EarthLinked AVS-0030-A Programming manual

SD-410-QS (H) (06/15) Copyright 2015 Earthlinked Technologies, Inc.
Classic Series
SD (H) Geothermal Heating and Cooling System
Quick-Start Instructions

SD-410-QS (H) (06/15) Page 2
Table of Contents
Model Nomenclature..........................................................................................................................5
Safety.................................................................................................................................................6
Equipment Manuals ...........................................................................................................................6
Installation..........................................................................................................................................7
Component Matching...................................................................................................................7
Compressor Unit Placement ........................................................................................................8
Refrigeration................................................................................................................................9
System Applications and Electrical ............................................................................................13
Plumbing....................................................................................................................................21
Antifreeze Protection..................................................................................................................23
Internal Heat Recovery System..................................................................................................24
Earth Loop Protection System..........................................................................................................28
Anode Wire Installation..............................................................................................................28
EPS Operation and Service .......................................................................................................33
Current Verification....................................................................................................................34
System Start-Up...............................................................................................................................35
Evacuation.................................................................................................................................35
Initial Charge..............................................................................................................................38
Final Charge..............................................................................................................................40
Cool Mode Start-Up...................................................................................................................43
Troubleshooting ...............................................................................................................................50
Compressor...............................................................................................................................50
System.......................................................................................................................................54
Commissioning Document ...............................................................................................................56
Tools and Equipment .......................................................................................................................64
Triple Evacuation .............................................................................................................................65

SD-410-QS (H) (06/15) Page 3
List of Figures
Figure 1. Matching Component Model Numbers..................................................................................7
Figure 2. General Layout of System Components ..............................................................................8
Figure 3. Compressor Unit Bracket Installation....................................................................................9
Figure 4. Compressor Unit Clearance..................................................................................................9
Figure 5. SD(H) Connections.............................................................................................................10
Figure 6. Line Set Sizes.....................................................................................................................12
Figure 7. SD(H) Electric Box Components & Electrical Data..............................................................14
Figure 8a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-1-60 ..........................................15
Figure 8b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-1-60.....................................16
Figure 9a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-3-60 ..........................................17
Figure 9b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-3-60.....................................18
Figure 10a. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating Application ................19
Figure 10b. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating Field Wiring Diagram20
Figure 11. Typical SD(H) Primary Hydronic Circuit Plumbing.............................................................21
Figure 12. Standard Storage Water Heater –Service Connections ..................................................25
Figure 13a. GSTE Storage Water Heater - Service Connections......................................................26
Figure 13b. GSTE Storage Water Heater –Tank Top View..............................................................26
Figure 14. Compressor Cabinet Socket/Cap.....................................................................................28
Figure 15. Disassembled Plug Connector.........................................................................................29
Figure 16. Anode Wire Insertion .......................................................................................................30
Figure 17. Install the Plug Insert .......................................................................................................31
Figure 18. Engage the Gland Nut .....................................................................................................31
Figure 19. Secure the Anode Wire....................................................................................................32
Figure 20. The Plug and Socket Joint...............................................................................................32
Figure 21. Electric Box with EPS Components .................................................................................33
Figure 22. EPS Current Ratings .......................................................................................................34
Figure 23. Test for DC Current .........................................................................................................34
Figure 24. SD(H) Internal Flow Schematic.........................................................................................35
Figure 25. SD(H) Piping.....................................................................................................................36
Figure 26. Evacuation of SD(H) System ............................................................................................37
Figure 27. Initial Charge of SD(H) System.........................................................................................39
Figure 28. Final Charge of SD(H) System.........................................................................................40
Figure 29. Charge at Bottom Sight Glass..........................................................................................41
Figure 30. Air System Performance Parameters...............................................................................42
Figure 31. Hydronic System Performance Parameters.....................................................................43

SD-410-QS (H) (06/15) Page 4
Figure 32. Suction Pressure and Temperature Measurements (SC System shown).........................45
Figure 33. Many Bubbles-Inline Sight Glass.....................................................................................46
Figure 34. Clear-Inline Sight Glass....................................................................................................46
Figure 35. Trickle of Bubbles-Inline Sight Glass.................................................................................46
Figure 36. Minimum Suction and Discharge Pressures.....................................................................47
Figure 37. Pressure-Temperature for R-410A....................................................................................48
Figure 38. Cooling Mode Start-Up ....................................................................................................49
Figure 39. Compressor Unit Voltage Information..............................................................................51
Figure 40. Compressor Motor Circuit Testing....................................................................................52
Figure 41. Compressor Motor Grounded Winding Test.....................................................................53
Figure 42. System Troubleshooting Chart.........................................................................................54

