dynabook Satellite C40-J Installation guide

Chapter 1
Hardware Overview

1.1 Features 1 Hardware Overview
SATELLITE PRO C40-J Maintenance Manual 1-i
Chapter 1 Contents
1.1  Feature ......................................................................................................... 1-1
1.2 System Unit Components ....................................................................................... 1-8
1.3 Solid State Drive (SSD).......................................................................................... 1-14
1.4 Power Supply ......................................................................................................... 1-15
1.5 Batteries ................................................................................................................. 1-16
1.51
Main Battery.............................................................................. 1-16
1.52
Battery Charging Control ........................................................... 1-17
Figures
Figure 1-1 ID Parts Description Placement .................................................................... 1-5
Figure 1-2 Computer Block Diagram ............................................................................ 1-6
Figure 1-3 System Board Congurations...................................................................... 1-7
Figure 1-4 System Unit Block Diagram ........................................................................ 1-8
Figure 1-5 Solid state driver ........................................................................................ 1-14
Tables
Table 1-1 SSD Specications....................................................................................... 1-15
Table 1-2 Battery Specications................................................................................... 1-16
Table 1-3 Quick/Normal Charging Time ...................................................................... 1-17

1 Hardware Overview 1.1 Features
1-1 Maintenance Manual SATELLITE PRO C40-J
1.1 System Features
Dynabook Satellite C40-J/ Satellite Pro C40-J is a Slim and Light entry notebook PC
based on the mobile Intel TGL & TGL-R series processor, providing high-speed
processing capabilities and advanced features. The computer employs a Lithium Ion
battery that allows it to be battery-operated for a longer period of time. The display uses
14-inch FHD and HD LED panel, at a resolution of 1920x1080 and 1366x768. The CPU
package is BGA type.
The computer has the following features:
Processor
1. CPU is mobile Intel TGL & TGL-R series processor:
Intel TGL-R i7 CPU
i7-1195G7 (5 G) Hz
Intel TGL-R i5 CPU
i5-1155G7 (4.5 G) Hz
Intel TGL-R i3 CPU
i3-1115G4 (4.1 G) Hz
Intel TGL i7 CPU
i7-1165G7 (4.7 G) Hz
Intel TGL i5 CPU
I5-1135G7 (4.2G) Hz
Intel TGL i3 CPU
i3-1115G4 (4.1G) Hz

1.1 Features 1 Hardware Overview
SATELLITE PRO C40-J Maintenance Manual 1-2
Intel TGL i3 CPU
i3-1125G4 (3.9G) Hz
Host Bridge System Controller
System Controller: Intel integrated Host bridge system into CPU.
Graphics
Internal: Intel® UHD Graphics for 11th Gen Intel® processors
Memory
The computer has 2 SO-DIMM DDR4 memory particles which support double
channel. DDR4 is driven at 1.2V. It can incorporate up to 32GB of memory
conguration.
Using the following sizes of memory conguration:
4096 MB SO-DIMM DDR4-3200MHz
8192 MB SO-DIMM DDR4-3200MHz
16384 MB SO-DIMM DDR4-3200MHz
Solid State Drive (SSD)
The computer accommodates SSD with following types:
SSD M.2 128GB/256GB/512GB (PCIe)
Display
LCD displays come in the following type at resolution 1920x1080 and
1366x768:
14” FHD 250nits eDP 1920x1080 LED display

1 Hardware Overview 1.1 Features
1-3 Maintenance Manual SATELLITE PRO C40-J
14" HD 220nits eDP 1366x768 LED display
On-Board LAN
The internal LAN supports 10/100/1Gbit Ethernet, enabling connection to a
LAN at up to 1Gbps. It supports Wake-up on LAN from S3/S4 and PXE boot
support. This internal LAN has RJ45 jack to directly accommodate a LAN
cable.
Wireless LAN
The internal Mini Card slot supports Intel Jeerson Peak1 (802.11ac+BT5.0),
Intel Jeerson Peak2 (802.11ac+BT5.0), Non-Intel CM251(802.11ac+BT5.0),
and Intel Harrison Peak2, 802.11ax+BT5.1 Wireless LAN cards. The Antenna
has two wires dual band.
Sound System
REALTEK ALC256&ALC256N integrated audio controller supports multimedia.
The sound system contains the following:
Stereo speakers
External microphone &Headphone combo jack
Integrated microphone (with Webcam)
Keyboard
many kinds’ countries keyboard, which is Non-backlight keyboardwith
UK/US/ JPkeyboard.
Pointing Device
Click Pad pointing device support. Gesture support for precision function as
Tapping/Tap and Drag/Pinch zoom/Up to 4 ngers.
USB Por

