EasyCare MANGAR AIRFLO 24 User manual

USER INSTRUCTIONS
MANGAR
AIRFLO 24 COMPRESSOR
USER INSTRUCTIONS
www.easycaresystems.co.uk

QUICK START GUIDE
ENGLISH
2
This Quick Start Guide is not intended to replace the full user instrucons.
Please read the full user instrucons before using the Airo 24.
CAUTION: The Airo 24 must be put on charge for 12 HOURS before rst use.
BEFORE USE
1 x Airo 24 compressor (A) ed with a
24v - 2200mAh Ni-MH baery pack.
1 x Baery charger (with mains adaptors) (B).
1 x User Instrucons.
1 x Mains Power Adaptor (Oponal).
A
B
STANDARD PACKAGE CONTENTS
Fit the appropriate mains adaptor to the
charger (see ‘Baery Charging’ page 8).
Connect the baery charger to a mains
power socket and the Airo 24 charging
socket.
www.easycaresystems.co.uk

QUICK START GUIDE
3
ENGLISH
Press the hand control
buons to raise the
ELK, Eagle or Camel.
4
Connect the 4-Way hand
control inlet hose to the
Airo 24.
2
Connect the 4-Way hand
control outlet hoses to the
corresponding numbered
connectors on the ELK,
Eagle or Camel.
1
Press the ‘POWER’ buon to
turn the Airo 24 ‘ON’.
3
NOTE: Disconnect the baery charger before using the Airo 24.
First 3
Hours
12
Hours
Fully
Charged
GREEN
GREEN
GREEN
GREEN
GREEN
GREEN
GREEN
GREEN
NOTE: In the case of a power cut, switching the power socket o or disconnecng the
charging lead, the charging process will not be interrupted as the unit remembers the
previous charge state.
OPERATING
CHARGE THE BATTERY FOR 12 HOURS BEFORE
USE.
For the rst 3 hours, the boom light will ash green.
Aer 3 hours the rst light will become a steady
green and the second light will start ashing. Aer
6 hours the boom 2 lights will remain green and
the third light will ash. Aer 9 hours the boom 3
will remain green and the top will be ashing. Then
aer 12 hours the charge is complete and the top
light will remain ashing and other 3 will be o.
www.easycaresystems.co.uk

QUICK START GUIDE
ENGLISH
4
The Baery Status Indicator lights serve 2 purposes:
1 - Whilst charging, the lights indicate which part of the charging cycle the baery is at.
2 - When the Baery Status Indicator Buon is pressed (with the Airo 24 removed from
charge), the lights indicate how much charge remains in the baery.
Baery Status
Indicator Buon
UNDERSTANDING THE BATTERY STATUS INDICATOR LIGHTS
TO DETERMINE THE BATTERY CHARGE STATE, YOU MUST DISCONNECT THE
CHARGING LEAD OR REMOVE THE AIRFLO 24 FROM THE STOWAGE BOARD
AND THEN PRESS THE ‘BATTERY STATUS INDICATOR’ BUTTON TO ACTIVATE THE
BATTERY STATUS INDICATOR LIGHTS
4 GREEN
OK to Use
GREEN
GREEN
GREEN
GREEN
3 GREEN
OK to Use
GREEN
GREEN
GREEN
2 GREEN
OK to Use
GREEN
GREEN
1 GREEN
OK to Use
GREEN
RED
DO NOT USE
RECHARGE
RED
www.easycaresystems.co.uk

QUICK START GUIDE
5
ENGLISH
DURING A LIFT
AFTER COMPLETING A LIFT
Disconnect the inatable unit and hand control and pack away. Turn o the compressor and
the boom green light will go out. The product will also auto turn o aer 2.5 minutes of
inacvity.
Press the Baery Status Indicator Buon.
4 GREEN
OK to Use
GREEN
GREEN
GREEN
GREEN
3 GREEN
OK to Use
GREEN
GREEN
GREEN
2 GREEN
OK to Use
GREEN
GREEN
1 GREEN
OK to Use
GREEN
RED
DO NOT USE
RECHARGE
RED
Each me the hand control is operated the unit does a baery test and indicates the
baery state. The hand control buon is then released when a compartment in the liing
device is lled. Product will then automacally turn o aer 2.5 mins of inacvity.
4 GREEN
OK to Use
GREEN
GREEN
GREEN
GREEN
3 GREEN
OK to Use
GREEN
GREEN
GREEN
2 GREEN
OK to connue
the li
GREEN
GREEN
1 GREEN
OK to connue
the li
GREEN
RED
OK to connue
the li - Recharge
when the li is
complete
RED
If you see a single solid red light (if this is within a li - the li can be completed), the Airo
should be put on unbroken charge immediately for a minimum of 3 hours. This will provide
sucient capacity to complete one more li.
Once the red light shows to achieve full capacity a full 12 hour charge is required.
www.easycaresystems.co.uk

