Eaton APS6-400 Series Operating instructions

Access Power Solutions
Installation and Operation Guide
(APS6-400 Series)
Issue:
IPN 997-00012-53B
Issue Date:
December 2010
Refer to the separate SC200 or SC100 system controller handbook for full
details of the system controller operation -
www.powerquality.eaton.com/DC-Manuals.
Eaton Corporation
Telecommunications Power Solutions
www.eaton.com/telecompower
[email protected]

The product discussed in this literature is subject to terms and conditions outlined in Eaton selling policies. The
sole source governing the rights and remedies of any purchaser of this equipment is the relevant Eaton selling
policy.
No warranties, express or implied, including warranties of fitness for a particular purpose or merchantability, or
warranties arising from course of dealing or usage of trade, are made regarding the information,
recommendations and descriptions contained herein.
In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict
liability or otherwise for any special, indirect, incidental or consequential damage or loss whatsoever, including but
not limited to damage or loss of use of equipment, plant or power system, cost of capital, loss of power, additional
expenses in the use of existing power facilities, or claims against the purchaser or user by its customers resulting
from the use of the information, recommendations and descriptions contained herein.
The information contained in this literature is subject to change without notice.
Subject to the right to use its equipment, Eaton Corporation does not convey any right, title or interest in its
intellectual property, including, without limitation, its patents, copyrights and know-how.
No part of this literature may be reproduced or transmitted in any form, by any means or for any purpose other
than the Purchaser’s personal use, without the express written permission of Eaton Corporation.
Eaton®, Matrix, Powerware®, IntergyTM, CellSureTM, SiteSureTM, PowerManagerIITM and DCToolsTM are trade
names, trademarks, and/or service marks of Eaton Corporation or its subsidiaries and affiliates. Unless otherwise
noted, brands, product names, trademarks or registered trademarks are the property of their respective holders.
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.

About This Guide


Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
i
AboutThis Guide
Scope
This guide covers installation, operation and maintenance of Access Power Solutions (APS6-400
Series) dc power systems (APS), controlled by the SC200 or SC100 system controller.
Refer to the separate SC200 or SC100 system controller handbook for full details of the system
controller operation - www.powerquality.eaton.com/DC-Manuals.
Audience
This guide is intended for use by:
Installers competent in:
installing and commissioning dc power systems
safe working practices for ac and dc powered equipment
the relevant local electrical safety regulations and wiring standards
Operators and maintenance staff competent in:
operation of dc power systems
safe working practices for ac and dc powered equipment
Related Information
SC100 System Controller Operation Handbook* –IPN 997-00012-63
SC200 System Controller Operation Handbook* –IPN 997-00012-50
PowerManagerII Online Help
DCTools Online Help
SiteSure-3G Installation and Operation Guide –IPN 997-00012-51
* Download from: www.powerquality.eaton.com/DC-Manuals
http://powerquality.eaton.com/DC-Manuals.
Reporting Problems with this Guide
Please use this email address to report any problems you find in this guide:
Eaton DC Product Marketing Communications
EMAIL: [email protected]m
For Further Information and Technical Assistance
For further information and technical assistance see Worldwide Support on page 101.

Access Power Solutions Installation Guide (APS6-400 Series)
ii
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010

