DVDO DVDO-H264/5-Encoder User manual

Version: V1.0.0
DVDO-H264/5-Encoder
DVDO-H264/5-Decoder
2K60 H26X Transmitter & Receiver
User Manual

2
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder User Manual
DVDO
Important Safety Instructions
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3.
To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments
/ accessories specified
by the manufacturer.
10. Refer all servicing to
qualified service
personnel.

3
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO
DVDO-H264/5-Encoder&DVDO-H264/5-
Decoder User Manual
Table of Contents
Introduction ...................................................................................................... 4
Features ................................................................................................... 4
Package Contents .................................................................................... 5
Specifications ........................................................................................... 6
Panel Description ..................................................................................... 7
Applications .............................................................................................. 8
FAQs.............................................................................................................. 10
Warranty Terms and Conditions..................................................................... 11

4
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder User Manual
DVDO
Introduction
This HDMI 2.0 transceiver can transmit the uncompressed 4K@60 Hz 4:4:4
video signal up to 100m over a Cat 6a/7 cable. It is integrated with both the
transmitter and receiver configuration. It can self-adjust to be a transmitter
and/or a receiver to adapt to the detected input signal; no additional operation is
required. It also supports dual video streaming and HDMI loop-out. Bidirectional
RS232 and IR are also available. Audio out port supports audio pass-through or
audio de-embedding output.
Features
Supports HDMI input and output resolutions up to 4K@60Hz YUV 4:4:4.
HDCP 2.2 compliant.
Supports dual HDMI video streaming or HDMI loop-out to local display.
Extends 4K signal up to 80m over a Cat 5e/6 cable and up to 100m over a
Cat 6a/7 cable.
Analog Audio port supports audio pass-through or audio de-embedding
output.
Bidirectional IR and RS232 pass-through.
USB 2.0 pass-through up to 480Mbps data rate.
Provides front panel, RS232 and LAN control options.
Bidirectional PoC capable - power adapter connected to either side can
power both transceivers. (Note: It is recommended that you connect the
power adapter to the transceiver at USB Device side before you use USB
function)

5
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO
DVDO-H264/5-Encoder&DVDO-H264/5-
Decoder User Manual
Package Contents
Before you start the installation of the product, please check the package
contents as below:
For transmitter:
DVDO-H264/5-Encoder x 1
DC 12V Power Adapter (with US, UK, EU and AU pins) x 1
Phoenix Male Connectors (3.5mm, 3 Pins) x 2
Mounting Brackets (with Screws) x 2
For receiver:
DVDO-H264/5-Decoder x 1
DC 12V Power Adapter (with US, UK, EU and AU pins) x 1
Phoenix Male Connectors (3.5mm, 3 Pins) x 2
Mounting Brackets (with Screws) x 2

6
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder User Manual
DVDO
Specifications
Video
Transmitter
Receiver
Input Port
1 x HDMI
1 x LAN
Input Resolutions
Up to 1080P@60Hz
Up to 1080P@60Hz
Output Port
1 x LAN
1 x HDMI
Output Resolutions
Up to 1080P@60Hz
Up to 1080P@60Hz
Video Protocol
H.265 Video Compression
Audio
Transmitter
Receiver
Input Port
1 x HDMI
1 x LAN
Output Port
1 x LAN, 1 x Line Out
1 x HDMI, 1 x Line Out
Audio Format
MPEG4-AAC and LPCM Stereo
Control
Control Method
VDirector App on iPad
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
10% to 90%, non-condensing
Storage Temperature -20°C to 70°C (-4°F to 140°F)
10% to 90%, non-condensing
Power Supply
DC 12V 1A/PoE
Power Consumption
TX: 5W (Max) RX: 6W (Max)
ESD Protection
Human body model:
•±8kV (air-gap discharge)
•±4kV (contact discharge)
Product Dimensions
(W x H x D)
175mm x 25mm x 100.2mm/
6.9'' x 0.98'' x 3.9'' each for TX and RX
Net Weight
0.60kg/1.32lbs each for TX and RX

