EasyAS INTERNAL SLIDING SHUTTER User manual

INSTALL
GUIDE
For more information visit
www.easyas-shutters.com
INTERNAL SLIDING SHUTTER
PACK CONTENTS: WHAT YOU WILL NEED:
• Face-fit Framing [ Top, Bottom, Left, Right ]
• Top Channels (Front & Back)
• Screws (Assembly, Fixing, Top Channel)
• Hinge Pins
• White Cover Stickers
• Sliding Shutter Panels
• Drill
• Drill Bit Suitable for Timber
(3mm required)
• Screw Tip Bit
(PH2 x 150mm Phillips Head Bit Required)
Unpack Framing Box
a. Locate Hardware and remove from Pack
b. Group different pack items together
STEP 1
Hinge Pins
Frame Screws
Hardware Pack
Track Screws
White Adhesive Stickers
A

For more information visit
www.easyas-shutters.com
Assemble Outer Frame
a. Layout frames into position using stickers as indicated
b. Screw all corners together with (Size mm??) screws
NOTE: Assemble in room where slider is to be installed
Install Frame
a. Place (pre-drilled beading side) frame in front of opening against
surface to which it be attached to
- Make sure edges are square to wall/architrave
b. Drill pilot holes through beading into architrave
using 3mm drill bit
c. Fasten with (size mm??) screws supplied
d. Place white covers over screw heads
STEP 2
STEP 3
L
T
B
R
a.
a. b.
b.
d.
c.
Architrave side
Pre-Drilled Beading
FRONT / INWARD FACING EDGE
T
TOP
B
BOTTOM
L
LEFT
R
RIGHT

For more information visit
www.easyas-shutters.com
Top U Channel
Top U Channel FRONT
BACK
Fit Top Channels
a. Position channels over pre-drilled holes
NOTE: Channels are labelled for positioning and front edge direction to face
b. Secure top channels into place with small screws supplied
Fit Shutters Rear Panels
Working from the back channel left to right
a. While holding the shutter panel securely, guide top edge of shutter panel into top track, followed by placing
bottom roller wheels onto bottom tracks
b. Repeat for second ‘joining’ panel making sure hinges pair
c. With panel(s) in place, join panels together using hinge pins on outward facing side of panels
STEP 4
STEP 5
a. b. c.
FRONT / INWARD FACING EDGE
Architrave side | Beading Edge
FRONT
BACK
ARCHITRAVE

For more information visit
www.easyas-shutters.com
Fit Shutters Front Panels
Working with the front channel left to right with blades in closed position
a. Repeat steps 5.a, b, c
Make Adjustments & Place White Hole Covers
a. First, with all blades in closed position check for smooth sliding operation of all panels
b. Panel edges should meet square against outer frame.
- If not, make adjustments to wheel heights (back of panel) using phillips head driver until
the shutter panel is square against frame
c. Place white covers over screw holes to finish
STEP 6
STEP 7
b.a.
a.
b.
c.
c.
Counter Clockwise
Clockwise
