DYNAVOICE CA802BT User manual

User manual
Model: CA802BT
EXPERIENCE THE NORDIC SOUND

Experience the Nordic Sound
In the middle of Sweden right next to lake Hjälmaren lies Örebro. It is known for
its live music scene, rich nature and beautiful city centre with the majestic castle
towering the many restaurants and the buzzing night life. This is where we design
and engineer Dynavoice.
The Dynavoice logo is a seal of quality. It guarantees that what you now have in
your possession comes from a passion for music and sound with you, the listener,
in focus.
Through our different products you will discover ’the Nordic Sound’, a warm and
powerful, yet detailed and natural sound that over the years has become synony-
mous with Dynavoice.
We want you to discover new details in your favourite songs, and experience new
dimensions when you re-watch your favourite movies with a Dynavoice
multichannel sound system. We love what we do, and we want you to hear and
feel our passion and dedication through our speakers.
Thank you for choosing Dynavoice, and enjoy listening to the Nordic Sound.

Features
Dynavoice Challenger CA802BT
• One piece aluminium die-cast chassis
• High performance/efficiency (class D) power amplifier chip by Infineon
• USB, optical, coaxial inputs
• Pre out for subwoofer
• APTX Bluetooth 5.0 receiver
• Low distortion volume control chip by NJRC (NJW1194)
• EQ modes and treble/bass adjustment
• High resolution IPS colour display
• Remote included
• Audio grade designed power adaptor
• Gold plated input and output terminals

Table of content
Important safety information ............................................................................................................
Unpacking/before you start ................................................................................................................
Functions ...............................................................................................................................................................
Main unit front .................................................................................................................................
Main unit back .................................................................................................................................
Remote control ...............................................................................................................................
Operating instructions ..............................................................................................................................
Connecting your amplifier......................................................................................................................
Technical specifications............................................................................................................................
4
5
6
6
7-8
9
10-12
13
14

4
Important safety information
Please read this information thoroughly in its entirety, heed all warnings,
follow all instructions and keep this manual for further use.
This symbol indicates that there
are important operating and main-
tenance instructions in the manual
that is included with the product.
This symbol indicates that there is
dangerous voltage constituting a risk
of electric shock present within the
product.
This product shall not be used near water or in any moist environments. Do not block any openings
or ventilations, keep a minimum of 10cm of open space around the unit when operating. Clean only
with a dry cloth.
Do not install near any heat sources such as radiators, stoves, or other apparatus (including ampli-
fiers) that produces heat.
Protect the power cord from being walked on or pinched, particularly at plugs, convenience recep-
tacles, and the point where they exit from the apparatus.
Unplug the amplifier during lightning storms or when unused for long periods of time.
All Dynavoice products are designed and manufactured to meet the highest quality standard. Refer
all servicing to qualified service personnel. Servicing is required when the product has been dama-
ged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not opera-
te normally, or has been dropped.
Warning: To reduce the risk of fire or electrical shock, do not expose this product to rain, liquid or
moisture. The product must not be exposed to dripping and splashing and no object filled with
liquids such as a vase of flowers or an opened soda can should be placed on the product. Neither
should any naked flame sources such as candles be placed on the product.
To reduce the risk of electric shock
do not remove cover (or back).
No user-removable parts inside. Refer
servicing to qualified personnel only.
When a cart is used for
transportation, use caution
when moving the cart to
avoid injury from tip-over.

