DVM International DVM-SA30IR User manual

Thank you for purchasing our smoke
detector. Take a few minutes to read the
user manual thoroughly and
familiarize yourself and your family
with how the smoke detector works.
And save it for future reference.
PRODUCT SPECIFICATIONS
Warranty period: Lifetime = 10 years.
After that, the smoke detector must be replaced.
Look for the production date on the sticker of the detector.
Power supply: Fixed Lithium battery 3 VDC (CR17450), battery not
interchangeable
Alarm Volume: >85dB (A) at 3 meters distance
Alarm Sensitivity: 0.10-0.16dB /m
Alarm Pause: About 8 minutes
Complies With: EN14604:2005/AC: 2008
Sound Pattern: ISO8201 (Beep 0.5s – Pauze 0.5s – Beep 0.5s – Pauze 0.5s – Beep 0.5s
– Pauze 1.5s while the red LED flashes. This pattern is repeated over and over
again.
Sound pattern of the wireless interconnection: Beep-Beep – Pause 1.2s. This pattern
is repeated over and over again.
DESCRIPTION
This is an optical smoke detector. These are particularly sensitive to detecting
visible microparticles (which arise from smoldering fires) and react faster than
ionization smoke detectors. An example of such smoldering fires is a burning
cigarette on a couch or bed, a common cause of devastating fires. Please note
that this device does not detect flames, temperature/heat, carbon monoxide or
other dangerous gases. The smoke detector has many advanced features and
a long service life with the fixed battery.
RECOMMENDED LOCATIONS FOR SMOKE
DETECTORS
1. Your smoke detector is suitable for the landing, hall, bedroom, living room and
dining room.
2. Install it in the stairwell and on each floor.
3. Smoke, heat and burning things spread horizontally after rising to the ceiling,
so install the alarm in the middle of the ceiling of a standard built house.
4. If for some reason the alarm cannot be installed in the middle of the ceiling,
the distance from the smoke detector to the wall should be at least 30 cm (see
Figure 1).
5. If the length of the room or hall is more than 10 meters, you need to install
several alarms there.
6. If the ceiling slopes, the smoke detector should be installed at least 50 cm from
the highest ceiling point in the room (see Figure 2).
Attention: This smoke detector is also suitable for installation in caravans, motor
homes and mobile homes.
1 2
2. Select one of the smoke detectors as the MASTER detector. Treat all other
smoke detectors as SLAVE detectors.
3. Press the master's test button three times within two seconds. The red LED
flashes quickly. The MASTER smoke detector is now in transmit mode for the
radio signal. This mode lasts 48 seconds.
4. While the MASTER smoke detector is in radio signal mode, press the test button
of a SLAVE detector three times within two seconds. The SLAVE detector stores the
signal from the MASTER detector and completes the pairing and gives a beep
with flash as confirmation.
5. Repeat the above steps on all other SLAVE detectors.
Clear wireless connection function
1. Determine which SLAVE detector should have the connection function
cleared.
2. Press the test button of the SLAVE detector three times within two seconds. The
red LED flashes quickly.
3. Press and hold the test button again until the red LED goes out the first time,
then release the test button immediately. The red LED will flash slowly.
4. Now press the test button again. The SLAVE detector beeps three times, which
means that the SLAVE detector has erased the wireless connection.
ATTENTION:
The smoke detector must first be activated, otherwise it will not work.
Thesmoke detector is designed to be wireless paired with up to 40 other smoke
detectors.
The smoke detectors are not designed to be paired with wireless detectors from
other series or manufacturers. The smoke detectors must first be connected to
each other in order to work in a coupled manner.
If one detector goes into alarm, all other, interconnected detectors, also go into
alarm. Only smoke detectors that are successfully linked can transmit the alarm.
If you clear the pairing, only the slave detector pairing is removed. The MASTER
detector cannot clear the link.
INSTALLATION:
WARNING: To prevent injury, the smoke detector must be securely
attached to the ceiling, as described below.
