WARNING
Read rules for safe operation and all instructions carefully. ECHO provides this Operator’s
Manual, which must be read and understood for proper and safe operation.
Power Blower
Operator's Manual
MODEL PB-200
X753003041
01/09
X7531135801

2
In t r o d u c t I o n
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-
job-dependability. Read and understand this manual. You will nd it easy to use and full of helpful operating tips and
SAFETY messages.
t h e o p e r a t o r ’sm a n u a l
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specications and information
for operation, starting, stopping, maintenance, storage and assembly
specic to this product.
Copyright© 2009 By Echo, Incorporated
All Rights Reserved.
ta b l e o f co n t e n t s
Introduction................................................................ 2
- The Operator's Manual .......................................2
Safety .........................................................................3
- Manual Safety Symbols and Important
Information .........................................................3
- International Symbols.........................................3
- Personal Condition and Safety Equipment .........3
- Equipment Check................................................6
Emission Control .......................................................6
Description.................................................................7
Contents .....................................................................8
Assembly....................................................................9
- Blower Application.............................................9
Operation....................................................................9
- Fuel .....................................................................9
- Starting Cold Engine......................................... 11
- Starting Warm Engine.......................................12
- Stopping Engine................................................12
- Operating Blower..............................................13
Maintenance.............................................................14
- Skill Levels .......................................................14
- Maintenance Intervals.......................................14
- Air Filter ...........................................................15
- Fuel Filter..........................................................15
- Spark Plug.........................................................16
- Cooling System.................................................16
- Exhaust System.................................................17
- Carburetor Adjustment......................................19
Troubleshooting .......................................................20
Storage .....................................................................21
Specications ...........................................................22
Servicing Information ..............................................24
- Parts/Serial Number..........................................24
- Service ..............................................................24
- ECHO Consumer Product Support...................24
- Warranty Card................................................... 24
- Additional or Replacement Manuals ................24
Specications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.

3
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
I n t e r n a t I o n a l s y m b o l s
SYMBOL
Carburetor Adjust-
ment
- Idle speed
Carburetor Adjust-
ment
- High speed
mixture
Emergency
Stop
Carburetoradjust-
ment
- Low speed
mixture
Ignition
ON/OFF
Primer
Bulb
Choke Control
"Cold Start"
Position
(Choke Closed)
Choke Control
"Run"
Position
(Choke Open)
DESCRIPTION SYMBOL DESCRIPTION
Hot
Surface
Read and under-
stand Operator's
Manual.
Wear eyes, ears
and head protec-
tion
Fuel and oil
mixture
Finger
Severing
Safety/Alert
Wear hand
protection. Use
two handed.
DO NOT smoke
near fuel.
DO NOT allow
ames or sparks
near fuel.
Wear slip resis-
tant foot wear.
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
p e r s o n a l c o n d I t I o n a n d s a f e t y e q u I p m e n t
WARNING
Power Blower users risk injury to themselves and others if the power blower is used improperly or safety precautions
are not followed. Proper clothing and safety gear must be worn when operating a blower.
sa f e t y
m a n u a l s a f e t y s y m b o l s a n d I m p o r t a n t I n f o r m a t I o n
Throughout this manual and on the product itself, you will nd safety alerts and helpful, informational messages preceded
by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.
WARNING
The safety alert symbol accompanied by the word
“WARNING” calls attention to an act or condi-
tion which CAN lead to serious personal injury or
death if not avoided.
CIRCLE AND SLASH SYMBOL
This symbol means the specic action
shown is prohibited. Ignoring these prohi-
bitions can result in serious or fatal injury.
CAUTION
The safety alert symbol accompanied by the word
“CAUTION” calls attention to an act or condition
which may lead to minor or moderate personal
injury if not avoided.
NOTE
This enclosed message provides tips for use, care and
maintenance of the unit.
IMPORTANT
The enclosed message provides information neces-
sary for the protection of the unit.
DANGER
The safety alert symbol accompanied by the word
“DANGER” calls attention to an act or condition
which WILL lead to serious personal injury or
death if not avoided.

