E-FLITE Mini Pulse XT User manual

Mini Pulse XT
Assembly Manual

2
Introduction................................................................3
Specifications.............................................................3
Using the Manual .......................................................3
Contents of Kit/Parts Layout .........................................4
Required Radio Equipment...........................................5
Important Information About Motor Selection .................6
Sport Outrunner Setup.................................................6
Optional Accessories ..................................................6
Required Tools and Adhesives......................................6
Note Regarding Hinges...............................................7
Note on Lithium Polymer Batteries.................................7
Warning....................................................................7
Limited Warranty Period ..............................................8
Limited Warranty & Limits of Liability.............................8
Safety Precautions.......................................................9
Questions, Assistance, and Repairs...............................9
Questions or Assistance...............................................9
Inspection or Repairs...................................................9
Warranty Inspection and Repairs................................10
Table of Contents
Non-Warranty Repairs...............................................10
Safety, Precautions, and Warnings..............................11
Landing Gear Installation...........................................12
Outrunner Motor Installation.......................................14
Cowling Installation ..................................................15
Tail Installation..........................................................19
Wing Preparation .....................................................24
Final Assembly .........................................................26
Control Throws .........................................................30
Range Testing the Radio ............................................31
Center of Gravity......................................................31
Preflight ...................................................................32
Notes ......................................................................33
2006 Official AMA
National Model Aircraft Safety Code..........................34

3
Introduction
Thank you for purchasing the Mini Pulse XT. Designed
from the beginning for electric power, the Mini Pulse XT
is developed from the Hangar 9®Pulse™ XT with the
same flight characteristics as the 40-size version. It is a
perfect transitional airplane for beginners who want to
learn aerobatics and for sport flyers who want an easy,
comfortable sport flyer. All flight control surfaces, hinges,
and control horns have been installed at the factory to
help speed up the building time.
Specifications
Wingspan: 42.5 in (1080mm)
Length: 37.5 in (875mm)
Wing Area: 330 sq in (21.5 sq dm)
Weight w/o Battery: 21–22 oz (710–820 g)
Weight w/ Battery: 25–27 oz (795–965 g)
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed
next to each step to keep track of each step completed.
Steps with a single circle () are performed once, while
steps with two circles () indicate that the step will
require repeating, such as for a right or left wing panel,
two servos, etc.
Remember to take your time and follow the directions.

4
Contents of Kit/Parts Layout
Large Replacement Parts:
EFL2376 Wing w/Ailerons
EFL2377 Fuselage
EFL2378 Tail Set
EFL2380 Main Landing Gear
EFL2381 Cowling
EFL2382 Wheel Pants
Small Replacement Parts:
EFL2379 Pushrod Set
EFL2383 Motor X-Mount
EFLA200 Micro Control Horns
FLA203 Micro Control Connectors
EFLA219 Steerable Tailwheel Assembly
EFLA223 Foam Park Wheels, 2"
EFLA213 E-flite/JR/Horizon Decals

5
You will need a minimum 4-channel transmitter, crystals,
micro receiver, and four sub-micro servos. You can choose
to purchase a complete radio system that includes all of
these items or, if you are using an existing transmitter, just
purchase the other required equipment separately.
Complete Radio System
SPM2460 DX6 DSM 6CH Park Flyer w/4-S75
Servos
Note: We recommend the crystal-free,
interference-free Spektrum®DX6 2.4GHz DSM®
6-Channel System, which includes a micro
receiver and 4 sub-micro servos.
Or Purchase Separately
SPM6000 AR6000 DSM DualLink™ 6-Channel
Park Flyer Rx
Or
JSP30610 6-Channel UltraLite Rx w/o Crystal,
Positive Shift JR/AIR (72MHz)
Or
JSP30615 6-Channel UltraLite Rx w/o Crystal,
Negative Shift FUT/HRC (72MHz)
JRPXFR** FM Receiver Crystal
JSP98110 6" Servo Extension (2)
JSP98030 12" Servo Extension (2)
JSP98020 Y-harness, Standard 6"
EFLRS75 7.5-Gram Sub-Micro Servo (4)
Required Radio Equipment

