Dynamode 2 PORT GIGA SWITCH User manual

VLAN Ethernet Switch
User’s Manual
Ver. 9.0
Dynamode Ltd

1
Table of Contents
1. Brief Introduction of the product ----------------
2. Networking connection -----------------------
3. Connect with other Switch/Hub -------------
4. Application ------------------------------------
5. LED introduction -------------------------
6. Product Specification ----------------------
7. Management and software introduction ------
7-1 Status Menu --------------------------------
7-1-1 Overview --------------------------------
7-1-2 Port Status -------------------------------
7-2 Configuration Menu ----------------------
7-2-1 Port setting -------------------------------
7-2-2 Port trunking setting ------------------------
7-2-3 Overrall setting --------------------------
7-2-4 QoS setting ------------------------------
7-2-5 Priority Tag remove/insert ------------
7-2-6 VLAN overall setting -----------------
7-2-7 VLAN setting
7-2-8 IGMP snooping------------
7-3 Security setting ------------
7-4 Diagnostic function --------
7-5 Reset to default configuration ---------
Dynamode Ltd

2
7-6 Save configuration ---------------
1. Brief Introduction of the product
This is a 24 x 10/100Mbps + 2 x 10/100/1000Mbps managed
fast switch. This switch supports many advanced features like
supporting 10/100Mbps half/full duplexe auto negotiation,
MD/MDI-X auto sense, Port-VLAN and Tag-VLAN,
bandwidth control management ect.. It is an ideal choice for
users who are seeking for a higher standard networking
connection with a reasonable price.
2. Networking connection
Connect a device to the switch
When the switch is connected with a 10-base Tx device , pls
use UTP Cat 3 or 5 cable
The length of the cable should comply with the IEEE
standards and max. 100 meters (328ft)
If the switch has a Tx fibre port, you can use long range
fibre to connect the switch. The switch supports
MD/MDI-X auto sense, so you can use straight cable to
connect the workstation or another switch/hub.
Dynamode Ltd

3. Connect with other Switch/Hub
The switch can connect with any 10Mbps or 100Mbps
switch/hub. Since all ports support MD/MDI-X auto sense, so
you can use straight cable or UTP cable to uplink the switch
through any port with other switch/hub.
4. Application
The switch can overcome the restriction of hub for uplink, and
improve the overall capacity and performance of the
networking. It can analyse the target address of the dada packet
to decide the forwarding destination of each packet. So the
switch can significately reduce the data flow in the networking.
3
Dynamode Ltd

Below figure shows the segmentation ability of the switch. The
channel dispute of each node is reduced to the minimum, and
the usability of each port is efficiently improved.
5. LED introduction
LED indicator
LED indicators provide some useful information like status of
the switch and each port.
LED status introduction:
LED Name Status Description
4
Off No powerPower On Power on
On
There is a device linked to
the corresponding port but
no activity
Link/Act
Flash
There is an active device
linked to the corresponding
port
On The device in 100Mbps100M bps
Off The device in 10Mbps
Dynamode Ltd

5
On Transfer in full duplexDuplex Off Transfer in half duplex
Giga port LED status introduction
6. Product Specification
-STANDARDS:IEEE802.3 10BASE-TxIEEE802.3u 100BASE
-Tx, IEEE802.3ab 1000BASE-Tx, IEEE802.1p,
IEEE802.1Q
-RATE: 10/100/1000Mbps RJ-45
-MODE: full/half duplex
-MEDIA: 10BASE-Tx UTP Cat 3,4,5; 100BASE-Tx UTP
Cat 5; 1000BASE-Tx UPT Cat 5e.
-PANEL LED: Power, Link/Act, 100Mbps, Duplex
-PORTS: 24 ports 10BASE-Tx/100BASE-Tx RJ45, 2
1000BASE-Tx RJ45
MDI-X/MDI: Auto sense
VLAN: Yes
QoS: Yes
TRUNK: Yes
Bandwidth Control: Yes
7. Management and software introduction
This switch support VLAN, Trunk, QoS, Ports
configuration (enable/disable, auto negotiation, half/full duplex,
flow control) ect. networking management functions. It can be
managed by management software through serial port(RS-232)
or browser.
Management through console port
Dynamode Ltd

Before the management, pls follow below steps:
1. Connet the switch console port with the PC serial port
(RS-232) through the cable enclosed.
2. Run the hyper terminal software of the windows. If your
PC hasn’t installed the hyper terminal software, pls
install it under “ control panel ----> add/delete software
---> Windows installation software ----> Communication
---> Hyper terminal” (Windows 98). For Windows 2000
the hyper terminal is intalled by default.
3. Input the name for the connection in the new link
dialogue.
4. Set the COM port according to the PC main board
( usually COM1).
6
Dynamode Ltd

5. Serial port settings:
Bit rate: 19200bps
Data location: 8
Parity check: None
Stop bit: 1
Flow control: None
7
Dynamode Ltd

After setting, switch on the power of the switch. The
software starts and enter into the log interface below:
Note:
If the hyper terminal interface has disorder words or no
reaction, pls check the serial port property settings, and if
the serial port is correctly connected or if the power of
the switch is on.
Input any key to enter into the main menu. See below
figure:
8
Dynamode Ltd

