Echo PB-620 User manual

Power Blower
Operator's Manual
MODEL PB-620
WARNING
Readrulesforsafeoperationandallinstructionscarefully. ECHOprovidesthis
Operator's Manual, which must be read and understood for proper and safe operation.
X753002803
01/09
X7531122203

2
Copyright© 2009 By Echo, Incorporated
All Rights Reserved.
THE OPERATOR'SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specifications and information for
operation, starting, stopping, maintenance, storage, and assembly
specific to this product.
TABLE OF CONTENTS
Introduction ................................................................... 2
- The Operator's Manual ........................................... 2
Safety ............................................................................. 3
- Manual Safety Symbols and Important Information 3
- International Symbols ............................................. 3
- Personal Condition and Safety Equipment ............. 3
- Equipment Check .................................................... 6
Emission Control ............................................................ 6
Description .................................................................... 7
Contents ........................................................................ 9
Assembly ....................................................................... 9
- Install Blower Pipes ................................................ 9
Operation ..................................................................... 10
- Fuel ....................................................................... 10
- Starting Cold Engine ............................................. 12
- Starting Warm Engine .......................................... 13
- Stopping Engine ................................................... 13
- Operating Blower ................................................. 14
Maintenance ................................................................ 15
- Skill Levels .......................................................... 15
- Maintenance Intervals .......................................... 15
- Air Filter ............................................................... 16
- Fuel Filter ............................................................. 16
- Spark Plug ............................................................ 17
- Cooling System .................................................... 17
- Exhaust System .................................................... 18
- Carburetor Adjustment ........................................ 20
Troubleshooting .......................................................... 22
Storage ......................................................................... 23
Specifications.............................................................. 24
Servicing Information ................................................. 28
- Parts ..................................................................... 28
- Service .................................................................. 28
- ECHO Consumer Product Support ...................... 28
- Warranty Registration .......................................... 28
- Additional or Replacement Manuals ................... 28
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and
SAFETY messages.

3
POWER BLOWER
OPERATOR'SMANUAL
INTERNATIONAL SYMBOLS
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING
Power Blower users risk injury to themselves and others if the power blower is used improperly or safety precautions
are not followed. Proper clothing and safety gear must be worn when operating a blower.
SYMBOL
Carburetor
Adjustment
-Idlespeed
Carburetor
Adjustment
- High speed
mixture
Stop
Carburetor
adjustment
- Low speed
mixture
Ignition
ON/OFF
Purge
Bulb
Choke Control
"Cold Start"
Position
(Choke Closed)
Choke Control
"Run"
Position
(Choke Open)
DESCRIPTION SYMBOL DESCRIPTION
Hot
Surface
Read and under-
stand Operator's
Manual.
Wear eyes, ears
and head
protection
Fuel and oil
mixture
Finger
Severing
Safety/Alert
Wear hand
protection. Use
two handed.
DO NOT smoke
near fuel.
DO NOT allow
flames or sparks
near fuel.
Wear slip
resistant foot
wear.
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
Idle Speed Fast Speed
SAFETY
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages
preceded by symbols or key words. The following is an explanation of those symbols and key words and what they
mean to you.
WARNING
Thesafety alert symbol accompaniedby the word
“WARNING” calls attention to an act or condition
which CAN lead to serious personal injury or death
ifnotavoided.
CIRCLE AND SLASH
SYMBOL
This symbol means the specific action
shown is prohibited. Ignoring these
prohibitions can result in serious or fatal
injury.
CAUTION
Thesafety alert symbol accompaniedby the word
“CAUTION” calls attention to an act or condition
which may lead to minor or moderate personal injury
ifnotavoided.
NOTE
This enclosed message provides tips for use, care
and maintenance of the unit.
IMPORTANT
The enclosed message provides information
necessary for the protection of the unit.
DANGER
Thesafety alert symbol accompaniedby the word
“DANGER” calls attention to an act or condition
which WILL lead to serious personal injury or death
ifnotavoided.

4
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your grip on the blower handle. Gloves also reduce the transmission
of machine vibration to your hands.
Breathing Protection
Wear a facemask to protect against dust.
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOT WEARSHORTS,
• DONOT WEAR TIES,SCARVES,and JEWELRY.
Wear sturdy work shoes with nonskid soles:
• DONOT WEAR OPENTOED SHOES,
• DONOTOPERATEUNITBAREFOOTED.
Keep long hair away from engine and blower intake. Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue, which may lead to heat stroke. Schedule heavy work for early
morning or late afternoon hours when temperatures are cooler.
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be
brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning
sensations, followed by loss of color and numbness in the fingers. The following precautions are strongly recom-
mended, because the minimum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physi-
cian before further exposing yourself to cold and vibration.

