E-Z Anchor Puller EZ-0404 User manual

Email additional questions to [e-mail]
The Electronic Fast Fall Solenoid System (EFF-2S-200E) is for those who want to deploy their
anchor twice as fast as the direct drive capabilities of the Hero and Patriot series currently allow
(100’ per minute), but do not necessarily want or need free-fall. Adding the EFF-2S-200E
doubles the voltage of your direct drive drum anchor winch while also allowing you to completely
control the drop by holding down the button until your anchor hits bottom.
HOW TO DEPLOY ANCHOR AND OPERATE THE EFF-2S-200E:
Turn on your EZ-EFF unit by pushing the on/off button and holding it for two seconds. While
holding in the “down” button, the EFF will activate after two seconds and drop your anchor at
twice the direct drive speed. Keep in mind that your drum anchor winch is still a direct drive unit,
meaning you must press and hold the rocker switch button down/up to operate it.
EFF-2S-200E INSTALLATION INSTRUCTIONS:
Install the EFF-2S-200E in a well-protected area,
away from exposure to water, using the mounting
tabs attached underneath the box.
*IMPORTANT NOTICE - THE EFF IS MEANT TO BE
INSTALLED IN A SAFE, DRY PLACE AWAY FROM ANY
OUTSIDE ELEMENTS. KEEP IN MIND THIS IS AN
ELECTRONIC POWER BOX AND MUST BE INSTALLED
AWAY FROM WATER!*
Keep the “on/off” button
into consideration when choosing the location of installation for the
EZ-EFF system: should you choose to temporarily suspend fast fall,
make sure the button is accessible. The “on/off” button is located on the
long edge of the unit, directly above the top of the unit where the logo
is.
Mount the rocker switch panel to the dash, then connect the drum
anchor winch motor cables to the motor terminals on the designated
side of your new EZ-EFF unit (wires shown in the below diagram).
Connect the negative cable from the house battery to the black battery
terminal on EFF-2S-200E, then connect the positive cable from the
battery/circuit breaker to the red terminal side labeled “battery power in”
on the EFF-2S-200E unit. Failure to connect the terminals in this way
will result in damage to internal components and void any warranties on
your EZ-EFF unit.
www.ezanchorpuller.com 1.800.800.1640 2

Email additional questions to [e-mail]
Diagram and Wiring Directions:
Recommended wiring for the EZ-EFF systems must begin from the motor wires to the house
battery. For recommended gauge wiring, refer to the wiring chart located in the drum anchor
winch manual. See the EFF unit wiring diagram on page 4. Refer to the below outline for wiring
details:
●Motor Wiring - Connect negative and positive terminals to the winch motor.
For the motor, maintain a minimum. 3 ft. / 1 m. when connected the EZ-EFF to the drum
anchor winch motor. Switch the motor wires around if the EZ-EFF does not go
down fast. Must maintain a minimum of 3 ft. of cable between the anchor winch
motor and EZ-EFF.
●Battery Wiring - Do Not cross battery wires! This will cause damage to your EZ-EFF and void
the warranty. For boat battery, negative terminals to boat battery / positive terminals to circuit
breaker, then to boat battery.
●Rocker Switch Wiring - Connect the EFF gray cable to your drum anchor winch rocker switch,
which is typically mounted at the helm:
●EFF Red wire to Red + on rocker switch
●EFF Black wire to Black - on rocker switch
●EFF Blue wire to “up” function on rocker switch
●EFF Green wire to “down” function on rocker switch
●Wireless Receiver Unit (remote control) -connect the
black output cable encasing the green and blue wires to the
appropriate connections on your wireless remote receiver box.
They should connect as such:
●EFF red wire to red + wire on remote receiver box
●EFF black wire to black - wire on remote receiver box
●EFF blue wire to green up solenoid coil wire on remote receiver
●EFF green wire to yellow down solenoid coil on remote receiver
www.ezanchorpuller.com 1.800.800.1640 3

Email additional questions to [e-mail]
It is important to test the direction of the anchor winch’s drum rotation before use. Before going
out on the water, test the direction of the drum rotation and interchange the position of the
cables connected at the motor terminals on the EZ-EFF if needed.
NOTICE: Ensure correct operation by observing the chain and rope falling fast, then
retrieving at normal speed. The EFF-2S-200E is not designed to retrieve the anchor at EFF
speeds. All warranties will be considered null and void if this occurs. With any questions or
concerns, contact E-Z Anchor Puller at 1.800.800.1640.
TIPS & TRICKS WHEN ANCHORING: To drop the anchor you should always go past your mark and
put the boat in reverse to idle back. When ready, press down on your rocker switch to deploy the anchor.
Observe the operation and ensure there is tension on the rope. Be sure not to overrun the rope on the
drum.
Once the rope becomes loose/slack, stop the downwards operation. If more rope is
required to be released; push and release the “down” side of the rocker switch panel until there is slack in
the rope again. When you’re satisfied with the position of your vessel and the amount of rope released,
turn off your engine and enjoy being at anchor!
When retrieving the anchor, start your engine and idle forward while pressing the “up” side of your rocker
switch. Be ready to stop as the anchor reaches the top bow roller and is securely in place. Now, you’re
ready to go find your next fishing spot! Always have a spare rope and anchor in case of a power
failure or winch failure in order to deploy the anchor.
WARRANTY INFORMATION
For complete warranty information and protection, please click the link or scan the QR code with
your camera phone below to go directly to our warranty page. You’ll receive a confirmation email
upon completion.
https://ezanchorpuller.force.com/s/warranty-information
