Dynamic DX-REM34 User manual

No. 60025, Issue 5. January 1999
TM
DX Dolphin Remote
(DX-Rem34)
Installation Manual
Order/Part Number for this Manual : GBK60025 issue 5
Important Notes
1. Read this Manual carefully before installing or operating your DX control system.
2. Due to continuous product improvement Dynamic reserves the right to update this Manual.
This Manual supersedes all previous issues which must not continue to be used.
3. Any attempt to gain access to or in any way abuse the electronic components and
associated assemblies that make up the wheelchair control system renders the
Manufacturer’s Warranty void and the Manufacturer free from liability.

No. 60025, Issue 5. January 1999
Contents
1Introduction .................................................1
2Related Documentation .......................................2
3Features ....................................................3
4Specifications ...............................................5
Electrical ................................................5
Mechanical ..............................................5
Environmental ............................................6
5Operation ...................................................7
On/Off and Key Lock system ................................7
Arming/Disarming the locking system .....................7
Using the system without the lock ........................7
Joystick OONAPU ........................................7
Drive Program Selection and Display ..........................8
Profile Selection .....................................8
Drive Program Display ................................8
Drive Inhibit Display ..................................8
Remote Status Display ................................8
System Status LED ...................................8
Lighting Control ..........................................9
Actuator Control ..........................................9
Battery Gauge Display ....................................10
6Installation and Testing ......................................11
Attention: If replacing existing Power Wheelchair Controller ........11
Compatibility with Power Wheelchairs ........................11
DX Dolphin Mounting .....................................12
DX Dolphin Connection with the DX System ...................13
Testing ................................................14
Powering Up Method ................................14
Power Up Response .................................14
DX Dolphin Check Sequence ..........................14
7Batteries and Charging ......................................15
Battery Type ............................................15
Battery Charging .........................................15
Battery Gauge ...........................................16
Battery Saver ............................................16

No. 60025, Issue 5. January 1999
Battery Condition Warnings ................................17
Battery High warning condition .........................17
Battery Low warning condition .........................17
Low Capacity warning condition ........................18
8Programming ...............................................19
Introduction .............................................19
Default Programs .........................................19
Auto Download ..........................................20
Programming Tools .......................................21
Dynamic Wizard ....................................21
HHP .............................................22
Wizard High Volume Programming ...........................22
Example ..........................................22
DX Dolphin Wizard Programming ............................24
Drive Program Parameters .............................24
Keypad and Speed Pot Parameters ......................28
Joystick Parameters ..................................30
Actuator Parameters .................................32
Lighting Parameters ..................................36
DX Dolphin HHP Programming .............................37
Initial Operation ....................................37
Test Driving and Saving Changes .......................38
To View / Adjust Drive Programs .......................38
To Adjust Joystick Source .............................39
Reverse Joystick - Forward / Reverse ....................39
To Enable Technician Mode ...........................40
Joystick Calibration ..................................40
Combined Lighting Actuator Module (CLAM) Enable .......41
Lighting Module (LM) Enable ..........................42
9Diagnostics and Fault Finding ................................43
Flash Code .............................................43
Limp Mode .............................................47
Wizard Diagnostics .......................................48
To View Diagnostics .................................48
Status Report ............................................48
To View Status Report ...............................48
Chair Log ..............................................49
To View Chair Log ..................................49
10 Product Disclaimer ..........................................52
11 Electromagnetic Compatibility (EMC) ..........................53

No. 60025, Issue 5. January 1999
12 Maintenance ...............................................54
13 Safety and Misuse Warnings ..................................55
14 Warranty ...................................................57
15 Sales and Service Information ................................58
16 Appendix A : Abbreviations ..................................59
17 Appendix B : Change Record .................................61
18 Anhang C : Deutschsprachige Warnhinweise ...................62