SD-410-QS (H) (06/15) Page 5
Model Nomenclature
Disclaimer
Proper installation and servicing of the EarthLinked®Heat Pump is essential to its reliable
performance. All EarthLinked®systems must be installed and serviced by a technician authorized by
Earthlinked Technologies. Installation and service must be made in accordance with the instructions
set forth in this manual. Failure to provide installation and service by an ETI authorized installer in a
manner consistent with this manual will void and nullify the limited warranty coverage for the system.
EarthlinkedTechnologies shall not be liable for any defect, unsatisfactory performance, damage or
loss, whether direct or consequential, relative to the design, manufacture, construction, application or
installation of the field specified components.
Earthlinked Technologies, Inc.
4151 South Pipkin Road
Lakeland, Florida 33811
tel. [phone] ● fax [phone]
[e-mail] ● www.earthlinked.com
CSI # 23 80 00

SD-410-QS (H) (06/15) Page 6
Safety
Warning, Caution and Important notices appear throughout the manual. Read these items carefully
before attempting installation, servicing or troubleshooting the equipment.
Equipment Manuals
The following is a listing of the equipment installation manuals that are provided with each component
specified for this EarthLinked®system.
Series SV Service Valve and ADK Adapter Kit
Series AVS Air Handler
Series CCS Cased Coil
SD Series Heating Option Kit, SDHO-1872
Series HWM Hydronic Water Module
Series PW1 Pump Wire Kit
Series HCM Hybrid Cooling Module
Series GSTE Storage Water Heater
Series GST Storage Water Tank
Model HHK/CWK-1872 Temperature Control Kit
Earth Loop Specification and Installation Manual
SureStart Manual
Earth Loop Protection Kit Installation Manual
IMPORTANT!
Notification of installation, operation or maintenance information which
is important, but which is not hazardous.
WARNING!
Indicates a hazardous situation, which if not avoided will result in
serious injury or death, or equipment or property damage.
CAUTION!
Indicates a potentially hazardous situation or an unsafe practice, which
if not avoided, may result in injury, or equipment or property damage.
IMPORTANT!
Read and follow all installation instructions in these manuals,
appropriate for the EarthLinked®system being installed, BEFORE
initiating the Start-Up procedure.

SD-410-QS (H) (06/15) Page 7
Installation
Component Matching
Upon receipt of the equipment, carefully check the component model numbers by referencing
Figure 1, to ensure that all components of the system match.
HEAT/COOL Applications
Compress.
Unit1
Air Handler3
Var. Speed
Cased Coil
TXV Kit Model4
Hydronic Water
Module
Hybrid Cooling
Module3
Earth Loop2
-024
AVS-0030-A
CCS-0036-A
TXV-2430CE
HWM-024C
HCM-1836C
-024-C
-030
AVS-0036-A
CCS-0036-A
TXV-2430CE
HWM-030C
-030-C
-036
AVS-0048-A
CCS-0048-A
TXV-3672CE
HWM-036C
-036-C
-042
AVS-0048-A
CCS-0048-A
TXV-3672CE
HWM-042C
HCM-4272C
-042-C
-048
AVS-0060-A
CCS-0060-A
TXV-3672CE
HWM-048C
-048-C
-054
AVS-0060-A
CCS-0060-A
TXV-3672CE
HWM-054C
-060-C
-060
AVS-0060-A
CCS-0060-A
TXV-3672CE
HWM-060C
-060-C
1.Contained in each compressor package:
compressor unit
four L-shaped hold down brackets
service valves-liquid and vapor
adapters for service valves and earth loop line set
product literature
2. All series Earth Loops
3. All air handlers and cased coils are delivered vertical, field convertible to horizontal. Electric heat is
ordered separately and field installed.
4. TXV Kits are ordered separately and field installed.
Figure 1. Matching Component Model Numbers
Guidelines for the general layout of the system components are shown in Figure 2. Before placing the
compressor unit (outside or indoors), review the guidelines in Figure 2.
Warning!
WEAR ADEQUATE PROTECTIVE CLOTHING AND PRACTICE ALL
APPLICABLE SAFETEY PRECAUTIONS WHILE INSTALLING THIS
EQUIPMENT. FAILURE TO DO SO MAY RESULT IN EQUIPMENT
AND/OR PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

