Echo CBL-58V User manual

Su sopladora ha sido diseñada y fabricada de conformidad con las
estrictasnormasparabrindarfiabilidad,facilidaddeusoyseguridad
para el operador. Con el debido cuidado, le brindará muchos años
de sólido y eficiente funcionamiento.
ADVERTENCIA Para reducir
el riesgo de lesiones, el usuario debe leer y comprender el
manual del operador antes de usar este producto.
Le agradecemos su compra.
Cesoufflanteaétéconçueetfabriquéeconformémentànosstrictes
normes de fiabilité, simplicité d’emploi et sécurité d’utilisation.
Correctement entretenue, elle vous donnera des années de
fonctionnement robuste et sans problème.
AVERTISSEMENT Pour
réduire les risques de blessures, l’utilisateur doit lire et veiller
à bien comprendre le manuel d’utilisation avant d’employer
ce produit.
Merci de votre achat.
Your blower has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING To reduce the risk of injury, the user must read and understand the operator’s
manual before using this product.
Thank you for your purchase.
58 Volt Blower
Soufflante 58 V
Sopladora de 58 V
CBL-58V
Batteries and Chargers Sold Separately
Piles et chargeur vendus séparément
Baterías y el cargador se venden por separado
Operator’s Manual
Manuel d’utilisation
Manual del operador
SAVE THIS MANUAL FOR FUTURE REFERENCE
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS

ii
Fig. 1
A - Switch trigger (gâchette, gatillo)
B - Debris scraper (chasse-débris, fregador de suciedad)
C - Cruise control lever (levier de régulateur de vitesse, palanca del control
de crucero)
See this fold-out section for all of the figures
referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes les figures
mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas las figuras
a las que se hace referencia en el manual del operador.
B
F
D - Battery latch button (bouton de verrouillage de la pile, botón del pestillo
de la batería)
E - Battery port (logement de batteries, receptáculo para baterías)
F - Blower tube (tube de soufflante, tubo de la sopladora)
A
C
D
E

iii
C
BD
E
F
Fig. 2 Fig. 4
Fig. 3
Fig. 5
A - Cruise control lever (levier de régulateur de
vitesse, palanca del control de crucero)
B - OFF position (position d’ARRÊT, posición
APAGADO)
C - LOW (1) speed (BASSE [1] vitesse, BAJA [1]
velocidad)
D - MEDIUM (2) speed (MOYEN [2] vitesse,
MEDIANO [2] velocidad)
E - HIGH (3) speed (RAPIDE [3] vitesse, ALTA
[3] velocidad)
F - MAX (4) speed (MAXIMAL [4] vitesse,
MÁXIMO [4] velocidad)
G - Switch trigger (gâchette, gatillo)
A - Blower tube (tube de soufflante, tubo de la sopladora)
B - Blower housing outlet (prise de boîtier de soufflante, salida del alojamiento de la sopladora)
A - Battery latch button (bouton de verrouillage de la pile, botón del pestillo de la batería)
B - Battery pack (bloc-piles, paquete de baterías)
C - Battery port (logement de batteries, receptáculo para baterías)
PROPER OPERATING POSITION
BONNE POSITION DE TRAVAIL
POSICIÓN CORRECTA PARA EL MANEJO
DE LA HERRAMIENTA
A
A
G
B
A
B
C

2 English
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
Important Safety Instructions ........................................................................................................................................3-4
Instructions importantes concernant la securite / Instrucciones de seguidad importantes
Symbols.........................................................................................................................................................................5-6
Symboles / Símbolos
Features............................................................................................................................................................................ 6
Caractéristiques / Características
Assembly.......................................................................................................................................................................6-7
Assemblage / Armado
Operation.......................................................................................................................................................................7-8
Utilisation / Funcionamiento
Maintenance..................................................................................................................................................................... 9
Entretien / Mantenimiento
Troubleshooting................................................................................................................................................................ 9
Dépannage / Corrección de problemas
Warranty ......................................................................................................................................................................... 10
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.