Unpacking
When you unpack your new Dynavoice speaker, please do it with care. In case the product involves
heavy lifting or if it is too big for one person to handle – make sure to have assistance, we do not
want you to break the product or yourself.
When life happens and you move to a new home, you will want to take your Dynavoice products
with you. The easiest way to do this is in the original packaging so if possible - keep the box and the
packing material.
The box contains:
Before you start
This amplifier is designed to be matched with a pair of Dynavoice floor standing speakers or book-
shelf speakers (please consult your local Dynavoice dealer for information regarding matching
speaker models with your amplifier). It is important that you do not block any ventilation or place
the amplifier inside any small, non-vented spaces. All other instructions regarding hazardous
placement can be found in the Important Safety Information.
Your amplifier has been tested at our factory before being sealed up inside the packaging, even so
we recommend you to go easy in the beginning. Make sure that everything was included in the box
and that you have made the right connections before turning on the amplifier.
The remote control requires 2x AAA batteries, make sure that there are no obstructions between
the amplifier and the remote signal.
The included Bluetooth antenna needs to be fixed in place, more about this can be found further
on in this manual.
Always make sure that your amplifier is turned off when you connect your speakers. Dis-
regarding this advice may cause a sudden audio spike that can permanently damage your
speakers.
To get the best experience possible from your new Dynavoice amplifier we recommend you to use
high quality cables throughout your entire system.
Bluetooth antennaManual AC 24V adaptor Remote control
5

6
Functions
CA802BT
1
2
3
4
1. Multi-function knob
2. 6,35mm Headphone jack
3. Display
4. Remote sensor
Main unit front
1. Multi-function knob
Press and hold to toggle ON/OFF. Press once for menu, turn left/right to adjust volume / switch
menu function.
2. 6,35mm Headphone jack
Connect headphones, see Operation instructions for menu directions.
3. Display
Shows menu options and selected function, see Operation instruction for menu directions.
4. Remote sensor
Sensor that registers usage of the remote control.

12 13
10
9 11
/R INCOAXIAL
5. Bluetooth Antenna
6. Coaxial IN / Right line input
7. Left channel input
8. Optical Audio input
9. Subwoofer Out
10. USB input
11. Right speaker output
12. Left speaker output
13. Power input (DC 24V)
Main unit back
5. Bluetooth Antenna
The antenna is included in the box and needs to be screwed in place in order for the Bluetooth
connection to function. Make sure to fix the antenna so that it can easily be screwed in place.
6. Coaxial IN/Right line input
Connect a 75 Ohm Coaxial RCA jack cable to establish a digital connection. Connect the right
channel of a RCA signal cable together with 7 to establish an AUX connection.
Please observe that 6+7 is the analogue AUX IN connection, Right and Left channel. The Coaxial IN
and AUX IN share the same inputs and can not be connected at the same time.
7. Left channel input
Connect the left channel of your RCA jack signal cable together with 6 to establish an AUX connec-
tion.
8. Optical Audio input
Connect a TOSLINK cable to establish a digital connection.
5
786
7

9. Subwoofer Out
Connect an RCA jack mono signal cable from your active subwoofer.
10. USB input
32bits 384KHz USB audio with driverless technology.
11. Right speaker output
Please pay attention to the + and – marking on the amplifier speaker connections.
Not doing so may affect the sound in a negative way.
12. Left speaker output
Please pay attention to the + and – marking on the amplifier speaker connections.
Not doing so may affect the sound in a negative way.
13. Power input (DC 24V)
Connection for the AC 24V adapter.
8

Remote control
9
Power ON/OFF
Mute/Long press
to BT reconnect
Volume +
Volume -
Menu/OK
Function switch
Output switch
Input switch
Display dimmer
N/A
Up/down select
EQ switch
The remote control requires 2x AAA batteries, make sure that there are no obstructions between
the amplifier and the remote signal.

Operation instructions
To start the amplifier, plug in the included AC 24V adaptor (Use the included power adaptor only).
Press and hold the multifunction knob, or press Power on the remote control. To access the menu,
push the multifunction knob or Menu button on the remote control.
Connecting the Bluetooth
Select Bluetooth in the Input menu. Turn on the “Bluetooth pairing” feature for the phone/music
player. Search and select “CA802BT” The phone/music player will confirm “connected” when
pairing is successful.
Troubleshooting
If the phone/music player doesn’t pair, use the “Bluetooth clear” function. See page 12 for further
instructions. When cleared, try connecting again.
10
42 DIR
USB
Connected
1. Volume
2. EQ Setting
3. Input source
4. Sampling rate
Toggle and press OK to access
required menu.
Main Display
• Input
• Output
• EQ
• Treble
• Bass
• Color
• BT Clear
• Dimmer
Toggle and press OK to access
required menu.
Setup menu
• Bluetooth
• USB audio
• Optical
• Coaxial
• AUX IN
Toggle and press OK to access
required menu.
Input setting
1
3
4
2
SETUP MENU
Input
Output
EQ
Treble
Bass
Color
BT Clear
Dimmer
INPUT
Bluetooth
USB audio
Optical
Coaxial
AUX IN