4
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your grip on the blower handle. Gloves also reduce the transmission
of machine vibration to your hands.
Breathing Protection
Wear a facemask to protect against dust.
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug tting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DO NOT WEAR SHORTS,
• DO NOT WEAR TIES, SCARVES, and JEWELRY.
Wear sturdy work shoes with nonskid soles:
• DO NOT WEAR OPEN TOED SHOES,
• DO NOT OPERATE UNIT BAREFOOTED.
Keep long hair away from engine and blower intake. Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue, which may lead to heat stroke. Schedule heavy work for early
morning or late afternoon hours when temperatures are cooler.
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which affects the ngers of certain individuals, may be
brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sen-
sations, followed by loss of color and numbness in the ngers. The following precautions are strongly recommended,
because the minimum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to ll each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the ngers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.

5
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual
and Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animals prevented from coming nearer than 15 m (50 ft.) while
the unit is in use.
• Take wind conditions into account: avoid open doors and win-
dows.
• Do not point blower at people or animals.
Keep a Firm Grip
• Hold the front and rear handles with both hands, with thumbs
and ngers encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slip-
pery, uneven or unstable surfaces. Do not work in odd positions
or on ladders. Do not over reach.
Avoid Hot Surfaces
• Keep exhaust area clear of ammable debris. Avoid contact dur-
ing and immediately after operation.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the ngers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high
risk for developing a Repetitive Stress Injury (RSI). An extreme RSI condition is Carpal Tunnel Syndrome (CTS), which
could occur when your wrist swells and squeezes a vital nerve that runs through the area.
Some believe that prolonged exposure to vibration may contribute to CTS. CTS can cause severe pain for months or
even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead try to maintain a straight wrist position. Also, when
grasping, use your whole hand, not just the thumb and index
nger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doc-
tor if you feel tingling, numbness, or pain in the ngers, hands,
wrists, or arms. The sooner RSI/CTS is diagnosed, the more
likely permanent nerve and muscle damage can be prevented.

6
e q u I p m e n t c h e c k
WARNING
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combi-
nation. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have
not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety
manual.
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed.
• Do not use blower if any part is missing or damaged.
• Have repairs done only by an authorized ECHO Service dealer.
• Do not use any attachment, accessory or replacement part unless it is recommended in this Operator's Manual.
WARNING
Moving parts can amputate ngers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings.
• ALWAYS stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing unit.
• DO NOT start or operate unit unless all guards and protective covers are properly assembled to unit.
• NEVER reach into any opening while the engine is running. Moving parts may not be visible through openings.
WARNING
Check fuel system for leaks due to fuel tank damage, especially if the unit is dropped. If damage or leaks are found,
do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an authorized
servicing dealer before using.
em I s s I o n co n t r o l (e x h a u s t & e v a p o r a t I v e )
EPA Phase 2 / CARB TIER III
The emission control system for the engine is EM/TWC (Engine Modication and 3-way Catalyst) and for the fuel tank
the Control System is EVAP (Evaporative Emissions) or N (for nylon tank). Evaporative emission may be applicable to
California models only.
An Emission Control Label is located on the engine.
(This is an EXAMPLE ONLY; information on label var-
ies by engine FAMILY).
PRODUCT EMISSION DURABILITY (EMISSION COMPLIANCE PERIOD)
The 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine
emissions output meets applicable emissions regulations, provided that approved maintenance procedures are
followed as listed in the Maintenance Section of this manual.
Important enGIne InformatIon
enGIne famIly: 8ehxs.0214kG dIsplacement: 21.2 c c
emIssIon complIance perIod : 300 hrs.
thIs enGIne meets u.s. epa ph2 exh and 2007 and
later calIfornIa exh and evap emIssIon reGula-
tIons for s.o.r.e.. refer to oWner's manual for
maIntenance specIfIcatIons and adJustments.

