EM PRO midi E – Revision 1 - Device Reference Manual – P –
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev. 1.2

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
1
Manufacturer
E.E.P.D. Electronic Equipment Produktion & Distribution GmbH
Gewerbering 3
85258 Weichs
Phone: [phone] – 0
Fax: [phone] – 109
Web: https://www.eepd.de
E-Mail: [e-mail]
09/2021 Version 1.2
General Notes
This user manual is for your information only.
The information contained herein has been checked carefully and is believed
to be reliable. However, E.E.P.D. GmbH gives no guarantee or warranty
concerning the accuracy of spoken information and shall not be responsible
for any loss or damage of any nature resulting from the usage of or from
reliance upon it.
We are thankful for all suggestions or improvements at any time.
E.E.P.D. GmbH reserves the right to make changes in the products or
specifications, or both, at any time without notice.
Copyright Notice
Copyright©2021 E.E.P.D. GmbH. ALL RIGHTS RESERVED!
E.E.P.D. GmbH copyrights this document. You may not reproduce, transmit,
transcribe, store in a retrieval system, or translate into any language or
computer language, in any form or by any means, or otherwise, any part of
this publication without the express written permission of E.E.P.D. GmbH.
Trademark Acknowledgement
E.E.P.D.® and EMTRUST® are registered trademarks of E.E.P.D. GmbH. All
rights reserved. All other mentioned trademarks are registered trademarks of
their owners.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
2
Disclaimer
This document is provided for the general information of the customer. It
describes the general functionality of the system and is not considered as
assured characteristics. The written declarations in this specification are not
constituent part of any contract.
E.E.P.D. GmbH reserves the right to modify the information contained in this
manual as necessary and the customer should ensure that he has the most
recent revision of this document.
E.E.P.D. GmbH makes no warranty for the use of its products and bears no
responsibility for any errors, which may appear in this document. The
customer should be on notice that the field of personal computers is the
subject of many patents held by different parties. Customers must ensure that
they take appropriate action so that their use of the products does not infringe
upon any patents. It is the policy of E.E.P.D. GmbH to respect the valid patent
rights of third parties and not to infringe upon or assist others to infringe upon
such rights.
E.E.P.D. GmbH assumes no responsibility for circuits, descriptions and tables
within this document as far as patents or other rights of third parties are
concerned.
Life Support Applications
E.E.P.D. GmbH products are not intended for being used as critical
components in life support appliances, devices or systems in which the failing
of an E.E.P.D. GmbH product could be expected to result in personal injury.
FCC and CE Disclaimer
E.E.P.D. GmbH gives no warranty at all that their products will meet the FCC
and CE standards when used in combination with other third party products
or when used in any other way than specified.
Warranty
The warranty and/or guarantee conditions according to the current terms and
conditions of E.E.P.D. GmbH apply.
Reshipment
If you return the EM PRO system to E.E.P.D. GmbH please remove all
connections and peripheral equipment.
Protect the unit with a suitable packaging, preferably use the original
packaging.
Packaging
The EM PRO system is in a protective package to avoid damage during
transport.
This protective package should be recycled in an environmentally friendly way
after use.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
3
Disposal of Device
At the end of the lifetime please dispose and/or recycle the
components of the device accordingly.
Technical Support
For technical information about hardware and software please contact:
[e-mail]

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
4
Table of Contents
General Notes ...............................................................................................1
Symbols.........................................................................................................6
Safety Instructions .......................................................................................7
System Information......................................................................................8
Options............................................................................................................8
Accessories ....................................................................................................9
Intended Use ..................................................................................................9
Scope of Delivery........................................................................................10
Type Label....................................................................................................10
System Dimensions......................................................................................11
Technical Data ............................................................................................13
Interfaces.....................................................................................................14
Connection Overview....................................................................................14
Power Button with LED.................................................................................15
HDD/SSD LED..............................................................................................16
Connections................................................................................................17
MiniDisplay Ports..........................................................................................17
Dual-USB 3.1 Gen2 (900mA each) ..............................................................17
Standard pin assignment..............................................................................17
2.5 Gigabit Ethernet Dual-Port .....................................................................18
Power Connector (DC)..................................................................................18
RS232 Port 1 ................................................................................................19
RS232 Port 2 ................................................................................................19
Front USB-C Port (max. 1.5A)......................................................................19
Commissioning...........................................................................................20
Switching on the device / Operation.............................................................20
UEFI/BIOS....................................................................................................21
Entering Setup ..............................................................................................21
Main Menu ....................................................................................................22
Advanced Menu............................................................................................25
Security Menu...............................................................................................55
Power Menu..................................................................................................59
Boot Menu.....................................................................................................61
AMD PBS Menu............................................................................................67
AMD CBS Menu............................................................................................71
Exit Menu......................................................................................................89
Revision History..........................................................................................91
Index of Figures..........................................................................................92
Index of Tables............................................................................................93
List of Abbreviations..................................................................................94

