exterior
Class A chimneys.
An approved pass-through device is always required,
whether the vent system passes through a wall or a
ceiling. Use a pass-through device from the same
maker who supplies the venting system.
Venting terminals shall not be recessed into a wall or
siding.
Vent Layout and Height Requirements
Venting for a Dutchwest can rise vertically through the
home, or can pass through an exterior wall and rise
along the outside of the home. Some codes require
that a Type B vent system rising on the outside of the
home be enclosed in a chase. Check your local codes
for requirements.
The minimum vent system height for the Dutchwest
Natural Vent Stove is 8’ (2.43m), (Fig. 7) measured
from the top of the stove. To determine the minimum
height the vent system must extend through or past the
roof, refer to the 1993 edition of the National Fuel Gas
Code.
Weight: Fully assembled 350 lbs.
Inlet Minimum 5.5” w.c. 11” w.c.
Inlet Maximum 14” w.c. 14” w.c.
Manifold Pressure 3.5” w.c. 10” w.c.
Gas Inlet and Manifold Pressures
Natural LP (Propane)
Dutchwest Natural Vent
Certified to:
ANSI Z21.86b-2001 / CSA Z2.33b-2001
Vented Gas Fireplace Heaters
The installation must conform with local codes or, in
the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 - latest edition.
(EXCEPTION: Do not derate this appliance for
altitude. Maintain the manifold pressure at 3.5” w.c.
for Natural Gas and 10” w.c. for Propane.)
High Elevations
Input ratings are shown in BTU per hour and are
certified without deration for elevations up to
4,500 feet (1,370m) above sea level.
For elevations above 4,500 feet (1,370m) in USA,
installations must be in accordance with the
current ANSI Z223.1/NFPA 54 and/or local codes
having jurisdiction.
In Canada, please consult provincial and/or local
authorities having jurisdiction for installations at
elevations above 4,500 feet (1,370m).
Gas Specifications
Max. Min.
Input Input
Model Fuel Gas Control BTU/h BTU/h
2467 Nat Millivolt 28,000 20,000
2468 Prop Millivolt 28,000 19,000
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual
for correct installation and operational proce-
dures. For assistance or additional information
consult a qualified installer, service agency, or
the gas supplier.

7
Dutchwest Natural Vent Gas Heater
30002008
Passing Through a
Combustible Wall or Ceiling
An approved pass-through device is always required
when a vent passes through a combustible wall or
ceiling. Check with the maker of the vent system for
the correct listed devices that are available. A listed
pass-through device is required whether or not the
installation includes decorative pipe around the Type B
venting system. NOTE: It is essential to seal between
the ceiling support (sometimes called a ‘firestop
spacer’) and the decorative pipe, if installed, with a
high-temperature silicone sealant. (Fig. 6)
Complete the venting system installation according to
the manufacturer’s instructions.
Fig. 7 Vent termination window.
Venting Requirements
Venting Runs
A: Vertical installations up to 36 feet (12m) in
height. Up to an 18 ft. horizontal vent run can be
installed within the vent system using a
maximum of two 90-degree elbows or four
45-degree elbows.
B: Vertical installations up to 36 feet (12m) in
height. Up to a 24 ft. horizontal vent run can be
installed within the vent system using a
maximum of two 45-degree elbows.
(Ratio = 2/3, Hor./Vert.)
= Acceptable venting configuration
= Unacceptable venting configuration
NOTE: When venting staight vertical, without an
elbow, a minimum of 8 ft. vertical is required
off the top of the stove.
Horizontal Run (in feet)
Vertical Run (in feet)
(Measured from top of the unit before any elbow)
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
1 2 4 6 8 10 12 14 16 18 20 22 24
AB
FP567b
Joists
Ceiling
Support
Trim
Collar
Air Space
Listed 4”
(102mm)
B-Vent
Decorative
6” Pipe
High-
Temperature
Silicone
Sealant
Air Space as
Required by
Code
ST361
Fig. 6 A ceiling pass-through, with decorative pipe around
the vent.
High-
Temperature
Silicone
Sealant

88
Dutchwest Natural Vent Gas Heater
30002008
Outer
Shroud Slot
Inner Shroud
Slot
ST194
Fig. 11 Position the fan to engage the inner shroud with the
fan bracket slots and secure with sheet metal screws.
Left Air
Duct
Fan
Inner
Shroud
ST720
Fig. 10 Attach snapstat wire assembly to inside of inner
shroud with clamp screws.