5
POWER BLOWER
OPERATOR'SMANUAL
DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual
and Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animals prevented from coming nearer than 15 m (50 ft.) while the
unit is in use.
• Take wind conditions into account: avoid open doors and
windows.
• Do not point blower at people or animals.
Keep a Firm Grip
• Hold the front and rear handles with both hands, with thumbs
and fingers encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on
slippery, uneven or unstable surfaces. Do not work in odd
positions or on ladders. Do not over reach.
Avoid Hot Surfaces
• Keep exhaust area clear of flammable debris. Avoid contact
during and immediately after operation.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high
risk for developing a Repetitive Stress Injury (RSI). An extreme RSI condition is Carpal Tunnel Syndrome (CTS), which
could occur when your wrist swells and squeezes a vital nerve that runs through the area.
Some believe that prolonged exposure to vibration may contribute to CTS. CTS can cause severe pain for months or
even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead try to maintain a straight wrist position. Also, when
grasping, use your whole hand, not just the thumb and index
finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a
doctor if you feel tingling, numbness, or pain in the fingers,
hands, wrists, or arms. The sooner RSI/CTS is diagnosed, the
more likely permanent nerve and muscle damage can be pre-
vented.

6
EQUIPMENT CHECK
WARNING
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which
have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and
safety manual.
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed.
• Do not use blower if any part is missing or damaged.
• Have repairs done only by an authorized ECHO Service dealer.
• Do not use any attachment, accessory or replacement part unless it is recommended in this Operator's Manual.
An Emission Control Label is located on the unit.
(This is an EXAMPLE ONLY, information on label
varies by engine FAMILY).
IMPORTANT ENGINE INFORMATION
ENGINE FAMILY: 9EHXS.0585KA DISPLACEMENT: 58.2 CC
EMISSION COMPLIANCE PERIOD : 300 HRS.
THIS ENGINE MEETS U.S. EPA PH2 EXH AND 2007 AND
LATER CALIFORNIA EXH AND EVAP EMISSION REGULA-
TIONS FOR S.O.R.E.. REFER TO OWNER'S MANUAL FOR
MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.
WARNING
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings.
•ALWAYS stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing unit.
•DO NOT start or operate unit unless all guards and protective covers are properly assembled to unit.
•NEVER reach into any opening while the engine is running. Moving parts may not be visible through openings.
EMISSION CONTROL (EXHAUST & EVAPORATIVE)
EPA Phase 2 / C.A.R.B. TIER III
The emission control system for the engine is EM/TWC (Engine Modification and 3-way Catalyst) and for the fuel
tank the Control System is EVAP (Evaporative Emissions) or N (for nylon tank). Evaporative emission may be appli-
cable to California models only.
PRODUCT EMISSION DURABILITY (EMISSION COMPLIANCE PERIOD)
The 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine
emissions output meets applicable emissions regulations, provided that approved maintenance procedures are
followed as listed in the Maintenance Section of this manual.
WARNING
Check fuel system for leaks due to fuel tank damage, especially if the unit is dropped. If damage or leaks are found,
do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an autho-
rized servicing dealer before using.

7
POWER BLOWER
OPERATOR'SMANUAL
Locate the safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc-
tions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING
instructions for specific information.
DESCRIPTION
1
2
3
4
5
6
7
10
15
11
12
13
14
Hot Decal (near muffler)
P/N X505002310
P/N 89016009461
General Warning Decal (located on top of blower housing)
Return to Idle
P/N X505000950
RETURN TO IDLE
BEFORE
SHUTTING OFF
Sound Label (located on blower housing)
72 Category III
dB(A)
Measured at 50 ft. (15m) per ANSI B175.2
P/N X508000150
8
9

