INTRODUCTION
This service manual contains information
for service and maintenance of ECHO RE-
CHARGEABLE POWER BLOWER, model
DPB-600.
For systematic diagnosis, to avoid extra work
and time loss, please refer to “Troubleshooting
chart” that describes problems, testing, reme-
dies and references. We recommend you make
use of Operator’s Manual and Parts Catalogue
together with this manual when servicing.
We are constantly working on technical improve-
ment of our products. For this reason, technical
data, equipment and design are subject to
change without notice. All specifications, illustra-
tions and directions in this manual are based on
the latest product information available at the
time of publication.

TABLE OF CONTENTS
DPB-600 3
Page Page
1 SERVICE INFORMATION.....................................4
1-1 Specifications ...................................................4
1-2 Technical data ..................................................4
1-3 Torque limits .....................................................4
2 TRIGGER SWITCH GRIP .....................................5
2-1 Trigger switch grip ............................................5
2-2 Disassembling trigger switch grip.....................5
2-3 Reassembling trigger switch grip .....................7
3 MOTOR CASE ......................................................9
3-1 Motor case........................................................9
3-2 Disassembling motor case .............................10
3-3 Reassembling motor case.............................. 11
4 FAN CASE ..........................................................13
4-1 Fan case.........................................................13
4-2 Disassembling fan case .................................14
4-3 Disassembling motor......................................16
4-4 Reassembling motor ......................................17
4-5 Reassembling fan case..................................18
5 BATTERY............................................................19
5-1 Battery and charger........................................19
5-2 Battery charge levels......................................19
5-3 Charger indicator lights ..................................20
-4 Battery disposal procedure.............................20

SERVICE INFORMATION DPB-600
4
1 SERVICE INFORMATION
1-1 Specifications
Dimensions Length mm(in) 954 (37.6)
Width mm(in) 187 (7.4)
Height mm(in) 336 (13.2)
Dry weight* kg(lb) 2.8 (6.1)
Motor Type DC electric motor
Rotation Clockwise as viewed from the output end
Voltage DC V 50.4
Rated output W 670
Battery
pack Type Lithium-ion
Voltage V 50.4
Capacity Ah/Wh 3.66/185
Weight kg(lb) 1p : 0.9
2p : 1.7
(1.9)
(3.7)
Battery
charger Input VAC 230-240
Rated output V-A 58.1 (4)
Vibration m/s20.7
Throttle Mount Trigger with cruise control
Blower Fan type Centrifugal, single stage
Max. air volume (with pipes)
m3/min ( ft3/min) 10.8 (382)
Max. air velocity (with pipes)
m/s (mph) 72.5 (162)
Discharge ID†62 (2.44)
* Without battery and blower pipes
†ID : Inner diameter
1-2 Technical data
Motor Maximum speed at no load r/min 10,800
Speed control Low (3,000 r/min) / High (8,000 r/min)
Battery Charging time minute 48 (80%) / 88 (100%)
Operating time/one charge* minute 15
* It varies according to work.
1-3 Torque limits
Descriptions Size kgf•cm N•m lbf•in
Motor Fan case M5 40 - 50 4 - 5 35 - 45
Fan LM8 100 - 200 10 - 20 90 - 180
Motor cover M4 20 - 30 2 - 3 18 - 25
Handle Rear Handle M5 25 - 35 2.5 - 3.5 22 - 30
Other Lead terninal M4 20 - 30 2 - 3 18 - 25
Blower grid M5 25 - 35 2.5 - 3.5 22 - 30
LM : Left hand thread

HANDLE GRIP
DPB-600 5
2. TRIGGER SWITCH GRIP
2-1 Trigger switch grip
A
B
C
D
E
F
G
H
A. Handle grip
B. Handle lid
C. Throttle trigger
D. Throttle lever
E. Locknut
F. Switch
G. Wire harness
H. Control board assy
2-2 Disassembling trigger switch grip
1. Remove torx bolts (B) and disassemble the
handle lid (A).
A
B