Grommet
Front View
Install the Optional Fan
1. The fan kit includes a blower assembly and a
rheostat assembly, connected by a cable. The
blower assembly mounts to the bottom rear of the
stove, and the rheostat mounts to the left side of the
valve. The assembly includes a ‘snapstat’ which
automatically turns the fan ON (or OFF) above (or
below) approximately 109°F. The rheostat also
provides a range of fan speed settings from Off
(which overrides the snapstat function) to High.
Unpack and inspect the blower assembly. Confirm
that the fan spins freely.
2. Attach the fan assembly to the bracket provided in
the log box. Use #10 sheet metal screws provided
with fan kit. Do not remove finger guard screws.
(Fig. 8)
3. Connect snapstat leads. Disconnect the snapstat
module from the leads inside the snapstat bracket.
(Fig. 9) Bend open the snapstat bracket. Use
needle nose pliers to remove the black plastic
grommet from the bracket. Discard the bracket.
Connect the two wires to the two snapstat extension
leads provided with the parts bag (wires with the
sleeve).
4. Disassemble the inner shroud from the outer shroud
by removing the four screws, two on each side.
5. Place the grommet provided in the manual bag
assembly on the inner shroud. Run the snapstat
extension assembly leads through the grommet
toward the firebox. (Fig. 10)
6. Assemble the inner shroud to the outer shroud
using previously removed screws.
7. Position the fan assembly so the ducts slide
between the inner and outer shroud. The inner
shroud should engage with the two slots in the ends
of the bracket so the bracket and shroud are
interlocked. (Fig. 11) Secure the bracket with the
four sheet metal screws provided in the finish bag.
8. Install the snapstat by loosening the front screw on
the inner side of the duct. (Fig. 12) Slide the
snapstat under the head of the screw and tighten.
Connect the leads to the snapstat. Make sure the
snapstat assembly is mounted straight front to back.
Snapstat Bracket
Snapstat Module
Pinch
Grommet to
Remove
ST670
Fig. 9 Remove the snapstat and grommet from the bracket
Snapstat
Wire Rheostat Wire
Fan
Bracket
Finger Guard
ST669
Fig. 8 Attach the fan assembly to the fan bracket.

9
Dutchwest Natural Vent Gas Heater
30002008
Snapstat
Left Air Duct
ST671
Fig. 12 Install the snapstat and connect the extension wire
terminals. View is with top removed, however, access is
available through the rear when installing fan before gas line
connection.
9. After sliding the firebox in place, the rheostat control
switch attaches to the left side of the valve bracket
at the front of the stove. (Fig. 13)
•Remove the plug from the rheostat bracket.
•Insert the switch box shaft through the hole in
the back of the right side of the valve bracket,
aligning the locator pin with the smaller hole in
that bracket.
•Attach the control knob to the rheostat shaft.
•Use the wire tie to secure the fan and rheostat
wire harnesses together.
10.Plug the power cord into a standard grounded 110
volt household outlet. If the fan control knob is not
turned to the OFF position, the fan will turn on when
the temperature at the snapstat reaches
approximately 109°F.
MOTOR
SNAPSTAT
ON/OFF
RHEOSTAT
WHT
WHT
BLK
BLK
BLK
GRN
BLK
POWER
ST196
Fig. 14 #2767 / FK26 fan wiring diagram.
Retaining Nut
Control Knob ST758
Fig. 13 Attach rheostat to left side of valve.
Rheostat
Venting System Assembly
The venting collar is on the sheet metal draft hood/heat
exchanger assembly, over the firebox. Use a B-vent
adapter, from the same maker as the rest of the B-vent
components, to join the first section of venting to the
draft hood.
The stove includes a spill switch. Operating this stove
when not connected to a properly installed and main-
tained venting system, or tampering with or disconnect-
ing the spill switch, can result in carbon monoxide (CO)
poisoning and possible death.
The stove includes a bracket for installing decorative 6”
(150mm) round stove pipe around the B-vent, for
appearance purposes only. The decorative pipe need
not be concentric with the vent pipe.
If the installation includes decorative stove pipe around
the venting system, make a cardboard template of the
decorative pipe by tracing its circumference. Put this
template in the flue recess in the stove top. Position
the template to fit well against the front of the recess.
(Fig. 16) Use this template to locate the bracket to hold
the decorative pipe. Depending on spacing, the bracket
may fit inside the decorative pipe without interfering
with the vent system. Fasten the bracket to the draft
hood/heat exchanger assembly with a sheet metal
screw.
