DYS MAGIC User manual

User Manual
（Plug and play option）
（V1.0 / 2015.01）
Bill of Material
Gopro camera mount
Camera fixed bracket
Finished display
Frame fixed screw
Gopro3 camera
Frame fixed screw
3 axis stabilizer x1
M2x12 screw x2
16340 charger x1
Others
Camera fixed bracket x1
Above unmounted screen, fixed with M2 x 12 inner-
hexagon screw。
2 3
Disclaimer
Description
Contents
Thanks for purchasing DYS products. Please use the product strictly in
accordance with this manual.
Please read this instruction manual carefully before using the product. By using
this product, you hereby agree to this disclaimer and signify that you have read it
in full.
Please do not calibrate the gimbal or change the structure without prior notice. As
DYS has no control over use, setup, final assembly, modification or misuse, no
liability shall be assumed nor accepted for any resulting damager or injury.By the
act of use, setup or assembly, the user accepts all resulting liability. DYS
assumes no liability for damages or injuries incurred directly or indirectly from the
use of this product.
Any problems while mounting or using this product, please contact with the
authorised agent or the customer service of DYS.
For Gopro4/ Gopro3+/ Gopro3 and same size sport camera.
Full aluminum handle with comfortable holding feeling as well as easy- to- use by one
hand.
Light weight, portable, friendly use and plug and play. Fast moving, chasing or turning,
low angle shooting can be achieved easily. Life time more than 2 hours .
Description 2
Contents 2
Disclaimer 2
Bill of Material 3
Gopro camera mount 3
Battery installation 4
Function keys usage 4
Axis rotation sketch 5
Characteristic 5
Attentions 6
R123A/16340 3.7Vx4（exclude）

Battery installation
Function key usage
1. Unscrew the battery cap of the handle, mount 3 fully charged batteries 16340.
2. Lock the battery cap.
Power switch
16340 battery
Operation
mode button
Micro
USB port
UP
Left Right
Down
1
2
5 64
300°
Axis rotation sketch
Characteristic
80° 359°
Item
Operating voltage 7.4V 11.1V 12.6V
Operating current 200mA 450mA 2A
Static tracking accuracy
±0.01° ±0.04°
±0.1°
- 80°
- 45°
- 20° 25° 45°
0°
0°
0°
+180°
+35°
+150°
Vertical handheld
Horizontal handheld
- 150°
- 50° +50°
0.3H 1H 3H 650mAh x3
1°/S 50°/S
80°/S1°/S
0°
±0.2° ±0.04°
Dynamic tracking accuracy
Pitch range
Roll range
Yaw range
Yaw range
Pitch follow speed
Yaw follow speed
Battery life（25℃）
Working temperature
Weight 300g
without batter and camera
Min Standard Max Comment
Attentions
2. Battery and charge attentions
1. Usage attention
Camera
movement button LED power
indicator light
Power
switch
3 4
5
1. Battery switch is the gimbal switch, please ensure the switch is
off while mounting the battery.
2. Please note that the polarity of battery cannot reverse while
mounting.
3. If battery fixed not firm enough，power will be bad contact or fail
to read.
3. Camera movement button
5. Power switch
4. LED power indicator light
Four directions sliding button，up and down, right and left moving with camera.
Power switch is battery switch and gimbal reboot switch. Gimbal will be start
when plug battery and press this switch.
Indicator light will be green when fully charged; Low battery warning will appear
when turn yellow; Power will be off at any time when turn red and keep blinking,
then it is time to charge the battery.
1. Micro USB port
2. Operation mode button
Setting modify and firmware upgrade
This gimbal has four defaulted working modes as following steps，
a Press 1 time, access Yaw Follow mode, sound "Da Da Di" means ok;
b. Press 2 times, access Yaw Lock mode, sound " Da Da Di" means ok;
c.
Press 3 times, access Pitch Lock, Yaw Follow mode, sound "Da Da Di" means ok;
d. Press 4 times, access Yaw, Roll control switching mode, sound "Di" means ok.
Note: Please do not use the stabilizer with other angles except for
the above, otherwise the stabilizer may not be used normally.
Please note sand proof, dust proof and water proof while using. Please
clean the gimbal with soft dry cloth when avaliable.
a. Do not soak battery into water, keep the battery in dry and cool place
when unused for a long time.
b. Do not use the battery with disposable battery such as dry cell, or other
battery with different capacities, models and varieties.
c. Do not leave or use battery near source of heat, otherwise it may catch
fire or auto ignition while overheating.
d. Use battery with equipped charger when charging. Do not charge when
no one is around.
e. Pay attention to discharge voltage, battery will overheat and slowdown in
performance, expansion, even fire and explosion.
f. Please pull the plug in time while full charge; Do not overcharging.
g. Please ensure that the battery is installed properly while using.
h. Ｄo not heat or throw the battery into fire
i. Do not short the battery by wire or any metals.
j. Do not ship or store battery with necklaces, hairpins or other metals.
k. Do not strike or drop battery, avoid battery of hitting with hard objects.
l. Do not impale battery with nails or other sharp objects;
m. Do not hammer or tread the battery.
n. Do not decompose the battery in any way.
o. Do not use the battery if any odor, deformation by heat or abnormal
phenomena.
p. Improper use, leakage or overcharging all may result in exploding or fire.
q. Please clean the dirty battery ends with dry cloth. Or it may lead to poor
contact, even energy loss or unable to charge.
r. Do not throw the battery casually.
s. Do not use batteries except for 16340 battery.
t. Keep battery out of the reach of children.