English 3
Whenusing anelectrical appliance, basicprecautionsshould
always be followed, including the following:
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING THIS BLOWER. To reduce the risk of electric
shock, fire and/or serious personal injury.
Know your power blower. Read operator’s manual
carefully. Learn its applications and limitations, as
well as the specific potential hazards related to this
blower. Following this rule will reduce the risk of electric
shock, fire, or serious injury.
Do not permit children to use blower. It is not a toy.
Close attention is necessary when used near children.
Use only accessories that are recommended by the
manufacturer for your model described in this manual.
Accessories that may be suitable for one blower may
create a risk of injury when used on another blower. Use
only as described in this manual.
Do not handle charger, including charger plug, and
charger terminals with wet hands.
Do not put any object into openings. Do not use with
any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
Do not charge the unit outdoors.
Keep hair, loose clothing, fingers, and all parts of body
away from openings and moving parts.
Turn off all controls before removing battery.
Use extra care when cleaning on stairs or steps.
Do not operate blowers in explosive atmospheres,
such as in the presence of flammable liquids, gases,
or dust. Blowers create sparks which may ignite the dust
or fumes.
Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
Keep bystanders, children, and visitors at least 50 ft.
away while operating a blower. Distractions can cause
you to lose control.
A battery operated blower with integral batteries or
a separate battery pack must be recharged only with
the specified charger for the battery. A charger that
may be suitable for one type of battery may create a risk
of fire when used with another battery.
Use battery operated blower only with specifically
designated battery pack. Use of any other batteries
may create a risk of fire.
Use battery only with charger listed. For use with
ECHO 58 V lithium-ion battery packs. See Tool/
Appliance/Battery Pack/Charger Correlation Supplement
991000233.
IMPORTANT SAFETY INSTRUCTIONS
Do not operate charger with a damaged cord or plug,
which could cause shorting and electric shock. If
damaged, have the charger replaced by an authorized
service center for ECHO brand 58 V outdoor products.
If appliance is not working as it should after being
dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
Stay alert, watch what you are doing and use common
sense when operating a power blower. Do not use
blower while tired, upset, or under the influence of
drugs, alcohol, or medication. A moment of inattention
while operating blowers may result in serious personal
injury.
Secure long hair above shoulder level to prevent
entanglement in moving parts.
Avoid accidental starting. Be sure switch is in the locked
or off position before inserting battery pack. Carrying
blowers with your finger on the switch or inserting the battery
pack into a blower with the switch on invites accidents.
Use safety equipment. Always wear eye protection.
Dust mask, non-skid safety shoes, hard hat, or hearing
protection must be used for appropriate conditions.
Do not wear loose clothing or jewelry. Contain long
hair. Loose clothes, jewelry, or long hair can be drawn
into air vents.
Do not use on a ladder, rooftop, tree, or other unstable
support. Stable footing on a solid surface enables better
control of the blower in unexpected situations.
Do not use blower if switch does not turn it on or off.
A blower that cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect battery pack from blower before making
any adjustments, changing accessories, or storing the
blower. Such preventive safety measures reduce the risk
of starting the blower accidentally.
When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys, nails,
screws, or other small metal objects that can make
a connection from one terminal to another. Shorting
the battery terminals together may cause sparks, burns,
or a fire.
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the blower’s operation. If damaged, have the
blower serviced before using. Many accidents are
caused by poorly maintained blowers.
Keep the blower and its handle dry, clean and free
from oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline, petroleum-
based products, or any strong solvents to clean your
blower. Following this rule will reduce the risk of loss of
control and deterioration of the enclosure plastic.

