Dynamix UPS650A System manual

UPS650A
Line Interactive UPS
UPS650A Line Interactive UPS | PRODUCT SPEC SHEET
PRODUCT SPECIFICATION
INTRODUCTION
DYNAMIX Line-interactive Uninterruptible Power Supply
(UPS) can instantly switches your computer to emergency
battery backup power and allows you to work through mains
power outages without data loss or downtime. It continuously
conditions the power coming into your computer and
providing power supply for virtually zero interruption.
This UPS is specially designed for PC users and also suitable
for computer peripherals or POS. A microprocessor is used
as the controller that renders the product an intelligent UPS
capable of self-protection and fault diagnosis. Build-in AVR
function automatically adjusts itself to maintain a power
supply of stable voltage when the utility power is of extra
high or low voltage. High-performance surge suppression
protects your computer from electrical noise and damaging
power surges.
PERFORMANCE:
Uninterruptible Power Supply
Protects your data by supplying battery backup when
power fails.
Microprocessor Control
By means of innovative software control programs, the
complicated hardware circuitry is inlaid in the powerful
microprocessor. Apart from reduced size, it also lowers the
defective rate of UPS.
Display
The UPS family is available with LCD . Every important
parameter such as input voltage, output voltage, frequency,
UPS working status is showed on the LCD screen, giving a
perfect dialogue mode.
Audible Alarms
Actively let you know if the unit is on battery, if the battery
is low, or if there is an overload condition.
High quality battery
The selection of high quality sealed lead-acid maintenance
free battery maximizes the life span of the battery for
enhanced economic benets.
Automatic Detection
When the UPS is powered on, it immediately performs
an inspection of the battery capacity.
Automatic Voltage Regulation
Corrects over- and under-voltages, without draining
the battery. This preserves battery resources and
ensures your UPS will provide the optimum runtime
during a complete blackout.
Surge Protection
Shields hardware from damage.
Automatic Charge
The UPS charges its battery whenever it is connected to
utility power.
Automatic Restart
If the UPS shuts down due to the low battery voltage
protection, when the AC power resumes, the UPS can
automatically restart without a manual switching on.

UPS650A Line Interactive UPS | PRODUCT SPEC SHEET
PRODUCT SPECIFICATION
PRESENTATION
Physical Appearance:
1. Display, If the UPS is with LCD display, display input voltage, output voltage, UPS operation mode, battery indicator,
battery capacity,mute, load capacity, charger,etc,.
2. ON/OFF power button, Press this button for 3 seconds to power ON/OFF the UPS. Press this button for less than
1 second to mute the UPS during battery back up mode.
3. Telephone/Modem/Fax protection ports. RJ45 ports, connect the telephone line, fax line, or internet cable to the input
port and connect the cable from the output port to the telephone, fax machine, PC for surge protection.
4. USB communication port with the computer, connect the UPS to the PC via a USB cable to achieve real time monitoring
of the UPS status through the management software in the PC. The USB port is a optional conguration, It may be
replaced with a RS232 communication port.
5. Output receptacles, output sockets for powering the back up equipment. Output sockets type subject to the
actual product conguration.
6. Input fuse
7. Input power cord
Front Panel Rear Panel
Figure 1.
UPS650A
Line Interactive UPS

UPS650A Line Interactive UPS | PRODUCT SPEC SHEET
PRODUCT SPECIFICATION
LCD DISPLAY:
1. Input voltage, showing input voltage when AC mains is on.
2. Output Voltage, showing output voltage when UPS is ON.
3. UPS mute indicator, light ON when the UPS is pressed to
be set in silence at battery back up mode.
4. AC mode, the UPS running at Normal Mode
5. Battery mode, the UPS is running at Battery back up mode
6. Load indicator, showing on when there is a load connected to the UPS
7. Load capacity grid, showing loading capacity level
8. Battery indicator, showing that the UPS is running on battery mode
9. Battery capacity grids, showing battery capacity level,
showing charging when it is running.
UPS OPERATION MODE UPS STATUS & LCD DISPLAY
Standby Mode
Utility Power ON, the UPS is connected to the AC mains, the UPS is switched o, the output is cut o, ,
the UPS power button light on in blue(optional), the LCD display “UPS OFF” in semi-brightness. Battery
indicator on, Battery capacity grids running showing that the UPS is charging its battery.
Normal Mode
(Normal indicator)
Utility power in NORMAL condition. LCD display “AC MODE”, input voltage, output voltage, battery
indicator on, battery capacity grids running, Output load indicator on, loading capacity grids showing
loading capacity level when load is connected, loading capacity grids OFF when load is not connected.
Battery Mode
(Backup indicator)
UPS transfer to BACKUP mode. The buzzer emits alarm every four seconds. Press “POWER” to disable the
alarm function. when the battery energy runs low, the UPS beeps rapidly until the UPS shuts down from
battery exhaustion or return to utility power operation. The UPS emit a long beeping sound when the
UPS shut down automatically.
Fault Mode UPS fail (output cut o automatically),the LCD display “UPS OFF” in semi-brightness.
Overload Mode
(Overload Indicator)
UPS overload. The LCD display “UPS OFF” , the load indicator ashes, the load capacity grids fully ON,and the
UPS emits a long beeping for 5 seconds to warn an overload condition, the UPS totally switched o after 5
seconds at battery back mode, while it enters into standby mode when it is overloaded at normal mode.
UPS650A
Line Interactive UPS