SD-410-QS (H) (06/15) Page 8
Figure 2. General Layout of System Components
Compressor Unit Placement
EarthLinked®compressor units may be located inside or outside. If outside, place compressor
unit on a standard HVAC outdoor unit pad. If inside, place it on a level, hard surface. If the
compressor unit is to be fastened down, see Figure 3 for bracket installation.
Avoid placing the compressor unit in or near the living area of the residence.
Attic installations must include a condensate pan with drain, and suspension from rafters with
suspension isolators.
Clearance around the unit for service is illustrated in Figure 4. However, local codes and
applicable regulations take precedence.
SD(H) Compressor Unit must be placed in an environment in which the surrounding air
temperature does not drop below 40°F.
If the compressor unit is located inside, allow 40 cubic feet of unrestricted space per ton of
nominal system capacity, around the compressor unit, consistent with the acceptable refrigerant
concentration limit (RCL) per ASHRAE Standards 15-2010 and 34-2010.

SD-410-QS (H) (06/15) Page 9
Figure 3. Compressor Unit Bracket Installation
Figure 4. Compressor Unit Clearance
Placement instructions for other pieces of equipment that make up the EarthLinked®System are
included with those pieces of equipment and are listed in this manual under Equipment Manuals.
Refrigeration
After the EarthLinked®compressor unit and other system components are placed, the refrigeration
system tubing is run from the compressor unit to the other components, as appropriate. Figure 5
illustrates the refrigeration and electrical connection points for the SD(H) compressor unit.
IMPORTANT!
EarthLinked®compressor units that provide space cooling shall be
equipped with an EarthLinked® Hybrid Cooling Module (HCM) when:
(1) Required by the performance tables OR where BOTH of the
following circumstances occur:
(2) Ambient outdoor temperatures have exceeded the outdoor summer
design temperature conditions for a continuous system run time of
at least 7 hours, coupled with the conditions described in (3).
(3) Low thermal conductivity soils that do not effectively absorb and
dissipate heat. Examples of such soils are light dry soil or dry
sand, peat and organic soils dry clay soils and hardpan.
ALSO
EarthLinked®compressor units that provide space heating shall be
equipped with a Heating Performance Enhancement (HPE) when
required by the performance tables.

SD-410-QS (H) (06/15) Page 10
PORT
FUNCTION
TYPE OF
CONNECTION
COMPRESSOR UNIT MODEL
CONNECTION SIZE, INCHES
-024
-030
-036
-042
-048
-054
-060
A1
Electrical, Power
1-1/4” Hole
1
1
1
1
1
1
1
B1,2
Electrical, Control
7/8” Hole
3/4
3/4
3/4
3/4
3/4
3/4
3/4
1
AH/CC Liquid
Braze
1/2
1/2
1/2
1/2
1/2
1/2
1/2
2
HWM Vapor
Braze
3/4
3/4
3/4
7/8
7/8
7/8
7/8
3
EL Liquid*
Braze
3/8
3/8
1/2
1/2
1/2
1/2
1/2
4
Anode Socket
--
---
---
---
---
---
---
---
5
EL Vapor*
Braze
5/8
3/4
3/4
3/4
7/8
7/8
7/8
6
AH/CC Vapor
Braze
3/4
3/4
3/4
7/8
7/8
7/8
7/8
7
Plugged
Braze
----
----
----
----
----
----
----
8
HWM Liquid
Braze
1/2
1/2
1/2
1/2
1/2
1/2
1/2
9
DWT Supply
Solder
1/2
1/2
1/2
1/2
1/2
1/2
1/2
10
DWT Return
Solder
1/2
1/2
1/2
1/2
1/2
1/2
1/2
N = Nameplate and other information
1: Nominal electrical connector sizes
2: Two additional electrical control ports on opposite side. Same size
*Line set sizes with provided compressor unit adapters
LEGEND
AH –Air Handler
CC –Cased Coil
EL –Earth Loop
HWM –Hydronic Water Module
DWM –Domestic Water Module
HWT –Hydronic Water Tank
DWT –Domestic Water Tank
DSH - Desuperheater
Figure 5. SD(H) Connections