No. 60025, Issue 5. January 1999
1 Introduction 1
ToBattery
Charger
ToHHP
orWizard
DX-TAM
DX-LMActuator
LeftIndicatorLights
RightIndicatorLights
SideLights
Optional DXBUS Optional DXBUS
Example
DXModuleExample DXModule
DXDolphin
(DX-REM34)
DXPower
Module
24V
Wheelchair
Battery
DXBUS
1 Introduction
The DX Dolphin Remote is a DX compatible remote supplied by Dynamic
Controls Ltd. As well as driving, this DX Remote has switches for selecting
up to five actuators, which can then be operated under joystick control. A
batterygauge,sidelights,indicatorlights,hazardlights,magnetickeyandhorn
are also supported. Up to five individual Drive Programs or profiles are
available, and the currently selected program is displayed.
This DX Remote has two standard DXBUS connectors so that it may be
connected to the DX System.
The DX Dolphin Remote and the associated DX Power Module are fully
programmable to cater for a wide range of chair types and user needs. Correct
installationandprogrammingareessentialtoensureoptimumperformanceand
safety.
This manual and others listed below must be read and understood. For more
information contact Dynamic Controls Ltd or an agent as listed in section14.
Example DX System

No. 60025, Issue 5. January 1999
Related Documentation 2
2
2 Related Documentation
ADX based wheelchair control system may comprise between two and
sixteen DX compatible modules depending on the application. Each DX
compatible module has its own Installation Manual which describes the
installation requirements of that particular module.
This Manual describes installation of the DX Dolphin Remote only and must
therefore be read in conjunction with the :
!DX Power Module (PMB) Installation Manual
!DX Hand Held Programmer (HHP) Manual
!Dynamic Wizard Installation Sheet / Online Help
!Installation Manuals for all other DX Modules to be used in your
application.

No. 60025, Issue 5. January 1999
3 Features 3
3 Features
Joystick Normally used for controlling wheelchair speed and
direction. Can also be used for actuator control
when any of the 5 actuators have been selected.
On/off switch / Toggles the entire DX control system between the
On and Off modes.
System Status LED The System Status LED indicates the On/Off status
of the system. It also flashes to indicate system
faults. (Refer to Diagnostics section 9 for Fault
Codes details.)
Remote Status LED The Remote Status LED indicates the status of the
Dolphin as an individual DX Module. If it is
flashing, there is a fault within the Dolphin.
Battery gauge Battery charge level is indicated by a set of ten
LEDs. These are arranged in an arc from left to right
as three red, four orange, and three green.
Actuator select A separate switch for each set of seat raise/lower,
switches(x5) seat tilt, back tilt, left leg rest and right leg rest, each
with its own LED indicator. Once selected, actuator
operation is activated using the joystick.
Drive Program A switch is used to cycle through and select one of
select switch the five Drive Programs.
Drive Program Aseven segment display for showing the currently
Display selected Drive program.
Lighting controls Separate push switches for the control of lights,
indicators, and hazard, each with its own LED.
Horn switch Activates horn while pressed if system power is on.
Magnetickeylock Magnetic key may be used to "lock" the DX System
to prevent unauthorised use (see later details).

No. 60025, Issue 5. January 1999
Features 3
4
Programming socket A standard HHP / Wizard socket.
HHP / Wizard socket
Standard DXBUS For connecting the DX Remote, with a DXBUS
Connection (x2) cable for connection to other DX compatible
modules.
Battery charger Standard 3 pin XLR type battery charger socket.
socket
Fully functional keypad

No. 60025, Issue 5. January 1999
4 Specifications 5
Keypad
Joystick Horngrill
Covered
chargersocket
Programmersocket
TwoDXBUS
connectors
182mm
85mm
147mm
4 Specifications
Electrical
Compatible with standard DXBUS
Operating voltage range 18V - 32 V d.c.
Charger rating 12 A RMS continuous, limited by
DXBUS rating.
Quiescent Current <1mA Off, typically 100mA On
Mechanical
Weight: 0.59 Kg
Mounting: As per Installation section 6, Mounting
Case material: Injection moulded plastic, Noryl N90 flame
retardant

No. 60025, Issue 5. January 1999
Specifications 4
6
Environmental
Parameter Min Max Units
Operating ambient temperature range -25 50 °C
Storage temperature range -25 70 °C
Operating and storage humidity 0 90 %RH
Environmental Rating IP54
RFI Emissions CISPR 11, Class B.
ESD ISO7176 part 21
Durability ISO7176 part 14 (pending).
Vibration Specification BS2011: part 2Fd and BS7527: section 3.5,
class 5M3.
Complies with environmental standard : prEN12184.