Template
Sheet Metal Screw
Bracket
ST777
Fig. 16 Use a template to locate the bracket for decorative
pipe to surround the B-vent pipe.
Insert the B-vent adapter into the flue collar and drill
1/8” (3mm) pilot holes through both the stove’s collar
and the adapter. Attach the adapter to the flue collar
with sheet metal screws. (Fig. 17)
ST778
Fig. 17 Attach the B-vent adapter to the flue.

1010
Dutchwest Natural Vent Gas Heater
30002008
Connect the Gas Supply Line
Check the Rating Plate attached by a steel cable to the
firebox, to confirm that you have the appropriate firebox
for the type of fuel to be used. The Dutchwest may be
converted from one gas to another using the appropri-
ate Fuel Conversion Kit listed on Page 23.
This appliance should only be
connected by a qualified gas techni-
cian. Test to confirm manifold
pressures as specified below.
The Dutchwest Heater and its individual shutoff
valve must be disconnected from the gas supply
piping during any pressure testing of that system
at test pressures in excess of 1/2 psig (3.5 kPa).
The Dutchwest Heater must be isolated from the
gas supply piping system by closing its indi-
vidual manual shutoff valve during any pressure
testing of the gas supply piping system at test
pressure equal to or less than 1/2 psig.
There must be a gas shutoff between the stove
and the supply.
In order to connect Natural Gas, use a fitting with
3/8” NPT nipple on the valve side and 1/2” natural
gas supply line with an input of 28,000 BTUs at a
manifold pressure of 3.5” and a minimum inlet
supply pressure of 5.5” w.c.
In order to connect Propane, use a fitting with
3/8” NPT nipple on the valve side and 1/2” pro-
pane gas supply line with an input of 26,000
BTUs at a manifold pressure of 10.0” and a
minimum inlet supply pressure of 11.0” w.c.
In the U.S.; Gas connection should be made in accor-
dance with current National Fuel Gas Code, ANSI
Z223.1/NFPA 54. Since some municipalities have
additional local codes, be sure to consult you local
authority.
In Canada; consult the local authority and CSA-B149.1
installation code.
Connect the gas supply and test for leaks. Use a 50/50
solution of liquid soap and water to test for leaks at gas
fittings and joints. Apply water/soap solution with brush
only - do not over apply. NEVER test with an open
flame. Light the pilot according to the directions on
Page 14, before going to the next step.
CAUTION
B-vent Pipe
Decorative
Pipe 7FSSK Bracket
ST374
Fig. 18 Install decorative pipe over the B-vent pipe.
Attach the first section of venting to the B-vent adapter.
Depending on the length of the individual venting
sections and the lengths of the decorative pipe, you
may need to slip the decorative pipe over the venting
sections before attaching upper sections to lower ones.
The sections of decorative pipe should be oriented with
their seams (if any) toward the wall; sections usually
do not need to be fastened at each joint, other than slip
sections. The decorative pipe need not be fastened to
the locating bracket on the stove. If the layout includes
a slip section, this should be the last section of pipe
visible in the room at the ceiling. Refer to Page 7,
Figure 6 for details on joining the decorative pipe at the
ceiling.

11
Dutchwest Natural Vent Gas Heater
30002008
Burner Information
The appliance must only use the gas specified on the
rating plate, unless converted using a CFM Specialty
Home Products Fuel Conversion Kit. Refer to Page 23
for the correct Fuel Conversion Kit for your model.
Conversion instructions are provided with each kit and
beginning on Page 16 in this manual.
THIS APPLIANCE SHOULD BE CON-
NECTED TO THE GAS SUPPLY ONLY BY A
QUALIFIED GAS SERVICE TECHNICIAN.
FOLLOW ALL LOCAL CODES.
THERE MUST BE A GAS SHUT-OFF BE-
TWEEN THE STOVE AND THE SUPPLY.
In order to connect Natural Gas, use a fitting with 3/8”
NPT nipple on the valve side and 1/2” natural gas
supply line with an input of 28,000 BTUs at a manifold
pressure of 3.5” and a minimum inlet supply pressure of
5.5” w.c.
In order to connect Propane, use a fitting with 3/8”
NPT nipple on the valve side and 1/2” propane gas
supply line with an input of 26,000 BTUs at a manifold
pressure of 10.0” and a minimum inlet supply pressure
of 11.0” w.c.
Install ON/OFF Switch
The switch assembly parts are found in the parts bag.