Table of Contents


Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
iii
Tableof Contents
About This Guide
Scope ........................................................................................................................................... i
Audience..................................................................................................................................... i
Related Information .................................................................................................................. i
Reporting Problems with this Guide...................................................................................... i
For Further Information and Technical Assistance .............................................................. i
Chapter 1 General Description
Overview ................................................................................................................................... 1
Access Power Solutions DC Power Systems ........................................................................ 2
Front View........................................................................................................................................ 2
Rear View ......................................................................................................................................... 3
Model Numbers........................................................................................................................ 4
Rectifiers .................................................................................................................................... 4
System Controller..................................................................................................................... 5
SC200 System Controller ................................................................................................................ 5
SC100 System Controller ................................................................................................................ 5
Compatible Software....................................................................................................................... 6
Other Features .......................................................................................................................... 7
External communications............................................................................................................... 7
Low Voltage Disconnect Options.................................................................................................. 7
Battery Mid-point Monitoring Option (SC200 only)................................................................... 8
Battery Time Remaining................................................................................................................. 8
Chapter 2 Preparation
Overview ................................................................................................................................... 9
Warnings ................................................................................................................................. 10
Inspecting the Equipment and Reporting Damage ........................................................... 12
Chapter 3 Installation
Overview ................................................................................................................................. 13
Installation Tasks.................................................................................................................... 14
Task 1 - Check the AC Supply and Grounding.................................................................. 14
Task 2 - Customize APS ........................................................................................................ 16
Task 3 - Mount the APS in the Rack .................................................................................... 22
Task 4 - Connect External Input/Output Cabling (if required)....................................... 25
Task 5 - Connect the DC Load and Battery Cables............................................................ 28
Task 6 - Install the Batteries .................................................................................................. 30
Task 7 - Mount the Battery Temperature Sensor ............................................................... 31
Task 8 - Connect the AC Supply Cable ............................................................................... 32
Installation Completed .......................................................................................................... 33
Chapter 4 Start-Up
Overview ................................................................................................................................. 35
Start-Up Tasks......................................................................................................................... 36
Task 1 - Inserting the Rectifiers ............................................................................................ 36
Task 2 - Pre-Power-Up Checklist ......................................................................................... 37
Task 3 - Applying AC Power................................................................................................ 37
Task 4 - Configuring the DC Power System....................................................................... 38
Task 5 - Applying DC Power to Battery and Load............................................................ 39
Start-Up Completed............................................................................................................... 40

Access Power Solutions Installation Guide (APS6-400 Series)
iv
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Chapter 5 System Controller
Configuration File...................................................................................................................42
Backup and Restore .......................................................................................................................42
Starting the SC200 or SC100 ..................................................................................................43
SC200 ...............................................................................................................................................43
SC100 ...............................................................................................................................................43
SC200 or SC100 Operation using the Keypad and Screen.................................................44
Keypad Access Security ................................................................................................................44
Alarm Indicators ............................................................................................................................45
SC200 or SC100 Operation Using a PC/Laptop .................................................................46
Using DCTools via USB (SC200 only) .........................................................................................46
Using DCTools via RS232 .............................................................................................................46
SC200 or SC100 Identity Information...................................................................................48
Chapter 6 Maintenance
Overview..................................................................................................................................49
Troubleshooting ......................................................................................................................50
System Problems............................................................................................................................50
System Controller Problems.........................................................................................................53
Replacing or Adding a Rectifier............................................................................................57
Replacing or Adding a Load circuit breaker .......................................................................59
Replacing the System Controller...........................................................................................60
Replacing the Input/Output Board......................................................................................62
Battery Mid-point Monitoring (String Fail) Alarm (SC200 only) .....................................64
Battery Disposal and Recycling ............................................................................................64

Table of Contents
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
v
Appendix A Equipment and Tools
Safety Equipment .......................................................................................................................... 65
Essential Tools................................................................................................................................ 65
Recommended Tools..................................................................................................................... 65
Standard Torque Settings...................................................................................................... 66
Appendix B Spare Parts Lists
Spare Parts Lists APS6-400.................................................................................................... 67
Appendix C Specifications
LVD Specifications APS6-400 ............................................................................................... 70
Appendix D Controller Menus
SC200 Menu ............................................................................................................................ 73
SC100 Menu ............................................................................................................................ 74
Appendix E Connector Pin-outs
System Controller Connector Pin-outs................................................................................ 75
I/O Board (IOBGP-00, -01) Connector Pin-outs................................................................. 77
Input/Output Board.............................................................................................................. 79
Connections............................................................................................................................. 81
Appendix F Commissioning
Analog Inputs ......................................................................................................................... 84
System Controls...................................................................................................................... 86
System Alarms........................................................................................................................ 90
Digital Inputs .......................................................................................................................... 93
Digital Outputs (Relays)........................................................................................................ 94
Commissioning Completed .................................................................................................. 94
Appendix G Circuit Diagrams
Equipment Incident Report
Worldwide Support
Index

