EAGLE CLAW Shappell WIDE HOUSE 4500 User manual

CONSUMER WARRANTY
Eagle Claw Shappell® warrants its products against defects in material and
workmanship for one (1) YEAR from date of purchase. We will provide FREE
repair or replacement, in whole or in part, at our option, for any product, found
in our opinion to be defective. If return is required, freight must be prepaid.
This warranty does not cover freight damage, ordinary wear and tear, abuse,
misuse or altered product.
WINDOWS ARE NOT GUARANTEED AT TEMPERATURES BELOW
–15 DEGREES FAHRENHEIT.
For warranty claim, send letter indicating product and explanation of defect
plus dated proof of purchase to Eagle Claw Fishing Tackle, ATTN: Warranty
Dept., 4245 E. 46th Ave., Denver, CO 80216.
REV 0616
REPLACEMENT PARTS
MODEL WH4500
Part# Description
10550 Frame Rod Roof (34”)
10552 Frame Rod Upper Side (36”)
10553 Frame Rod Lower Side (40-3/4”)
10527 Hub Plate
10528 Plastic Hub Insert
10532 Hub Body & Bolt & Strap
10554 Replacement Window - 29” W x 12” H
IA2 Ice Anchor (pair)
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM
THIS TENT FABRIC. This tent meets the flammability requirements of
CPAI-84. The fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may render the flame
resistant properties ineffective.
CARBON MONOXIDE POISONING HAZARD: This shelter must be
ventilated if using an oxygen consuming heat source. DO NOT PACK SNOW
AROUND SHELTER or in any way prevent fresh air from entering shelter.
Failure to ventilate shelter could create a serious health hazard or death.
Windows cannot be made to withstand temperatures below –15o F. (see warranty)
MAINTENANCE: After each use, set up shelter until fabric is completely dry.
Never leave shelter folded/closed with a wet cover.
NOTICE: It is normal for fabric to have some pinholes. This does not affect
water repellency.
READ SETUP & TAKEDOWN INSTRUCTIONS BEFORE USING SHELTER
IMPORTANT SAFETY INFORMATION
CO
To order parts, please give Part No., Description and Qty needed.
EAGLE CLAW FISHING TACKLE
ATTN: Shappell Parts Dept.
4245 E. 46th Ave., Denver, CO 80216
[phone]
LOT #: ____________

Set Up Take Down
1) Remove tent from
bag and set hub end
on ice. (Fig. 1)
2) Unfold tent and
screw in ice anchor
at one corner eyelet.
(Fig. 2)
Fig. 2
Fig. 3
4) Pull out side hub while pushing
against top center. (Fig. 4)
5) Pull out all remaining hubs.
(Fig. 5)
6) Install remaining ice anchors as
needed. (Fig. 6)
1) Remove ice anchors, leaving
one. Push in on side hub so it
pops in. (Fig. 7)
2) Push remaining side
hubs in. (Fig. 8)
3) Push top hub down. (Fig. 9)
Fig. 10
4) Remove last ice anchor and fold all corners up. (Fig. 10) & (Fig. 11)
5) Put tent into bag with hubs at the bottom of bag. (Fig. 12)
Fig. 9
Push
Fig. 12
Shoulder Carry Straps
Fig. 11
Fig. 1
Fig. 6
Fig. 4
Pull
Fig. 5
Push
Pull
3) Pull up on top hub or pull out side hub, whatever is easiest. (Fig. 3)
Push
Fig. 8
Push
Fig. 7
Push