1. Attach switch assembly to left rear side of stove
shroud (when facing shroud) using two screws and
existing holes in shroud. (Fig. 19)
2. Run wires down back of stove, under bottom of rear
shroud to valve.
3. Attach wires to valve terminals. (Fig. 20)
Switch
Assembly
Screws
Existing
Holes
ST315
Fig. 19 Attach switch assembly to rear shroud.
PILOT
ADJ
TP TH
TPTH
ST228
Fig. 20 Attach switch wires to valve.
Install the Log Set
1. Remove the logs from their packaging, and inspect
each piece for damage. DO NOT INSTALL DAM-
AGED LOGS.
2. Install the rear log centering it side to side on the
sheet metal shelf at the back of the firebox. (Fig. 21)
The log will touch both sides and the back wall of
the firebox.
3. Install the right log by engaging hole on bottom with
pin on the rear log. (Fig. 21) Then set right bottom
side on the burner so the edge of the log touches
the right side of the firebox. The right log does not
use the locator pins on the burner to stay in place.
4. Install the left log by engaging hole on bottom with
pin on rear log. (Fig. 21) Then set left bottom side
on the burner so the edge of the log touches the left
side of the firebox.
5. Loosely sprinkle the lava rocks directly on top of the
burner in front of and between the decorative grate
and the right and left logs. Use the lava rock to
cover brackets on the burner. (Fig. 22)
Thermostat
Wire / Gauge Maximum Run
18 40 feet
20 25 feet
22 16 feet
Thermostat Connection (optional)
Use only a thermostat rated for 500 - 750 millivolts.
Check the table below for the appropriate gauge
thermostat wire to use for the length of lead required in
your installation.
1. Install the wall thermostat in the desired location and
run the wires to the stove location. Terminate these
leads with 1/4” female connectors.
2. Connect the thermostat wires to the valve. (Fig. 20)

1212
Dutchwest Natural Vent Gas Heater
30002008
Install the Stove Front
Insert the handle stub into the hole in the front casting.
Fasten in place with the 3/8” locking nut provided. (Fig.
23)
The front attaches to the stove by four steel tabs that
engage with corresponding cast ribs onto the sides and
bottom of the stove body. Position the front about 3”
down from stove top and lift the plate to engage the
upper tabs behind the adjacent ribs on the sides. (Fig.
24) Then lower the front into position, so the lower tabs
engage with the corresponding ribs at the bottom.
When properly installed, the bottom of the stove front
cannot be pulled away from the sides without also lifting
it.
3/8”
Locking
Nut
Handle Stub
ST773
Fig. 23 Insert handle stub into hole in front. Secure with 3/8”
locking nut.
LG142
Fig. 21 Completed log installation.
Lava Rock
Fig. 21 Install the back, left and right logs.
LG141
Right
Log
Decorative Grate
Rear Log
Left Log
Engage steel
tabs behind
the cast iron
bosses
Bottom tabs engage
notch in the leg ST780
Fig. 24 Install the front plate.
D
UTCH
W
EST
D
UTCH
W
EST
Est.1974

13
Dutchwest Natural Vent Gas Heater
30002008
Operation
Your First Fire
Read these instructions carefully and familiarize
yourself with the burner controls. Locate the pilot
assembly, Figure 25. Follow the lighting instructions on
Page 14 exactly.
During the first fire, it is not unusual to smell some
odor associated with new logs, paint and metal being
heated. Odors should dissipate within an hour or so,
however, you can open a window to provide fresh air
to alleviate the condition.
Pilot and Burner Inspection
Each time you light your heater check that the pilot
flame and burner flame patterns are as shown in
Figures 26 and 27. If flame patterns are incorrect, turn
the heater off. Contact your dealer or a qualified gas
technician for assistance. Do not operate the heater
until the pilot flame is correct.
Follow regular maintenance procedures as described
on Page 19.
Fig. 25 Pilot Assembly location.
ST769
Pilot
Assembly
LG143
Fig. 27 Correct burner flame pattern.
Red Glow
CO105c
Fig. 26 Correct pilot flame pattern.

1414
Dutchwest Natural Vent Gas Heater
30002008
3. Open control access panel.
4. Push in gas control knob slightly and turn
clockwise to "OFF". Do not force.
5. Close control access panel.
1. STOP! Read the safety information above.
2. Turn off all electrical power to the fireplace.
3. For MN/MP/TN/TP appliances ONLY, go on to
Step 4. For RN/RP appliances turn the On/Off
switch to “OFF” position or set thermostat to
lowest level.