7
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO
DVDO-H264/5-Encoder&DVDO-H264/5-
Decoder User Manual
Panel Description
Front Panel
Status LED
Power LED
Reset LED
Reset
Key
LAN (PoE)
RS232HDMI InAudio OutPower
Connector
Rear Panel
Status LED ID Key
Power LED
Reset LED
Reset
Key
LAN (PoE)
RS232HDMI OutAudio OutPower
Connector
(Press this key to display information
of TX and RX on screen)

8
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder User Manual
DVDO
Applications
(1) 1-1: Extender
Transmitter
HDMI RS232
RS232HDMI
Laptop
Receiver
Projector
(2) 1-n: Splitter
Transmitter
Switch
HDMI
DVD Player
HDMI
Receiver TV
HDMI
Receiver TV
...
(3) m - n: Matrix/Video Wall
To configure matrix and video wall, perform the following:
a) Scan the QR code or search "VDirector" in Apple App Store
with your iPad to install VDirector.
b) Connect all transmitters, receivers and the wireless router
to the network switch according to the following diagram shown:
Wireless Router
iPad
Transmitter
Laptop
HDMI
Transmitter Switch
HDMI
DVD Player
Audio/Video Output
Audio/Video Input
Control
...
Receiver HDMI TV
Receiver
...
HDMI
TV
(VDirector)

9
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO
DVDO-H264/5-Encoder&DVDO-H264/5-
Decoder User Manual
c) Configure the wireless router properly, and then connect your iPad to
the Wi-Fi network. Launch VDirector on iPad, VDirector will start
searching for online devices, and the following main screen will appear:
No.
Name
Description
1
Logo
This logo can be changed to a new one.
2
System
Configuration
Button
Click this button to enter system configuration page
for the functions: 1) Naming and Sequenc
ing; 2)
Video Wall Settings; 3) Advanced Settings; 4)
System Information.
3 RX List Shows the list of online RX devices, including single
device and devices for video walls.
4
RX Preview
Shows the live preview of current RX assignments.
5
TX List
Shows the IP stream’s live preview from TX device.
6 To All Screens
Drag a TX from TX list over this button means the
switching of this TX to all RX devices in RX list,
including video walls.
7 Display
On/Off
Display On: Turn on all RXs' displays.
Display Off
: Set all RXs' displays to standby
state.

10
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder User Manual
DVDO
FAQs
(1) Do the network switch and the wireless router require specific settings?
The network switch doesn't require specific settings. If the wireless router
enables DHCP function, ensure the IP address doesn't start with
"169.254".
(2) Why can't the VDirector find online devices?
Ensure the network switch's broadcasting function is not disabled
intentionally.
(3) Do the transmitter and receiver support RS232 routing?
Yes. RS232 and audio routing will always follow video routing.
(4) Is it also available to configure video wall in the 1-n application?
Yes.
(5) What about the networking size?
Limitless except that one transmitter can’t be watched by more than 50
receivers at the same time. Note: As the number of the watching receivers
increases, the end-to-end latency increases accordingly.
(6) May I change the matched transmitter for a receiver without using
VDirector app?
Yes. The matched transmitter will change by simply holding on the ID key
in the front panel of a receiver for 2 seconds.

11
DVDO-H264/5-Encoder&DVDO-H264/5-Decoder _V1.0.0
DVDO
DVDO-H264/5-Encoder&DVDO-H264/5-
Decoder User Manual
Warranty Terms and Conditions
For the following cases we shall charge for the service(s) claimed for the
products if the product is still remediable and the warranty card becomes
unenforceable or inapplicable.
1. The original serial number (specified by us) labeled on the product has
been removed, erased, replaced, defaced or is illegible.
2. The warranty has expired.
3. The defects are caused by the fact that the product is repaired,
dismantled or altered by anyone that is not from an authorized service
partner. The defects are caused by the fact that the product is used or
handled improperly, roughly or not as instructed in the applicable User
Guide.
4. The defects are caused by any force majeure including but not limited to
accidents, fire, earthquake, lightning, tsunami and war.
5. The service, configuration and gifts promised by salesman only but not
covered by normal contract.
6. We preserve the right for interpretation of these cases above and to make
changes to them at any time without notice.