No. 60025, Issue 5. January 1999
5 Operation 7
5 Operation
On/Off and Key Lock system
The On/Off button toggles the system power on or off provided the DX
Remote is not locked.
The Key Lock system uses a magnetic key to power the wheelchair down in
such a way to prevent subsequent unauthorised power up and driving. This
function is required for TÜV approval and operates as follows :
Arming/Disarming the locking system
To arm the locking system hold the magnetic key on or near the key symbol
on the DX Remote front panel. The system will beep and automatically power
itself down and no LEDs should be lit.
Toturn thechair backon presstheOn/Off button.This willcause thesystem
to power up but the chair needs to be disarmed before it can be driven - this
waiting to be disarmed state is indicated by the flashing key symbol.
To disarm the lock put the magnetic key on or near the key symbol - this will
cause the key to stop flashing and the chair may now be driven normally. If the
wheelchair is not disarmed within one minute, the Dolphin will automatically
turn itself off.
Using the system without the lock
Iflocking thechairis notrequiredsimply powerthechair downbypressing the
On/Off button - all indicators will go out.
To turn the system back on press the On/Off button - the system is now able
to be driven without the use of the magnetic key.
Joystick OONAPU
All DX Remotes feature Out Of Neutral At Power Up (OONAPU) detection.
If the system is powered up while the joystick is not in the neutral position, or
an inhibit condition such as a battery charger is removed, the System Status
LED flashes rapidly for either as long as the condition persists or for a
maximum of 5 seconds.
If the condition persists, after 5 seconds a DX Module Fault (Flash Code 1) is
signalled on the System Status LED, and the Remote Status LED flashes. This
is a latching fault and must be cleared by powering the system down and up
again (with the joystick in neutral).

No. 60025, Issue 5. January 1999
Operation 5
8
An OONAPU fault is also generated if the joystick source is changed. This
occurs when the Attendant / User switch on the DX-ACU is toggled or the
Drive Program is changed causing a joystick swap, while the joystick is not in
the neutral position. In these situations the fault is non-latching and the system
does not need to be powered down to clear the fault.
Drive Program Selection and Display
The Dolphin can offer up to five different Driving Programs, depending on its
configuration. (See Programming section.)
Profile Selection
Profiles can be selected using the Drive Program Select switch. Pressing this
switch will increment the Drive Program number up to the maximum
configured value. A further switch press will return the Dolphin to Profile 1.
Drive Program Display
The current Drive Program number is displayed on the 7-segment Drive
Program Display. When the ACU has control of the wheelchair, this display
is blank.
Drive Inhibit Display
A'-' is displayed on the Drive Program Display whenever the DX System is in
Drive Inhibit state, e.g. during battery charging, operation of actuators, active
Stop Switch (CLAM or TAM).
Remote Status Display
The Remote Module Status is displayed beside the 7-segment Drive Program
display. This LED will flash if there is an internal DX Remote fault, or if an
OONAPU fault has occurred.
System Status LED
The System Status LED is displayed above the On/Off switch. This LED is lit
if the system is turned on. It also flashes in groups called Flash Codes, to
indicate system faults.

No. 60025, Issue 5. January 1999
5 Operation 9
Lighting Control
A set of four lighting control switches, with feedback LED's, are provided to
control the Lighting System. A lighting module must be installed and enabled.
Suitable modules include: DX Combined Lighting Actuator Module (CLAM);
a DX Lighting Module (LM); or a DX Servo Lighting Module (SLM).
The Light switch toggles on or off the Head/Tail/Sidelight output,
independently of any other switch (except the On / Off switch). The Light
switch LED is lit when the lights are activated.
The Left or Right Indicator switch flashes the appropriate indicator output.
These are turned off by either pressing the same Indicator switch again, or
pressingtheotherIndicatorswitch,ortheHazardswitch.EachassociatedLED
is lit when its matching Indicator switch is active.
The Hazard switch flashes both indicator outputs concurrently. The Hazard
LED also flashes if the Hazard LED is enabled. (See Programming section.)
The Hazard Indication can only be cancelled by pressing the Hazard switch
again.
All lighting functions will only operate with the system power on. Refer to the
relevant Installation Manual (e.g. LM or CLAM) for further lighting details.
Actuator Control
The DX Remote supports the control of up to five actuators if a correctly
configured actuator control module is present (see Programming section). For
example, a Combined Lighting Actuator Module (CLAM) can drive five
actuators or a Two Actuator Module (TAM) can drive two actuators.
The Dolphin has a set of five Actuator Select switches. Pressing an Actuator
Select switch will inhibit driving and select the appropriate actuator output as
indicated by the adjacent LED. The actuator order assigned in the Wizard as
Actuator 1, 2, 3, 4 and 5 Enable, is arranged on the Dolphin keypad as follows:

No. 60025, Issue 5. January 1999
Operation 5
10
The actuator may then be adjusted up or down with
the Joystick, by deflecting the Joystick beyond half
travel in the forward / reverse axis.
Toresumedriving,pressthecurrentActuatorSelect
switch again to deselect. Alternatively another
actuator may be selected directly.
If the user attempts to change modes (e.g. from
driving to actuator mode) while the Joystick is
deflected, the current mode will be terminated and
the Joystick must be returned to neutral position
before the newly selected mode will operate.
The Joystick Actuator parameter must be set to ‘yes’ and the Actuator While
Drive parameter must be set to ‘no’ if actuators are to be controlled with the
Dolphin Joystick, (See Programming section). An Actuator Remote Control
(ARC) can be used to control the actuators. If an ARC is used to control the
actuators the Actuator Select switches on the Dolphin are disabled and the
Joystick Actuator parameter should be set to ‘no’.
The above information is for normal, intended operation of actuators by the
Dolphin. Other options for actuator operation are possible, dependant on
programming. See the TAM Installation Manual for full explanations.
Refer to the relevant DX Module Installation Manual for further actuator
details.
Battery Gauge Display
Battery charge level is continuously indicated by a set of ten LED's. These are
arranged in an arc from left to right as three red, four orange and three green.
The Battery Gauge provides true, useable battery capacity information, and
indicates other related battery conditions. Full battery capacity is indicated by
all ten LEDs on.

No. 60025, Issue 5. January 1999
6 Installation and Testing 11
6 Installation and Testing
Attention:IfreplacingexistingPowerWheelchairController
The model DX joystick/controller recently installed by your home care dealer,
has been designed to function and perform in the same manner as the
joystick/controller you may have already become accustomed to. If properly
installed and programmed, you should notice no difference in the manner in
which your wheelchair performs.
Should your wheelchair not perform as expected, or if you are not satisfied
with its performance, immediately contact the home health care dealer who
performedthe installation,or contactInvacare TechnicalServices Department
at [phone].
Compatibility with Power Wheelchairs
The model DX Series power wheelchair controller will function on those
wheelchairs equipped with the following specifications:
!Motor resistance from 0 to 0.5 ohms;
!Motor voltage from 20V to 30V;
!Batteries greater than 20Ahr lead acid;
!Motor current 60 - 80 Amp maximum;
!12V or 24V parking brake;
(Note: 12V motors can be used if the controller is programmed to half speed)
Note : This controller is not designed for use with specialty type power
wheelchairs, such as stair climbing wheelchairs or stand up wheelchairs.

No. 60025, Issue 5. January 1999
Installation and Testing 6
12
45mm
57mm 45mm
185mm
85mm
DX Dolphin Mounting
The DX Dolphin Remote can be mounted on either side of the wheelchair, in
an upright position, using four M4 screws.
Warning : For safe installation, select a screw length that protrudes between
4mm and 10mm into the case.
Dimensions of the mounting positions are shown below.
Note : If the programmer socket needs to be accessible when the DX
Remote is mounted, make allowance for this prior to fitting.

No. 60025, Issue 5. January 1999
6 Installation and Testing 13
TwoDXBUS
connectors
DX Dolphin Connection with the DX System
The Dolphin has two DXBUS connectors which
enables any DXBUS cable to be used to interconnect
it to the remainder of the DX system.
The Dolphin will normally be connected directly to
one of the two PM DXBUS connectors.
Note : If only one DXBUS connector is used on the Dolphin and the
remaining connector is accessible to the wheelchair user, a dummy connector
should be fitted to the unused connector. This will comply with ISO7176.
The DXBUS cables are available in the following standard lengths:
DXBUS Cable, Straight, 0.12 M Part/Order Number GSM 630012
DXBUS Cable, Straight, 0.3 M Part/Order Number GSM 63003
DXBUS Cable, Straight, 0.5 M Part/Order Number GSM 63005
DXBUS Cable, Straight, 1.0 M Part/Order Number GSM 63010
DXBUS Cable, Straight, 1.5 M Part/Order Number GSM 63015
The DXBUS is also available with a ferrite.
DXBUS Cable, Ferrite, 2.0 M Part/Order Number GSM 63020F
Other cable lengths in multiples of 0.1 m are available on request.
Warning: Any protruding screws should be either plastic or plastic coated to
prevent short circuits occurring with the DXBUS Cable pins.