4 English
Do not point the blower nozzle in the direction of
people or pets.
Never run the unit without the proper equipment
attached. Always ensure the blower tubes are installed.
When not in use, blower should be stored indoors in
a dry, locked up place—out of the reach of children.
Donothang unit sothattheswitch trigger isdepressed.
Do not dispose of a severely damaged or worn out
battery pack or this blower by incinerating. The battery
can explode in fire.
Blower service must be performed only by qualified
repair personnel. Service or maintenance performed by
unqualified personnel may result in a risk of injury.
When servicing a blower, use only identical replacement
parts. Follow instructions in the Maintenance section of
this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of shock or
injury.
Never use blower near fires, fireplaces, hot ashes,
barbecue pits, etc. Use near fires or ashes can spread
fires and result in serious injury and/or property damage.
Never use blower to spread chemicals, fertilizers,
or any other toxic substances. Spreading these
substances could result in serious injury to the operator
or bystanders.
Never place blower on any surface, except a hard,
clean surface when motor is running. Gravel, sand,
and other debris can be picked up by the air inlet and
thrown at the operator or bystanders, causing possible
serious injuries.
For household use only.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions also.
Always wear safety glasses with side shields. Everyday
glasses have only impact resistant lenses. They are NOT
safety glasses. Following this rule will reduce the risk of
eye injury.
Alwaysweareye protectionwithside shields markedto
comply with ANSI Z87.1 along with hearing protection
when operating this equipment.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reduce the risk of serious personal injury.
Battery blowers do not have to be plugged into
an electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery powered blower or when
changing accessories. Following this rule will reduce the
risk of electric shock, fire, or serious personal injury.
Do not place battery powered blowers or their
batteries near fire or heat. This will reduce the risk of
explosion and possibly injury.
Don’t expose blowers to rain or wet conditions. Water
entering a blower will increase the risk of electric shock.
Wear heavy long pants, long sleeves, boots, and
gloves. Avoid loose garments or jewelry that could get
caught in moving parts of the machine or its motor.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and improve
your footing on slippery surfaces.
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance.
Check the work area before each use. Remove all
objects such as rocks, broken glass, nails, wire, or string
which canbe thrown or becomeentangled in the machine.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

English 5
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
Symbol Signal Meaning
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates important information not related to an
injury hazard, such as a situation that may result in property damage.
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Symbol Name Designation/Explanation
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s
Manual
To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye and Hearing
Protection
Always wear eye protection with side shields marked to comply
with ANSI Z87.1 along with hearing protection when operating this
equipment.
Impeller Blades Rotating impeller blades can cause severe injury.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Keep Bystanders
Away Keep all bystanders at least 50 ft. away.
Long Hair Failure to keep long hair away from the air inlet could result in personal
injury.
Blower Tube Do not operate without tube in place.
Loose Clothing Failure to keep loose clothing from being drawn into air intake could
result in personal injury.
Ricochet Thrown objects can ricochet and result in personal injury or property
damage.
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state, or federal
laws may prohibit disposal of batteries in ordinary trash. Consult your
local waste authority for information regarding available recycling and/
or disposal options.

6 English
FEATURES
Know Your Blower
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
Blower Tube
The blower tube can be installed on the blower without
using any tools.
Debris Scraper
The debris scraper is great for wet sticky leaves. It allows you
to scrape wet leaves or debris while operating the blower.
Cruise Control
The cruise control feature allows you to lock the blower on
whenyouoperate it continuouslyforextendedperiods of time.
Variable Speed Switch Trigger
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
ASSEMBLY
Unpacking
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Symbol Name Designation/Explanation
V Volts Voltage
min Minutes Time
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotational speed, at no load
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
PRODUCT SPECIFICATIONS
Motor.....................................................................................................................................................................58 Volts DC
Air Velocity
Max. CFM......................................................................................................................................................................450
Max. MPH......................................................................................................................................................................120
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Donot discardthe packingmaterialuntil youhave carefully
inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-877-396-3036 for assistance.
Packing List
Blower
Blower Tube with Scraper
Operator’s Manual

