TMCT-10 Barcode Scanner
User Manual

2
IMPORTANT NOTICE
Safety Precaution
* DO NOT disassemble the scanner, or place foreignmatter into the scanner cause a short circuit
or circuit damage.
* DO NOT expose the scanner or battery to any flammable sources.
Maintenances Precaution
* Use a clean cloth to wipe dust off the body of the scanner.
* If you find the scanner abnormal, write down the specific scenario and consult the maintenance
person.

3
Contents
IMPORTANT NOTICE...............................................................................................................................2
Safety Precaution..................................................................................................................................2
Maintenances Precaution ......................................................................................................................2
Contents........................................................................................................................................................3
Overview of TMCT-10 Barcode Scanner................................................................................................5
Features of the Scanner.........................................................................................................................5
Appearance ...........................................................................................................................................5
Introduction of Key Function................................................................................................................6
Specifications........................................................................................................................................6
Correct Aiming......................................................................................................................................7
Incorrect Aiming...................................................................................................................................7
QUICK START............................................................................................................................................7
Enter the Setting Mode .........................................................................................................................8
Exit the Setting Mode with Save...........................................................................................................9
Exit the Setting Mode without Save .....................................................................................................9
Restore Factory Defaults.......................................................................................................................9
Check Software Version......................................................................................................................10
Save Custom Settings .........................................................................................................................10
Chapter 1 Features and Basic Setups..................................................................................................12
1.1 Battery...........................................................................................................................................13
1.1.1 Mounting the battery (charging) ........................................................................................13
1.1.2 How to operate TMCT-10 Barcode Scanner......................................................................13
1.1.3 Auto Power Off..................................................................................................................15
1.2 Transmit Buffer.............................................................................................................................16
1.2.1 Inventory Mode..................................................................................................................17
1.3 LED Indicator ...............................................................................................................................18
1.4 Beeper...........................................................................................................................................19
1.4.1 Beeper Volume...................................................................................................................20
1.5 Scan Modes...................................................................................................................................21
1.5.1 Manual Mode.....................................................................................................................21
1.5.2 Continuous Mode...............................................................................................................22
1.5.3 Auto Power Off Mode........................................................................................................23
1.5.4 Auto-induction Mode.........................................................................................................25
1.6 Symbologies Supported ................................................................................................................26
1.7 USB Wired Data Transmission .....................................................................................................26
Chapter 2 How to Connect with BT............................................................................................................27
2.1. Select Output Interface.................................................................................................................28
2.1.1 BT SPP Mode.....................................................................................................................28
2.1.2 BT HID Mode....................................................................................................................28
2.2 Setting up a BT connection...........................................................................................................29

4
2.3 Connect to PC via BT ...................................................................................................................30
2.4 Connect to PDA via BT ................................................................................................................36
2.4.1 One-clickAndroid Connection ..........................................................................................39
2.4.2 One-click iOS Connection .................................................................................................43
2.4.3 Connect via BT Input Method............................................................................................46
Chapter 3 SYMBOLOGY SETTINGS .....................................................................................................55
3.1 CODABAR...................................................................................................................................56
3.2 CODE 25 –INDUSTRIAL25........................................................................................................57
3.3 CODE 25 –INTERLEAVED 25....................................................................................................58
3.4 CODE 25 –MATRIX 25 ...............................................................................................................59
3.5 CODE 25-STANDARD 25...........................................................................................................60
3.6 CODE 39.......................................................................................................................................61
3.6.1 Enable/Disable Code 39.....................................................................................................61
3.6.2 START/STOP Transmission...............................................................................................61
3.6.3 Checksum Verification....................................................................................................62
3.6.4 STANDARD/FULLASCII CODE 39..............................................................................62
3.7 CODE 93.......................................................................................................................................64
3.8 Code 128.......................................................................................................................................65
3.9 EAN-8...........................................................................................................................................66
3.9.1 Enable/Disable EAN-8.......................................................................................................66
3.9.2 Convert to EAN-13............................................................................................................66
3.9.3 Checksum Transmission.....................................................................................................67
3.10 EAN-13.......................................................................................................................................68
3.10.1 Enable/Disable EAN-13...................................................................................................68
3.10.2 Convert to ISBN...............................................................................................................68
3.10.3 Checksum Transmission...................................................................................................69
3.11 UPC-A.........................................................................................................................................70
3.11.1 UPC-A Output ‘0’ ............................................................................................................70
3.11.2 UPC-A Checksum Transmission......................................................................................70
3.12 UPC-E.........................................................................................................................................71
3.12.1 Enable/Disable UPC-E.....................................................................................................71
3.12.2 UPC-E Checksum Transmission......................................................................................71
3.13 MSI .............................................................................................................................................72
3.14 CODE 11.....................................................................................................................................73
Chapter 4 DEFINING OUTPUT FORMAT..............................................................................................74
4.1 CODE ID......................................................................................................................................75
4.2 Suffix Code of Barcode Settings...................................................................................................76
APPENDIX I..............................................................................................................................................77

5
Overview of TMCT-10 Barcode Scanner
Features of the Scanner
- No need to install any app or software, easy to use
- Integrated 1500mAh rechargeable Li-Ion battery, it can be charged by any USB 2.0 port
- Two ways of connection: USB cable connection and bluetooth wireless connection, Signal
Range of up to 10m
- Compatible Operating Systems: Microsoft Windows XP/7/8, Mobile6/Wince, Google Android 4.0
Above, Apple iOS 7, Mac OS-X
- Internal memory of 256 KB, can store 2600 barcodes; Robust design: Designed to survive free
fall height of 1.50 m
Appearance