4. Open control access panel.
5. Push in gas control knob slightly and turn
clockwise to "OFF".
10. Push the control knob all the way in and hold.
Immediately light the pilot by repeatedly
depressing the piezo spark ignitor until a flame
appears. Continue to hold the control knob in for
about one (1) minute after the pilot is lit. Release
knob and it will pop back up. Pilot should remain
lit. If it goes out, repeat steps 5 through 8.
FOR YOUR SAFETY READ BEFORE LIGHTING
instructions.
•If you cannot reach your gas supplier, call the
Fire Department
C. Use only your hand to push in or turn the gas
control knob. Never use tools. If the knob will not
push in or turn by hand, do not try to repair it, call a
qualified service technician. Applying force or any
attempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service techni-
cian to inspect the heater and to replace any part of
the control system and any gas control which has
been under water.
A. This heater has a pilot which must be lit manu-
ally. When lighting the pilot follow these instruc-
tions exactly.
B. BEFORE LIGHTING smell all around the heater
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any fireplace
•Do not touch any electric switch
• Do not use any phone in your building
•Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
To Turn Off Gas To Heater
Lighting and Operating Instructions
1. Turn the On/Off switch to Off position or set the
thermostat to lowest setting.
2. Turn off all electric power to the fireplace if
service is to be performed.
Lighting Instructions
6. Wait five (5) minutes to clear out any gas. Then
smell for gas, including near the floor. If you
smell gas, STOP! Follow "B" in the safety
information above. If you do not smell gas, go
to the next step.
7. Remove glass door before lighting pilot. (See
Glass Frame Removal section).
8. Visibly locate pilot by the main burner.
9. Turn knob on gas control counterclockwise
to "PILOT".
•If knob does not pop up when released, stop
and immediately call your service technician or
gas supplier.
• If after several tries, the pilot will not stay lit,
turn the gas control knob to "OFF" and call your
service technician or gas supplier.
11. Replace glass door.
12. Turn gas control knob to “ON” position.
13. For RN/RP appliances turn the On/Off switch to
“ON” position or set thermostat to desired setting.
14. Turn on all electrical power to the fireplace.
WARNING:If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
Euro SIT SIT NOVA Honeywell
PILOT
ON
OFF
ON
P
I
L
O
T
O
F
F
O
F
F
5
4
3
2
1
O
F
F
P
i
l
o
t
3/8" - 1/2"

15
Dutchwest Natural Vent Gas Heater
30002008
A. Defective or misaligned Using a match, light [ilot. If pilot lights, turn off pilot and
electrode at the pilot push the ignitor button again. If pilot will not light, check
gap at electrode and pilot - it should be 1/8” to have a
strong spark.
B. Defective ignitor (push Push piezo ignitor button. Check for spark at electrode
button) and pilot. If there is no spark at the pilot, and electrode
wire is properly connected, replace ignitor.
A. Defective pilot generator Check pilot flame. It must impinge on the thermocouple
(thermocouple) or thermopile. NOTE: This pilot burner assembly uses
both a thermocouple adn a thermopile. The thermo-
couple operates the pilot flame. Tighten the thermo-
couple. The thermopile operates the main valve. (ON
and OFF) Clean and/or adjust pilot for maximum flame
impingement on thermocouple and thermopile.
B. Defective automatic valve Turn valve knob to “Pilot”. Maintain flow to pilot; millivolt
operator mete should read greater than 10mV. If the reading is
okay and the pilot does not stay on, replace the gas
valve. NOTE: An interrupter block (not supplied) must
be used to conduct this test.
C.Defective safety switch Check the continuity accross the safety limit switch with
the unit cold. If there is no continuity, the safety switch
needs to be replaced.
A. Remote switch or wires Check rocker switch and wires for proper connection
defective Use jumper wires across terminals at rocker switch. If
burner lights, replace rocker switch. If okay, use jumper
wires across rocker switch wires at the valve. If burner
lights, wires are faulty or connections are bad.
B. Thermopile may not gen- 1. Be sure wire connecitons from thermopile at gas
ate sufficient voltage valve terminals are tight and thermopile is fully inserted
into pilot bracket.
2. One of the rocker switch wires may be grounded
Remove rocker switch wire form valve termianls. If
burner now stays lit, trace rocker switch wiring from
ground. It may be grounded to the appliance of the
gas supply line.