8
1. SAFETY DECAL - Lists important safety precautions.
2. SPARK PLUG - Provides spark to ignite fuel mixture.
3. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER - The muffler or catalytic muffler controls
exhaust noise and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the
muffler. Keep exhaust area clear of flammable debris.
4. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then quickly and firmly. When
engine starts, return handle slowly. DO NOT let handle snap back, or damage to unit will occur.
5. AIR CLEANER - Contains replaceable air filter element.
6. FUEL TANK CAP - Covers and seals fuel tank.
7. SHOULDER HARNESS - Used to support unit on operator's back. The straps are adjustable.
8. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close
choke for cold starting. Move choke lever to "RUN" ( ) position to open choke.
9. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from
the carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb
an additional 4 or 5 times.
10. LOCKING KNOB - Allows operator to adjust handle position for optimum comfort and control.
11. HANDLE - Used by operator to direct and control air flow.
12. COMBINATION THROTTLE POSITION /STOP SWITCH BUTTON - Controls engine speed and turns
ignition on or off. Forward position - STOP. First detent position - IDLE. Move button back to increase speed,
forward to decrease speed. Use Throttle Position Button to set and hold blower speed for continuous operation.
13. THROTTLE TRIGGER - Spring-loaded Throttle Trigger controls engine speed. Releasing Trigger returns
engine to speed setting set by Throttle Position Stop Switch Button. Always release trigger and allow engine to
return to idle before shutting off with Throttle Position Stop Switch Button. Use Throttle Trigger to vary blower
speed settings for intermittent operation.
14. BLOWER PIPES - Exclusive positive locking system.
15. FLEXIBLE PIPE - Allows for full range of movement.

9
POWER BLOWER
OPERATOR'SMANUAL
CONTENTS
___ 1 - Power Head
___ 1 - FlexPipe
___ 1 - Pipe w/swivel
___ 1 - Straight Pipe
___ 1 - Straight Pipe w/decal
___ 1 - Operator's Manual
___ 1 - Warranty Registration Card
___ 1 - ECHO Emissions and Warranty Statement
___ 1 - Plastic Bag
___ 2 - Clamps w/screws
___ 1 - Guide Loop
___ 1 - Echo Power Blend X TM 2-stroke oil sample
WARNING
Never perform maintenance or assembly procedures with engine
running or serious personal injury may result.
INSTALL BLOWER PIPES
1. Place guide loop (G) across elbow clamp, and turn until clips
fully engage clamp band.
2. Assemble clamps (A) onto both ends of flexible pipe (B).
NOTE
Clamp with cable guide loop (G) fits elbow end of flexible pipe.
3. Assemble swivel pipe (C) into flexible pipe (B).
NOTE
Assure throttle cable is not twisted before installing handle (E).
4. Position cable between the elbow (D) and frame and along the
top of the flexible pipe. Loosen knob (H) on handle (E). Align
notch in handle with tabs (F). Install onto swivel pipe (C) past
long ridges in pipe.
ASSEMBLY
GG
E
B
H
F
D
G
AA
B
C

10
5. Assemble flexible pipe (B) to elbow (D) on blower and tighten
clamps (A). Position guide loop (G) on inside (blower side) of
flexible tube.
NOTE
A light lubricant may be used to ease assembly of flexible pipe to
blower elbow.
6. Clip throttle cable into throttle cable guide loop (G).
7. Move handle (E) to desired position. Tighten knob (H) hand
tight.
8. Assemble straight pipe (I) onto swivel pipe (C), until you feel
light resistance. Do not force connection. Hold swivel pipe and
turn straight pipe clockwise, engaging positive locking channels,
until connection is firm. Do not force connection.
9. Assemble straight pipe with decal (J) to straight pipe (I) as in
step 8.
NOTE
Blower use will eventually loosen pipe connections. Exclusive
positive locking system allows pipes to be tightened. If loosening
occurs, remove two straight pipes and install according to instruc-
tions 8 & 9.
OPERATION
G
EI
J
C
E
H
WARNING
Operation of this equipment may create sparks that can start fires around dry vegetation. This unit is equipped with a
spark arrestor and a spark arrestor may be required. The operator should contact local fire agencies for laws or
regulations relating to fire prevention requirements.
FUEL
NOTICE: Use of unmixed, improperly mixed, or fuel older than 90 days, (stale fuel), may cause hard starting, poor
performance, or severe engine damage and void the product warranty. Read and follow instructions in the Storage
section of this manual.
WARNING
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete
stop before removing obstructions, clearing debris, or servicing unit. Blower housing may contain shredder blades
and other sharp edges that can cause serious injuries if touched, even if engine is off and blades are not moving.
Wear gloves to protect hands from sharp edges and hot surfaces.