7
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
1
2
3
4
5
6
7
8
10
9
11
P/N 89016009461
65 Category I
dB(A)
Measured at 50 ft. (15m) per ANSI B175.2
P/N X508000120
Sound Label (located on blower housing)
de s c r I p t I o n
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc-
tions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING
instructions for specic information.
Hot Decal (near mufer)
P/N X505002310
General Warning Decal (located on top of blower housing)

8
1. STOP SWITCH - "SLIDE SWITCH" mounted on top of handle. Push forward to start and run. Slide back to stop.
2. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration, press trigger gradu-
ally for best operating technique.
3. SPARK PLUG - Provides spark to ignite fuel mixture.
4. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER -The mufer or catalytic mufer controls
exhaust noise and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the
mufer. Keep exhaust area clear of ammable debris.
5. RECOIL STARTER HANDLE - Pull recoil handle slowly until recoil starter engages, then quickly and rmly.
When engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
6. FUEL TANK CAP - Covers and seals fuel tank.
7. AIR CLEANER - Contains replaceable air lter element.
8. THROTTLE POSITION LEVER - Pull back to increase engine speed. Friction washers maintain throttle lever
setting.
9. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from
the carburetor. Pump purge bulb until fuel is visible and ows freely in the clear fuel tank return line. Pump purge
bulb an additional 4 or 5 times.
10. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close
choke for cold starting. Move choke lever to "RUN" ( ) position to open choke.
11. BLOWER PIPES - Twist lock design.
co n t e n t s
1 - Power Head
1 - Blower Pipe Assembly
1 - Operator's Manual
1 - Warranty Registration Card
1 - ECHO Emissions and Warranty Statement
1 - Echo Power BlendX TM 2-stroke oil sample

9
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
NOTICE: Use of unmixed, improperly mixed, or fuel older than 90 days, (stale fuel), may cause hard starting, poor
performance, or severe engine damage and void the product warranty. Read and follow instructions in the Storage
section of this manual.
f u e l
WARNING
Alternative fuels, such as E-20 (20% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements are
NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance prob-
lems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to,
improper clutch engagement. Alternative fuels may also cause premature deterioration of fuel lines, gaskets, carbu-
retors and other engine components.
as s e m b l y
WARNING
Never perform maintenance or assembly procedures with engine
running or serious personal injury may result.
b l o W e r a p p l I c a t I o n
Install Blower Pipes
1. Align grooves in straight pipe with pegs on blower housing and
slide pipe onto housing.
2. Turn straight pipe clockwise to lock into place.
3. Align grooves in fan head nozzle with pegs on straight pipe and
slide fan head nozzle onto straight pipe.
4. Turn fan head nozzle clockwise to lock into place.
op e r a t I o n
WARNING
Moving parts can amputate ngers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing unit. Blower housing may contain shredder blades and
other sharp edges that can cause serious injuries if touched, even if engine is off and blades are not moving. Wear
gloves to protect hands from sharp edges and hot surfaces.
WARNING
Operation of this equipment may create sparks that can start res around dry vegetation. This unit is equipped
with a spark arrestor and a spark arrestor may be required. The operator should contact local re agencies for
laws or regulations relating to re prevention requirements.