6
Important Information About Motor
Selection
We recommend the E-flite®Park 450 Brushless Outrunner,
890Kv (EFLM1400) to provide you with excellent sport
and aerobatic power and a worry-free outrunner motor.
The Mini Pulse XT does not include a propeller, but we
recommend our 10X8 Electric Prop (EFLP1080E).
Sport Outrunner Setup
EFLM1400 Park 450 Brushless Outrunner
Motor, 890Kv
EFLA1025 25-Amp Pro Brushless ESC
THP21003SPL 2100mAh 3-Cell 11.1V Li-Po,
16GA
Or
EFLB1035 11.1V 2100mAh 3-Cell Li-Po,
16GA
EFLP1080E 10 x 8 Electric Prop
EFLAEC302 EC3 Battery Connector, Female (2)
EFLC3005 Celectra 1- to 3-cell Li-Po Charger
This is a sport flyer setup for smooth and stable flights.
Optional Accessories
EFLA110 Power Meter
Required Tools and Adhesives
Tools & Equipment
EFLA250 Park Flyer Tool Assortment, 5-piece
Or Purchase Separately
EFLA257 Screwdriver, #0 Phillips (or included
with EFLA250)
EFLA251 Hex Wrench: 3/32" (or included
with EFLA250)
Nut driver: 1/4"
Drill
Drill bit: 1/16" (1.5mm), 5/64" (2mm)
Masking tape
Card stock
Felt-tipped pen
Needle-nose pliers
Canopy glue

7
Note Regarding Hinges
For your convenience and to speed the assembly process,
the hinges have already been installed and glued. We
suggest that you take a minute before beginning assembly
of your model to check them.
Grasp the wing and aileron at each hinge location, then
gently pull on the aileron to ensure the hinges are secure
and cannot easily be pulled away from either surface.
Use caution when gripping the wing and aileron to avoid
crushing or damaging the structure. Repeat this process for
the elevator and rudder.
If, however, you find that the hinges pull away, simply
wick thin CA into the hinge slots and reinstall the
hinges/surfaces.
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly
more volatile than alkaline or Ni-Cd/Ni-MH
batteries used in RC applications. All
manufacturer’s instructions and warnings
must be followed closely. Mishandling of
Li-Po batteries can result in fire. Always follow
the manufacturer’s instructions when disposing
of Lithium Polymer batteries.
Warning
An RC aircraft is not a toy! If misused, it can cause
serious bodily harm and damage to property. Fly
only in open areas, preferably at AMA (Academy of
Model Aeronautics) approved flying sites, following all
instructions included with your radio.
Keep loose items that can get entangled in the propeller
away from the prop, including loose clothing, or other
objects such as pencils and screwdrivers. Especially keep
your hands away from the propeller.

Limited Warranty Period
Horizon Hobby, Inc. guarantees this product to be free
from defects in both material and workmanship at the
date of purchase.
Limited Warranty & Limits of Liability
Pursuant to this Limited Warranty, Horizon Hobby, Inc.
will, at its option, (i) repair or (ii) replace, any product
determined by Horizon Hobby, Inc. to be defective. In the
event of a defect, these are your exclusive remedies.
This warranty does not cover cosmetic damage or damage
due to acts of God, accident, misuse, abuse, negligence,
commercial use, or modification of or to any part of
the product. This warranty does not cover damage due
to improper installation, operation, maintenance, or
attempted repair by anyone other than an authorized
Horizon Hobby, Inc. service center. This warranty is
limited to the original purchaser and is not transferable.
In no case shall Horizon Hobby’s liability exceed the
original cost of the purchased product and will not
cover consequential, incidental or collateral damage.
Horizon Hobby, Inc. reserves the right to inspect any and
all equipment involved in a warranty claim. Repair or
replacement decisions are at the sole discretion of Horizon
Hobby, Inc. Further, Horizon Hobby reserves the right to
change or modify this warranty without notice.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER. HORIZON HOBBY, INC. SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
As Horizon Hobby, Inc. has no control over use, setup,
final assembly, modification or misuse, no liability shall be
assumed nor accepted for any resulting damage or injury.
By the act of use, setup or assembly, the user accepts all
resulting liability.
If you as the purchaser or user are not prepared to accept
the liability associated with the use of this product, you
are advised to return this product immediately in new and
unused condition to the place of purchase.
8

Safety Precautions
This is a sophisticated hobby product and not a toy. It
must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate
this product in a safe and responsible manner could result
in injury or damage to the product or other property. This
product is not intended for use by children without direct
adult supervision.
The product manual contains instructions for safety,
operation and maintenance. It is essential to read and
follow all the instructions and warnings in the manual,
prior to assembly, setup or use, in order to operate
correctly and avoid damage or injury.
Questions,Assistance, and Repairs
Your local hobby store and/or place of purchase cannot
provide warranty support or repair. Once assembly, setup
or use of the product has been started, you must contact
Horizon Hobby, Inc. directly. This will enable Horizon to
better answer your questions and service you in the event
that you may need any assistance.
Questions or Assistance
For questions or assistance, please direct your email to
[e-mail], or call 877.504.0233
toll-free to speak to a service technician.
Inspection or Repairs
If your product needs to be inspected or repaired, please
call for a Return Merchandise Authorization (RMA). Pack
the product securely using a shipping carton. Please note
that original boxes may be included, but are not designed
to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and
insurance for lost or damaged parcels, as Horizon Hobby,
Inc. is not responsible for merchandise until it arrives and
is accepted at our facility. Include your complete name,
address, phone number where you can be reached during
business days, RMA number, and a brief summary of the
problem. Be sure your name, address, and RMA number
are clearly written on the shipping carton.
9