11
POWER BLOWER
OPERATOR'SMANUAL
Fuel Requirements
Gasoline - Use 89 Octane [R+M/2] (mid grade or higher) gasoline known to be good quality. Gasoline may contain up
to 10% Ethanol (grain alcohol) or 15% MTBE (methyl tertiary-butyl ether). Gasoline containing methanol (wood
alcohol) is NOT approved.
Two Stroke Oil - A two-stroke engine oil meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FC/FD Standards must
be used. Echo brand premium Power Blend X TM Universal 2-Stroke Oil meets these standards. Engine problems due
to inadequate lubrication caused by failure to use anSO-L-EGD (ISO/CD 13738) and J.A.S.O. FC/FD certified oil,
such as Echo premium Power Blend X TM, will void the two-stroke engine warranty.
IMPORTANT
Echo premium Power Blend X TM Universal 2-Stroke Oil may be mixed at 50:1 ratio for application in all Echo
engines sold in the past regardless of ratio specified in those manuals.
HandlingFuel
DANGER
Fuel is VERY flammable. Use extreme care when mixing, storing or handling or serious personal injury may
result.
• Use an approved fuel container.
• DO NOT smoke near fuel.
• DO NOT allow flames or sparks near fuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps slowly allowing pressure to equalize.
• NEVER refuel a unit when the engine is HOT or RUNNING!
• DO NOT fill fuel tanks indoors. ALWAYS fill fuel tanks outdoors over bare ground.
• DO NOT overfill fuel tank. Wipe up spills immediately.
• Securely tighten fuel tank cap and close fuel container after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or operate unit until leakage is repaired.
• Move at least 3m (10 ft.) from refueling location before starting the engine.
WARNING
Alternative fuels, such as E-20 (20% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements
are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance
problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not
limited to, improper clutch engagement. Alternative fuels may also cause premature deterioration of fuel lines,
gaskets, carburetors and other engine components.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4.Add remaining gasoline, close fuel container, and remix.
IMPORTANT
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers
to reduce fuel spillage.

12
IMPORTANT
Stored fuel ages. Do not mix more fuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizer is added.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container
thoroughly before each use.
After use
• DO NOT store a unit with fuel in its tank. Leaks can occur.
Return unused fuel to an approved fuel storage container.
Storage - Fuel storage laws vary by locality. Contact your local
government for the laws affecting your area. As a precaution, store
fuel in an approved, airtight container. Store in a well-ventilated,
unoccupied building, away from sparks and flames.
STARTING COLD ENGINE
• Recoil starter: Use short pulls - only 1/2-2/3 of rope length for
starting. Do not allow the rope to snap back in. Always hold the unit
firmly.
1. Throttle Position/Stop Switch Button
Slide Throttle Position /Stop Switch Button (A) back to idle
position (first detent away from stop position)
2. Choke
Move choke (B) up to Cold Start position ( ).
3. Purge Bulb
Pump purge bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
4. Recoil Starter
Pull recoil starter handle (D) until engine fires (5 pulls maxi-
mum).
5. Choke
Move choke (B) down to run position ( ), and if necessary,
restart engine.
NOTE
If engine does not start after 5 pulls, move choke to "Cold Start"
position, and repeat steps 4 & 5.
NOTE
Allow engine to warm up before use.
A
B
C
D

13
POWER BLOWER
OPERATOR'SMANUAL
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke.
1. Throttle Position/Stop Switch Button
Slide Throttle Position /Stop Switch Button (A) back to idle
position (first detent away from stop position).
2. Purge Bulb
Pump purge bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
3. Recoil Starter
Pull recoil starter handle (D) and engine should start.
NOTE
If engine does not start after 5 pulls, use cold start procedures.
A
C
D
STOPPING ENGINE
1. Throttle Position/Stop Switch Button
Release throttle trigger. Move Throttle Position /Stop Switch
Button (A) forward to idle position (first detent away from stop
position) and allow engine to return to idle before shutting off
engine.
2. Throttle Position/Stop Switch Button
Move Throttle Position /Stop Switch Button (A) all the way
forward to STOP position.
WARNING
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using blower
again.
A

14
OPERATING BLOWER
WARNING
Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a
poison gas. Breathing CO can cause unconsciousness, serious
injury, or death. Exhaust can cause serious burns. ALWAYS
position unit so that exhaust is directed away from your face and
body.
WARNING
Always wear safety glasses, hearing protection, a face filter mask,
and take all safety precautions, or serious personal injury may
result.
Do not point the blower pipe in the direction of people or pets.
Read the Safety Section carefully.
IMPORTANT
To avoid engine damage due to over-revving, do not block blower
pipe opening.
1. Use only during appropriate hours.
2. Allow the engine to warm up at a fast idle for a few minutes.
3. Control blower speed with Throttle Trigger (B), or for continu-
ous use, set engine speed with Combination Throttle Position /
Stop Switch Button (A).
4. Use lower speed to blow dry leaves from walks, patios and drives.
5. Additional speed may be necessary to clean grass and leaves from
a lawn or flower bed.
6. Higher speed may be necessary to move gravel, dirt, snow,
bottles or cans from a driveway, street, parking lot or stadium.
7. Always stop unit using stop engine procedure.
NOTE
Never use a higher speed setting than necessary to perform a task.
Remember, the higher the engine speed, the louder the blower noise.
Minimize dust by using blower at lower speeds and by dampening
material with water/mist when necessary. Keep debris on your
property.
Be Smart - be a good neighbor.
A
B

