Introduction
Thank you for purchasing this product!
Pictor series is a set of high-performance S zoom lenses produced by
DZOFILM. Good representation of details, vivid colors and smooth transition of image
as well as can be characterized in this series of lenses. They are suitable for different
kinds of projects, documentary, MV, commercials, films, live broadcast etc, bringing
audience with pure and vivid image texture and natural transition of focus shiing.
Safety Notes
Please do not watch the sun or bright light source through the lens, otherwise
it will cause visually disabled.
Never use organic solvents such as paint thinner or benzene to clean the lens.
Attach the front and rear caps when the lens is not in use.
Store the lens and filter in cool, dry locations to prevent mold and rust. Do not
store in direct sunlight or with naphtha or camphor moth balls.
Please keep the lens dry and wipe the water droplets off if there are water
droplets on the glass surface.
Leaving the lens near heater or in other extremely hot locations could cause
damage or warping.
Use a blower to remove dust and lint from the glass surfaces of the lens or
filter. To remove smudges and fingerprints, apply a small amount of lens
cleaner to a soft, clean cotton cloth or lens-cleaning tissue and clean from the
center outwards using a circular motion. Do not leave smears or touch the glass
with your finger.
●
●
●
●
●
●
●

2
6
7
8
9
1
2
3
4
5
Lens Parts
Front cap
Lens Mark
Focusing Ring
Holes for Zoom Lever Socket *
(M, mm deep)
Zoom Lever Socket
Zoom Ring
Aperture Ring
Rear Cap
Holes for Supporting Base *
(M, mm deep)

Aperture Ring
Zoom Ring
Focusing Ring
3
Lens Control
Focus Control
Rotate the focus ring to increase or decrease the focus distance.
Zoom Control
Rotate the zoom ring to zoom out, increasing the area visible in the frame or zoom in
on the subject so that it fills a larger area in the frame.
Aperture Control
Rotate the aperture ring to stop aperture down, raising theT-stop and narrowing the
aperture, or lower theT-stop to widen the aperture.

4
Flange Back Adjustment
Note : You can download and print the chart on DZOFILM website-Download-Star
Chart for Adjusting Back Flange（Click to jump to the website）
Step Two : Aach the lens to the camera;
Step Three : Select the maximum aperture (wide open);
Step Four : Set the object .maway from the camera sensor plane, and adjust it
to the center of the whole image.
.Preparation
.Flange Back Adjustment
Every Pictor lens will process flange back adjustment on standard. But to the
tolerance of different cameras, to achieve the best performance of this product and to
match the cameras, please adjust flange back of the product.
Step One : Rotate the zoom ring to the longest focal length, and rotate the focus
ring until the image to its clearest, mark down the focusing distance S;
Step Two : Rotate the zoom ring to the widest focal length and rotate the focus ring
until the image to its clearest, mark down the focusing distance S;
Step Three : Compare the difference between S and S. If S<S, then need to add
shims; otherwise decrease the shims,
Note : The shim adjustment is evaluated on the angle between S and S. If the
angle is bigger, then need to change more shims and vice versa.
Step Four : Repeat step until S=S.Then it means the lens in under parfocal.
Step One : Ready your subject. You can use a "Star Chart", or other high-resolution
black-and-white objects;

6
.m
Maximum aperture
Set the object .m away from
the camera sensor plane, and
adjust it to the center of the
whole image.
Φ
5
Rotate the focal length to mm, and focus till the image is at its sharpest, the
focusing distance mark is .m (S). And then rotate the zoom ring to mm, re-focus
to the image at its sharpest, current focusing distance mark is .m (S). S<S.
According to the sheet below, add .mm shims on the lens mount and double check.
At this time, both mm and mm focus at the closest under . focus mark. That
means this lens is under parfocal.
Take Pictor Zoom -mm as an example：
-mm shim adjustment reference
mm focusing
mark S（m）Shim adjustment（mm）
mm focusing
mark S（m）

0.65
0.7
0.75
0.8
0.85
+0.25
+0.2
+0.14
+0.12
0.9 +0.07
+0.09
0.95
1
1.1
+0.04
+0.02
0
1.2 -0.02
1.3 -0.04
1.4 -0.06
1.5 -0.08
1.7 -0.11
2
2.5
3.5
4.5
6
10
-0.14
-0.16
-0.18
-0.2
-0.22
-0.24
1.1
6
-mm shim adjustment reference
mm focusing
mark S（m）Shim adjustment（mm）
mm focusing
mark S（m）
-mm shim adjustment reference
mm focusing
mark S（m）Shim adjustment（mm）
mm focusing
mark S（m）
Note: Shim adjustment: "+" means adding shims, and "-" decreasing shims.