3. Check the thermopile with a millivolt meter. Take
reading at thermopile (“TP” and “TP/TH”) terminals of
gas valve. Should read 325 millivolts minimum while
holding valve knob depressed in PILOT position and
with rocker switch OFF. Replace faulty thermopile if
reading is below specified minimum.
C. Plugged burner orifice Check burner orifices for debris, and remove.
D. Defective automatic valve Turn knob to ON, place rocker switch to ON. Millivolt
operator meter should read greater than 10mV. If the reading is
okay and the burner does not light, replace the valve.
A. Pilot flame may be too low Clean and/or adjust pilot flame for maximum flame
or high, (blowing or lifting). impingement on thermocouple and thermopile.
causing the pilot to drop out
B. Possible blockage of the Check the vent termianl for blockage.
vent terminal
Troubleshooting / Honeywell #8420 Gas Control System
NOTE: Before troubleshooting the gas control system, be sure the external gas shutoff is in the “ON” position.
WARNING: REMOVE THE GLASS PANEL BEFORE PERFORMING ANY GAS CONTROL SERVICE WORK.
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
1. Spark ignitor will
not light
2. Pilot will not stay lit
after carefully
following the
lighting instructions
3. Pilot lights, no gas
to burner, valve
knob ON, remote
switch (rocker
switch) ON
4. Frequent pilot
outage

1616
Dutchwest Natural Vent Gas Heater
30002008
Conversion Precautions
Conversion must be completed only by qualified
personnel. Before proceeding, turn control knob on
valve to “OFF” and turn gas supply OFF. Turn OFF any
electricity that may be going to the appliance. CAU-
TION: Allow stove to cool completely before beginning
conversion.
Conversion Procedure
1. Remove stove front. Lift stove front up and then
swing bottom out and away to disengage from the
stove body. (Page 19, Fig. 36)
2. Swing open the swiveling latches at the top left and
right corners of the glass frame. (Page 20, Fig. 37)
3. Pull the top edge of the glass and frame assembly
away from the firebox face. Place the assembly out
of the way on a flat, padded surface such as a
counter protected by a towel.
4. Remove the logset from the firebox.
L
O
H
I
L
O
H
I
Cap
Hi-Lo
Knob
Lift Open
Center Screw CO100
Fig. 30 Remove center screw from Hi-Lo knob.
Fuel Conversion Instructions
WARNING! This conversion kit shall be installed
by a qualified service agency in accordance with
the manufacturer’s instructions and all applicable
codes and requirements of the authority having
jurisdiction. If the information in these instruc-
tions is not followed exactly, a fire, explosion or
production of carbon monoxide may result
causing property damage, personal injury or loss
of life. The qualified service agency is respon-
sible for the proper installation of this kit. The
installation is not proper and complete until the
operation of the converted appliance is checked
as specified in the manufacturer’s instructions
supplied with the kit.
CAUTION: The gas supply shall be shut off prior
to disconnecting the electrical power, before
5. Remove the rear log bracket by loosening the screw
and sliding the bracket up. CAUTION: Do not
remove the screw completely. It would be very
difficult to replace it. (Fig. 29)
6. Remove the right and left log bracket assembly by
unfastening the two screws which hold the burner in
place. (Fig. 29)
7. Hold the burner at the right hand side and lift to clear
the right burner leg. Then pull to the right to clear the
injectors on the left hand side.
8. Remove injector orifices from left burner leg using
1/2” wrench. (Fig. 35)
9. Install conversion orifices. (Refer to Table 2)
10. Remove cap from HI/LO knob. This can be accom-
plished by lifting the plastic cap off the screw. (Fig.
30)
11. Remove the screw from center of HI/LO knob with
small screwdriver turning counterclockwise. (Fig. 30)
12.Insert blue painted screw when converting to natural
gas and red painted screw when converting to LP.
13. Tighten screw (do not over tighten), replace cap.
14. Locate pilot. (Fig. 29)
15. Replace pilot orifice.
• Remove pilot hood by lifting up. (Fig. 31) NOTE: It
is not necessary to remove the pilot tube for conver-
sion.
PILOT
ON
OFF
PILOT
ADJ
L
O
H
I
Main
Gas Line
Gas Supply Inlet
ST770
Fig. 28 Attach the gas line to the left side of the valve.
Remove Screws Rear Log Bracket
Pilot
Left & Right Log
Bracket Assembly ST350
Fig. 29 Remove rear log bracket and left and right log
bracket assembly.