SD-410-QS (H) (06/15) Page 11
Compressor units are shipped from the factory with a low pressure nitrogen holding charge. Carefully
relieve the holding charge when the compressor unit is being prepared to connect refrigerant system
piping.
Caution!
This compressor unit is equipped with POE lubricant. POE lubricant
absorbs significant amounts of moisture from the air very rapidly.
Exposure of the POE lubricant to air must be minimized. Even a few
minutes of exposure to air can be harmful to the system.
After the initial nitrogen holding charge has been released from the
compressor unit, it is critical that air not be allowed to enter the
compressor unit during the process of preparing compressor unit
refrigerant connections (tube cutting, deburring, cleaning, brazing, etc).
To ensure air does not enter the compressor unit while preparing
refrigerant connections, “trickle” dry nitrogen through the compressor
unit, entering at the access port nearest the Active Charge Control
(ACC), to keep airborne moisture out of the compressor unit and the
POE lubricant.
Complete preparing and brazing all compressor unit refrigerant
connections at one setting to minimize exposure of open connections
to air. Failure to implement the above precautions will result in an
extended period of time to effectively evacuate the system, and may
adversely affect system performance and cause system failure.
Caution!
REFRIGERANT PIPING CONNECTIONS
Refrigerant joints are to be brazed with 15% silver content brazing
alloy, utilizing the NITROGEN BRAZING PROCESS.
NITROGEN BRAZING PROCESS
PURPOSE:
Utilize the NITROGEN BRAZING PROCESS on all brazed refrigerant
piping connections. This process eliminates oxidation products from
inside joint surfaces.
TECHNIQUE:
“Trickle” nitrogen gas at 1-2 psi pressure through the joint area being
brazed, to displace the oxygen. When oxygen has been displaced,
turn off the nitrogen, and relieve the pressure at the joint to
atmospheric prior to brazing.
CONSEQUENCES:
Failure to displace oxygen with nitrogen at the brazed joint will result
in particulate matter being released into the system. The result is
discoloration of refrigerant oil, contamination of the system and
possible system failure.

SD-410-QS (H) (06/15) Page 12
The compressor unit package contains a service valve kit and an adapter kit. The two service
valves are to be installed on the earth loop vapor and liquid connections of the compressor
unit, using the adapters to right-size to the proper earth loop line set.
Installation of the service valves will provide isolation of the earth loop system from the compressor
unit and provide easy access to the refrigerant system.
For the installation of system components requiring refrigeration connections, refer to Figure 6 for line
set sizes and the appropriate installation manual(s) following Figure 6.
LINE SET ADAPTERS REQUIRED FOR THE AIR HANDLER, CASED COIL, HYDROINIC
WATER MODULE AND DOMESTIC WATER MODULE ARE FIELD SUPPLIED. CHECK ALL
APPROPRIATE COMPRESSOR UNIT STUB-OUT TUBING SIZES FOR REQUIRED FIELD
SUPPLIED ADAPTERS!
EARTHLOOP, AIR HANDLER, CASED COIL LINE SETS
HWM LINE SETS
COMPRESSOR
UNIT SIZE
LINE SET O.D., INCHES
HWM
MODEL
LINE SET O.D., INCHES
LIQUID*
VAPOR*
LIQUID*
VAPOR*
2.0 Tons (-024)
3/8
5/8
-024C
3/8
1/2
2.5 Tons (-030)
3/8
3/4
-030C
3/8
1/2
3.0 Tons (-036)
1/2
3/4
-036C
3/8
1/2
3.5 Tons (-042)
1/2
3/4
-042C
1/2
5/8
4.0 Tons (-048)
1/2
7/8
-048C
1/2
5/8
4.5 Tons (-054)
1/2
7/8
-054C
1/2
3/4
5.0 Tons (-060)
1/2
7/8
-060C
1/2
3/4
*Liquid and Vapor lines must BOTH be insulated with Armaflex® or equivalent with at least 1/2” wall thickness for the full
length of the line set.
Figure 6. Line Set Sizes
Series SV Service Valve and ADK Adapter Kit
Series AVS Air Handler
Series CCS Cased Coil
SD Series Heating Option Kit, SDHO-1872
Series HWM Hydronic Water Module
Series HCM Hybrid Cooling Module
DIRECT AXXESS®Earth Loop Specification and Installation Manual
After installing and nitrogen brazing the HVAC system components and compressor unit service
valves, turn the Service Valves to Full Open and pressurize the refrigeration system to 150 psig with
dry nitrogen and a trace of refrigerant. Valve off the nitrogen Tank from the HVAC system
components and check joints with a sensitive Electronic Leak Detector to ensure they are sealed.
Repair any leaks and re-test as appropriate.

