4+,19(14038,:,1!;08*/
!5,*0-0*(80437378(11(8043(3+5,6(803.37869*80437
911,803
Maintain liquid level high and low limits with the 4+,1 9(1 4038 ,:,1
!;08*/Units can be used for single or dual point level control in semi-solid liquids,
industrial slurries or heavy-bodied liquids like wastewater. Standard 24 inch
electrodes can be cut by the end-user to a shorter length or lengthened by adding
up to two 24 inch extensions (sold separately) to reach the maximum
recommended length of 72 inches. Model DPL contains no moving parts to get
stuck or wear out. Controller features adjustable sensitivity and DIN rail-mountable
socket mount.
!""
Conductivity Probes
1. Probes can be but to length. emove probes from sensor head by carefully
unthreading them from inserts. 4348 overtighten when re-installing.
2. Cut two (2) probes to the same length, these will be the common and lower
level probes. See Figure 1.
3. Cut one (1) probe to the desired length for the upper level of the tank. See
figure 1.
4. Spacer should be located approximately 1 inch (25.4 mm) from bottom of
shortest probe.
5. If build up occurs on probes a short circuit could occur. If this happens apply
shrink tubing to the probes leaving the last 1/2 inch (12.7 mm) bare.
Wiring (from sensor head to controller)
1. Install cable into sensor head through the compression fitting supplied
2. Attach the black lead between the common probe terminal and terminal five (5)
on the socket mount. See figure 2.
3. Attach the white lead between the lower level probe terminal and terminal (6)
on the socket mount.
4. Attach the red lead between the upper level probe terminal and terminal eight
(8) on the socket mount.
5. Tighten compression fitting until cable cannot be pushed into sensor head.
% !
Install controller according to applicable electrical codes. Do not connect directly to
line voltage. Not for use in hazardous (explosive) environments. Do not exceed
pressure and temperature ratings.
## "
Pumy-Up Operation is designed to keep tank levels at the high electrode position.
The conroller output switches from normally open to normally closed when the
liquid level falls below the lower level electrode. When the switch is normally
closed, the load to a pump or solenoid valve is turned on and the tank begins to
refill. The pump or solenoid valve remails on until the liquid level reaches the high
level electrode.
1. Connect sensor head to controller as discussed above.
2. Connect the decive power supply to terminal 1. (The device power supply is the
voltage required by the device (pump, valve, etc.) being turned in or off. This
voltage can be either AC or DC Volts and up to 220 VAC max.) See figures 2
and 3.
3. Connect one end of the pump/valve to terminal 4 and the other end to the
device power supply.
4. Connect 110 VAC power to terminal 2 and 7.
5. Snap the controller onto the socket.
%' !" #"!
/43, ;;;+;=,60378*42
&>"'#! (< ,2(0103-4+;=,62(01*42
!"!
1,*864+,71/8” dia, 24” length, standard.
%,88,+(687316 Stainless Steel, polypropylene. All food grade materials.
493803.!,3746,(+1” NPT.
(<02926,7796,30 psig (2.06 bar).
(<02925,6(803.",25,6(896,212˚F (100˚C)
433,*803.()1,64),844386411,610 ft (3.0 m).
!,3703.$418(.,12 VAC.
64),!,37080:08=Adjustable to 100,000 Ohms
4;,6!9551=120 VAC 50/60 Hz.
98598SPDT, 5 Amps @240 VAC.
64),3*14796,IP68 (NEMA 6).
(<029264),,3.8/72” (1.8 m) with optional extensions.
493803.4386411,6Standard octal socket or 35mm DIN rail.
1,*860*(1433,*80437Screw terminals located on socket mount.
%,0./864),77,2)1=1.5 lbs (0.68 kg).
%,0./84386411,61.0 lb (0.45 kg).
27.1
[687]
24.00
[610]
1" MALE NPT
0.13
[3.2]
3.11
[79]
2.385
[60.58]
Ø2.26
[57]
1.40
[35]
3.73
[95]
2.81
[71]
2.25
[57]
1.75
[44]
UPPER LEVEL
LOWER LEVEL
COMMON LEVEL
SPACER
110 VAC (WHITE)
UPPER LEVEL PROBE
DEVICE POWER SUPPLY
110 VAC (BLACK)
LOWER LEVEL PROBE
PROBE COMMON
NORMALLY CLOSED
NORMALLY OPEN
7
8
1
2
6
5
4
3
#
#