11
• Speakers
• Headphones
Toggle and press OK to access
required menu.
Output setting
• Direct
• Tone
• Bass
• Super Bass
• Rock
• Soft
• Clear
Toggle and press OK to access
required menu.
Direct - Sound is sent unaffected to the speakers. (Tone controls are decoupled)
Tone – apply this to set TREBLE and BASS. TONE will automatically be selected when
adjusting BASS or TREBLE.
Bass, Super Bass, Rock, Soft – are pre-set EQ settings.
EQ settings
Adjust the bass and treble levels.
Adjusting treble/bass automatically
switches pr-set EQ mode to Tone.
Bass/Treble
Treble Tune: -10dB~+10dB
Treble Tune: -10dB~+10dB
OUTPUT
Speakers
Headphones
EQ
Direct
Tone
Bass
Super Bass
Rock
Soft
Clear
TREBLE
0dB
BASS
0dB

12
• White
• Red
• Green
• Blue
• Yellow
• Cyan
• Orange
• Purple
Toggle to select the display color of
your choice.
Color
Turn the multifunction knob or press
up or down on the remote to discon-
nect and clear the list of connected BT
units.
BT list clear
Auto Off turns off the screen, the
machine is still working. Press the
remote control or use the machine's
knob to wake up the screen.
Dimmer
COLOR
White
Red
Green
Blue
Yellow
Cyan
Orange
Purple
BT list clear
Turn to clear
DIMMER
Always ON
Auto O

13
+- +-
Connecting your amplifier
Below you will find some examples on how to connect your speakers to your new Dynavoice ampli-
fier. These are some basic type of connections, please consult your local Dynavoice dealer if you
feel unsure.
Single-wiring
The standard way to connect your speaker is following the positive (+) and negative (-) markings on
the speaker to your amplifier creating a single-wiring connection. This connection is necessary on
the models with a single connector terminal, and optional on a model with a bi-wiring terminal.
When you use a single-wiring connection with a bi-wiring terminal, keep the shorting bars in place.
RIGHT SPEAKER LEFT SPEAKER
AMPLIFIER

Technical specifications
Dynavoice Challenger CA802BT
Type: Bluetooth amplifier
Input mode: USB, Opticial, Coaxial, Line in & Bluetooth
Output mode: 6,35mm headphone, speaker
THD+N (A-weighted): 0.003%
SNR (A-weighted): 108dB
DAC chip: ESS ES9023
Output power amplifier: 80Wx2(4 ohm), 40Wx2(8 ohm)
Output power headphone amp: 100mWx2(32 ohm)
Power consumption: 35W (normal amplifier volume)
Standby power: <0.5W
Size: 151x170x38mm (WxHxD)
Package dimensions: 294x232x88mm (WxHxD)
Weight: 520g
14
All Dynavoice products complies with
the relevant provisions of the RoHS
Directive for the European Union. In
common with all Electrical and
Electronic Equipment (EEE) the
Dynavoice product should not be
disposed of as household waste.
Alternative arrangements may apply
in other jurisdictions.
©2020, Winn Scandinavia AB
Dynavoice and Experience the Nordic Sound are trademarks of Winn Scandinavia AB, registered in Sweden and other countries
The crossed-out wheelie bin symbol
means that the product, literature and
packaging included must be taken to
separate collection at the end of their
working life. Do not dispose of these
products as unsorted municipal waste:
take them for recycling. For info on
your nearest recycling point, check
with your local waste authority.

Thank you for choosing
Dynavoice!
For further information and contact, please visit our website dynavoice.se, or our
Facebook page facebook.com/Dynavoice.