Access Power Solutions Installation Guide (APS6-400 Series)
vi
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010

Chapter 1
General Description


Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
1
C h a p t e r 1
GeneralDescription
Overview
Topic Page
Access Power Solutions DC Power Systems 2
Model Numbers 4
Rectifiers 4
System Controller 5
Other Features 7

Access Power Solutions Installation Guide (APS6-400 Series)
2
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Access Power Solutions DC Power Systems
Front View
Rectifier modules (see details on page 4)
SC200 or SC100 system controller (see details on
page 5)
Battery circuit breaker cover
Battery circuit breakers (up to 6, alarm on electrical
trip or when switched off). Connected to optional
battery disconnect LVD (if fitted).
Protective earth termination (M10)
Load circuit breaker cover
Load circuit breakers (up to 20, alarm on electrical trip
only). 1-10 connected to optional load disconnect
LVD (if fitted) for low-priority loads (see LVD Options
on page 7).
Telecom ground link terminal (M10, see details on
page 25)

General Description
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
3
Rear View
AC wiring space (see connection details on page 32).
AC terminal covers with holes to suit up to 1" conduit.
Input/Output (I/O) cover.
I/O Board (see details on page 79).
Load and Battery common bar.
DC common-chassis (ac ground) link (see details on
page 23).
Load live cable terminals.
Alternate load terminal bar for 2-pole load circuit
breakers.
DC terminal cover.
Battery live cable terminals.
Alternate battery terminal bar for 2-pole battery circuit
breakers.

Access Power Solutions Installation Guide (APS6-400 Series)
4
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Model Numbers
Model Number
System Controller
LVD Contactor(s)
APS6-410
SC100
None *
APS6-411
SC100
Battery only
APS6-41L
SC100
Low-priority load only *
APS6-412
SC100
Battery and low-priority load
APS6-420
SC200
None *
APS6-421
SC200
Battery only
APS6-42L
SC200
Low-priority load only *
APS6-422
SC200
Battery and low-priority load
* In APSs without an internal battery disconnect LVD, either the total battery current must be
less than 285A or the APS must be protected by an external battery LVD set to 43V or higher.
Rectifiers
Access Power Solutions are fitted with 48V, 2000W (APR48-ES) and/or 48V, 1800W (APR48-3G)
rectifiers. The rectifiers are fan-cooled and hot-pluggable.
See Specifications on page 69 for further information. See Troubleshooting on page 50 for details of
rectifier alarms.
Left: APR48-3G
Right: APR48-ES
Power On LED (Green)
Minor Alarm LED (Yellow)
Major Alarm LED (Red)
Serial Number
Retaining Screw. Tighten to 1.5Nm
(13.3 inch-pounds).

General Description
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
5
System Controller
The SC200 or SC100 system controller provides control, communications and alarm functions.
The system controller is supplied pre-configured. Configuration changes can be made with the
keypad, or via a PC connected to the USB connector (SC200) or RS232 (SC100) connector. Or
changes can be made remotely (see External Communications on page 7).
For basic operating information see System Controller on page 41. For further details refer to
the System Controller Operation Handbook (see Related Information on page i).
See Troubleshooting on page 53 in the System Controller Operation Handbook for details of
system controller alarms.
SC200 System Controller
The SC200 system controller is an advanced control and monitoring solution which provides a
full suite of communications options, including built-in Ethernet interface, Web server, and
SNMP agent.
Alarm notifications may be by SNMP traps, SMS text messaging, dial-out to PowerManagerII
remote monitoring software, or relay contact closures.
Power on LED (green)
Minor alarm LED (yellow)
Critical/Major alarm LED (red)
Color LCD
Soft keys (2)
Navigation keys (4)
USB 1.1 connector (12Mb/s)
Retaining screw
Power and system
communications connector
RS232 connector
Ethernet connector and
status LEDs
SC100 System Controller
The SC100 system controller is a full-featured control and monitoring solution which provides
alarm notifications via dial-out modem to PowerManagerII remote monitoring software, SMS
text messaging, or by relay contact closures.