6
Introduction of Key Function
Note: Long press Scan button 3 seconds will turn on the TMCT-10 scanner.
Long press Scan button 3 seconds will turn off the TMCT-10 scanner.
Flip the Scan button can read the barcodes.
Specifications
PHYSICAL CHARACTERISTICS
Material
ABS+TPU
Size
Length 167mm*Width 70mm* Height 85.5mm
Color
White, Black
Power supply
Built-in rechargeable lithium battery
Weight
150g（With battery）
PERFORMANCE CHARACTRISTICS
Bluetooth
Bluetooth class 2.0, Version +EDR
Interfaces Supported
Multiple Interface with: USB, RS232, PS2 Keyboard
Interfaces Supported
SPP, HID
Light Source (Laser)
Laser LED 650+/-20nm
Sensor
2500 pixels
Decode Capability
Codabar, Code 11, Code 93, MSI, Code 128, UCC/EAN-128, Code
39, EAN-8, EAN-13, UPC-A, ISBN, Industrial 25, Interleaved 25,
Standard 25, 2/5 Matrix
Resolution
5mil
Nominal Working Distance
6~30cm
Decode Rate
200 decodes per second
Scan width
30mm=Scanner Window
Decode mode
Single-Line Aiming
Scan mode
Auto off mode / Manual mode
Print Contrast Minimum
30%
Scan angles
Roll 30°Pitch 75°Yaw65°
Cylinder Horizontal Scan
Diameter 35mm
Indication
Beeper, LED
Radio Range
10m Visual range
POWER
Voltage
DC 5V
Laser Safety
Accord with national level two laser safety standards
EMC
CE & FCC DOC Compliance
standby Current
35mA

7
Operating current
60mA
USER ENVIRONMENT
Operating Temp.
0 to 50.°C / 32 to 122°F
Storage Temp.
0 to 50.°C / 32 to 122°F
Operating Humidity
20-85% ( non-condensing )
Storage Humidity
20-85% ( non-condensing )
Drop Specifications
Free fall of 1.5m air drop
Accessories
Lithium battery, Charger., Data lines
Correct Aiming
Incorrect Aiming
QUICK START
The setting of the TMCT-10 Barcode Scanner can be changed by reading the setup barcodes
contained in this manual. This section describes the procedure of setting the TMCT-10 Barcode
Scanner by reading the setup barcodes and provides some example for demonstration.
Steps Action Feedback if Successful
1 Turn on TMCT-10 Barcode Scanner... It will responsewith a long beep（high tone）,
its LED shows red and with Intmt twinkle.
Note: How the TMCT-10 Barcode Scanner establishes a connection with computer or other
compatible device, please refer to Chapter 2.
2 Enter the Setting Mode... The TMCT-10 Barcode Scanner will response
three beeps (tone descending from high to
low), and its LED indicator will flashing purple.
Enter Setup

8
3 Read a Setup barcode The TMCT-10 Barcode Scanner will response
three beeps (tone ascending from low to
high), and its LED indicator
will flashing purple.
For Example:
4 Exit the Setting Mode... The TMCT-10 Barcode Scanner will response
three beeps (tone descending from high to
low), and its LED indicator will not flashing
purple and power off.
Note: When any setup error occurs, the TMCT-10 Barcode Scanner will respond with a long
beep (low tone), and its LED indicator will flashing purple.
Steps of Setup:
Enter the Setting Mode
For the scanner to enter the setting mode, you must have it read the "Enter Setup" barcode,
which will be located at the bottom of almost every page of this manual.
The TMCT-10 Barcode Scanner will respond with three beeps (tone descending from high to
low), and its LED indicator becomes purple and go off quickly after reading the barcode.
Enable Codabar
Exit with Save
Enter Setup
Details (eg: Enable/Disable a Barcode)
Exit Setup
Enter Setup

9
For setting scanner parameters, see "Read a Setup Barcode" below.
Exit the Setting Mode with Save
For the scanner to exit the setting mode, you must have it read the "Exit with Save" barcode,
which will be located at the bottom of almost every page of this manual.
Just like reading the "Enter Setup" barcode, the scanner will respond with three beeps (tone
ascending from low to high) after reading the barcode.
Exit the Setting Mode without Save
If you want to exit the setting mode without saving any changes, you must have the scanner read
the "Exit without Save" barcode.
Just like reading the "Enter Setup" barcode, the scanner will respond with three beeps (tone
ascending from low to high) after reading the barcode.
Restore Factory Defaults
"Restore Factory Defaults" is a special barcode. The TMCT-10 Barcode Scanner will respond
with a short beep (high tone) after reading this barcode. At this time, the scanner system could
restore factory defaults, and no need to read "Exit with Save" barcode again. The Scanner
defaults enable HID, PIN defaults 10010.
Restore Factory
Defaults
Exit with Save
Exit without Save

10
Note: Most of setting mode have restore factory defaults selection. The factory default value for
each setting is indicated by an asterisk "*".
You could use this barcode at the following status:
1、The scanner can not work. For example, it can not read barcodes.
2、You forget the settings you did to the scanner before, and you don't want to be affected by the
settings when you use the scanner.
3、After using a function which is not be used usually in the scanner.
Check Software Version
If you want to know the software version of TMCT-10, should read the ‘Enter Setup’ and ‘Output
Software Version’ barcode:
Checking the software version is done at the enter setup mode, so after output the software
version, need to read ‘Exit without Save’ barcode.
Save Custom Settings
1. You may change factory defaults, and customize some functions suitable for your own
Enter Setup
Exit without Save
Output Software Version