HANDLE GRIP DPB-600
6
2-2 Disassembling trigger switch grip (Continued)
2. Remove the throttle trigger (C).
3. If control board (D) and switch (E) are damaged,
remove and replace the lead terminal (F) and (G)
with new one.
4. Remove terminal(F) and (G) from switch(E) and
assembly control board (D).
5. If throttle lever (N) is damaged, remove torx bolt
(H), spring washer (J), washer (K), (L) locknut (M)
and throttle lever (N). Replace damaged parts with
new one.
E
D
F
G
N
JK
L
M
H
C
E
D
D
F
E
G

HANDLE GRIP
DPB-600 7
2-3 Resassembling trigger switch grip
1. Install throttle lever (N) on handle lid (A) and
fasten with the torx bolt (H). Check throttle lever (N)
works smoothly and set to the position as shown
(Fig. P : STOP position).
2. The terminal has no locking Tabs on connectors.
Gently push until connector is fully seated on con-
trol board assy (D) and switch (E).
3. Install switch (E), wire harness (t) and control
board (D) on fan case as shown.
6 pole terminals D
E
4 pole terminal
E
Dt
N
H
Fig. P
A

HANDLE GRIP DPB-600
8
2-3 Resassembling trigger switch grip (continued)
4. When installing lead (v) and wire harness (t),
make sure they are installed into the groove part.
5. When installing control board assy (D), attach
control board so that its claw part comes to the left
side as the left figure.
6. Fix throttle trigger (C) on handle. When fixing
it, hook the claw part of the throttle trigger (c) with
handle as shown.
7. Install throttle trigger (C) so as not to be
contacted with wire harness (t). Fit harness (t) into
the groove firmly.
8. Insert the rear end of handle lid (A) into the
motor cover, and fasten torx bolt (V).
9. Align the claw of handle grip with the groove of
handle lid (A), and fasten by torx bolt (B).
A
B
V
D t
v
c
C

MOTOR CASE
DPB-600 9
3. MOTOR CASE
3-1 Motor case
LBP-560-200
LCJQ-560C
*Batteries and charger are handled
as accessories instead of spare parts.
Battery and charger are not serviceable.
H
D
C
B
E
G
A
F
A. Motor assy
B. Stator assy
C. Rotor assy
D. Motor case
E. Motor case
F. Motor cover
G. Lead terminal
H. Control board assy

MOTOR CASE DPB-600
10
3-2 Disassembling motor case
Replace the circuit board in the motor case as the
following procedure.
1. Remove torx bolts (A) and motor case (B).
2. Remove terminals (C), (D), (E), (F) from control
board assy (a).
3. After pull out control board assy (a), remove the
all connected terminals, and remove control board
assy (a) and lead terminal (G), (H).
4. Check the followings, and replace with the new
one in case it has a defect.
1) Breakage of control board assy (a) and
connected other terminals.
2) Breakage or burning of control board assy (a).
3) Disconnection of lead wire breakage of the ter-
minals (G), (H).
A
B
a
CD
E
F
H
G
a
CD
E
F
G
H
a

MOTOR CASE
DPB-600 11
3-3 Reassembling motor case
1. Assemble control board assy to the fan case as
shown and connect couplers of the lead terminal
(C), (D) of the handle lid side each other.
2. Connect assembly motor side coupler (E), (F).
Note: Assemble so that motor's lead wire goes
through the upper part, and lead terminal's lead
wire goes through the bottom as shown. Install
each lead wires without sticking out to the outside
of a case lib (b).
3. Connect couplers of a thick lead wire (G) and (H).
4. Assemble thick lead wire (K), (L) and a
couplers(G), (H) to a motor case as shown.
Note: Assemble the lead wire to the groove of the
motor case surely. Install the connection coupler
so that claw part turns outward (g), (h).
5. Fasten motor cover (B) by torx bolts (A).
G
H
C
D
E
F
b
K
hgL
H
G
(A)
(B)