No. 60025, Issue 5. January 1999
Installation and Testing 6
14
Testing
Ensure that all DX Modules used in your DX System have been installed as
specified in their Installation Manuals. The Dolphin needs to be correctly
programmed for the appropriate wheelchair prior to testing.
ADX Remote contains the complete wheelchair system set up, from which all
DX Modules download their relevant information when the DX System is first
turned on. Refer to the later Auto Download section.
Powering Up Method
Power up the Dolphin by pressing the On/Off switch.
Power Up Response
The power up response for the Dolphin is :
!The System Status LED will come on steady.
Note : The first time the Dolphin is turned on, the System Status LED will
flash a fault. This is because the Dolphin must download its information to the
DX Power Module . Turn the Dolphin off then on to clear this fault. Refer to
the later Auto Download section.
!At least one of the LEDs on the Battery gauge will be on.
!The Mode display will indicate a number from 1 - 5.
DX Dolphin Check Sequence
Perform the following Dolphin check sequence :
1. Press the On/Off switch again and check the Power LED turns off. Press
it again to turn it on.
2. Press the Drive Program select switch a number of times. Check that the
display changes as expected.
3. Check all Lighting Buttons operate correctly.
4. Check the Key Lock system operates correctly.
5. Perform the remainder of the tests as outlined in the Testing sections of the
Installation Manuals of all other DX Modules used on the wheelchair.

No. 60025, Issue 5. January 1999
7 Batteries and Charging 15
Inhibit
Battery-
Battery+
BatteryChargerPlug
frontview
BatteryCharger
12
3
7 Batteries and Charging
Battery Type
The DX System is designed to perform optimally with either Lead-Acid or Gel
Cell 24 V deep cycle batteries, rated at 20 - 120 Amp hours. The maximum
average discharge rate must not exceed half the rated capacity, in Amp hours.
High continuous discharge rates dramatically reduces the available battery
capacity. For example, at a discharge rate equal to the rated capacity, the
available capacity is 50 - 60 %. At a discharge rate of half the rated capacity,
the available capacity is 70 - 80 %..
Awheelchair that draws maximum average battery current of 20 A, requires
abattery of at least 40 Amp hours. A battery of only 20 Amp-hours, would
begin to suffer a drop in performance at about half of its available capacity.
The 40 Amp hour battery would have a full performance range of 4.5 times
greater than the 20 Amp hour battery; a 80 Amp hour battery would only
increase this range by 2.5 when compared to a 40 Amp hour battery.
Battery Charging
The battery charger socket is a 3 pin XLR type with pin configuration as
shown below. Ensure that the charger used is compatible with this pin out
before connection.
Note : The inhibit is shorted to B- on the Battery Charger plug.

No. 60025, Issue 5. January 1999
Batteries and Charging 7
16
The wheelchair is automatically disabled from driving whenever the battery
charger is plugged in. The Drive Program will show ‘ ’ to indicate that the
wheelchair is inhibited.
Connection of the battery charger will automatically power the wheelchair, if
the wheelchair was powered down at the time of connection. This allows the
progressofbatterychargingtobemonitoredontheDolphinbatterygauge.The
wheelchair can, if required, be subsequently powered down by pressing the
On/Off switch, and charging will still proceed normally.
Battery Gauge
The Battery Gauge provides true, useable battery capacity information. A full
battery with at least 85 % of rated capacity, is represented by all ten LED’s lit.
Some new batteries can start with as little as 80 % capacity, developing higher
capacity in their early life (sometimes up to 110 %), before slowly
deteriorating over their rated life.
As the battery voltage drops, the number of LEDs lit reduces from right to left.
When only the red LEDs are lit, the available battery capacity is typically less
than 10 %. At this level and below, the Battery Gauge flashes at 1 Hz to alert
the user that the wheelchair is running on reserve capacity. The battery
capacity will reduce more rapidly in the reserve capacity range.
Battery Saver
The Battery Saver is a feature programmed into the DX Remote. When the
battery capacity is in the reserve range (below 21V), the wheelchair
performance is reduced. This is to preserve the life of the battery by
encouraging the user to recharge the battery before it becomes harmfully flat.
Operating the wheelchair with more than two LEDs of the Battery Gauge lit
will generally give normal wheelchair performance. This is provided that the
battery size and the PM program settings are matched to the wheelchair.