M2*5 Screws
Pin Slot under Lens Mount
7
PL Mount Assembly Instruction
Align the slot on PL mount to the pin on the rear of lens. Then lay the PL mount flat
on the lens rear and slightly rotate the mount. If the mount cannot move, that means
the mount sits in right place.Tighten the pcs of M* screws symmetrically on by one
to keep the balance of lens mount.

PL
LPL EF
Lens Mark Slot on the front of Lens Mount
Pin Slot under Lens Mount
8
M2*18 Screws
Notice: Aer changing to EF mount, the rear element will extrude from the lens. Please
do not place the lens on the desk with rear part upside down, in case of causing damage
to lens surface.
EF Mount Assembly Instruction
Align the slot on EF mount to the pin on the rear of lens. Then lay the PL mount flat
on the lens rear and slightly rotate the mount. If the mount cannot move, that means
the mount sits in right place.Tighten the pcs of M* screws symmetrically on by
one to keep the balance of lens mount.
Aer changing mounts, adjusting shim thickness is needed to ensure the accuracy
of focusing. Please refer to following chart about shim adjustment. Focusing marks can
be correct again aer shim adjustment.
Unchanged
Unchanged

Specification
Focal Length
Mount
Aperture
Image Circle
Close Focus
(Metric/ Imperial)
Zoom Ratio
Mag. Ratio
(Close Focus)
Flange Distance
Iris Control
Focus Control
Zoom Control
Front Dia.
(Metric/ Imperial)
Filter Size
Length
(Metric/ Imperial)
Iris Blade 16
≈1520g ≈1700g ≈1880g
164mm（PL）6.46"/
171.9mm(EF)6.77"
175mm（PL）6.89"/
182.9mm(EF)7.20"
173mm（PL）6.81"/
181mm(EF)7.13"
M86*0.75
95mm/3.74"
270°
100°
65° 72° 61°
0.6m/2ft
2.75X 2.5X
20mm：0.0477
55mm：0.125
50mm：0.074
125mm：0.184
14mm：0.037
30mm：0.073
2.14X
31.5mm（S35）
52mm（PL）/44mm（EF）
T2.8-22
PL/EF
0.8m/2ft8in 0.6m/2ft
Weight
20-55mm 50-125mm 14-30mm
9
Specification

10
Aer-sales Service
Repairs ：Return the product to the point of purchase for repairs. Please note that we
reserve the right to refuse service in the event of damage so severe that there is lile
hope of function being restored, whether said damage is caused by physical shocks,
exposure to or immersion in sand, mud, or water or the like.
Warranty service：Should the product malfunction in the course of normal use as set
forth in the user's manual and accompanying documentation, it may be returned to the
point of purchase for repairs within warranty period. The owner is responsible for all
shipping costs. The warranty period varies with the country or region of purchase.
Stored dated receipts or other proof of purchase in a safe place, as it will be required
for repairs made under warranty.
Service Outside the Warranty Period：Request for service will normally be accepted
within a period of roughly 5 years following the end of production, during which time
spares will be kept on hand, although owners may be offered an equivalent product
during this period in the event that spares are not available. Compatibility with
consumables and accessories for the original product is not guaranteed. To prevent
waste, repairs or replacement may be made using refurbished parts or products, and
DZOFILM may collect returned parts or products for later use. When returning a
product for repair, please let us know if you need the original parts.
Privacy：DZOFILM obeys all applicable laws and regulations concerning the handling
of names, addresses, phone numbers, and other personal information provided by
users.

11
The Name and Content of Hazardous Substances
Hazardous Substances
Part Name
Lens Shell
Inner Mechanics
Optics
Other Parts
This table is formulated in accordance of SJ/T.
:Indicates that the concentration of the hazardous substance of at least
one of all homogeneous materials in the parts may be above the relevant
threshold of the GB/T standard.
Pb Hg Cd Cr(VI) PBB PBDE
○:Indicates that the concentration of the hazardous substance in all
homogeneous materials in the parts is below the relevant threshold of
the GB/T standard.
The "" in the above table indicates that there are one or more exemptions
are applied in the parts stated in RoHS //EU.