15
POWER BLOWER
OPERATOR'SMANUAL
MAINTENANCE
WARNING
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete
stop before removing obstructions, clearing debris, or servicing unit. Allow unit to cool before performing service.
Wear gloves to protect hands from sharp edges and hot surfaces.
Your ECHO blower is designed to provide many hours of trouble-free service. Regular scheduled maintenance will help
your blower achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the
ECHO Dealer do it, each maintenance task has been graded. If a task is not listed, see your ECHO Dealer for repairs.
SKILL LEVELS
Level 1 = Easy to do. Common tools may be required.
Level 2 = Moderate difficulty. Some specialized tools may be required.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier.
COMPONENT / SYSTEM MAINTENANCE
PROCEDURE
REQ'D
SKILL
LEVEL
DAILY OR
BEFORE USE
EVERY
REFUEL
3 MONTHS
OR 90
HOURS
YEARLY
600 HOURS
Air Filter Inspect/Clean 1I / C * R *
Choke Shutter Inspect/Clean 1I / C
Fuel Filter Inspect/Replace 1I * I / R *
Fuel Cap Gasket Inspect/Replace 1I *
Fuel System Inspect/Replace 1I (1) * I (1) *
Spark Plug Inspect/Clean/Replace 1I / C / R *
Cooling System Inspect/Clean 2I / C
Muffler Spark Arrestor Inspect/Clean/Replace 2I / C / R *
Cylinder Exhaust Port Inspect/Clean/Decarbon 2I / C
Recoil Starter Rope Inspect/Clean 1I / C *
Screws/Nuts/Bolts Inspect/Tighten/Replace 1I *
MAINTENANCE PROCEDURE LETTER CODES: I = INSPECT, R = REPLACE, C = CLEAN
IMPORTANT NOTE - Time intervals shown are maximum. Actual use and your experience will determine the
frequency of required maintenance.
MAINTENANCE PROCEDURE NOTES:
(1) Low evaporative fuel tanks DO NOT require regular maintenance to maintain emission integrity.
* All recommendations to replace are based on the finding of damage or wear during inspection.
MAINTENANCE INTERVALS

16
AIR FILTER
Level 1.
Tools required: 25 - 50 mm (1 - 2 in.) Cleaning brush.
Parts required: REPOWERTM Tune Up Kit
NOTE
Clean daily.
1. Close choke (Cold Start Position ( ). This prevents dirt from
entering the carburetor throat when the air filter is removed.
Brush accumulated dirt from air cleaner area.
2. Remove air filter cover. Brush dirt from inside cover.
3. Remove air filter and lightly brush debris from filter. Replace
filter if it is damaged, fuel soaked, very dirty, or the rubber
sealing edges are deformed.
4. If filter can be reused, be certain it:
• Fits tightly in the air filter cavity.
• Is installed with the original side out.
5. Install air filter cover.
FUEL FILTER
Level 1.
Tools required: 200-250 mm (8 - 10 in.) length of wire with one end
bent into a hook, clean rag, funnel, and an approved
fuel container.
Parts required: REPOWERTM Tune Up Kit
DANGER
Fuel is VERY flammable. Use extreme care when mixing, storing or
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and
empty fuel tank.
2. Use the “fuel line hook” to pull the fuel line and filter from the
tank.
3. Remove the filter from the line and install the new filter.