10
Handling Fuel
DANGER
Fuel is VERY ammable. Use extreme care when mixing, storing
or handling or serious personal injury may result.
• Use an approved fuel container.
• DO NOT smoke near fuel.
• DO NOT allow ames or sparks near fuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVER refuel a unit when the engine is HOT or RUNNING!
• DO NOT ll fuel tanks indoors. ALWAYS ll fuel tanks outdoors
over bare ground.
• DO NOT overll fuel tank. Wipe up spills immediately.
• Securely tighten fuel tank cap and close fuel container after refu-
eling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
• Move at least 3m (10 ft.) from refueling location before starting
the engine.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount
of gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Add remaining gasoline, close fuel container, and remix.
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.
After use
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to an
approved fuel storage container.
Storage - Fuel storage laws vary by locality.
Contact your local government for the laws
affecting your area. As a precaution, store
fuel in an approved, airtight container. Store
in a well-ventilated, unoccupied building,
away from sparks and ames.
IMPORTANT
Stored fuel ages. Do not mix more
fuel than you expect to use in thirty
(30) days, ninety (90) days when a
fuel stabilizer is added.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container thor-
oughly before each use.
Fuel Requirements
Gasoline - Use 89 Octane [R+M/2] (mid grade or higher) gasoline
known to be good quality. Gasoline may contain up to 10% Ethanol
(grain alcohol) or 15% MTBE (methyl tertiary-butyl ether). Gasoline
containing methanol (wood alcohol) is NOT approved.
Two Stroke Oil - A two-stroke engine oil meeting ISO-L-EGD (ISO/
CD 13738) and JASO M345/FC/FD Standards must be used. ECHO
brand premium Power Blend X TM Universal 2-Stroke Oil meets these
standards. Engine problems due to inadequate lubrication caused by
failure to use an ISO-L-EGD (ISO/CD 13738) and JASO M345/FC/
FD certied oil, such as ECHO premium Power Blend X TM, will void
the two-stroke engine warranty.
IMPORTANT
Echo premium Power Blend TM Universal 2-Stroke Oil may be
mixed at 50:1 ratio for application in all Echo engines sold in the
past regardless of ratio specied in those manuals.
Shoulder
level
Fuel tank

11
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
s t a r t I n G c o l d e n G I n e
• Provide all operators of this equipment with the Operator's Manual
and instructions for safe operation.
• Before starting the unit, equip yourself and any other person work-
ing within the 15 m (50 ft.) Safety Zone with the required Protective
Equipment and clothing.
1. Stop Switch
Move stop switch button (A) away from the STOP position.
2. Throttle Position
Move throttle position lever (B) midway between idle and full
throttle positions.
A
B
3. Choke
Move choke (C) to "Cold Start" ( ) Position.
4. Purge Bulb
Pump purge bulb (D) until fuel is visible and ows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
IMPORTANT
Recoil starter: Use short pulls - only 1/2-2/3 of rope for start-
ing. Do not allow the rope to snap back in. Always hold the unit
rmly.
5. Recoil Starter
Place the unit on a at, clear area. Firmly grasp throttle grip with
left hand and rapidly pull recoil starter handle/rope (E) until en-
gine res (5 pulls maximum).
6. Choke
After engine res (or 5 pulls), move choke lever to “Run” ( )
position and pull starter handle/rope until engine starts and runs.
Allow unit to warm up at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions 2- 5.
7. After engine warm up, gradually depress throttle trigger to in-
crease engine RPM to operating speed.
C
D
E

12
A
B
E
s t a r t I n G W a r m e n G I n e
The starting procedure is the same as Cold Start except DO NOT close
the choke.
1. Stop Switch
Move stop switch button (A) away from the STOP position.
2. Throttle Position
Move throttle position lever (B) midway between idle and full
throttle positions.
3. Recoil Starter
Place the unit on a at clear area. Firmly grasp throttle grip with
left hand and rapidly pull recoil starter handle/rope (E) until en-
gine res.
IMPORTANT
Recoil starter: Use short pulls - only 1/2-2/3 of rope for start-
ing. Do not allow the rope to snap back in. Always hold the unit
rmly.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
s t o p p I n G e n G I n e
1. Throttle Trigger/Throttle Position Lever
Release throttle trigger (F). Move throttle position lever (B)
forward to idle position and allow engine to return to idle before
shutting engine off.
2. Stop Switch
Move stop switch (B) to "Stop" position.
WARNING
If engine does not stop when stop switch is moved to STOP posi-
tion, close choke - COLD START position - to stall engine. Have
your ECHO dealer repair stop switch before using blower again.
.
A
F
B