简介...........................................................................................1
安全注意事项 .............................................................................1
镜头部件 ....................................................................................2
镜头控制 ....................................................................................3
后焦调节 ....................................................................................4
1.准备工作 ..............................................................................4
2.调节后焦 ..............................................................................4
PL卡口安装说明 .........................................................................7
EF卡口安装说明 .........................................................................8
技术规格 ....................................................................................9
售后服务 ..................................................................................10
产品中有害物质的名称及含量....................................................11

安全注意事项
11
● 请勿透过镜头或摄影机观看太阳或明亮的光源，否则会使视力受损;
● 切勿使用涂料稀释剂或苯等有机溶剂清洁镜头；
● 不使用镜头时，请盖上镜头前后盖；
● 为防止发霉，请将镜头和滤镜存放在阴凉、干燥的地方，切不可存放在直射
● 请保持镜头干燥，如受潮或有水滴请擦拭干净后存放；
● 勿将镜头放置在加热器旁或其他极其炎热的地方，可能导致损坏或变形；
● 请使用吹气球去除镜头或滤镜玻璃表面的灰尘，若要去除污点和指纹，可用一
块滴有少许镜头清洁剂的干净软绵布或镜头清洁纸，以圆周运动方式从里向
外进行清洁，注意不要留下污渍，也不要用手指触摸玻璃；
感谢您购买本系列产品！
绘梦师（Pictor）系列是DZOFILM旗下的S35画幅高性能变焦镜头，可以让您在
视频创作时还原拍摄细节，色彩通透、过渡均匀自然。适合在纪录片、MV、中型商业
片、网络电影、直播等场景使用，带来纯净而生动的电影质感，较小的呼吸效应使画
面焦点转换更自然。
阳光下，也不要与石脑油或樟脑丸放一起；

2
镜头前盖
镜头标记
对焦环
变焦拨杆插孔*4（M3,深4mm）
变焦拨杆
变焦环
光阑环
卡口后盖
支撑座插孔*2（M3，深3mm）
6
7
8
9
1
2
3
4
5

光圈环
变焦环
对焦环
3
对焦控制
旋转对焦环，可增加或减少对焦距离，从而调整画面中的焦点位置。
变焦控制
旋转变焦环，可放大或缩小画面中的可视区域以及被摄主体的大小。
光圈控制
旋转光圈环，可放大或缩小光孔直径，调整画面明暗度以及被摄主体的背景虚化效果。

1.准备工作
2.调节后焦
重复 1-2 步骤，直到S2等于S1时，说明镜头已处于齐焦状态，完成后焦
调节。
准备好拍摄对象。可使用“星状测试图”，或使用其他黑白相间的、对比
度较高的拍摄对象；
步骤二 ： 镜头安装到相机或摄影机上；
镜头调整为最大光圈；
将拍摄对象放置在距离相机成像面约1.5米处，并调整其位置在画面
中心。
步骤三 ：
步骤四 ：
步骤一 ：
步骤一 旋转变焦环至最长焦端，然后旋转对焦环至画面最清晰状态，记下此时
的对焦刻度值S1；
：
步骤二 旋转变焦环至最广角端，然后旋转对焦环至画面最清晰状态，记下此
时的对焦刻度值S2；
：
步骤三 对比S2与S1的大小，若S2小于S1，则需要增加后焦垫片；若S2大于S1，
则需要减少后焦垫片;
：
步骤四 ：
提 示 垫片的调整量与S1，S2的差值对应的对焦环旋转角度有关，旋转角度
越大，需要调整的垫片越多，反之亦然；
：
提 示 可前往“DZOFILM官网-资料下载-后焦调整星图”处下载（点击此处跳转）：
4
绘梦师系列镜头在出厂前会按照标准调整后焦，但不同摄影机的法兰距在出
厂时可能会有一点不同，为了方便与不同的摄影机匹配，达到最佳成像效果，需要
进行后焦调节操作。

6
以Pictor Zoom 50-125mm为例，假设镜头变焦至125端，对焦至画面最清晰时，
对焦刻度值为1.5m，再将镜头变焦至50端，重新对焦至画面最清晰时，对焦刻度值
为1.4m，比1.5m小，参考下方“后焦垫片调整参考表”，将后焦垫片增加0.12mm后，
重新确认，125端和50端，画面最清晰时对焦刻度值都在1.5m，说明镜头已处于齐
焦状态，后焦调节完成。
例：
将拍摄对象在距离相机成像画面“Φ”标记处约1.5m放置，
将拍摄对象位于画面中心。
5

0.65
0.7
0.75
0.8
0.85
+0.25
+0.2
+0.14
+0.12
0.9 +0.07
+0.09
0.95
1
1.1
+0.04
+0.02
0
1.2 -0.02
1.3 -0.04
1.4 -0.06
1.5 -0.08
1.7 -0.11
2
2.5
3.5
4.5
6
10
-0.14
-0.16
-0.18
-0.2
-0.22
-0.24
1.1
6
提示 : 后焦垫片调整值，“+”代表要增加垫片，“-”代表要减少垫片。
