TECHNICAL SPECIFICATIONS CB523M
CINEMA SYSTEMS
DESCRIPTIVE DATA continued
DESCRIPTIVE DATA
Part Number 999825
LF Subsystem & Loading 2x15-in vented
MF Subsystem & Loading 1x10-in orn-loaded
HF Subsystem & Loading 1x1.4-in exit compression driver
on CD orn
Configuration 3-way, full range
Powering Mode Tri-amplified
System Crossover EAW CX300-CB523M
Cabinet Type (s ape) Rectangular
Enclosure Materials LF-3/4-in Medium Density Fiberboard
15 mm birc plywood baffle-
MF/HF-MDF
Finis Textured black
Connectors 2x2-terminal barrier strips
(LF and MF) plus 2x bind posts (HF)
Dimensions inc es millimeters
Heig t 69.41 1763
Widt 24.80 630
Dept 17.75 451
Weig ts pounds kilograms
Net Weig t (approx) 235 10.69
S ipping Weig t (approx) 253 115.1
• Approved for use in THX®-certified t eaters
• For medium-sized t eaters
• Tri-amplified 3-way screen c annel loudspeaker
T e CB523M tri-amplified t ree-way full-range screen c annel loud-
speaker system as been approved for use in THX® certified t eaters.
T ree-way design dramatically advances cinema audio quality by
improving t e naturalness and intelligibility of dialog, eliminating
distortion from excessive driver excursion and extending pattern
control into t e lower octaves.
T e two component system includes a BV253C dual 15-in low
frequency enclosure and an HK523M mid/ ig section.
T e low frequency enclosure uses optimally tuned enclosure venting
to increase LF response w ile limiting driver excursion. T is met od
produces less distortion and minimizes driver strain w ile extending
LF response to t e lowest octaves. T e enclosure’s s allow dimension
allows convenient placement be ind t e screen.
T e HK523M MF/HF section features a orn-loaded 10-in cone and a
ig power 1.4-in exit compression driver loaded wit a 90°x45°
coverage pattern constant directivity orn.
T e adjustable steel bracket attac ing t e MF/HF section to t e LF
enclosure can be positioned at one of t ree mounting points for
optimum front/rear placement. T e bracket allows t e MF/HF section
to be aimed independently of t e LF section in bot t e orizontal
and vertical planes and can be locked once it is positioned.
Input connectors for t e LF and MF sections are two-terminal
barrier strips t at accommodate bare wire, tinned leads or spade
lugs. Bind posts for t e ig frequency section are located directly
on compression driver. T e input panels are located on t e sides and
top of t e enclosures for convenient access in cramped installation
areas.