1 Hardware Overview 1.1 Features
SATELLITE PRO C40-J Maintenance Manual 1-4
The computer has three USB ports, two for USB3.0 type A, Another One is
USB type C (USB3.1 Gen1/DP/PD). High-Speed USB3.0/3.1 allows data
transfers up to 5Gbps
HDMI Out Port
A HDMI monitor can be connected to HDMI Out Port on the computer.
Bridge Media Slot
This slot is for your memory card requirements like SD/Mini SD (need
adaptor)/Micro SD (need adaptor)/SDHC/SDXC and MMC Cards to provide
memory card read on your computer.
Webcam with embedded internal microphone
The computer has an internal camera. It supports HD (0.9M) with Camera
shutter. It also supports Camera LED, LED is on when Camera working. The
internal microphone is embedded in this camera module.
Battery
The computer has a 2 Cell (6000mAh) Lithium Ion battery pack.
Figures 1-1/1-2/1-3 and 1-4 show the computer and its system unit
conguration, respectively.

1 Hardware Overview 1.1 Features
1-5 Maintenance Manual SATELLITE PRO C40-J

1.1 Features 1 Hardware Overview
SATELLITE PRO C40-J Maintenance Manual 1-6
Figure 1-1 ID Parts Description Placement
Figure 1-2 Computer Block Diagram

1 Hardware Overview 1.1 Features
SATELLITE PRO C40-J Maintenance Manual 1-7
Figure 1-3 System Board Congurations

1.2 System Unit Components 1 Hardware Overview
1-8 Maintenance Manual SATELLITE PRO C40-J
1
1.2 System Unit Components
Figure 1-4 System Unit Block
Diagram

1 Hardware Overview 1.2 System Unit Components
SATELLITE PRO C40-J Maintenance Manual 1-9
The system unit of the computer consists of the following components:
Processor: CPU is mobile Intel TGL&TGL-R Processor:
Intel TGL-R i7 CPU
i7-1195G7 (5 G) Hz
Intel TGL-R i5 CPU
i5-1155G7 (4.5 G) Hz
Intel TGL-R i3 CPU
i3-1115G4 (4.1 G) Hz
Intel TGL i7 CPU
i7-1165G7 (4.7 G) Hz
Intel TGL i5 CPU
I5-1135G7 (4.2G) Hz
Intel TGL i3 CPU
i3-1115G4 (4.1G) Hz
Intel TGL i3 CPU
i3-1125G4 (3.9G) Hz
Memory: The computer has 2 SO-DIMM DDR4 memory particles which support
double channel. It can incorporate up to 16GB of memory conguration.
PC4-3200(3200MHz) SO-DIMM DDR4 supported
DDR4 1.2V operation

1 Hardware Overview 1.2 System Unit Components
1-10 Maintenance Manual SATELLITE PRO C40-J
Data transfer rates: PC4-3200
BIOS ROM (Flash memory)
Storage Size
Nv Storage size: 128K
NVRAM_BACKUP size: 192k
FV_MAIN_WRAPPER size: 4992k
FV_MAIN_WRAPPER free space: 2609k
FV_DATA size: 832k
FV_DATA free space: 3k
FV_NETWORK_WRAPPER size: 2240k
FV_NETWORK_WRAPPER free space: 1648k
FV_BB size: 448k
FV_BB free space: 65k
FV_BB_AFTER_MEMORY_WRAPPER size: 256k
FV_BB_AFTER_MEMORY_WRAPPER free space: 62k
FV_FSP_S size: 576k
FV_FSP_S free space: 215k
FV_FSP size :448K System Controller
Mobile Intel integrated TGL&TGL-R into CPU.
System Memory Interface
Technology Enhancements of Intel Fast Memory Access
System Memory Frequency
DRAM Clock Generation
DRAM Reference Voltage Generation
Processor Graphics Controller(GT)
Digital Display Interface(DDI)
Platform Environmental Control Interface(PECI)
Advanced Conguration and Power Interface
(ACPI) states supported
Processor Core Power Management
Integrated Memory Controller (IMC) Power Management
Graphics Power Management
Intel Turbo Boost Technology 2.0 Power Control
Congurable TDP (cTDP) and Low Power Mode
Adaptive Thermal Monitor
Digital Thermal Sensor
Intel Memory Thermal Management
Scenario Design Power(SDP)