17
POWER BLOWER
OPERATOR'SMANUAL
SPARK PLUG
Level 1.
Tools required: 19 mm Spark Plug deep socket, feeler gauge
Parts Required: REPOWERTM Tune Up Kit
IMPORTANT
Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada)
otherwise severe engine damage may occur.
1. Remove spark plug, and check for fouling, and worn or rounded
center electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean. Remaining sand will damage engine.
3. Adjust spark plug gap by bending outer electrode.
4. Tighten spark plug to 150-170 kgf • cm (130-150 in.• lbf). 0.65 mm
(0.026 in.)
COOLING SYSTEM
Level 2.
Tools required: 25 - 50 mm (1 - 2 in.) cleaning brush, cross head
screwdriver
Parts Required: None, if you are careful.
IMPORTANT
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder fin area. This flow of air carries
combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes are blocked, preventing cooling air from reaching the
cylinder.
• Dust and grass build up on the outside of the cylinder. This build
up insulates the engine and prevents the heat from leaving.
Removal of cooling passage blockages or cleaning of cooling fins is
considered “Normal Maintenance.” Any failure attributed to lack of
maintenance is not warranted.
Cleaning Grill
1. Remove accumulated debris from intake grill between backpack
frame and blower housing.

18
A
B
C
EXHAUST SYSTEM
Spark Arrestor Screen
Level 2.
Tools required: Cross head screwdriver, soft metal brush
Parts Required: Spark arrestor screen, Gaskets (3)
IMPORTANT
Carbon deposits in muffler will cause a drop in engine output and
overheating. Spark arrestor screen must be checked periodically.
1. Remove spark plug lead from spark plug, and remove engine or
muffler cover (5 screws).
2. Remove spark arrestor cover (A), gaskets (B) and spark arrestor
screen (C) from muffler.
3. Clean carbon deposits from muffler components.
NOTE
When cleaning carbon deposits, be careful not to damage the
catalytic element inside muffler.
4. Replace screen if it is cracked, plugged, or has holes burned
through.
5. Install engine cover or muffler cover and attach spark plug lead.
Cleaning Cylinder Fins
1. Disconnect spark plug lead (A), and pull lead out of upper cover
clamp and lower cover clamp.
2. Remove 5 screws and remove engine cover (B).
3. Clean cylinder fins (C) to allow cooling air to pass freely.
B
C
A

19
POWER BLOWER
OPERATOR'SMANUAL
Exhaust Port Cleaning
Level 2.
Tools required: 4 & 5 mm Hexagon wrench, Cross head
screwdriver, Wood or plastic scraper
Parts Required: As needed: Heat Shield
1. Remove spark plug lead from spark plug, and remove engine or
muffler cover (5 screws).
2. Place piston at top dead center. Remove muffler (A) gasket (B),
and heat shield (C).
3. Use a wood or plastic scraping tool to clean deposits from
cylinder exhaust port.
IMPORTANT
Never use a metal tool to scrape carbon from the exhaust port.
Do not scratch the cylinder or piston when cleaning the exhaust
port. Do not allow carbon particles to enter the cylinder.
4. Inspect heat shield (C) and gasket (B) and replace if damaged.
5. Install heat shield (C), gasket (B), and muffler (A).
6. Tighten muffler mounting bolts (or nuts) to 110-130 in•lbf
(130-150 kgf•cm).
7. Install engine cover.
8. Attach spark plug lead.
9. Start engine, and warm to operating temperature.
10. Stop engine, and re-tighten mounting bolts (or nuts) to specifica-
tions.
A
B
C

20
CARBURETOR ADJUSTMENT
Engine Break-In
New engines must be operated for a minimum duration of two tanks of
fuel before carburetor adjustments can be made. During the break-in
period your engine performance will increase and exhaust emissions will
stabilize. Idle speed can be adjusted as required.
High Altitude Operation
This engine has been factory adjusted to maintain satisfactory starting,
emission, and durability performance up to 1,100 feet mean sea level
(MSL) (96.0 kPa and below). To maintain proper engine operation and
emission compliance above 1,100 feet MSL the carburetor may need
to be adjusted by an authorized ECHO service dealer.
IMPORTANT
If the engine is adjusted for operation above 1,100 feet MSL, the
carburetor must be re-adjusted when operating the engine below
1,100 feet MSL, otherwise severe engine damage can result.
IMPORTANT
For engine operation above 2,000 feet, turn the high-speed needle
lean (CW) until the engine runs between 7,000 and 8,000 RPM. Then
turn the low-speed needle lean (CW) until the engine does not
hesitate on acceleration.
For engine operation below 2,000 feet, turn the high-speed needle
rich (CCW) until the engine runs between 7,000 and 8,000 RPM.
Then turn the low-speed needle rich (CCW) until the engine does
not hesitate on acceleration.
DONOTREMOVE LIMITER CAPS!
Level 2.
Tools required: Screwdriver,tachometer (Echo P/N99051130017)
Parts required: None.
NOTE
Do not adjust carburetor unless necessary. If you have difficulty,
see your ECHO dealer.