Note:
When you finished the settings/configuration, pls choose
“save” to save them. After finishing all settings, restart
the switch to effect the settings.
Key explanation:
Digital keys: choose the relative option;
F : Refresh the current page;
There are 6 options on the main menu, for details pls see
below:
7-1 Status Menu
See figure below:
9
Dynamode Ltd

Explanation:
Overview: Overview the status of the switch
Port Status: Show status of the ports
Key “0”: return to the previous page
7-1-1 Overview
Seefigurebelow:
10
Dynamode Ltd

Explanation:
1. Input “E”, enter into switch name change
2. after change, press “enter” key to confirm
7-1-2 Port Status
100M ports:
1000M ports:
11
Dynamode Ltd

Explanation:
Digitalkey“1”:PageUP
Digital key “2”: PageDown
“Speed”: Show the ports speed
“Duplex”: Show status of half/full duplex of the port
“Link”: Show Link status of the port. Up means link,
Down means not link.
“Flow Control”: Port flow control status. Enable
means open, Disable means close.
“Auto Negotiation”: Port auto negotiation status.
“Enable” means open, Disable means close
“Trunk”: Shows if the port is in any Trunk group
7-2 Configuration Menu
See figure below:
12
Dynamode Ltd

7-2-1 Port setting
See figure below:
13
Dynamode Ltd

Explanation:
“I/M/J/L”: Up/Down/Left/Right seperately
“Space”: Change the chosen option
“R” Key: Restart and set to auto negotiation mode
“Enable”: Port Enable/Disable setting. “Enable” is open,
“Disable” is close.
“Speed advertisement”: Port connection speed and
full/half duplex settings.
“100M Full” means 100Mbps/Full duplex
“100M Half” means 100Mbps/Half duplex
“10M Full” means 10Mbps/Full duplex
“10M Half” means 10Mbps/Half duplex
“1000M Full” means 1000Mbps/Full duplex
“Flow Control”: Port flow control settings
“Enable” means flow control is enabled
“Disable” means flow control is disabled
14
“Tx Only” means only enable flow control for
Dynamode Ltd

15
port transmitting package
“Rx Only” means only enable flow control for
port receiving package
“Symmetric” means balance flow control for
the ports
“Rx Bandwidth”: Receiving bandwidth control
“Non-control”: no bandwidth control
“128Kbps”: the port can only transmission data
at 128Kbps bandwith
“256Kbps”: the port can only transmission data
at 256Kbps bandwith
“512Kbps”: the port can only transmission data
at 512Kbps bandwith
“1Mbps”: the port can only transmission data at
1M bps bandwith
“2Mbps”: the port can only transmission data
at 2M bps bandwith
“4Mbps”: the port can only transmission data
at 4M bps bandwith
“8Mbps”: the port can only transmission data at
8M bps bandwith
“Tx Bandwidth”: Transmisstion bandwidth control
(settingssameasabove)
7-2-2 Port trunking setting
Port trunking is mainly used for improve the uplink
Dynamode Ltd

bandwith for two switches connection. The switch
support non-dynamic load-balance distribution mode
based on port.
Non-dynamic load-balance distribution mode based
on port should be assigned each port flow to the
appointed trunking port according to the actual port flow
in accordance with the principal of average to improve
the bandwidth. The assighment principal is according to
the sequence of the port number averagely.
Note:
This switch is already preset 8 trunk group. The user
can choose to enable the relative Trunk group according
to actual requirement.
7-2-3 Overrall setting
See below figure:
16
Dynamode Ltd

Explanation:
“Half Duplex Back Pressure Flow”
“Broadcast Storm Filtering Control”
“Loop Detect”
7-2-4 QoS setting
QoS function provide two internal sequence system
to support two different level of communication. High
priority and Low priority. The dada flow with High
priority has more short delay with the internal process
of the switch, reduce the time waiting maximumly for
some delay sensitive communication.
Seefigurebelow:
17
Dynamode Ltd

Explanation:
“TOS/Diff Serv. Priority”: Enable/Disable
“802.1p Priority”: 802.1p Enable/Disable
“Adapted Flow Control”: If Enable this function, during
data transmission, if the port priority is setted High,
the flow control of the port will be disabled
automatically; If the port priority is setted Low, the
flow control of the port will be Enabled
automatically.
“Priority Weighted Ration (High: Low)”: The firmware
preseted 4 kinds of priority, 1:0, 4:1, 8:1, 16:1
seperately. The user can set it according to their
requirement.
Note:
The priority of static port is higher than 802.1p and
OS/Diff Serv.
18
Dynamode Ltd

7-2-5 Priority Tag Insert/Remove
See figure below:
802.1Q VLAN tag principle:
Behind the original MAC address, 4 octet tag
will be inserted. If the Ether type of data package is
0 x8100, it means this data package include
IEEE802.1Q/802.1p tag. In the tag, except for the
above mentioned 2 octet, there are 3 bit priority
information, 1 bit CFI information (Canonical
Format Identifier, used to compress the Token Ring
data package, so it can transmission in the Ethernet),
12 bit VLAN ID(VID). 3 bit priority information is
for 802.1p, VID is identifier of VLAN for 802.1Q.
Since there are 12 bits for VID, so it can set 4094
VLAN.
19