1 Hardware Overview 1.2 System Unit Components
SATELLITE PRO C40-J Maintenance Manual 1-11
Card Bus Controller
REALTEK RTS5170
Memory Card Reader Controller
Audio Controller
REALTEK ALC256 integrated audio controller supports multimedia. The sound
system features contain the following:
integrates a 4-channel DAC, 4-channel ADC, and a stereo Class-D Speaker
Amplier with 2 watts per channel output power.
4-channel ADC that supports 16/20/24-bit PCM format for independent two
stereo channel audio inputs. All ADCs support 44.1K/48K/96/192KHz sample
rates.
4 GPIOs for customized applications (pin-shared with digital microphone
interface and SPDIF-OUT)
Supports combo jack with stereo headphone output and mono microphone
input on a 4-pole jack
Volume synchronization for PCBEEP in D0/D3 mode
KBC/EC (Keyboard Controller/Embedded Controller)
A KBC IT5570E-128 chip is used to serve as KBC/EC and Super IO: KBC
Scan controller function
Interface controller function
EC
Power Supply sequence control
Overheat shutdown support
LED control
Beep control
Cooling fan speed control
Universal I/O port
Battery capacity check
Flash memory reprogramming function

1.2 System Unit Components 1 Hardware Overview
1-12 Maintenance Manual SATELLITE PRO C40-J
EC access interface
I2C communication control
Clock Generator
Mobile Intel TGL&TGL-R CPU integrated Clock Generator
Generating the clock signal required for the system
LAN Controller
REALTEK _ RTL8111H-CG& RTL8125BG 10/100M/1000M bit
Fully compliant with IEEE 802.3,
Supports PCI Express 1.1
Transmit/Receive on-chip buer support
Supports PCI MSI (Message Signaled Interrupt) and MSI-X
Wake-On LAN and “RealWoW!” Technology
(remote wake-up) support
Supports Microsoft Wake-up frame
Wireless LAN Controller
Support following M.2: CNVio2 wireless LAN cards
Intel Jeerson Peak1, 802.11ac+BT5.0
Intel Jeerson Peak2, 802.11ac+BT5.0
Non-Intel CM251, 802.11ac+BT5.0
Intel Harrison Peak2, 802.11ax+BT5.1
Data Rate
Intel Jeerson Peak1
IEEE 802.11b: 11Mbps
IEEE 802.11a/g: 54Mbps
IEEE 802.11n: 150Mbps
IEEE 802.11ac: 433.3Mbps
Intel Jeerson Peak2
IEEE 802.11b: 11Mbps
IEEE 802.11a/g: 54Mbps
IEEE 802.11n: 258Mbps
IEEE 802.11ac: 1366Mbps

1 Hardware Overview 1.2 System Unit Component
SATELLITE PRO C40-J Maintenance Manual 1-13
Non-Intel CM251
IEEE 802.11b: 11Mbps
IEEE 802.11a/g: 54Mbps
IEEE 802.11n: 150Mbps
IEEE 802.11ac: 433Mbps
Intel Harrison Peak2
IEEE 802.11b: 11Mbps
IEEE 802.11a/g: 54Mbps
IEEE 802.11n: 300Mbps
IEEE 802.11ac: 866.7Mbps
IEEE 802.11ax: 2.4Gbps
Frequency Channel
Intel Jeerson Peak1
IEEE802.11b/g: 2.4GHz
IEEE802.11n: 2.4GHz/5GHz
IEEE 802.11a: 2.4GHz
IEEE802.11ac: 5GHz
Intel Jeerson Peak2
IEEE 802.11a/b/g: 2.4Ghz
IEEE 802.11n: 2.4Ghz/5Ghz
IEEE 802.11ac: 2.4Ghz/5Ghz
Non-Intel CM251
IEEE802.11b/g :2.4GHz
IEEE802.11n :2.4GHz/5GHz
IEEE802.11a: 5GHz
IEEE802.11ac: 5GHz
Intel Harrison Peak2
IEEE802.11b/g :2.4GHz
IEEE802.11n :2.4GHz/5GHz
IEEE 802.11ax :2.4GHz/5GHz
IEEE802.11a/ac: 5GHz