English 7
ASSEMBLY
WARNING
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from
the tool when assembling parts.
Assembling the Blower Tube
See Figure 2.
Align raised tabs on blower housing outlet to the slots
on blower tube; slide together and tighten securely by
twisting. Check tightness after initial use and retighten if
needed.
NOTE: When tightening, ensure the blower tube’s locking
ribslides over the raised tabsof the blowerhousing outlet.
To remove, rotate the tube to unlock it and remove from
the blower housing outlet.
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this blower.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
OPERATION
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
Applications
You may use this product for the purposes listed below:
Clearing leaves and other debris from your lawn
Keeping decks and driveways free from grass clippings,
leaves, pine needles, and other debris
This product will accept ECHO 58V lithium-ion battery
packs only.
For complete charging instructions, refer to the Operator’s
Manuals for your ECHO battery pack and charger models.
To Install/Remove Battery Pack
See Figure 3.
WARNING
Always remove battery pack from your tool when you
are assembling parts, making adjustments, cleaning,
or when not in use. Removing battery pack will prevent
accidental starting that could cause serious personal
injury.
To install:
Move the cruise control lever completely forward (off
position).
Align the groove on the battery pack with raised rib in the
blower’s battery port.
Insert the battery pack into the blower until it clicks into
place.
WARNING
Be sure the battery pack is fully seated and secure in the
blower battery port before beginning operation. Failure
to securely seat the battery pack could cause the battery
pack to fall out, resulting in serious personal injury.
To remove:
Move the cruise control lever completely forward (off
position).
Press the battery latch button on the tool and pull the
battery pack out using the handle.

8 English
OPERATION
WARNING
To avoid serious personal injury, always remove the
battery pack and keep hands clear of the trigger when
carrying or transporting the tool.
Starting/Stopping the Blower
See Figure 4.

To start the blower, depress the switch trigger.

To stop the blower, release the switch trigger.
Operating the Blower
See Figure 5.

To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the center
of a pile.

To reduce sound levels, limit the number of pieces of
equipment used at any one time.

Use rakes and brooms to loosen debris before blowing.
In dusty conditions, slightly dampen surfaces when water
is available.

Conserve water by using power blowers instead of hoses
for many lawn and garden applications, including areas
such as gutters, screens, patios, grills, porches, and
gardens.

Watch out for children, pets, open windows, or freshly
washed cars, and blow debris safely away.

After using blowers or other equipment, CLEAN UP!
Dispose of debris properly.
Cruise Control
See Figure 4.

Squeeze the switch trigger.

Move the cruise control lever toward the rear of the blower
and into either the LOW (1), MEDIUM (2), HIGH (3) or
MAXIMUM (4) speed position.

Release the switch trigger and your blower will continue
running at the speed you selected.

Tostoptheblower,movethecruisecontrollevercompletely
forward (off position).
If the cruise control feature is engaged during use and the
battery pack is removed from the tool, disengage the cruise
control feature immediately.
WARNING
Before connecting a battery pack to the blower, always
check to be sure it is not in cruise control (move the
cruise control lever completely forward to the off
position). Failure to ensure that it is not locked-on could
result in accidental starting of the blower resulting in
possible serious injury. Do not lock the switch trigger in
applications where the blower may need to be suddenly
stopped.

English 9
MAINTENANCE
WARNING
When servicing, use only identical replacement parts.
Use of any other parts can create a hazard or cause
product damage.
WARNING
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING
To avoid serious personal injury, always remove the
battery pack from the product when cleaning or
performing any maintenance.
General Maintenance
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which can result in serious personal
injury.
Cleaning the blower
Stop the motor and remove the battery pack.
Clean dirt and debris from the blower using a damp cloth
with a mild detergent.
NOTICE
Do not use any strong detergents on the plastic housing
or the handle. They can be damaged by certain aromatic
oils such as pine and lemon, and by solvents such as
kerosene.
Storage
Remove the battery pack from the blower before storing.
Clean all foreign material from the blower.
Store indoors in a secure place that is inaccessible to
children.Keepawayfromcorrosiveagentssuch asgarden
chemicals and de-icing salts.
Do not hang unit so that the switch trigger is depressed.
TROUBLESHOOTING
Problem Possible Cause Solution
Motor fails to start when switch
trigger is depressed
Battery is not secure.
Battery is not charged.
To secure the battery pack, make sure the battery is
fully seated and the battery latch button on the tool is
snapped into place.
Charge the battery pack according to the instructions
included with your charger.
Blower will not stop Cruise control is on. Turn off cruise control.
Motor stops while switch trigger
is depressed.
Motor is overloaded. Release switch trigger, wait several seconds, then
depress trigger again. Motor should restart. If it doesn’t,
remove battery pack, reinstall battery pack, and then
try again.