13
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
BA
o p e r a t I n G b l o W e r
WARNING
Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a
poison gas. Breathing CO can cause unconsciousness, serious in-
jury, or death. Exhaust can cause serious burns. ALWAYS position
unit so that exhaust is directed away from your face and body.
WARNING
Always wear safety glasses, hearing protection and a face lter
mask or serious personal injury may result. Do not point the blower
pipe in the direction of people or pets.
Read the Safety Section carefully.
IMPORTANT
To avoid engine damage due to over-revving, do not block
blower pipe.
1. Use only during appropriate hours.
2. Allow the engine to warm up at a fast idle for a few minutes.
3. Control engine speed with throttle trigger (F), or for continu-
ous use, set engine speed with throttle position lever (B). Rotate
throttle position lever forward for lower speed, back for higher
speed.
4. Use lower speed to blow debris from hard surfaces.
5. Additional speed may be necessary to clean debris, snow, etc.
from lawns and owerbeds.
NOTE
Never use a higher speed setting than necessary to perform a task.
Remember, the higher the engine speed, the louder the blower
noise. Minimize dust by using blower at lower speeds. Keep debris
on your property.
Be Smart - be a good neighbor.

14
Your ECHO blower is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your blower achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have
the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.
s k I l l l e v e l
Level 1 = Easy to do. Common tools may be required.
Level 2 = Moderate difculty. Some specialized tools may be required.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier.
m a I n t e n a n c e I n t e r v a l s
WARNING
Moving parts can amputate ngers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing unit. Allow unit to cool before performing service. Wear
gloves to protect hands from sharp edges and hot surfaces.
ma I n t e n a n c e
COMPONENT / SYSTEM MAINTENANCE
PROCEDURE
REQ'D
SKILL
LEVEL
DAILY OR
BEFORE USE
EVERY
REFUEL
3 MONTHS
OR 90
HOURS
YEARLY
600 HOURS
Air Filter Inspect/Clean 1I / C * R *
Choke Shutter Inspect/Clean 1I / C
Fuel Filter Inspect/Replace 1I * I / R *
Fuel Cap Gasket Inspect/Replace 1I * R *
Fuel System Inspect/Replace 1I (1) * I (1) *
Spark Plug Inspect/Clean/Replace 1I / C / R *
Cooling System Inspect/Clean 2I / C
Muffler Spark Arrestor Inspect/Clean/Replace 2I / C / R *
Cylinder Exhaust Port Inspect/Clean/Decarbon 2I / C
Recoil Starter Rope Inspect/Clean 1I / C *
Screws/Nuts/Bolts Inspect/Tighten/Replace 1I *
MAINTENANCE PROCEDURE LETTER CODES: I = INSPECT, R = REPLACE, C = CLEAN
IMPORTANT NOTE - Time intervals shown are maximum. Actual use and your experience will determine the
frequency of required maintenance.
MAINTENANCE PROCEDURE NOTES:
(1) Low evaporative fuel tanks DO NOT require regular maintenance to maintain emission integrity.
* All recommendations to replace are based on the finding of damage or wear during inspection.

15
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
a I r f I l t e r
Level 1.
Tools required: 25-50 mm (1-2 in.) Cleaning brush.
Parts required: REPOWERTM Air and Filter Kit
NOTE
Clean daily.
1. Close choke (Cold Start Position [ ]). This prevents dirt from
entering the carburetor throat when the air lter is removed. Brush
accumulated dirt from air cleaner area.
2. Remove air lter cover. Brush dirt from inside cover.
3. Remove air lter and lightly brush debris from lter. Replace
lter if it is damaged, fuel soaked, very dirty, or the rubber sealing
edges are deformed.
4. If lter can be reused, be certain it:
• Fits tightly in the air lter cavity.
• Is installed with the original side out.
5. Install air lter cover.
f u e l f I l t e r
Level 1.
Tools required: 200-250 mm (8-10 in.) length of wire with one end
bent into a hook, Clean rag, funnel, and an approved
fuel container.
Parts required: REPOWERTM Air and Filter Kit
WARNING
Fuel is VERY ammable. Use extreme care when mixing, storing
or handling.
1. Use a clean rag to remove loose dirt from around fuel cap and
empty fuel tank.
2. Use the “fuel line hook” to pull the fuel line and lter from the
tank.
3. Remove the lter from the line and install the new lter.