SD-410-QS (H) (06/15) Page 13
System Applications and Electrical
The SD(H) compressor unit electrical box major components and electric data for all compressor
sizes are shown in Figure 7.
The SureStart Module is a factory installed component that (1) reduces compressor starting current
and (2) reduces compressor starting torque, thus reducing stress on the compressor at start-up.
The Earth Loop Protection Control System, comprised of the EPS Power Supply, EPS Module and
EPS Fuse is in the contained within the electric box. This system is factory wired and ready to be
connected to the anode wire through an external electrical connection on the backside of the
compressor cabinet. The anode wire connection is detailed in a later section of this manual.
SD(H) Heating and Cooling System electrical and application illustrations are as follows.
Figure 8a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-1-60
Figure 8b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-1-60
Figure 9a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-3-60
Figure 9b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-3-60
Figure 10a. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating System Application
Figure 10b. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating System Field
Wiring (Part 1 of 2)
Figure 10b. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating System Field
Wiring (Part 2 of 2)

SD-410-QS (H) (06/15) Page 14
Compressor
Unit Model
Compressor
Model
Voltage/Phase/
Hz
Voltage
LRA
RLA
MCA
MFS
Min.
Max.
-024-1C
ZP25K6E-PFV
230-1-60
207
253
72.5
15.0
18.0
30
-024-2C
ZP25K63-TF5
230-3-60
207
253
61.4
9.8
12.0
20
-030-1C
ZP31K5E-PFV
230-1-60
207
253
78.0
18.6
23.0
35
-030-2C
ZP31K5E-TF5
230-3-60
207
253
73.0
11.6
14.0
20
-036-1C
ZP38K5E-PFV
230-1-60
207
253
109.0
22.1
27.0
40
-036-2C
ZP38K5E-TP5
230-3-60
207
253
83.1
15.1
19.0
30
-042-1C
ZP44K5E-PFV
230-1-60
207
253
135.0
23.9
29.0
50
-042-2C
ZP44K5E-TF5
230-3-60
207
253
98.0
16.1
20.0
30
-048-1C
ZP51K5E-PFV
230-1-60
207
253
134.0
29.4
36.0
60
-048-2C
ZP51K5E-TF5
230-3-60
207
253
110.0
17.8
22.0
35
-054-1C
ZP57K5E-PFV
230-1-60
207
253
178.0
31.6
39.0
60
-054-2C
ZP57K5E-TF5
230-3-60
207
253
136.0
21.4
26.0
40
-060-1C
ZP61K5E-PFV
230-1-60
207
253
178.0
34.3
42.0
60
-060-2C
ZP61K5E-TF5
230-3-60
207
253
136.0
21.9
27.0
40
LRA = Locked Rotor Amps
RLA = Rated Load Amps
MCA = Minimum Circuit Ampacity
MFS = Maximum Fuse or HACR Circuit Breaker Size
(External)
AWS = Consult NEC and Local Codes
Figure 7. SD(H) Electric Box Components & Electrical Data

SD-410-QS (H) (06/15) Page 15
Figure 8a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-1-60

SD-410-QS (H) (06/15) Page 16
Figure 8b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-1-60

SD-410-QS (H) (06/15) Page 17
Figure 9a. SD(H) Compressor Unit Electrical Ladder Diagram, 230-3-60

SD-410-QS (H) (06/15) Page 18
Figure 9b. SD(H) Compressor Unit Electrical Schematic Diagram, 230-3-60

SD-410-QS (H) (06/15) Page 19
Figure 10a. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating Application

SD-410-QS (H) (06/15) Page 20
Figure 10b. SD(H) Air Heating/Cooling, Hydronic Heating and Water Heating
Field Wiring Diagram
