EastRising ERC802FS-1 User manual
EASTRISING TECHNOLOGY CO., LTD.
旭 日 东 方 科 技 有 限 公 司
ERC802FS-1
LCD Module User Manual
URL :www.lcd-china.com DocumentName:ERC802FS-1Manual-Rev2.0 page:1of9
REV Descriptions Release Date
1.0 Preliminay Release Nov-24-2008
2.0 Revise LCD type from Grey STN to FSTN Mar-09-2011
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
Table of Content
1. Basic Specifications…………………………………………………………………………………………………………...3
1.1 Display and Mechanical Specifications…………..………………………………………………………………………3
1.2 Block Diagram…………………………...………….……………………………………………………………………3
1.3 Terminal Functions…………………….…………………………………………………………………..……..............4
1.4 Mechanical Drawing ………..………………………………………………..…………………………………..............5
2. Absolute Maximum Ratings…………………………………………………………………………………………………6
3. Electrical Characteristics..…………………………………………………………………………………….…….............7
4. IC Contents Attachment………………………………………………………………………………. ……………............7
5. LCM Numbering System..…………….…………………………………………….……………………………………….8
6. Design and Handling Precaution……………………………………………..……………………….…………………….9
URL :www.lcd-china.com DocumentName:ERC802FS-1Manual-Rev2.0 page:2of9
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
1.0 Basic Specification
1.1 Display and Mechanical Specification
ITEM STANDARD VALUE UNIT
Display Type 8 Characters X 2 Lines --
LCD Type FSTN / Transflective / Positive --
LCD Duty 1/16 --
LCD Bias 1/4 Bias
Viewing Direction 6:00 Clock
Backlight Type Edge LED Backlight with white color --
Interface I2C Interface --
Driver IC ST7032 (Gold Bump Chip) --
IC Package COG --
Module Dimension 36.0(W) × 23.5(H) × 4.2(T) (MAX) mm
VisualArea 32.0(W) × 14.5(H) mm
Dot size 0.545 ×0.645 mm
Dot Pitch 0.60 ×0.70 mm
Operating Temperatue -10 ~ 60 ℃
Storage Temperature -20 ~ 70 ℃
1.2 Block Diagram
URL :www.lcd-china.com DocumentName:ERC802FS-1Manual-Rev2.0 page:3of9
LED Backlight Circuit
LCD Panel
8 Characters X 2 Lines
ST7032
VDD
VSS
VEE
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
1.3 Terminal Functions
URL :www.lcd-china.com DocumentName:ERC802FS-1Manual-Rev2.0 page:4of9
Pin
No. Pin
Name I/O Descriptions
1 POR I Reset signal Low active
2 SCL I Serial colock
3 SDA I/O Serial data
4 VSS Power
Signal ground for LCM (0V)
5 VDD Power
Power supply for logic for LCM (3.0V)
6 CAPP Power
7 CAPN Power
For voltage booster circuit(VDD-VSS)
External capacitor about 0.1u~4.7uf
8 VLCD Connect a capacitor between this terminal and vdd
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
1.4 Mechanical Drawing
URL :www.lcd-china.com DocumentName:ERC802FS-1 Manual-Rev2.0 page:5of9
旭日东方科技有限公司
LCM NO.:
DRAWN BY :
3.VIEWING DIRECTION: 6 O'CLOCK
1.DISPLAY TYPE: FSTN
2.LCD POLARIZER TYPE: TRANSFLECTIVE/POSITIVE
4.OPERATING VOLTAGE: VDD:3.0V ; VLCD:4.8V
6.OPERATING TEMP: -10 ~ +60°C
8.LCD CONNECTOR: COG+FPC+BL
9.BACKLIGHT:
STORAGE TEMP: -20 ~ +70°C
5.DRIVE METHOD: 1/16 DUTY,1/4 BIAS
NOTE:
Customer NO.:
Customer: Customer Approve By:
APPROVED BY :
TEL: +86-755-22219423, FAX: +86-755-22651263
CHECKED BY :
CD
1 OF 1
SHEET:
UNIT: MM
REV:A0
SIZE: A4
A0
REV. DESCRIPTION OF MODIFY
1'ST,DESIGN MODIFY BY
WSL Mar-08-2011
DATE
7.DISPLAY DRIVER: ST7032
10.Unspecified tolerance is ±0.20mm
PIN
NAME
1 2 543 76
RST SCLSDA VSSVDDCAPP
0.545
0.60
2.945
3.545
0.645
0.70
5.545
5.945
SCALE:4/1
LCD:8X2 Characters
ST7032i
S1 S80
C1
C8 C16 C9
18
A
K
White Color LED Backlight
A1
A2
ERC802FS-1
EastRising Technology Co.,Ltd.