UPS650A Line Interactive UPS | PRODUCT SPEC SHEET
PRODUCT SPECIFICATION
INSTALLATION
Inspection
Inspect the UPS upon receipt; make sure that nothing is damaged. The packaging is recyclable.
Save it for reuse or dispose of it properly.
Placement
Install the UPS in a protected area with adequate airow, and away from direct sunlight and excessive dust.
Do not operate the UPS where the temperature and humidity is outside the specied limits in the Specications Table.
Connect to Utility
Connect the AC input power connector to utility power to power up the UPS.
Charge the battery
The battery in the UPS will lose some charge in shipping and storage. It will recharge completely after
approximately 8 hours of normal operation. Do not expect full battery run time during this initial recharge period.
Connect the loads
Plug the loads into the output connectors on the rear of the UPS.
Caution: Never connect a laser printer or scanner to the UPS with other computer equipment.
A laser printer or scanner periodically draws signicantly more power than when idle, and may overload the UPS.
Connect Modem/Phone/Network for Surge Protection(Only for models with RJ45)
Connect a single modem/phone line into surge-protected “IN”outlet on the rear panel of the UPS,
Connect from “Out” outlet to the computer/phone with another cable.
Connect communication cable (Only for models with RS232/USB port)
To achieve management of the UPS status and computer data auto saving, connect the communication
cable one end to the RS232/USB port & the other to the RS232/USB port of the PC.
OPERATION:
Switch On
With the UPS plugged in, press and hold the POWER button more than 3 seconds until hearing one beep
sound to switch the UPS on.
Switch O
By pressing and hold the POWER button more than 3 seconds until hearing one beep sound.
Silence
In Backup mode, push the POWER button less than 1 second to silence the audible alarm.
Backup (slow alarm)
When in Backup mode, the “battery” illuminates and the UPS emit beeping sound every four seconds.
The alarms stops when the UPS return to the utility power operation. Press the POWER button to stop the beeping.
Low Battery (rapid alarm)
In Backup mode, when the battery energy runs low, the UPS beeps rapidly until the UPS shuts down from battery exhaus-
tion or return to utility power operation. The UPS emit a long beeping sound when the UPS shut down automatically.
Overload (continuous alarm)
When the UPS is overloaded, the load indicator ashes, the load capacity grids fully ON, and the UPS emits a long
beeping for 5 seconds to warn an overload condition. Disconnect nonessential load equipment from UPS to eliminate
the overload.
UPS650A
Line Interactive UPS

UPS650A Line Interactive UPS | PRODUCT SPEC SHEET
PRODUCT SPECIFICATION
SPECIFICATION
MAINTENANCE:
1. With normal use, a UPS battery will last two to three years depend on number of discharge and temperature.
Replacement and servicing of the battery should be performed or supervised by personnel knowledgeable of
batteries and their precautions. Keep unauthorised persons away.
2. Charge the UPS’s battery every 3 months during extended storage.
3. Disconnect the power during extended storage to avoid overcharge of the battery.
4. Avoid overload or short circuit though the UPS has build-in overload and short circuit protect function.
TROUBLESHOOTING:
Characteristic Specication
MODEL UPS650A
Rated Power 650VA
Backup Power 390W
Input Voltage 145-290V~
AVR Range 200-250V~
Battery mode output 210-230V~
Frequency 50Hz/60Hz
Battery Sealed, maintenance-free lead acid
Capacity 1X 12V/7AH
Back-up time (half load) Over 8 minutes
Recharge Time 10-hours (90%)
Display & indicators AC Mode, Battery Mode,Input Voltage, Output Voltage, Battery Capacity, Load Capacity, Charger,Buzzer.
Audible Alarm(Battery Mode) Beeping sound every four seconds, rapid beeping(every 0.5 second) if approaches nal discharge
Fault (overload) Continuous beeping
Temperature -5º – 40º
Humidity 10-90% RH, non-condensing.
Audible Noise < 45dBA
Transfer time < 10 ms
Net Weight(kgs) 5.5
Dimension 85x320x155mm
Problem Possible Cause Action To Take
UPS not on, LCD not lit POWER button not pushed or push too short. Press the POWER button and hold more
than 4 seconds.
PCB failure Replace the PCB, call for service
UPS always at battery mode
Power cord lose Re-plug the power cord
AC fuse burn out Replace the AC fuse
Line voltage too high, too low or black out Normal condition
PCB failure Replace the PCB, call for service
Buzzer continuous beeping Overload Remove the non-critical loads
UPS does not provide expected run time.
Low battery warning is sounded prematurely.
Battery is weak due to wear or successive
mains outages
Allow UPS to recharge battery for a minimum
of 8 hours. If UPS sounds low battery warning
prematurely, when retested, battery should
be replaced.