16
s p a r k p l u G
Level 2.
Tools required: 3/4 in. Spark Plug deep socket, Feeler gauge
Parts Required: REPOWERTM Tune-Up Kit
IMPORTANT
Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada)
otherwise severe engine damage may occur.
1. Remove spark plug and check for fouling, worn and rounded
center electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean. Remaining sand will damage engine.
3. Adjust spark plug gap by bending outer electrode.
4. Tighten spark plug to 150-170 kgf • cm (130-150 in • lbf).
c o o l I n G s y s t e m
Level 2.
Tools required: 25-50 mm (1-2 in.) Cleaning brush, 3 mm Hex
Wrench, Cross Head Screwdriver
Parts Required: None, if you are careful.
IMPORTANT
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder n area. This ow of air carries
combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes are blocked, preventing cooling air from reaching the
cylinder.
• Dust and grass build up on the outside of the cylinder. This build up
insulates the engine and prevents the heat from leaving.
Removal of cooling passage blockages or cleaning of cooling ns is
considered “Normal Maintenance”. Any failure attributed to lack of
maintenance is not warranted.
Cleaning Grill
1. Brush accumulated debris from crankcase intake grill above the
fuel tank.
INTAKE
GRILL
0.65 mm
(0.026 in.)

17
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
Cleaning Cylinder Fins
1. Remove spark plug lead and spark plug.
2. Remove two upper 3 mm hex screws at recoil starter.
3. Remove engine cover (ve screws), pull cover away from engine.
Loosely install spark plug to prevent dirt from entering cylinder.
Clean cylinder ns to allow cooling air to pass freely.
4. Remove spark plug and loosely reassemble engine cover with ve
cross head and two hex head screws.
5. Tighten all screws securely.
6. Install spark plug and spark plug lead.
e x h a u s t s y s t e m
Spark Arrestor Screen
Level 2.
Tools required: Cross Head Screwdriver, 3 mm Hex Wrench, Soft
metal brush
Parts Required: Spark arrestor screen, Gasket
IMPORTANT
Carbon deposits in mufer will cause a drop in engine output and
overheating. Spark arrestor screen must be checked periodically.
1. Remove spark lead and spark plug.
2. Remove two upper 3 mm hex screws at recoil starter.
3. Remove ve engine cover screws and remove cover from engine.
4. Remove spark arrestor covers (A, B), gasket (C) and spark ar-
restor screen (D) from mufer. Replace screen if plugged with
carbon deposits.
NOTE
When cleaning carbon deposit, be careful not to damage the cata-
lytic element inside mufer.
5. Install spark arrestor screen, gasket, and covers.
6. Loosely reassemble engine cover with ve cross head and two
hex head screws.
7. Tighten all screws securely.
8. Install spark plug and spark plug lead.
DC
B
A

18
A
Exhaust Port Cleaning
Level 2.
Tools required: 4 mm Hex Wrench., Wood or plastic scraper
Parts Required: As needed: Heat Shield
1. Remove engine cover. (See "Cleaning Cylinder Fins for step by
step instructions)
2. Place piston at top dead center. Remove mufer (A), heat shield
(B), and eyeplate (C).
3. Use a wood or plastic scraping tool to clean deposits from cylin-
der exhaust port.
IMPORTANT
Never use a metal tool to scrape carbon from the exhaust port.
Do not scratch the cylinder or piston when cleaning the exhaust
port. Do not allow carbon particles to enter the cylinder.
4. Inspect heat shield, and replace if damaged.
5. Install heat shield, mufer, and eyeplate.
6. Tighten mufer mounting bolts (or nuts) to 80-95 in•lbf (90-110
kgf•cm).
7. Install engine cover and attach spark plug lead.
8. Start engine, and warm to operating temperature.
9. Stop engine, and re-tighten mounting bolts (or nuts) to specica-
tions.
B
c

