Dynalink D 0985 User manual

Operating Instructions
D 0985
USB Conference Microphone
Clear, crisp audio | Easily Portable | Centered mute button
Rugged diecast | Rubber feet for isolation from external noise
Compatible with Windows and Mac OS
Features

D 0985 Portable Conference Microphone
This USB conferencing microphone is a portable device allowing you to
take your conference room and meetings anywhere. It plugs into your
laptop via USB type C connection and provides clear and crisp audio
for group conferencing and one on one communications. It can also
be used to take audio only phone calls and allow groups of meeting
participants to be included in the conversation. A convenient centrally
mounted mute button provides a quick way to switch the microphone on
or off without touching the connected device. Rugged diecast casing
with rubber feet provides excellent isolation from external noise.
Includes 2m USB C to USB C cable. Dimensions: 70 x 15mm
Package Contents
Overview
1 x Microphone
1 x USB C to USB C Cable
1 x User Manual
Specications
Type: .............................................................................................Condenser
Polar Pattern: ......................................................................Omnidirectional
Power Supply: ..............................................................................5V/200mA
MIC Sample Rate: ................................................................. 48kHz at 16Bit
Frequency Response: ............................................................. 100Hz-16KHz
Microphone Sensitivity: ............................................................... -42+/-3dB
Weight: .................................................................................................. 140g
Connection: ........................................................................ USB C (USB 2.0)
System Requirements: ............................Windows 7/Mac OS 10.6 or later
Operation Voltage: ........................................................................5V +/-5%
S/N Ratio: ........................................................................................... >60dB
Handy Tips
• Place the microphone as close as practical to the desired sound source.
• Work close to the microphone for extra bass response.
• Place the microphone as far as possible from reective surfaces.

D 0985 Portable Conference Microphone
Conguration on Windows
A pop-up notication will appear to signal that your computer is
connected to the microphone.
Note: This product is a Plug-and-Play device and does not require any
driver installation.
Headphones / Speaker Settings
Go to Control Panel > Hardware and sound > Sound > Playback
and make sure that a green tick appears next to Speaker. If the
green tick does not appear next to Speakers, select Speakers and
then press Set Default.
Note: The D 0985 is not equipped with a built-in speaker. In order to
output the sound, an external speaker or headphones is required.
Microphone Settings
Go to Recording (same window) and make sure that a green tick
appears next to Microphone. If the green tick does not appear next
to Microphone, select Microphone and then press Set Default.
Set Up for Windows
Conguration on Mac OS
Note: This product is a Plug-and-Play device and does not require any
driver installation.
Headphones / Speaker Settings
Go to System Preferences > Sound > Output and select USB
Conference Mic.
Microphone Settings
Go to System Preferences > Sound > Input and select USB Conference
Mic.
Set Up for Mac OS