Access Power Solutions Installation Guide (APS6-400 Series)
6
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Power on LED (green)
Minor alarm LED (yellow)
Critical/Major alarm LED (red)
LCD
Navigation keys (4)
RS232 D9M connector
Retaining screw
Power and system
communications connector
Compatible Software
The following software is compatible with the SC200 or SC100 system controller:
DCTools Configuration Software. Latest version is available free from
www.powerquality.eaton.com/downloads.
PowerManagerII Remote Control and Monitoring Software. Contact your Eaton dc product
supplier for further information (see Worldwide Support on page 101).
Recommended web browsers (SC200 only): Microsoft Internet Explorer 8 (IE6 is compatible
but with reduced performance), Mozilla Firefox 3.0.

General Description
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
7
Other Features
External communications
Refer to the system controller handbook for information on these communications options.
Communications options
SC200
SC100
Communication with DCTools via USB

-
Communication with DCTools or PowerManagerII via RS232


Communication with DCTools or PowerManagerII via
an external PSTN or GSM modem (dial-in and dial-out on alarm)


Communication with DCTools or PowerManagerII via Ethernet

-
Communication with web browser software via an IP network

-
Communication with a Network Management System (NMS) using
SNMP

-
Communication with a Building Management System (BMS) using
Modbus

-
Alarm and status messages to GSM Short Messaging Service (SMS)
text capable cell phones


Communication with an alarm management system using
voltage-free relay contacts (on an IOBGP I/O board)


Low Voltage Disconnect Options
The APS can be fitted with one or two Low Voltage Disconnect (LVD) contactors (see Model
Numbers on page 4) at the time of installation (see details on page 19).
One of the two LVDs is connected as a battery disconnect and the other as a low-priority load
disconnect (connected to circuit breakers 1-10).
See LVD Specifications on page 70 for the current ratings. In APSs without an internal battery
disconnect LVD, either the total battery current must be less than 285A or the APS must be
protected by an external battery LVD set to 43V or higher.
For information on operation see Low Voltage Disconnect (LVD) in the System Controller
Operation Handbook.

Access Power Solutions Installation Guide (APS6-400 Series)
8
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Battery Mid-point Monitoring Option (SC200 only)
Battery Mid-point Monitoring provides a cost-effective method for the early detection of
internal battery faults. The voltages of the two halves of a battery string are measured and the
system controller generates an alarm signal if a voltage imbalance is detected.
A voltage imbalance is an indication that one or more cells has an internal fault. Further
investigation can then isolate the faulty cell(s) and action can be taken to correct the problem
and prevent a total battery failure.
To connect the Battery Mid-point Monitoring option see details on page 30. If a String Fail alarm
is generated see Troubleshooting on page 50.
To ensure reliable operation Mid-point Monitoring operates only when the battery is in float
charge and after a configurable lockout period since the last battery discharge, Fast Charge,
Equalize or Battery Test.
Battery Time Remaining
The SC200 or SC100 obtains characterization data from either periodic battery discharges
(SC100) or every full battery discharge (SC200), to a specified end voltage.
During a battery discharge, the SC200 or SC100 uses this characterization data to calculate an
estimated time until the battery will reach the specified end voltage.
If a battery disconnect LVD is fitted then the end voltage will usually be the voltage at which the
LVD disconnects the battery.
Battery Time Remaining is designed for a constant power load. The accuracy of the time
remaining calculation will be reduced if the dc power system is connected to a predominantly
resistive (constant current) load.
The time remaining calculation will not be correct if a non-essential load is disconnected during
the battery discharge.
The following information is available about Battery Time Remaining.
Parameter
Description
Where to find:
Battery Time
Remaining*
During a battery discharge, this is the estimated time
until the battery voltage will be equal to the End
Voltage, at the present battery current. Time Remaining
will be re-calculated if the load current varies during
discharge (for example, when a load disconnect LVD
operates).
SC200 or SC100: Menu >
Controls > Batt Time
Remaining
DCTools/Web: Batteries
Estimated State of
Charge (SOC)*
The estimated charge left in the battery (Ah).
*Values of Battery Time Remaining and SOC are only available during a discharge and if the
battery has been characterized. The values will be N/A when the Battery Charge State is
Floating or Charge, or if the battery has not been characterized. See Battery Characterization.
For details refer to Battery Time Remaining in the SC200 or SC100 System Controller Operation
Handbook (see Related Information on page i).