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
5

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
6
Symbols
The red danger sign warns you if incorrect operation puts your
life or health at great risk. Both the components and the
peripherals could be destroyed.
The orange warning sign warns you that an incorrect or missing
operation could seriously endanger your health or destroy the
used components.
The yellow caution sign indicates that an incorrect or missing
action could damage the components.
The yellow ESD symbol indicates that electrostatic sensitive
components could be destroyed. Unpack shielded
components only with ESD protection such as an ESD
wristband or on an ESD protected area.
The information sign gives you further information and advice
for optimal use of this product.
For example, it draws your attention to necessary or optional
accessories.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
7
Safety Instructions
Safety of People
The product generates considerable heat. The housing
transports this heat to the environment and thus becomes hot.
Take care if you touch the housing as this may cause burns!
Please follow all safety instructions at the installation site.
Make sure that no or only necessary cables are connected to
the BoxPC during installation.
If access to the BoxPC interfaces is not available after
installation, all necessary connections must be made before.
Device Safety
The BoxPC operates exclusively within the specified DC
voltage range. Repair work should only be made by an
authorized and certified specialty retailer or by the
manufacturer's customer service. Do not open the device to
avoid damage.
Modifications that have not been approved by the
manufacturer void the warranty. Dust, dirt, moisture, and
extreme temperatures may significantly impair proper
operation.
The device may only be opened by a qualified person.
Cooling System
The BoxPC consists of a compact, robust metal housing with
ventilation holes. It is equipped with an automated fan. To
ensure sufficient heat dissipation, never cover the ventilation
holes of the case. Do not place any objects onto the device.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
8
System Information
Required Tools
For the installation of the EM PRO system the following standard tools are
recommended:
•Cable connection: Slot screwdriver
•Socket wrench 5.5 mm
•Torx screwdriver T10
Other required tools are depending on the installation place and method.
External Notice
All external documentation to install the EM PRO system should be obeyed.
Software
Supported operating systems are:
Microsoft® Windows® 10
Microsoft® Windows® 10 IoT Enterprise
Linux Ubuntu 20.04 LTS.
Options
Options
Description
Memory*
V2000 processors: Max. 32 GB dual-
channel DDR4 SODIMM up to 3200 MT/s,
with ECC-support
SSD*
64 GB – 2 TB
Operating System*
Windows® 10, Windows® 10 IoT
Enterprise, Linux Ubuntu 20.04 LTS
*factory assembled on request
#
ODM option
Tab. 1: Options

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
9
Accessories
For accessories please contact our sales department.
Accessories
Description
Power supply (180 W / 19.5
V or 120 W / 24 V))
Power supply incl. cable with EU plug
Display cable
Cable MiniDP to HDMI, 2 m, with interlock
Cable MiniDP to DP, 2 m
Tab. 2: Accessories
Intended Use
The EM PRO midi is a personal computer to be used with Windows 10,
Windows 10 IoT Enterprise or Ubuntu Linux 20.04 LTS. It has been designed
for office and workshop environments.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
10
Scope of Delivery
Before you begin installation, please check that your shipment is complete
and contains the items listed on the delivery note.
Type Label
Fig. 1: Type label
1– Manufacturer
2– Product name
3– Serial number with barcode
4– Power input
5– Certification information
6– MAC address
2
1
3
4
5
6

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
11
System Dimensions
Fig. 2: Dimensions front side, all values [mm] approx.
Fig. 3: Dimensions backside, all values [mm] approx.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
12
Fig. 4: Dimensions side, all values [mm] approx.
Fig. 5: Dimensions top side, all values [mm] approx.

