EasyAS 0022390 User manual

Frame
Screw
70mm
Hinge
Locking Screw
11mm
Check out the install video at easyas-shutters.com
I
N
T
E
R
N
A
T
I
O
N
A
L
P
R
O
T
E
C
T
E
D
PATENT
INSTALL
GUIDE
Hinge
Pin
80mm
PACK CONTENTSPACK CONTENTS
• Adjustable outer frame
• 4 x frame corner covers
• Multi Tool (Allen Key / Phillips Head Screwdriver)
• Screws (Phillips Head ) - see below
• Plantation Shutter Panels with mid-rail(s)
• Hinge Pins
• White Stickers
DOUBLE PANEL WITH MID-RAIL(S)
APPLIES TO MODELSAPPLIES TO MODELS
II/N: 0022390
JI/N: 0022392
NI/N: 0022396
OI/N: 0022397
SI/N: 0022401
TI/N: 0022402
+ Custom Configuration: P2-M1, P2-M2

• On a soft surface, lay out the adjustable frame, on the floor, in front of the window with hinges
pointing toward you
• Using the labels on each frame, lay out the adjustable frame in the following sequence, as
shown in figure 1(A):
T – Top, L – Left, B – Bottom, R – Right
• Assemble the adjustable frame corners by sliding the locking key into
position at the back of the frame, as shown in figure 2(A)
• Clip the corner covers onto the adjustable frame, as shown in figure 2(B)
NOTE: Hinge pin ‘holes’ need to be in an upward position.
1(A)
L
T
B
R
BACK VIEW OF FRAME
Locking
Key
Make sure
edges are flush
NOTE: These images are showing the back face of the shutter.
2(A)
BACK VIEW OF FRAME
2(B)
BACK VIEW OF FRAME
STEP 1
STEP 2

• Insert the adjustable frame into the window reveal as shown in figure 3(A).
• Using the Allen key, adjust the frame evenly by turning each adjuster 2 full turns at a time in an
anticlockwise direction to expand frame into the opening. Adjust each side adjuster evenly until a
tight, square fit, is achieved as shown in figure 3(B)
• Using the screws provided, secure the frame in place by inserting one screw into each side of the
frame. Each screw should be inserted through the hole in the centre of each adjuster, as shown in
figure 3(C)
NOTE: At this stage only use 1 screw on each side & insert
through the adjusters closest to the centre of each side.
NOTE: Hinges must be facing toward you when mounting.
3(B)3(A)
3(C)
USE ALLEN KEY
Frame Screw
70mm
NOTE: Take care while placing hinge pins to avoid damage and
scratches.
4(B)4(A)
Hinge Pin
STEP 4
STEP 3
NOTE: The two(2) panels will be numbered
Left & Right (1, 2)
• Insert the LEFT shutter panel first onto the hinges and secure with the hinge pins, as shown in
figure 4 (A)
• Repeat this step for the right shutter panel
• Open and close the shutter panels to check fit as shown in figure 4(B)
• Using the Allen key, make small adjustments to the adjustable frame, to align the doors if required

Check out the install video at easyas-shutters.com
• Using the screws provided, secure the adjustable frame, (Top, Bottom, Left and Right) by fixing the
remaining screws permanently into the window jamb, as shown in figure 5(A)
• Once complete, place white stickers (supplied) over adjusters/screws as shown in figure 5(B)
• Screw in the remaining ‘Hinge locking’ screws in place 5(C)
STEP 5
5(A) 5(B) 5(C)
Hinge locking screwWhite stickersSecure frame with remaining screws
Check out the install video at
easy-as.com.au or easy-as.co.nz