Chapter 2
Preparation


Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
9
C h a p t e r 2
Preparation
Overview
Topic Page
Warnings 10
Inspecting the Equipment and Reporting Damage 12

Access Power Solutions Installation Guide (APS6-400 Series)
10
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
Warnings
This section contains important warnings. Read these warnings before installing or operating
Access Power Solutions dc power systems.

Electrical Safety
The case of the Access Power Solutions (APS6-400 Series) dc power system is a fire enclosure as specified
in UL 60950-1. The system can be installed in an enclosed cabinet or an open relay rack.
The dc power system may be powered from multiple ac sources. All power sources must be isolated
before internally servicing the equipment.
The dc power system must be connected to a suitable and readily accessible disconnect device(s).
The dc power system is not compatible with IT (Impedance Terra) ac supply. For advice see Worldwide
Support on page 101.
A registered electrician (or suitably qualified person) must check the integrity of the installed cabling,
BEFORE the dc power system is powered up.
Tasks must be performed in the sequence documented in this guide.

Location and Environment
The APS must be installed in a Restricted Access Location (dedicated equipment rooms, equipment
closets, or similar) in accordance with the U.S. National Electric Code (NEC), ANSI/NFPA No. 70, and
according to the applicable local codes.
For ease of access and to maintain optimum system cooling, observe the clearances stated on page 22.
Ensure the ambient temperature and humidity are within the ranges in the Specifications on page 70.
Dust build-up within the APS may cause premature failure. In dusty environments filter the ventilation
air entering the equipment room. Ensure regular cleaning of the air filters.
Do not allow water or any foreign object to enter the APS. Do not place objects containing liquid on top of
or near the unit.

Reverse Polarity
Always check that the battery cables have been terminated to the correct system polarity BEFORE
connecting the batteries or closing the battery disconnect device. Connecting batteries to the dc power
system with incorrect system polarity will damage the rectifiers and void all warranty claims.

Hazardous Energy Levels
Rectifiers and batteries contain hazardous energy levels. Only personnel trained and experienced in dc
power systems are to service/maintain this equipment.
Always use insulated tools.
Do not short-circuit the live and common bus bars or cables.

Battery Current
In APSs without an internal battery disconnect LVD, either the total battery current must be less than
285A or the APS must be protected by an external battery LVD set to 43V or higher.
The short circuit current capability of the battery circuit connected to the battery input terminals must not
exceed 5,000A.

Preparation
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010
11

Batteries
The plastic cases of batteries installed in Eaton dc power system racks must have a flammability rating of
UL 94-V2 or better.
Flooded cell lead acid batteries must be installed in a battery room. Do not install flooded lead acid
batteries in an Eaton dc power system rack.
Flooded cell and VRLA lead acid batteries can emit explosive gases and must be installed with adequate
ventilation. Refer to the battery manufacturer or supplier for advice on minimum ventilation levels.
Do not wear a synthetic dust-coat or overalls. Synthetic fabrics can hold static electric charges that create
sparks during discharge.
Remove rings, wristwatch and other metal jewelry that might be exposed to battery terminals, before
installing batteries.
Batteries are powerful sources of energy and present a potential electrical shock and energy hazard. The
energy hazard is always present, even if the batteries are not connected. Avoid short circuiting terminals
of opposite polarity.
Always use insulated tools.
Do not place tools, loose cables or metal objects (such as interconnecting bars) on top of batteries.
Do not drop tools, loose cables or metal objects onto intercell connections or terminals of opposite
polarity.
Only terminate cables and interconnecting bars after confirming that the termination will not create a
short circuit.
Always tighten battery terminal bolts according to the battery manufacturer’s specification. Failing to do
so can cause erratic battery performance, possible damage to the battery, and/or personal injury.
There is a risk of electric shock if a battery is replaced by an incorrect type.
Dispose of batteries according to the instructions on page 64.

