Eastman Nevercold 70601 User manual

FROM

USER MANUAL

INSTALLS

UNDE

-SINK-

HOW IT WORKS

TUB

CIRCULATOR WITH BUILT IN THERMOSTAT

AND TIMER (INSTALLED FURTHEST

POINT FROM HEAT SOURCE)

SHOWER

SINK

Get hot water comfort at every faucet

• Save time, no more waiting for hot water

• Save hot water, up to 12,000 gallons a year

• Save energy, save on utility and sewer fees

GO GREEN, help conserve this precious resource

for more information visit nevercoldwater.com

APPLICATION

The NEVERCOLD™ circulators are designed to deliver hot water instantly at the point

of use (under sink). Water savings can be as great as 12,000 – 15,000 gallons per

year with 4-5 taps in a home. NEVERCOLD™ circulator is designed to be user friendly,

reliable and to produce a professional installation.

WARNING: Risk of electric shock. The NEVERCOLD™ kits are supplied with a

grounding conductor and grounding type attachment plug. To reduce the risk of

electric shock, be certain that it is connected only to a properly grounding type

receptacle.

WARNING: When installing NEVERCOLD™ observe all applicable electrical and

plumbing codes.

WARNING: To avoid electrical shock, disconnect power prior to connecting or

disconnecting NEVERCOLD™.

WARNING: Risk of electric shock. NEVERCOLD™ has not been investigated for use in

swimming pool or marine areas.

WARNING: NEVERCOLD™ is acceptable for indoor use only. Employer uniquement a

l’interieur.

CAUTION: NEVERCOLD™ has been evaluated for use with water only. The suitability

of NEVERCOLD™ for use with liquids other than water is the responsibility of the end

user.

For optimum reliability and performance please follow the installation instructions

outlined in this manual.

NOTE: Please note that this is not an anti-scald unit. There may be some warm water

in the cold water line under the sink where the circulator is installed. Once the cold

water line is opened, the warm water will disappear in a short time. (Longer hot water

lines may result in longer time for hot water to reach the sink.)

70601

REQUIRED TOOLS

(2) - Pipe wrenches which open to at least 1-1/2"

(1) - Adjustable wrench which opens to at least 1"

Undersink Installation Instructions

Hot Water

Supply

Cold Water

Supply

Tee

Hot

Union

Tailpiece

Gasket

Union

Tailpiece

Gasket

Red Marking

Warning: Red mark on tting must be attached to

the side of the pump with the red mark!

Cold

Pump

Tee

(Figure 1)

INSTRUCTIONS for NEVERCOLD™Undersink Mount (see Fig. 1)

1. Locate the hot and cold shut off valves typically located near

the faucet(s) under the counter. This faucet should be the furthest point fromThis faucet should be the furthest point from

the heat source.the heat source.

2. Close both shut off valves (Fig. 1) and disconnect the flexible hoses attached to

each valve by turning the nut at the end of the hoses counter clockwise. (Fig 2)

3. Install one Tee at each valve. Connect female port of the Tee to the port

on the valves from which you have just disconnected the hoses. (Fig. 3)

4. Connect the hoses which you had disconnected from the valves to the top

port of the Tee.

Installation Tip:

MAKE SURE YOU CONNECT THE HOSES TO THE SAME VALVE TO WHICH THEY

HAD ORIGINALLY BEEN CONNECTED.

(Fig. 1) (Fig. 2) (Fig. 3)

5. Attach the unions (gaskets, nuts and tail pieces) to the pump casing. The

gaskets must be located between pump casing and tail piece. MAKE SUREMAKE SURE

THE TAIL PIECE MARKED RED IS MATCHED UP WITH THE RED MARKING ONTHE TAIL PIECE MARKED RED IS MATCHED UP WITH THE RED MARKING ON

THE INLET SIDE (THAT IS OPPOSITE DIRECTION OF ARROW) OF THE PUMP.THE INLET SIDE (THAT IS OPPOSITE DIRECTION OF ARROW) OF THE PUMP.

You will need two pipe wrenches that open to at least 1-1/2" inches.