Warranty Inspection and Repairs
To receive warranty service, you must include your
original sales receipt verifying the proof-of-purchase
date. Providing warranty conditions have been met, your
product will be repaired or replaced free of charge.
Repair or replacement decisions are at the sole discretion
of Horizon Hobby.
Non-Warranty Repairs
Should your repair not be covered by warranty and the
expense exceeds 50% of the retail purchase cost, you will
be provided with an estimate advising you of your options.
You will be billed for any return freight for non-warranty
repairs. Please advise us of your preferred method of
payment. Horizon Hobby accepts money orders and
cashiers checks, as well as Visa, MasterCard, American
Express, and Discover cards. If you choose to pay by
credit card, please include your credit card number and
expiration date. Any repair left unpaid or unclaimed
after 90 days will be considered abandoned and will be
disposed of accordingly.
Electronics and engines requiring inspection or
repair should be shipped to the following address
(freight prepaid):
Horizon Service Center
4105 Fieldstone Road
Champaign, Illinois 61822
All other products requiring inspection or repair should be
shipped to the following address (freight prepaid):
Horizon Product Support
4105 Fieldstone Road
Champaign, Illinois 61822
10

As the user of this product, you are solely responsible for
operating it in a manner that does not endanger yourself
and others or result in damage to the product or the
property of others.
Carefully follow the directions and warnings for this and
any optional support equipment (chargers, rechargeable
battery packs, etc.) that you use.
This model is controlled by a radio signal that is subject to
interference from many sources outside your control. This
interference can cause momentary loss of control so it is
necessary to always keep a safe distance in all directions
around your model, as this margin will help to avoid
collisions or injury.
• Always operate your model in an open area away from
cars, traffic, or people.
• Avoid operating your model in the street where injury or
damage can occur.
• Never operate the model out into the street or populated
areas for any reason.
• Never operate your model with low transmitter batteries.
• Carefully follow the directions and warnings for this and
any optional support equipment (chargers, rechargeable
battery packs, etc.) that you use.
• Keep all chemicals, small parts and anything electrical
out of the reach of children.
• Moisture causes damage to electronics. Avoid water
exposure to all equipment not specifically designed and
protected for this purpose.
Safety, Precautions, and Warnings
11

1. Place the landing gear onto the bottom of
the fuselage. They will angle back slightly when
installed in the correct direction. Attach with
two 4-40 x 1/2" socket head bolts and two #4
black washers.
Landing Gear Installation
Required Parts
Fuselage
Main landing gear
Wheel pant (L&R)
2" (50mm) wheel (2)
4-40 x 1/2" socket head bolts (2)
#4 black washers (2)
4-40 nut (2)
4-40 locknut (2)
4-40 x 1 1/4" socket head bolts (2)
#4 steel washers (4)
2mm x 6mm wood screws (2)
Required Tools and Adhesives
Hex wrench: 3/32"
Phillips screwdriver (small)
Nut driver: 1/4"
Needle-nose pliers
Note: You may consider using a larger
diameter wheel, such as 2 1/4" (58mm), if
your flying site has rough terrain. By using a
larger wheel, you will not be able to use the
included wheel pants.
12

2. Slide the 4-40 x 1 1/4" socket head bolt
through one of the 2" wheels. Slide a #4 steel
washer so it fits against the wheel. Next secure
a 4-40 nut against the washer. Make sure the
wheel still spins freely. Slide a second #4 steel
washer onto the bolt. This washer will fit inside
the wheel pant.
3. Fit the assembly in Step 2 into the wheel pant
and insert the bolt into the landing gear. With
the fuselage level to the work surface, rotate the
wheel pant so it is also level to your work surface
and secure the pant to the landing gear with a
2mm x 6mm wood screw. Secure the bolt with
a 4-40 locknut while using needle-nose pliers to
hold the head of the bolt inside the pant.
3. Repeat Steps 2 and 3 for the remaining wheel
and wheel pant.
13