19
Po w e r Bl o w e r
oP e r a t o r 'sMa n u a l
c a r b u r e t o r a d J u s t m e n t
Engine Break-In
New engines must be operated a minimum duration of two tanks of fuel
break-in before carburetor adjustments can be made. During the break-
in period your engine performance will increase and exhaust emissions
will stabilize. Idle speed can be adjusted as required.
High Altitude Operation
This engine has been factory adjusted to maintain satisfactory starting,
emission, and durability performance up to 1,100 feet mean sea level
(MSL) (96.0 kPa and below). To maintain proper engine operation and
emission compliance above 1,100 feet MSL the carburetor may need to
be adjusted by an authorized ECHO service dealer.
IMPORTANT
If the engine is adjusted for operation above 1,100 feet MSL, the
carburetor must be re-adjusted when operating the engine below
1,100 feet MSL, otherwise severe engine damage can result.
Level 2.
Tools required: Screwdriver, tachometer (Echo P/N 99051130017)
Parts required: None.
NOTE
Every unit is run at the factory and the carburetor is set in com-
pliance with emission regulations. This carburetor does not have
acceleration and high speed adjustment needles.
1. Before adjusting the carburetor, clean or replace the air lter and
spark arrestor screen and blower pipes are installed.
2. Start engine and run for several minutes to reach operating tem-
perature.
3. Stop engine. Turn red HI speed needle (A) CCW (counter clock-
wise) to stop.
4. Idle Speed Adjustment with tachometer.
•Start engine and turn “idle” speed adjustment screw (B) to idle
RPM found on page 22 in the "Specications" section of this
manual.
5. Accelerate to full throttle for 2-3 seconds to clear excess fuel from
engine then return to idle. Accelerate to full throttle to check for
smooth transition from idle to full throttle. If engine stops or
stalls after full warm up return the unit to your authorized ECHO
dealer for repair.
6. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed
RPM should be set to specications found on page 22 "Specica-
tions" of this manual.
7. Check idle speed and reset if necessary.
A
B

20
tr o u b l e s h o o t I n G
DANGER
Fuel vapors are extremely ammable and may cause re and/or explosion. Never test for ignition spark by ground-
ing spark plug near cylinder plug hole, otherwise serious personal injury may result.
TRAHCGNITOOHSELBUORT
melborPkcehCsutatSesuaCydemeR
-sknarcenignE
/drahstrats
t'nseod
trats
roterubractaleuFroterubractaleufoNdeggolcreniartsleuF
deggolcenilleuF
roterubraC
ecalperronaelC
ecalperronaelC
relaedohcEruoyeeS
rednilyctaleuFrednilyctaleufoNroterubraCrelaedohcEruoyeeS
leufhtiwtewrelffuMhcirooterutxiMleuFekohcnepO
retlifriaecalper/naelC
roterubractsujdA
relaedohcEruoyeeS
dnetakrapS
eriwgulpfo
krapsoNffohctiwspotS
melborp
lacirtcelE
hctiwskcolretnI
NOothctiwsnruT
relaedohcEruoyeeS
relaedohcEruoyeeS
gulptakrapSkrapsoNtcerrocnipagkrapS
nobrachtiwderevoC
leufhtiwdeluoF
evitcefedgulP
).ni620.0(mm56.ottsujdA
ecalperronaelC
ecalperronaelC
gulpecalpeR
,snurenignE
roseidtub
tonseod
etarelecca
ylreporp
retlifriAytridretlifriAraewlamroNecalperronaelC
retlifleuFytridretlifleuFseudiser/stnanimatnoCni
leuf
ecalpeR
tnevleuFdeggulptnevleuFleufniseudiser/stnanim
atnoCecalperronaelC
gulPkrapSnrow/ytridgulPraewlamroNecalperrotsujdadnanaelC
roterubraCtnemtsujdareporpmInoitarbiVtsujdA
metsySgnilooCmetsysgnilooC
deggulp/ytrid
ninoitarepodednetxE
snoitacolytsud/ytrid
naelC
neercSrotserrAkrapSneercsrotserrakrapS
deggulp
raewlamroNecalpeR
seodenignE
knarcton
A/NA/NmelborpenignelanretnIrelaedohcEruoyeeS
,snurenignE
t'nseodrewolb
sirokrow
nevenu/kaew
epiprewolBdeggolcepiPsirbedfopu-dliuBgolcnU
esool
epiPnoitarbiVnethgiT
degamadepiPesusiM/raeWecalpeR