Model: DVM-SA30IR
LOCATIONS TO AVOID
1. Avoid the environment of appliances or places where normal combustion
regularly takes place (such as in kitchens, near stoves, hot water boilers, etc.).
Use specialized smoke detectors, such as temperature detectors, for these areas
to prevent unwanted alarms.
2. Keep at least 3 meters away from rooms with high humidity, such as
bathrooms or rooms near dishwashers or washing machines.
3. Keep a minimum distance of 1 meter from air vents or ventilation openings for
heating and cooling. The air can blow away/suck away smoke from the
detector, preventing the detector from sounding the alarm (in time).
4. Avoid areas where the temperature may fall below 5°C or above 40°C.
5. Avoid extremely dusty or dirty environments. The dust particles prevent the
detector from functioning properly.
6. Also avoid the airflow of (loose) air conditioning units and fans.
ACTIVATE:
Press and hold the test button for about 3 seconds until the LED lights up. Then
release the test button within about 2 seconds. The smoke detector gives a beep
signal to indicate that it is activated and enters the working state.
WIRELESS INTERCONNECTION FUNCTION
1. Make sure all smoke detectors are activated.
Figure 1
Ceiling
30 cm
Figure 2
50 cm
200 cm
21
1116
DoP: RD-380D-HR-24-001
EN 14604:2005/AC:2008
Installation drawing
Figure 3
DECKE
Boreholes
Mounting plugs
Screws
Tighten Unscrew
Smoke detector
OPERATION AND TESTING:
Testing
Press the test button. If the detector works correctly, the alarm will go off. If the
alarm does not go off, the battery is empty or the smoke detector is defective.
DO NOT USE an open flame to test your detector! You can use this to damage the
detector or cause a fire.
NOTE: Test the smoke detector every week!
Resting state:
The red LED flashes 1 time every 48 seconds to indicate that the smoke detector
is active.
Alarm state:
When the detector detects combustion products, it gives a sound alarm and the
red LED flashes once every second. The sound alarm and the flashing LED
continue until the air is clean again.
© Copyright DVM International B.V.

3
TROUBLE SHOOTING
WARRANTY INFORMATION
Guarantees from the producer to the end user (the consumer). The manufacturer
guarantees that each new smoke detector under normal use and maintenance,
for a period of 10 years from the date of manufacture, is free from defects in
materials and workmanship. This warranty does not cover damage resulting
from accident, misuse or misuse or lack of reasonable care for the product. The
manufacturer is in no way liable for any incidental or consequential damages
in the event of breach of this or any other warranty, express or implied, of any
kind whatsoever. Defective products can be returned to the seller with a detailed
description of the problem.
DVM International B.V.
Vlierlaan 5
3735 KT Bosch en Duin
Netherlands
Tel: [phone]
Email: [e-mail]
Manufactured in China.
4
Malfunction Solution
Smoke detector does not
go off during tests.
1. You must activate the smoke detector for
installation.
2. Clean the smoke detector. See "REGULAR
MAINTENANCE".
3. If malfunctions occur during the warranty
period, you can return the detector to your
supplier.
4. If the detector is no longer covered by the
warranty, replace it with a new one.
The smoke detector
beeps approximately
every 48 seconds while
the red LED flashes once
The battery is low, replace the smoke
detector.
Smoke alarm beeps
approximately every 48
seconds (detector goes
into interference mode)
1. Clean the smoke detector. See "REGULAR
MAINTENANCE".
2. Buy a new smoke detector and replace the
defective detector.
The alarm sounds
differently. It starts and
stops again.
1. Clean the smoke detector. See "REGULAR
MAINTENANCE".
2. If the malfunctions occur during the
warranty period, you can return the detector
to the supplier.
3. If the malfunctions occur outside the
warranty period, replace the detector with a
new one.
Smoke detector
occasionally makes
alarm or makes alarm
when cooking,
showering, or something
similar.
1. Press the alarm pause button.
2. Clean the smoke detector. See "REGULAR
MAINTENANCE".