ENGLISH
AIRFLO 24
6
Intended Use
The Mangar Airo 24 is a low pressure air
compressor, which has been designed to inate
the Mangar ‘Camel’, 'Eagle' and ‘ELK’ pneumac
liing equipment through a 4-Way pneumac hand
control. The 4-Way hand control is supplied with
the Camel, ELK and Eagle.
Applied Parts (Accessories) for the Airo 24:
Mangar ELK (Emergency liing cushion)
Mangar Camel (Emergency liing cushion)
Mangar Eagle (Emergency Liing Cushion)
Contents
Intended Use Pg 6
Warnings Pg 6
Baery Status Indicator Pg 7
Baery Charging Pg 8
Mains Power Adaptor (oponal) Pg 9
Operaon Pg 9
Cleaning & Storage Pg 10
Maintenance Pg 10
Trouble shoong guide Pg 11
Specicaons Pg 11
Symbols used on Airo 24 and Charger Pg 12
Symbols used on packaging Pg 13
Warranty Pg 13
Declaraon of Conformity Pg 50
•Be sure that you have read and understood these
instrucons and those provided with any other
Winncare product, before operang the equipment.
•To avoid the risk of electric shock, NEVER recharge
the baery in the bathroom, outdoors or in a damp
environment.
•To avoid the risk of electric shock, do not use the
oponal mains power adaptor in the bathroom,
outdoors or in a damp environment.
•Always disconnect from the baery charger before
cleaning.
•Use only the supplied baery charger.
•Do not operate the Airo 24 compressor in the
presence of ammable anaesthec mixtures with air,
oxygen or nitrous oxide, as these mixtures can create
a combusble environment leading to the potenal
for re or even an explosion in the presence of a
spark.
•Ensure that when in use, the Airo 24 and its
connected hoses are laid out in such a way as to
avoid any risk of tripping or strangulaon.
•Ensure that children and pets do not interfere with
the safe operaon of the Airo 24 and inatable
product.
•Keep the Airo 24 and inatable product away from
sources of heat.
•Disconnect the Airo 24 compressor from the
inatable product before transporng so as to avoid
accidental inaon.
•The Airo 24 should only be used for its stated
purpose and should not be modied in any way.
•The oponal mains power adaptor (The Mean
Well Enterprises AC/DC Switching Adaptor Model
GSM220A20-R7B) is specic to the Airo 24 and is
the only approved unit to be used for this purpose.
•Do not operate the compressor outside of the
specied duty cycle of 20% ‘Operang Time’ and
80% ‘Non-Operang Time’. Maximum connuous
operang me = 3 minutes.
•WARNING: This product and associated
packaging does not contain any materials known
to cause an allergic reacon. Please refer to the
seperate inatable equipment instrucons for
further details.
The ELK requires assistance to help li a paent
from the oor to an elevated sing posion. Once
in a sing posion, the paent can be transferred
to a chair or helped to a standing posion.
The Camel and Eagle can be operated with or
without assistance and when inated, lis the
paent into a raised seated posion ready to stand.
No special skills or training are required to operate
the Airo 24 and its accessories.
Further guidance on operaon can be found in the
individual accessory User Instrucons.
The Airo compressor and applied parts are
intended for connual re-use as required and no
special acons or operaons are needed to achieve
this.
WARNINGS
www.easycaresystems.co.uk

AIRFLO 24
7
ENGLISH
Baery State Indicator
Power Buon
RED
Recharge
Immediately
2 GREEN
OK to Use
3 GREEN
OK to Use
4 GREEN
OK to Use
1 GREEN
OK to Use
When the ‘Power’ buon is pressed, the compressor will momentarily run and
then stop. The boom light on the indicator will show GREEN.
WARNING: The baery must be put on charge immediately as soon as the red indicator light
appears. Running the Airo24 on RED unl the baery is exhausted will damage the baery.
When the compressor is running, the baery status indicator lights will only indicate the state of
baery charge as it was at the start of the li. When the compressor stops running, the baery
status indicator will show a boom green light (this will be red if the baery charge has become
low).
IMPORTANT: To maximize the life and liing performance of the baery, fully recharge the
baery aer use.
Fully charge the baery for a minimum of 12 hours before using the Airo 24 for the rst me.
When the Baery State Indicator buon is pressed, the lights indicate how much
charge remains in the baery.
www.easycaresystems.co.uk