1.3 Solid State Drive(SSD) 1 Hardware Overview
1-14 Maintenance Manual SATELLITE PRO C40-J
1.3 Solid State Drive (SSD)
The M.2 PCIe SSD is fully consist of semiconductor device and using NAND ash
Memory which has a high reliability and a high technology in a small form factor
for using a SSD
The SSD is shown in Figure 1-5 and some of its specications are listed in Table 1-1.
Figure 1-5 Solid state driver

1 Hardware Overview 1.4 Power supply
SATELLITE PRO C40-J Maintenance Manual 1-15
Table 1-1 SSD Specications
1.4 Power Supply
The power supply unit provides many dierent voltages for the system board and
performs the following functions:
1.
Power input monitor
Checks whether the DC power supply (AC adapter) is connected to the
computer.
Checks whether the battery pack is connected to the computer.
Monitors the DC power supply input (AC Adapter output).
2.
Power supply's internal control
Turns on and o the battery pack charging power supply.
Issues a charging current instruction to the PWM control IC of the battery
pack charging power supply.
Controls the supply of power to the system block (load/logic circuit side).
Controls forced shutdown if the power supply malfunctions.
3.
Logic circuit control
Item Read Write Bytes per sector
M.2 128G PCIe SSD 2250MB/s 600MB/s 512Byte
M.2 256G PCIe SSD 2500MB/s 1100MB/s 512Byte
M.2 512G PCIe SSD 2500MB/s 2100MB/s 512Byte

1.5 Batteries 1 Hardware Overview
1-16 Maintenance Manual SATELLITE PRO C40-J
Instructs the gate array to enable/disable tuning the power on.
Controls power-on/o operation.
4.
Status display
Turns on the Power.
Battery indicator (in Blue or Amber or Amber Blink).
5.
External interface
Performs communication through the SMBUS (via the internal EC/KBC).
Transfers the power supply operation mode.
6.
Output monitor
Monitors the voltage, over voltage, input/output current of the battery pack.
Monitors the internal temperature of the battery pack.
1.5 Batteries
The computer has the following type of battery:
Main Battery Pack
Table 1-2 list the specications of battery.
Table 1-2 Battery Specications
Battery Type Material Output voltage Capacity
Main Battery Pack 2 Cell Lithium Ion 7.6 V 6000 mAh
1.51
Main Battery
The main battery pack serves as the computer's main power source when the

1 Hardware Overview 1.5 Batteries
SATELLITE PRO C40-J Maintenance Manual 1-17
AC adapter is not attached. The main battery maintains the state of the computer
so that it can resume it.
1.52
Battery Charging Control
Battery charging is controlled by TI BQ24780S. When AC adapter and battery
pack are attached to the computer, BQ24780S controls the charge on/o state
and detects a full charge.
Battery Charge
When the AC adapter is attached, the battery is charged by o-state charge when the system is
powered o or by on-state charge when it is powered on.
Table 1-3 Quick/Normal Charging Time
State Charge Time
O-State Charge 2 Cell Less than 4 hours
On-State Charge 2 Cell over 4 hours
Any of the following cases stops battery charge:
1. The battery becomes fully charged.
2. The AC adapter or battery pack is removed.
3. The battery or AC adapter voltage is abnormal.
Detection of full charge
A full charge is detected only when the battery is being charged by quick or
normal charge. A full charge is detected when either of the following
conditions is met:
NOTE: The time required for normal charge depends on the power consumption by the
system. Using the uorescent lamp and frequently accessing the disk consume much
power and lengthen the charge time.

1.5 Batteries 1 Hardware Overview
1-18 Maintenance Manual SATELLITE PRO C40-J
1.
The current in the battery charging circuit drops below
the predetermined value.
2.
The charging time exceeds the xed limit.