3. Move the smoke detector to a different
location and press the test button.
Low battery voltage:
IMPORTANT: For the smoke detector to function correctly, the battery voltage
must be sufficient. If the battery voltage becomes too low, the detector will sound
a beep every 48 seconds, with the LED flashing 1x. When you hear this, you
should immediately install a new smoke detector.
The smoke detector will warn of a low battery voltage for at least 30 days.
If you do not install a new detector in time, the smoke detector may not receive
enough voltage to alert you in a real fire situation.
Fault notication:
The detector beeps every 48 seconds.
Alarm pause
If the smoke detector is in alarm you can press the test button, the alarm signal
(beeps) is then silent for about 8 minutes. The red LED continues to flash n every
8 seconds, as an indication that the smoke detector is on Alarm pause.
If the smoke detector generates the complete alarm signal (beeps and flashing
LED) and you are not testing the alarm, the smoke detector warns of a
potentially dangerous situation that requires your immediate attention. Use the
alarm break only after you have made sure that there is no persistent fire
situation. Do not block the smoke detector vents or turn off the smoke detector in
any way, as this will lift your protection.
Smoke detectors can sometimes respond to cooking fumes or other non-
emergency situations. In the event of a known false alarm, your smoke detector
can be temporarily switched off by pressing the test button. Your smoke detector
automatically returns to full sensitivity within 8 minutes.
NOTE:
1. Press and release the alarm pause button (reset button), the alarm signal
stops.
2. The alarm stops and goes into a reset cycle with reduced sensitivity for about 8
minutes.
3. During the reset cycle with reduced sensitivity, the red LED flashes once every
8 seconds.
4. The smoke detector will automatically return to full sensitivity after completing
the reset cycle and the red LED will flash again every 48 seconds.
DANGER: Never ignore an alarm. Ignoring the alarm can lead to injury or
death. If your smoke alarm goes off and you're not entirely sure of the source of
the smoke, make sure everyone leaves the house immediately.
WHAT TO DO IN CASE OF A FIRE IN YOUR HOME
1. Don't panic and stay calm.
2. Alert your roommates and especially small children.
3. All leave your home immediately. Every second counts, so don't waste time
getting dressed or picking up valuables.
4. Do not open any interior door without first feeling the surface. If the door is hot,
or if you see smoke coming through the cracks, don't open that door! Choose
another escape route, if necessary through a window to the outside (take into
account how high above the ground that window is).
If the door is cool, place your shoulder against it, open the door a little, and be
ready to slam the door shut if heat and smoke come in.
5. If the air is smoky, stay close to the floor. Breathe shallowly through a cloth,
wetting it if possible.
6. If you are outside, go to a place that has been agreed in advance with your
housemates. Make sure everyone is present.
7. Call the fire department with your mobile phone or with the neighbor's phone.
Under no circumstances do you go back to get your phone or other things.
8. Do not go back into your home until the fire department gives permission.
REGULAR MAINTENANCE
In addition to performing a monthly test, the detector must be cleaned regularly to
remove dust and stuck dirt.
Clean the detector at least once a month.
Use a vacuum cleaner with the soft brush, vacuum the entire outside of the
smoke detector.
This smoke detector has a low-battery monitor that ensures that the detector
beeps approximately every 48 seconds for at least 30 days and the red LED
flashes at the same time when the battery is low.
If there is an empty or defective battery or other malfunctions, you can consult
"TROUBLESHOOTING" for a solution. If there are still malfunctions and you are in
the warranty period, you can send the smoke detector to your supplier.
IMPORTANT: Do not try to open the case to clean the inside. This can damage
the measuring chamber and you lose the right to warranty.
Warnings:
• Optical smoke detectors can reduce the risk of disaster, but they cannot
guarantee 100% safety.
• To ensure your maximum safety, you should install all smoke detectors exactly
according to this manual.
• Keep the smoke detectors clean. Make sure no dust accumulates and test at
least once a week.
• Replace the smoke detectors immediately if they do not work properly.
© Copyright DVM International B.V.
