DW DWCPPADESB User manual

OWNER’S MANUAL
DWCPPADESB
Peter Erskine’s
Stand-Alone Stick Bag
Thanks for purchasing this DW product. It has been designed and
manufactured to provide a lifetime of trouble-free service. Please take a
moment to familiarize yourself with the exclusive features and operating
suggestions contained in this manual in order to ensure its optimum
performance. Should you have any further questions, feel free to contact
your local authorized DW dealer.
— Don Lombardi
President, Drum Workshop, Inc.
The Drummer’s Choice®
DRUM WORKSHOP, INC
3450 Lunar Court • Oxnard, CA 93030 USA
www.dwdrums.com
specifications subject to change without notice
© DW 2008
DWCPPADPESB
Peter Erskine Manual.indd 1 8/5/08 2:45:20 PM

3
7
B
A
A
B
Assembly:
Step 1:
First, place the bag face down with the “Stand-Alone Stick Bag”
logo facing the floor. Right below the center logo Aon the
back you will find aVelcro®Brand strap Bholding the bag together.
Step 3:
Lift open the exposed flaps to form an “L” shape.
Step 4:
Next, take the short flap and extend it to the end of the bag,
forming a pyramid shape or ‘triangle.’
Step 5:
Reconnect the Velcro®Brand strap through the ring attached
to bottom section of the bag.
Step 6:
Inside the ‘triangle’ there is a rectangular Velcro®Brand flap.
Take this flap and attach it to the back of the flap that holds
the tripod receiver.
Step 2:
Pull apart the Velcro®Brand strap Ato open the bag. Pull
the Velcro®Brand strap through Bthe ring attached to the
bottom of the bag. Receiver facing down.
Step 7:
Next, place the bag right side up, with the flap holding the
tripod receiver facing down.
4
5
6
Step 8:
To open the front section of the Stand-Alone Stick Bag (the
section with the “Stand-Alone Stick Bag” logo), unzip the two
zippers and pull open the long front flap.
Step 11:
To open the tripod base, turn it over and loosen the wing nut
at the bottom. Using the bent thumb latch, rotate the locking
plate underneath to allow the three legs to move freely.
Step 12:
Once the lock plate and legs are alinged,
pull each leg down one by one.
Step 14:
There is a tripod receiver on the bottom of the stick bag.
This is where the tripod will be inserted.
Step 9:
Flip the long front flap over the top and behind the bag.
Step 15:
Loosen the thumbscrew on the receiver to prepare for the tripod.
Align the tripod receiver of the stick bag to the top of the tripod.
Step 16:
You can adjust the height of the Stand-Alone Stick Bag by loosening and tightening
the thumbscrew. Thanks to this height-adjustable feature, the Stand-Alone Stick
Bag works for drummers as well as percussionists!
11
12
Step 13:
Rotate the lock plate to lock the three legs in the standing
position.Tighten the wing nut to lock the legs in place.
Step 10:
Bend the small upper flap inward and align the Velcro®Brand to attach this flap to
the back of the bag. Optionally, you can put the strap of the stick
bag just above the Velcro®Brand to keep the strap tucked away.
This will form a small platform on the top of the bag.
13
10
DWCPPADESB
Peter Erskine’s Stand-Alone Stick Bag
Our product features genuineVELCRO®Brand fasteners
Peter Erskine Manual.indd 2 8/5/08 2:45:21 PM