Outrunner Motor Installation
Required Parts
Fuselage
Brushless motor
4-40 x 1 1/4" socket head screw (4)
Aluminum motor spacer, 13/16" (20mm) (4)
Required Tools and Adhesives
Hex wrench: 3/32"
Screwdriver (Phillips #0)
Note: This section covers the installation of
the recommended Park 450 Outrunner motor.
The holes in the firewall for mounting the
custom X-mount will also fit the hole pattern for
our E-flite® Firewall Stick Mount (EFLM1916
– available separately) if you prefer to use a
gearbox with an inrunner motor.
1. Attach the supplied aluminum motor X-mount
to the motor using the screws provided with the
motor. The wider section of the mount will be
positioned towards the motor wires.
14

2. Attach the Outrunner motor to the front of the
firewall using four 4-40 x 1 1/4" socket head
screws and the aluminum motor spacers.
Cowling Installation
Required Parts
Fuselage w/motor installed
Cowling
2mm x 8mm wood screw (4)
Propeller
Spinner
Prop adapter (for outrunner motor)
Electronic speed control
Required Tools and Adhesives
Screwdriver (Phillips #0)
Cardstock
Masking tape
Drill
Drill bit; 1/16" (1.5mm), 5/64" (2mm)
Important Information About Your Brushless ESC
Make sure your ESC brake is programmed to Off.
Also, be sure to use an ESC with the proper 9V cutoff
when using 3-cell Li-Po packs, or 6V cutoff when using
2-cell Li-Po packs.
15

1. Solder any connectors to the speed control
to connect to the motor battery and motor if
necessary. Connect the ESC to the motor and
secure it to the inside of the fuselage using hook
and loop material. Actual ESC location may vary.
Important Information About Your Propeller
It is also very important to check to be sure the
propeller is balanced before installing onto the shaft. An
unbalanced propeller may strip the gears or cause poor
flight characteristics.
16

2. Connect the speed control to the radio system
and motor battery. Check that the motor is
rotating in the correct direction. It will rotate
counterclockwise when viewed from the front of
the aircraft. Use the instructions with your speed
control to correct a motor that is operating in the
wrong direction.
3. Tape small pieces of cardstock to the fuselage to
indicate the locations of the cowl mounting tabs
at the front of the fuselage.
4. Slide the cowling onto the fuselage. Install the
propeller adapter onto the Outrunner shaft. You
may need to ream out the hole on your prop hub
to fit the prop adapter shaft at this point. Slide the
propeller onto the prop adapter shaft. The spinner
backplate and spacers may need to be enlarged
as well to fit the prop adapter. Slide the spinner
backplate and any needed spacers onto the prop
adapter shaft. Secure the propeller using the prop
adapter spinner and be sure it is secure and tight.
17

Note: Make sure to check the balance of
the propeller after enlarging the hole in the
propeller.
5. Position the cowl so it is around 1/16"–1/8"
(1.5mm–3mm) from the spinner backplate. Use
the cardstock to drill four 1/16" (1.5mm) holes
through the cowl into the cowl mounting tabs in
the fuselage.
6. Enlarge the holes in the cowl using a 5/64"
(2mm) drill bit. Secure the cowl using four
2mm x 8mm sheet metal screws. Snap the
spinner cone onto the spinner backplate once
the cowl is secure.
Hint: Use thin CA to harden the holes drilled
into the cowl mounting tabs. This will help to
prevent the screws from vibrating loose in flight.
18

Tail Installation
Required Parts
Fuselage
Rudder/Fin
Stabilizer/Elevator
Servo (2)
Servo extension, 12" (305mm) (2)
Control connectors w/backplate (2)
2mm x 4mm screw (2)
4-40 locknut (2)
#4 washer (2)
Linkage wire, 4" (102mm) for elevator
Linkage wire, 5 1/2" (140mm) for rudder
Tailwheel, 3/4"
Wheel collar (tailwheel)
Required Tools and Adhesives
Nut driver: 1/4"
Drill
Drill bit: 1/16" (1.5mm)
Screwdriver, #0 Phillips
1. Attach the tail wheel to the tail gear wire using a
1/16" wheel collar and setscrew.
19

2. Locate the stabilizer/elevator assembly. Position
the stabilizer/elevator assembly so the control
horn will face down, away from the fin. The
threaded rods from the rudder/fin assembly will
slide into the two holes in the stabilizer.
3. Slide the rudder/stabilizer assembly onto the
fuselage. Slide the #4 washers onto the threaded
rods. Thread the nuts onto the rod, tightening
them snugly against the bottom of the fuselage.
Note: The tail section is removable for easy
transporting if needed.
20