MOTOR CASE DPB-600
12
3-3 Reassembling motor case (continued)
Note: Install the lib (J) of the motor cover so as not
to run onto the fan case (M) as shown.
J
M

FAN CASE
DPB-600 13
4. FAN CASE
4-1 Fan case
C
A
GF
H
B
E
D
A. Fan case
B. Fan case
C. Rear handle
D. Lever piece
E. Blower grid
F. Blower fan
G. Washer
H. Flange nut

FAN CASE DPB-600
14
4-2 Disassembling fan case
1. Remove torx bolts (A) and blower grid (B).
2. Remove torx bolts (C) from fan case.
3. Remove torx bolt (E) and rear handle (D).
4. Disassemble fan case (F), (G) and remove lead
terminal (H) and lever piece (J).
J
F
G
D
E
E
F
G
H
C
C
C
A
B

FAN CASE
DPB-600 15
4-2 Disassembling fan case (Continued)
1. Remove nut (K) while holding it by hand so
that a blower fan does not turn around (left-hand
thread).
Note : By holding the fan with left hand and
pressing the fan by right thumb with holding a
wrench, power is easily increased to fingers so as
to loosen the nut.
2. After removed nut, tap the shaft of the rotor with
a plastic hammer lightly and remove blower fan (L).
3. Remove torx bolts (M).
4. Remove motor assembly (N).
L
K
M
N

FAN CASE DPB-600
16
4-3 Disassembling motor
When rotation malfunction, abnormal noise and
looseness, since these may be caused by bearing
damage or corrosion of stator part, replace it by
the following procedures.
1. Remove torx bolt (O) and motor case lid (N).
2. Remove rotor assy (P) from motor case lid (N)
in the direction of the arrow.
3. Tap lightly a flange part of the screw aperture (r)
with the plastic hammer (T). And hold stator assy
(S) by hand and remove it from motor case (R) by
shaking it in right and left.
O
O
N
S
NP
R
r
S
r
T
S
R

FAN CASE
DPB-600 17
4-4 Reassembling motor (Service hint)
1. When installing stator assy, place the motor
case on the flat place with making the bottom
section upward, and push it in the arrow direction
by tapping lightly with plastic hammer.
Note : Attach the projection part (A) and (B) of
stator assy so that these match the notch part of
the motor case as shown.
(A) : Wide
(B) : Narrow
2. Attach rotor assy (P) straightly to motion case lid
(N) without tilting it.
N
P
R
A
B

FAN CASE DPB-600
18
4-5 Reassembling fan case (Service hint)
1. Attach motor assy (A) to blower fan (B) so that
the flat part of rotor shaft of the motor assy fits to
the rotor shaft hole of the blower fan.
Note : Take care to install washer (C).
2. Install lever piece (D) as shown.
D
View B
View A
A
B
C
View A View B

BATTERY
DPB-600 19
Battery Charger
When there is abnormality or run out, replace the defective units as required.
The battery comes to have little charge capacity by repeating charge.
By 500 times of charge, charge capacity falls to about 60%, but this is not trouble normally.
5. BATTERY
5-1 Battery and charger
5-2 Battery power indicator
DANGER
Do not dismantle battery and the battery charger.
If dismantle, there is the risk of ignition or explosion and I may lead to
the death or injury.

BATTERY DPB-600
20
5-4 Battery disposal procedure
Battery contains lithium.
Dispose of only at a designated collection point.
Lithium-ion batteries must be recycled or disposed
of properly.
5-3 Charger indicator lights
Will not charge – Try unplugging to reset charger
Green
flash
Green
on
Red
flash
Red
on
Charging
Charging
complete
Will not
charge
Hi / Lo temp
Normal charging
Charging completed. Remove battery pack from charger.
A fully discharged battery will charge in about 72 minuites.
Charger cannot detect battery. Remove battery pack and
clean contacts or terminals. Reinstall battery pack.
Battery pack is above or below normal temperature range.
When battery cools down or warms up, charger will automatically
begin charging
LED indicator will be on or will flash when battery is attached on charger.