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
13
Technical Data
•AMD V2000 processor series:
oV2516 / 6C / 12T / 2.1 GHz – 3.95 GHz / 10 – 25 W
(ODM option only)
oV2718 / 8C / 16T / 1.7 GHz – 4.15 GHz / 12 – 25 W
(ODM option only)
oV2546 / 6C / 12T / 3.0 GHz – 3.95 GHz / 35 – 54 W
(ODM option only)
oV2748 / 8C / 16T / 2.9 GHz – 4.25 GHz / 35 – 54 W
•Memory V2000 processor series:
Max. 32 GB dual-channel DDR4 SODIMM up to 3200 MT/s, with ECC-
support
•Ethernet: 2 Intel® i225 2.5Gbit with IEEE1588
•WiFi/BT (ODM option only): 802.11 AC with diversity / Bluetooth version 5
•SSD (optional): 1 M.2 PCIe/SATA + 1 PCIe only, 64 GB – 2 TB each
slot
•USB ports: 2 USB 3.1 Gen2 (900mA each) at rear side, 1 USB 2.0
under top case, 1 USB-C at front side (max. 1.5A)
•Serial ports: 2 RS-232
•2 Mini-DP++ connectors up to 4096 x 2160 @ 60 Hz
•Sound 3.5 mm MIC in / headphone out, CTIA version
•Controlled FAN (PWM + Tacho) and hardware monitoring
•Power LED
•Power supply: Min. 10.8 V / Max. 26.4 V (DC)
•Operating temperature: min. 0
°C to max. +50 °C ambient
•Storage temperature: -40
°C to +85 °C
•Relative humidity: 95
% @ 40 °C, non-condensing
•Housing: sturdy metal case
•Mounting: stand alone
•Dimensions approx.: 111 x 117 x 201 mm
•Weight: approx. 1750 g + options
•Conformity: CE, ROHS, REACH

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
14
Interfaces
Connection Overview
The EM PRO midi BoxPC is equipped with the following standard interfaces:
1– 2x Mini-DP++ connector
2– Dual-USB 3.1 Gen2 port, type A (900mA each)
3– 2x Ethernet 10/100/1000/2500 Mbit/s (RJ45), Port 1 supports WoL
4– Power supply
5– Power button (emergency power button on the rear side)
6– 2x Serial port RS-232
7– Sound 3.5 mm MIC in / headphone out, CTIA version
8– USB-C port (max. 1.5A)
9– WiFi/BT (ODM option only)
Front View
Fig. 6: BoxPC EM PRO midi front view
8
5
7

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
15
Rear View
Fig. 7: BoxPC EM PRO midi rear view
Power Button with LED
The Power Button has an integrated LED that lights up a green ring around
the Power button when the system is turned on.
Press the power button (Fig.8) once to switch the computer on and off.
Press and hold the power button (>4 Sec.) to hard power off the system in an
emergency.
Fig. 8: Power Button with LED | USB-C
4
3
2
1
USB-C
5
6
9

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
16
HDD/SSD LED
See fig. 9 for the location of the second Power-LED and the HDD/SSD-LED
Fig. 9: Power-LED | HDD/SSD-LED
HDD/SSD-LED
Power-LED

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
17
Connections
MiniDisplay Ports
Standard pin assignment
Fig. 10: MiniDisplay port schematic
Important Note:
There are two kinds of DisplayPort cables available:
Cables for direct connection to a MiniDisplay Port monitor
with Pin 20 on both ends of the cable NOT connected.
Cables for use with dongles (e.
g. MiniDisplay Port to Display
Port, MiniDisplay Port to HDMI) with Pin 20 on both ends of
the cable connected.
Possible effects if wrong cable is used:
- System might not start up properly.
- Dongle doesn’t work properly (e.g. black display).
Dual-USB 3.1 Gen2 (900mA each)
Standard pin assignment
Fig. 11: Dual-USB 3.1 Gen2 detail

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
18
2.5 Gigabit Ethernet Dual-Port
Standard pin assignment
Fig. 12: Dual-Ethernet detail
Yellow LED
Speed-LED is on during 2.5 or 1 Gbit transmission and switched off during
10/100 Mbit transmission.
Green LED
Link-/Activity-LED is permanently on to indicate an active connection on the
Ethernet port. LED flashes during communication with the Ethernet network.
Power Connector (DC)
Fig. 13: Power connector schematic
Counterpart - plug:
CUI Devices Power Plug ID 2.5mm, AD 5.5mm
Ordering number: PP3-002B
Pin
Signal
Description
1
PVIN
DC+ (min 10.8 V to max. 26.4 V)
2
GND
Ground
Tab. 3: Pin assignment power connector

EM PRO midi E Device Reference Manual – P – Revision 1
E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs
Copyright © 2021 by E.E.P.D. GmbH. All rights reserved. | Rev.1.2
19
RS232 Port 1
9-pin D-Sub
Signal
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
Tab. 4: Pin assignment RS232
Fig. 14: 9-pin D-SUB connector
RS232 Port 2
9-pin D-Sub
Signal
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
Tab. 5: Pin assignment RS232
Front USB-C Port (max. 1.5A)
Standard pin assignment
Fig. 15: USB-C Detail