ENGLISH
AIRFLO 24
8
1
B
A
First 3
Hours
12
Hours
Baery Charging - g. 1
•Check the baery charger casing and lead
for signs of damage and if damaged DO NOT
USE.
•Fit the appropriate mains plug adaptor to
the baery charger (A).
•Plug the baery charger into a mains power
socket and connect the charger output lead
to the Airo 24 charging socket (B).
NOTE: On rst charge or when ng a new
baery it should be charged for a minimum of
12 hours. On subsequent charges
the Airo calculates the charging period
based on usage and will not necessarily start
on the boom light ashing.
•For the rst 3 hours, the boom light will
ash green. Aer 3 hours the rst light will
become a steady green and the second light
will start ashing. Aer 6 hours the boom
2 lights will remain green and the third light
will ash. Aer 9 hours the boom 3 will
remain green and the top will be ashing.
Then aer 12 hours all lights will briey
become steady green.
•The compressor will move into an energy
saving mode with the top LED ashing
every 6 seconds and the other 3 will be o.
NOTE: The compressor will not run whilst the charger is connected.
To maintain baery condion, it is recommended that the Airo 24 is le connuously on charge
when not in use. The baeries cannot be overcharged using this charger.
WARNING: DO NOT recharge the baeries in a bathroom or in a damp environment.
When the baery is charged:
www.easycaresystems.co.uk

AIRFLO 24
9
ENGLISH
AB
A
3
Operaon - g. 3
Disconnect the Airo 24 from the baery
charger and place it in a safe and convenient
posion. NOTE: The Airo compressor should
not be placed in a posion where it is dicult
to operate the ‘Power’ buon in an emergency.
•Connect the four hoses (A) from the
4-Way Hand Control to the corresponding
numbered and coloured connectors on the
Mangar Camel, Eagle or ELK.
•Connect the hose (B) from the hand control
to the Airo 24 air outlet socket (C). The
connector will ‘click’ into place when rmly
pushed onto the socket.
•To switch on, press the ‘Power’ buon (D).
The compressor will run when a buon on
the hand control is pressed and stop when
the buon is released. An internal pressure
switch will stop the compressor running
when each corresponding secon of the
inatable product has reached full pressure.
C
D
Mains Power Adaptor (oponal)
An oponal mains power adaptor is available
to power the Airo 24 directly from a mains
power socket. The adaptor is specic to the
Airo 24 and is the only approved unit to be
used for this purpose. Connect the adaptor
between a mains power socket and the
adaptor inlet socket on the end of the Airo 24
(Fig. 2).
NOTE: This adaptor, has a non-standard
output connector and powers the Airo 24
directly, it will not charge the baery. The only
way to charge the baery is to use the charger
which was supplied with the Airo 24. With
the power adaptor connected, the Airo 24
behaves in the same way as if it was running
on the baery, the only funconal dierence
is that the baery indicator will show boom
LED orange whilst the Airo is running. With
the adaptor connected, the Airo 24 will also
run if there is no baery ed.
2
•Pressing any of the numbered hand control buons will deliver air to the corresponding
numbered hose (follow the User Instrucons for the Winncare product that is to be inated).
•To switch the Airo 24 o aer use, press the ‘Power’ buon. The boom indicator light will go
out. The pump will also automacally turn o aer 2.5 minutes of inacvity.
www.easycaresystems.co.uk

ENGLISH
AIRFLO 24
10
Maintenance - g. 4
The Airo 24 has been designed to be maintenance free and
apart from replacing the baery, the Airo contains no other user
serviceable parts.
Baery replacement:
Disposal
When the Airo 24 has reached the end of it’s working life, remove the baery for safe disposal in
accordance with local regulaons, and dispose of the Airo 24 at your local household waste recycling
centre (civic amenity site).
Cleaning
Unless contaminaon is suspected, periodic cleaning is all that is recommended. The Airo 24 should be
cleaned/disinfected as follows:
•Unplug the Airo 24 from the baery charger. Clean the external surfaces using a non abrasive damp
cloth with warm water. Wipe dry thoroughly with a dry towel before reconnecng to the baery
charger. Do not allow moisture to enter any part of the compressor.
•Do not use solvent-based products.
Disinfecng/Sterilising
•Disinfecon – Pre-clean the Airo compressor by wiping with a damp cloth and then disinfect by
wiping with a 1:10 soluon of household liquid bleach and water - 1 part bleach to 10 parts cold
water (10,000ppm (1%) Sodium Hypochlorite soluon). Do not allow moisture to enter any part of
the compressor. Allow to air dry. In usual circumstances this product does not require sterilisaon for
reuse.
Storage
•When not in use, store in a dry place together with these instrucons. To maintain the baeries, when
being stored for long periods, leave the Airo 24 on charge.
When it becomes apparent that the Airo 24 is producing fewer than expected liing cycles, the baery is
probably reaching the end of its working life and should be replaced. For opmal performance, Winncare
recommends replacing baeries every 12 months.
If a fault should develop or if you require assistance in seng up using or maintaining the equipment, please
contact your supplier.
A
B
4
•Turn the Airo 24 onto its end containing the air outlet socket,
remove the screw (A) and slide the end panel (B) away from
the housing.
•Disconnect the wire from the baery pack and remove the
baery pack from the baery compartment.
•Fit the replacement baery pack, ensuring that the connector
is secure, ret the end panel and secure the screw (A).
•To calibrate the baery indicator, it is essenal before use to
charge for 12 hours.
www.easycaresystems.co.uk