Loosen Screw

17
Dutchwest Natural Vent Gas Heater
30002008
Pilot Hood
Pilot
Bracket
CO105a
Fig. 31 Remove pilot hood.
Index Tab
Snap Ring
Allen Wrench
CO106a
Fig. 32 Remove pilot orifice.
• Remove pilot orifice with allen wrench. (Fig. 32)
• Install the conversion orifice.
• Reinstall pilot hood. Be sure to align hood with
index tab.
16. Adjust air shutter on the burner. The air shutter is
located on the bottom of the burner on the left. (Fig.
46) Loosen the two nuts holding the shutter in place.
On natural gas units, the shutter is shipped fully
closed. To convert to LP, reset the shutter as speci-
fied in Table 2. (Fig. 34) On propane unit the shutter
is set at 1/8” or 3/8” opening depending on rating
plate serial number. To convert to natural gas, the
shutter should set to fully closed. Refasten the two
nuts.
Front Injector Air Inlet
Air Shutter
Burner
Air Shutter
Rear
Injector Air
Inlet -
Covered
Configuration for
Stove with Serial
#’s up to #5250
Configuration for Stoves with
Serial #’s Starting at 5251
ST718
Fig. 33 Natural gas air shutter setting.
1/8"
3/8"
Air Shutter
(LP Position)
Air Shutter
(LP Position)
Configuration for
Stove with Serial #’s
up to #5483
Configuration for Stoves with
Serial #’s Starting at #5484
ST726
Fig. 34 LP air shutter settings.
Fig. 35 Remove and replace injector orifices.
90¡
Left Burner Leg
Injector Orifices
ST353a
NOTE: Be sure burner leg remains at a 90°angle to
firebox base after conversion.
17. Replace burner. Slide the burner in at an angle with
left side lower than the right side. Slide the left side
onto the injectors, making sure the burner leg
remains at a 90°angle to the base. Lower the right
hand side down in to place. Make sure the burner is
as far left as possible and the injector shoulders are
inside the burner.
NOTE: It is very critical to keep the left burner leg,
which holds the injectors, at a 90°angel to the base.
(Fig. 35) This keeps the orifices aligned with the
tubes inside burner. Failure to do so could affect the
flame appearance and performance of the unit.
18. Place conversion label on valve.
19. Reinstall the right and left log bracket assembly.
20. Replace logs.
21. Replace glass and stove front.
22. Check manifold pressure.
Conversion is complete.

1818
Dutchwest Natural Vent Gas Heater
30002008
Conversion to LP Input (BTU/h) Air Shutter
Kit # Front Part # Rear Part # Minimum Maximum Setting
000-5022 #69 / .029” 30000513 #54 / .055” 20000130 21,500 28,000 3/8” Open
Conversion to Natural Gas Input (BTU/h) Air Shutter
Kit # Front Part # Rear Part # Minimum Maximum Setting
000-5021 #54 / .055” 20000130 #44 / .086” 30000334 19,000 28,000 Fully Closed
Table 2. Injector Orifice Size Matrix

19
Dutchwest Natural Vent Gas Heater
30002008
Maintenance
Your Dutchwest Gas Heater will provide years of
service with minimal upkeep. The following procedures
will help ensure that your stove continues to function
properly.
Annual System Inspection
Have the entire heater and venting system inspected
annually by a qualified gas technician. Replace any
worn or broken parts.
Logset and Burner /
Cleaning and Inspection
Cleanliness is critical to the proper function of the
heater. The logset and burner must all be kept free of
dust and unobstructed by debris. Inspect these areas
before each use and clean as necessary.
1. Turn the burner OFF and let the heater cool com-
pletely before cleaning.
2. Lift the Stove Front up and then swing the bottom
out to disengage it from the heater shell. (Fig. 36)
3. Carefully remove the glass and frame assembly and
place it out of the way on a flat, padded surface
such as a counter protected by a towel.
4. Carefully inspect the Logs for damage. Contact your
local dealer if any damage is evident. DO NOT
OPERATE THE HEATER WITH DAMAGED LOGS.
5. Use a soft bristled brush to sweep dust or debris
from the Logs, Pilot and Burner. Use care as the
logs are fragile and susceptible to damage.
6. Replace the glass panel and frame assembly.
7. Replace the Stove Front.
Care of Cast Iron
An occasional dusting with a dry rag will help keep the
painted surfaces looking new. Use high-temperature
stove paints, available through your local dealer, to
touch-up areas as needed. Clean areas to be painted
with a wire brush and be sure to cover the logs, burner
and valve assembly, glass and frame assembly. Apply
the paint sparingly; two light coats of paint will give
better results than a single heavy coat.