Rectifiers
Do not install the rectifiers until the room has been cleaned and is dust free.
To reduce the risk of electric shock and maintain optimum system cooling, always cover empty rectifier
slots with blanking panels.
To avoid electrical shock, do not place hands inside the rectifier magazine.
Rectifier cases may exceed 100ºC (212ºF), especially after prolonged operation. Use suitable gloves when
removing a rectifier from the magazine.
Do not attempt to disassemble faulty rectifiers. Return them (in their original packaging) with a
completed Equipment Incident Report on page 99.

Servicing and Maintenance
The APS contains hazardous voltages and hazardous energy levels. Before undertaking any maintenance
task refer to the Warnings on page 10.
If a maintenance task must be performed on a "live" system then take all necessary precautions to avoid
short-circuits or disconnection of the load equipment, and follow any "live-working" instructions
applicable to the site.
Only perform the maintenance tasks described in the Maintenance chapter. All other tasks are classified
as Servicing. Servicing must only be performed according to specific instructions and only by personnel
authorized by Eaton. This includes disassembly and/or servicing of any modules.
For further information on Servicing contact your local Eaton dc product supplier, or refer to the contact
details on page 101.

Access Power Solutions Installation Guide (APS6-400 Series)
12
Copyright © 2009-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-53B December 2010

Telecom Ground and dc Supply Bond to Chassis
CAUTION: This equipment has a connection between the earthed conductor of the dc supply circuit and
the earthing conductor.
Cet appareil comporte une connexion entre le conducteur relié à la terre du circuit d'alimentation c.c. et son
conducteur de terre.
All of the following installation conditions must be met:
This equipment shall be connected directly to the dc supply system earthing electrode conductor or
to a bonding jumper from an earthing terminal bar or bus to which the dc supply system earthing
electrode conductor is connected.
This equipment shall be located in the same immediate area (such as adjacent cabinets) as any other
equipment that has a connection between the earthed conductor of the same dc supply circuit and
the earthing conductor, and also the point of earthing of the dc system. The dc system shall not be
earthed elsewhere.
The dc supply source shall be located within the same premises as this equipment.
Switching or disconnecting devices shall not be in the earthed circuit conductor between the dc
source and the point of the connection of the earthing electrode conductor.
Ce matériel doit être raccordé directement au conducteur de la prise de terre du circuit d'alimentation c.c. ou à une
tresse de mise à la masse reliée à une barre omnibus de terre laquelle est raccordée à l'électrode de terre du circuit
d'alimentation c.c. Les appareils dont les conducteurs de terre respectifs sont raccordés au conducteur de terre du
même circuit d'alimentation c.c. doivent être installés à proximité les uns des autres (p.ex., dans des armoires
adjacentes) et à proximité de la prise de terre du circuit d'alimentation c.c. Le circuit d'alimentation c.c. ne doit
comporter aucune autre prise de terre. La source d'alimentation du circuit c.c. doit être située dans la même pièce
que le matériel. Il ne doit y avoir aucun dispositif de commutation ou de sectionnement entre le point de
raccordement au conducteur de la source d'alimentation c.c. et le point de raccordement à la prise de terre.

EMC Compliance
This Eaton product ("the equipment") has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the Federal Communications Commission (FCC) Rules. These limits
are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions in this installation guide, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Changes or modifications to the equipment not approved by Eaton Corporation could void the FCC
authority to operate the equipment.
Inspecting the Equipment and Reporting Damage
Unpack the equipment and inspect it carefully for possible damage that may have occurred
while in transit. Do not use any damaged equipment.
Report any damage immediately, using a completed Equipment Incident Report on page 99.
Keep the original packaging to use if any item needs to be returned for replacement or repair.