AIRFLO 24
11
ENGLISH
Specicaons
Airo 24
Weight: 4.1Kg
Output pressure: 0.31 bar
Baeries: 1 x 24v - 2200mAh Ni-MH Airo 24 Baery Pack (Mangar Prt No. CD0314)
Baery Life: 500 charging cycles (when used in accordance with baery charging
instrucons). For opmal performance, Winncare recommends replacing
baeries every 12 months.
Environmental protecon: IP41 (Protecon from entry by solid objects with a diameter or
thickness greater than 1.0mm & dripping water)
Type BF equipment
This equipment has been tested and meets the requirements of current EMC legislaon
Charger: Model number - SP3009SRM
Input: AC 100v - 240v,
50-60Hz, 0.35A Max
Output: DC 30v, 0.45A
Class II Double insulated equipment.
Trouble shoong guide
Problem Remedy
•Compressor does not run when the 4 way
hand control buons are pressed.
•Ensure that the Airo 24 has been switched
on.
•Ensure the charger is disconnected from the
Airo
•Check that there are no kinks in the air hose.
•Compressor keeps stopping when trying to
inate the liing aid. •Check that there are no kinks in the air hose.
•No Baery status indicator Lights
•Unit switched o -turn unit on.
•Thermal fuse on baery has tripped – Allow
unit to cool down 60-90minutes. A solid red
LED will display aer temperature normalizes
and fuse resets. This will have reset the
charge sequence.
•Boom Baery status indicator solid Red
Light •Low Baery Capacity, recharge.
•Boom Baery status indicator Flashing Red
every 2 seconds
•Internal Pump Temperature too high –
allow Airo to cool down 60-90mins before
aempng a li.
•Boom Baery status indicator ashing Red
every ½ second
•Baery Voltage low – Re charge. If occurs
repeatedly replace the baery.
•Compressor causes electrical interference
with another piece of electrical equipment.
•Move either the compressor or other item
further away from each other unl the
interference stops.
Oponal Mains Power Adaptor:
Meanwell Switching Adaptor - GSMZZOA20-R7B
Input: AC 100v - 240v,
50-60Hz, 4A
Output: DC 20v, 0.45A
www.easycaresystems.co.uk

ENGLISH
AIRFLO 24
12
Symbols used on Airo 24 and Charger labels
Alternang current (AC)
Fuse (with rang)
Class II Double Insulated equipment
Dangerous voltage
Direct current (DC)
Duty cycle
I = Operang me
O = Non operang me
(Max connuous operang me = 5
minutes)
For indoor use only. Do Not connect
to mains power in a bathroom or
outdoors.
Recycle
Do not dispose of in household waste
Type BF equipment (protecon
against electric shock)
Max/Min operang environment
temperature
Aenon consult instrucons
Power Buon
Date of manufacture
Baery Status Indicator Buon
www.easycaresystems.co.uk

AIRFLO 24
13
ENGLISH
Symbols used on packaging
Keep packaging dry
Handle with care
Max/Min storage temperature
Net & gross weights
Stack no more than ve high
Recycle packaging
Do not dispose of in household waste
Warranty
The warranty is given against defects in material and workmanship and comprises piece, parts and
labour. The warranty is not valid in the case of fair wear and tear, wilful damage, common neglect,
misuse or unauthorised alteraon or repair by unqualied persons.
The following statements do not aect the consumer’s statutory rights. This product is sold on the
understanding that in the event of any defect of manufacture or material appearing within the
warranty period, the defect will be reced free of charge providing that:
(a) Reasonable evidence is provided (e.g. purchase invoice, delivery note) that the claim is being
made within the warranty period.
(b) The defect is not aributable to accidental damage (either in transit or otherwise), misuse or
unauthorised repair.
Max/Min humidity when transporng
or in storage
Max/Min pressure when transporng or
in storage
Max/Min temperature when
transporng or in storage
www.easycaresystems.co.uk

Special Products and Service
Contact Us
Units 5 and 6 Lower Vicarage Road Southampton
Hampshire
SO19 7RJ
T: 02380 420678
E: [email protected]