Firmly tighten the two union nuts to avoid leaks. Do not install the pump

upside down. (Fig. 4)

6. Place the pump into its intended location with the bracket on the floor

and fasten with screws if necessary. It is also possible to install the pump

horizontally but make sure that the wall to which it is fastened is sturdy

enough to support the pump. NOTE: BE SURE THE ARROWS ON THE PUMP

POINT TO THE COLD WATER SIDE. (Fig. 5)

4(Fig. 4) (Fig. 5) (Fig. 6)

7. Install the flex hoses by attaching one end to the remaining port of the

Tee and the other end to the pump. MAKE SURE THE HOSE ATTACHED TOMAKE SURE THE HOSE ATTACHED TO

THE HOT VALVE IS CONNECTED TO THE INLET SIDE (THAT IS THE OPPOSITETHE HOT VALVE IS CONNECTED TO THE INLET SIDE (THAT IS THE OPPOSITE

DIRECTION OF THE ARROW) OF THE PUMP. MAKE SURE THE HOSEDIRECTION OF THE ARROW) OF THE PUMP. MAKE SURE THE HOSE

ATTACHED TO THE COLD VALVE IS CONNECTED TO THE DISCHARGE SIDEATTACHED TO THE COLD VALVE IS CONNECTED TO THE DISCHARGE SIDE

(THAT IS THE SIDE THE ARROW IS POINTING TO) OF THE PUMP. (Fig. 6)(THAT IS THE SIDE THE ARROW IS POINTING TO) OF THE PUMP. (Fig. 6)

8. Open the valves. Check for leaks.

9. Plug in the cord to any convenient grounded, 115 volt outlet. Your kit

contains a circulator with a built-in timer. Follow the step by step

directions on the timer instruction sheet to program the timer to meet

your hot water needs. (Fig. 7)

10. The system will settle in 2 to 3 hours. Opening faucets will help release

any trapped air.

(Fig. 7) Complete Installation

MECHANICAL TIMER OPERATION

The timer will turn the circulator on and off based on the times when hot water is

needed. This may only be in the mornings and evenings depending on the

schedules of the residence.

SETTING INSTRUCTIONS

1. To set the current time, rotate the outer ring until the arrow head lines up with the

correct time. This is a 24-hour clock so 1 to 12 on the clock indicates 1AM to noon

and 13 to 24 on the clock indicates 1PM to midnight.

2. To set the time that the pump will operate, move all the tabs outward during the

time period. (Fig. 1)

Example: To set ON at 7:00AM and OFF at 10:00AM move all of the tabs between

7 and 10 to outward position.

3. By following the instructions in step 2 multiple on-off cycles can be set.

4. The override switch has 3 positions. (Fig. 2) The “I” indicates the pump will run

continuously (24 hours a day) The position next to the clock symbol indicates the

pump will follow the settings of the tabs. The “O” indicates the pump is off

(not running).

Fig. 1 Fig. 2

REPLACEMENT CARTRIDGE INSTRUCTIONS

CLEANING CARTRIDGE ASSEMBLYCLEANING CARTRIDGE ASSEMBLY

NEVERCOLD™NEVERCOLD™ pumps are speciﬁcally designed to prevent solid particles from

entering the bearing / rotor chamber of the cartridge. However, in systems heavily

contaminated by dirt, construction debris, etc., particles may enter the chamber on

initial ﬁlling of the system and on rare occasions cause rotor blockage.

The NEVERCOLD™NEVERCOLD™ pump is designed to permit cleaning the interior of the cartridge

and de-blocking. To do so, separate the two parts (refer to #6 under “Replacing

Cartridge Assembly”) by grabbing the impeller and cartridge sleeve with opposite

hands and pulling apart. Clean (rinse) the two parts and re-assemble. Follow the

procedure under “Replacing Cartridge Assembly.” It is also recommended to flush the

system.

REPLACING CARTRIDGE ASSEMBLY (Replacement cartridge sold separately)REPLACING CARTRIDGE ASSEMBLY (Replacement cartridge sold separately)

1. Disconnect power.

2.Reduce system pressure to zero and let fluid cool down.

3. Close shut off valves. If there are no shut off valves, drain system.

4. Remove pump housing bolts and pull out motor assembly.

5. Remove cartridge. Insert screw drivers between motor housing and square plate

and force cartridge out.