Javen
CAPNVLCD
A,A 27.76
V,A 32.00 MIN
LCD&LED 36.00
20.00 2-8.00
A,A 11.49
V,A 14.50 MIN
LCD 17.50
LCD&LED 23.50
FPC 30.00±2.0
4.00
6.00
P1.0*(8-1)=7.00
9.00
W 0.50
0.30±0.05
0.10
1.70
4.10 MAX
2-0.50
8.00 MAX
4.75
FRONT
BACK
Tony Liu
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
2. Absolute Maximum Ratings
Items Symbol Min Max. Unit Condition
Supply Voltage (Logic) VDD-Vss -0.3 +6.0 V Vss=0V
Supply Voltage (LCD Driver) VSS-VEE -0.3+Vss 7.0-Vss V Vss=0V
Input Voltage VIN -0.3 VDD+0.3 V Vss=0V
Operating Temperature TOP -10 +60
℃No Condensation
Storage Temperature TST -20 +70
℃No Condensation
Cautions:
Any stresses exceeding the Absolute Maximum Ratings may cause substantial damage to the device Functional operation of
this device at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme
conditions may affect device reliability
3. Electrical Characteristics
3.1 DC Characteristics
Items Symbol Min Typ. Max. Unit Condition
Supply Voltage (Logic) VDD-Vss 2.7 3.0 3.3 V
Supply Voltage (LCD Driver) VSS-VEE
--
VDD
--
V 25℃
VIH 0.7VDD -- VDD V --
Input Voltage VIL -- -- 1.0 --
VOH 0.8VDD -- VDD V Ioh=-0.04mAOutput Voltage VOL -- -- 0.2VDD V Ioh=0.04mA
Logic Supply Current IDD -- 1 1mA VDD-Vss=3.0V
3.2 LED Backlight Circuit Characteristics
Items Symbol MIN TYP. MAX. Unit Application pin
Forward Voltage VfLED+ 2.9 3.1 3.3 V LED+
Forward Current IfLED+ - 15 20 mA LED+
Cautions:
Exceeding the recommended driving current could cause substantial damage to the backlight and shorten its lifetime.
No. of = 1 x 1 =1 (LAMP)
URL :www.lcd-china.com DocumentName:ERC802FS-1 Manual-Rev2.0 page:6of9
LED +
LED -
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
4. IC ContentsAttachment:
Reference Documents From Sitronix ST7032 LCD Driver with
Contents
ST7032 (Version 1.2 ) Page
1. GENERAL DESCRIPTION…………………………………………….P1
2. BLOCK DIAGRAM …………………………………………………..…P6
3. DESCRIPTiON OF FUNCTIONS………………………………………P10- P18
4. TIMING CHARACTERISTICS…………………………………………P39,47,48
5. COMMAND DESCRIPTION………………………………………….....P20- P28
URL :www.lcd-china.com DocumentName:ERC802FS-1 Manual-Rev2.0 page:7of9
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
5. LCM Numbering System
ER C 802 F S -1
Version Number
Edge LED Backlight with White color
FSTN-LCD
8CharactersX2Lines
COGLCDModule
EastRisingTechnology
URL :www.lcd-china.com DocumentName:ERC802FS-1 Manual-Rev2.0 page:8of9
w
w
w
.
l
c
d
-
c
h
i
n
a
.
c
o
m
EastRising
LCD Module User Manual ERC802FS-1
6. Design and Handling Precaution
1.0 The LCD panel is made by glass.Any mechanical shock (eg. dropping form high place) will damage
the LCD module.
2.0 Do not add excessive force on the surface of the display, which may cause the Display color change
abnormally.
3.0 The polarizer on the LCD is easily get scratched. If possible, do not remove the LCD protective film
until the last step of installation.
4.0 Never attempt to disassemble or rework the LCD module.
5.0 Only Clean the LCD with Isopropyl Alcohol or Ethyl Alcohol. Other solvents (eg. water) may damage
the LCD.
6.0 When mounting the LCD module, make sure that it is free form twisting, warping and distortion.
7.0 Ensure to provide enough space (with cushion) between case and LCD panel to prevent external
force adding on it, or it may cause damage to the LCD or degrade the display result.
8.0 Only hold the LCD module by its side. Never hold LCD module by adds force on the heat seal or
TAB.
9.0 Never add force to component of the LCD module. It may cause invisible damage or degrade of the
reliability.
10.0 LCD module could be easily damaged by static electricity. Be careful to maintain an optimum
anti-static work environment to protect the LCD module.
11.0 When peeling off the protective film from LCD, static charge may cause abnormal display pattern.
It is normal and will resume to normal in a short while.
12.0 Take care and prevent get hurt by the LCD panel sharp edge.
13.0 Never operate the LCD module exceed the absolute maximum ratings.
14.0 Keep the signal line as short as possible to prevent noisy signal applying to LCD module.
15.0 Never apply signal to the LCD module without power supply.
16.0 IC chip (eg. TAB or COG) is sensitive to the light. Strong lighting environment could Possibly cause
malfunction. Light sealing structure casing is recommend.
17.0 LCD module reliability may be reduced by temperature shock.
18.0 When storing the LCD module, avoid exposure to the direct sunlight, high humidity, high
temperature or low temperature. They may damage or degrade the LCD module
URL :www.lcd-china.com DocumentName:ERC802FS-1 Manual-Rev2.0 page:9of9