Clean porcelain enamel surfaces with a soft, damp
cloth. Do not use abrasive cleaning agents. If neces-
sary, use only a cleaning agent formulated especially
for use on porcelain enamel surfaces.
CAUTION
TURN THE PILOT OFF BEFORE PAINTING.
ALLOW THE HEATER TO COOL COMPLETELY
BEFORE PAINTING.
Cleaning the Glass
WARNING: Let the glass cool completely before
attempting to clean.
It will be necessary to clean the glass periodically.
During start-up, condensation, which is normal, forms
on the inside of the glass and causes lint, dust and
other airborne particles to cling to the glass surface.
Also, initial paint curing may deposit a slight film on the
glass. It is therefore recommended that the glass be
cleaned two or three times with a non-ammonia house-
hold cleaner and warm water (we recommend gas
fireplace glass cleaner). After that the glass should be
cleaned two or three times during each heating season
depending on the circumstances present.
Clean glass after first two weeks of
operation.
Glass Replacement
Replace glass only with CFM Specialty Home Products
approved parts. Refer to Page 22 for Replacement
Parts. Refer to Figure 37 and previous instructions for
removal of the damaged glass frame.
Fig. 36 Remove the Stove Front.
ST771a
D
UTCH
W
EST
D
UTCH
W
EST
Est.1974

2020
Dutchwest Natural Vent Gas Heater
30002008
Gasket Replacement
The Dutchwest Gas Heater uses a ‘tadpole’ type gasket
to seal between the glass panel and the frame. In time,
this gasket can become brittle and compressed and
should be replaced. New gasket is available from your
dealer.
Shut off the gas supply and allow the stove to cool.
Wear safety goggles and a dust mask.
1. Remove the Front, Glass Frame and Glass Panel.
(Figs. 36, 37) Remove the old gasket. Use a razor
blade, with rounded corners, to separate the glass
and gasket from the frame, and to clean the glass of
any remaining cement or bits of gasket.
2. Determine the correct length of gasket by laying it
out around the edge of the glass. Allow an extra 1 -
2” (25-50mm). Mark the spot to be cut. Use a utility
knife.
3. Starting on a long edge, remove about 6” of the
protective paper strip and apply the flat adhesive
face of the gasket around the outside-facing edge of
the panel. Continue around the panel, applying
about 6” at a time and being careful to not stretch
the material. Do not overlap the gasket ends. (Fig.
38)
4. Apply a thin bead of high temperature silicone
rubber sealant along the inside corner of the glass
frame, all around the perimeter. Place the flat
gasketed side of the glass panel back into the steel
frame. Pinch the rounded inside-facing gasket
material to bulk it up.
5. Replace the glass frame and front panel as previ-
ously described.
Inspect the Vent System Annually
Have the vent system inspected annually by a quali-
fied technician. Shut off the main gas supply before
inspecting the system. Both the inner exhaust pipe and
the outer combustion supply pipe must be checked to
confirm that they are unblocked and in good condition.
Check the Gas Flame Regularly
To ensure that the stove is operating properly, check
the flames periodically to confirm they match Figure 39.
The flames will be blue during the first 15-20 minutes of
operation, and will gradually turn to yellow.
Do not use your stove if the flame pattern differs from
that shown here. Contact your Dutchwest dealer or a
qualified technician for help.
Stove Disassembly
If there is ever a need to remove the firebox assembly
from the stove shell, support the firebox with solid
stands about 6” (150mm) tall under the left and right
outer edges of the firebox base. Do not set the firebox
assembly directly on the floor; this can damage the
control valve and/or the gas lines from the valve to the
firebox.
Before removing the firebox from the shell, disconnect
the on/off switch wires from the valve. If the assembly
includes the optional fan, disconnect the fan rheostat. If
the installation includes a wall thermostat, disconnect
the thermostat leads from valve.
Disconnection and reconnection to the gas line should
only be done by a qualified gas service technician.
Upon reinstallation, the vent system must be sealed to
the firebox as shown in the installation section, Page 9.
Also be sure the logs are placed in the firebox correctly,
as shown on Page 11, Figures 21, 22.
Fig. 39 Correct flame pattern.
LG143
Red Glow
ST582
Fig. 37 Release the latches to release the glass frame.
ST179
Fig. 38 Wrap the gasket material around the outside edge of
the glass.