6. Insert new cartridge. Cartridge consists of two parts

7. Install new motor assembly using new O-ring gasket. Make sure gasket is

properly placed.

8. Follow installation procedure to start up circulator.

LIMITED WARRANTY

NEVERCOLD™ warrants its products to the original user against defects in material andNEVERCOLD™ warrants its products to the original user against defects in material and

workmanship for a period of one (1) year from the date of consumer purchase. Complete pumpsworkmanship for a period of one (1) year from the date of consumer purchase. Complete pumps

warranty is three (3) years from date of purchase. Valves and timers and accessories carry a onewarranty is three (3) years from date of purchase. Valves and timers and accessories carry a one

(1) year warranty from date of purchase. In the event of such defects within the warranty period,(1) year warranty from date of purchase. In the event of such defects within the warranty period,

NEVERCOLD™ will, at its option, replace or recondition the product without charge, FOBNEVERCOLD™ will, at its option, replace or recondition the product without charge, FOB

NEVERCOLD™ factory. This shall constitute the exclusive remedy for breach of warranty, andNEVERCOLD™ factory. This shall constitute the exclusive remedy for breach of warranty, and

NEVERCOLD™ shall not be responsible for any cost of removal, installation, transportation or anyNEVERCOLD™ shall not be responsible for any cost of removal, installation, transportation or any

charges which may arise in connection with the warranty claims and shall not be responsible forcharges which may arise in connection with the warranty claims and shall not be responsible for

any incidental or consequential damages, including without limitation, damages or other costsany incidental or consequential damages, including without limitation, damages or other costs

resulting from labor charges, delays, or vandalism. Negligence, fouling caused by foreignresulting from labor charges, delays, or vandalism. Negligence, fouling caused by foreign

materials, damage from adverse water conditions, freezing, chemicals, certain additives, or anymaterials, damage from adverse water conditions, freezing, chemicals, certain additives, or any

other circumstances over which NEVERCOLD™ has no control. This warranty shall be invalidatedother circumstances over which NEVERCOLD™ has no control. This warranty shall be invalidated

by any abuse, misuse, misapplication or improper installation or maintenance of the product.by any abuse, misuse, misapplication or improper installation or maintenance of the product.

NEVERCOLD™ makes no other warranties express or implied except as provided in this limitedNEVERCOLD™ makes no other warranties express or implied except as provided in this limited

warranty.warranty.

To obtain service under this warranty, the defective product must be returned to the distributorTo obtain service under this warranty, the defective product must be returned to the distributor

or dealer of NEVERCOLD™ products from which it was purchased together with proof of purchaseor dealer of NEVERCOLD™ products from which it was purchased together with proof of purchase

and installation date, and supporting installation data. Unless otherwise provided, the distributorand installation date, and supporting installation data. Unless otherwise provided, the distributor

or dealer will contact NEVERCOLD™ or an authorized service station for instructions. Any defectiveor dealer will contact NEVERCOLD™ or an authorized service station for instructions. Any defective

product to be returned to NEVERCOLD™ or a service station must be sent freight prepaid;product to be returned to NEVERCOLD™ or a service station must be sent freight prepaid;

documentation supporting the warranty claim and/or a Return Material Authorization must bedocumentation supporting the warranty claim and/or a Return Material Authorization must be

included if so instructed.included if so instructed.

NEVERCOLD™ WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES,NEVERCOLD™ WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES,

LOSSES, OR EXPENSES ARISING FROM INSTALLATION, USE, OR ANY OTHER CAUSES. THERELOSSES, OR EXPENSES ARISING FROM INSTALLATION, USE, OR ANY OTHER CAUSES. THERE

ARE NOT EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESSARE NOT EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE, WHICH EXTEND BEYONG THOSE WARRANTIES DESCRIBED ORFOR A PARTICULAR PURPOSE, WHICH EXTEND BEYONG THOSE WARRANTIES DESCRIBED OR

REFERRED TO ABOVE.REFERRED TO ABOVE.

US DESIGN, US BUILT, PATENTED.

US: PAT. 8,183,500, PAT. 8,303,184, PAT. 9,328,736,

PAT. 9,863,647, PAT. D834,145

CAN: PAT. 2,935,949, PAT. 2,883,495
