Echo GT-2150_SI(6digits)(35)(36) Instruction Manual

PARTS CATALOG
GRASS-TRIMMER /
BRUSHCUTTER
GT-2150_SI(6digits)( 5)( 6)
GT-2150_SI(6digits)(35)(36)

GT-2150_SI(6digits)( 5)( 6)
1. Cylinder, Crankcase, Piston, Fan Cover
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 101011-06562 1 CYLINDER
2 900162-05022 2
BOLT, H.S. 5*22
5*22 W,SW
3 101010-44332 1
GASKET, CYL. BASE
4 100000-48732 1
PISTON KIT
Sr/Nr 015370 and
before/GT-2150
4 100000-48732 1
PISTON KIT
Sr/Nr 35005300
and before/GT-
2150SI
4 P021-001101 1
PISTON KIT
Sus. by P021-
001102
4 P021-001102 1
PISTON KIT
Sr/Nr 36001001
and after/GT-
2150(SI)
5 + 100011-05330 2
RING, PISTON
Sr/Nr 015370 and
before/GT-2150
5 + 100011-05330 2
RING, PISTON
Sr/Nr 35005300
and before/GT-
2150SI
5 + A101-000000 2
RING,PISTON
Sr/Nr 36001001
and after/GT-
2150(SI)
6 + 100013-11520 1
PIN, PISTON
7 + 100015-04630 2
CIRCLIP, PISTON PIN
8 + 100014-11520 2
SPACER, PISTON PIN
- 1 -

GT-2150_SI(6digits)( 5)( 6)
1. Cylinder, Crankcase, Piston, Fan Cover
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
9 100100-44732 1 CRANKSHAFT ASSY
Sus. by A011-
000101
9 100100-44733 1
CRANKSHAFT
Sus. by A011-
000101
9 A011-000101 1
CRANKSHAFT,ASM
10 + 100012-51230 1
BEARING, NEEDLE
8*12*10 Sus. by V553-
000010
10 + V553-000030 1
BEARING,NEEDLE 8
Sus. by V553-
000010
10 + V553-000010 1
BEARING,NEEDLE 8
HK0810
11 100204-52130 1
CRANKCASE KIT
Sus. by 100204-
52132
11 100204-52131 1
CRANKCASE KIT
Sus. by 100204-
52132
11 100204-52132 1
CRANKCASE KIT
12 + 100212-42030 2
OILSEAL
ISCD12*22*4.5 Sus. by 100212-
42031
12 + 100212-42031 2
OILSEAL
ISCD 12*22*4.5
13 + 100215-03930 2
PIN, DOWEL
14 + 900810-36201 2
BEARING, BALL 6201
6201/C3 Sus. by 94035-
36201
14 + 94035-36201 2
BEARING BALL
6201X3JR2C3
15 + 100242-42030 1
GASKET, CRANKCASE
16 + 900162-05028 3
BOLT, H.S. 5*28
5*28 W,SW
17 101535-44730 1
COVER, FAN
- 2 -

GT-2150_SI(6digits)( 5)( 6)
1. Cylinder, Crankcase, Piston, Fan Cover
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
18 900238-04016 4 SCREW 4*16 4*16
19 101514-42031 1
COVER, CYLINDER
20 900238-04012 2
SCREW 4*12
4*12
21 X503-000030 1
LABEL,MODEL
GT-2150
21 X543-000100 1
LABEL,MODEL
GT-2150SI GT-2150SI
22 900238-04016 2
SCREW 4*16
4*16
23 610903-51030 1
HOLDER KIT
24 + 900142-05025 2
BOLT 5*25 (W/W,SW)
5*25
25 + 610922-51030 1
FIXTURE, MAIN PIPE
26 + 610923-51030 1
FIXTURE, MAIN PIPE
27 610910-51030 1
CUSHION
28 900814-06201 1
BEARING, BALL 6201
6201ZZ
29 900702-00032 1
CIRCLIP 32
CR-32
30 175005-44331 1
DRUM, CLUTCH
- 3 -

GT-2150_SI(6digits)( 5)( 6)
2. Magneto, Clutch
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
6 175000-52130 1 CLUTCH ASSY
Sus. by 175000-
56830
6 175000-56830 1
CLUTCH ASSY
Sus. by 175000-
56831
7 156801-12360 1
ROTOR, MAGNETO
Sus. by 156801-
44731
7 156801-44731 1
FLYWHEEL
8 900162-04022 2
BOLT, H.S. 4*22
4*22 W,SW
9 156601-52130 1
COIL, IGNITION
Sus. by 156601-
44732
9 156601-44731 1
COIL, IGNITION
Sus. by 156601-
44732
9 156601-44732 1
COIL, IGNITION
EMG-32 2605 Sr/Nr 35999999
and before
9 156601-52130 1
COIL, IGNITION
Sr/Nr 36001001
and after/GT-
2150(SI)
10 159012-01620 1
CAP, SPARK PLUG
11 159011-03432 1
COIL, SPARK PLUG
12 159017-10230 1
PLUG, SPARK (RCJ-7Y)
RCJ-7Y Sr/Nr 015370 and
before/GT-2150
12 159017-10230 1
PLUG, SPARK (RCJ-7Y)
RCJ-7Y
Sr/Nr 35005300
and before/GT-
2150SI
- 4 -

GT-2150_SI(6digits)( 5)( 6)
2. Magneto, Clutch
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
12 159010-10230 1 PLUG, SPARK (BPMR-7A BPMR-7A
Sr/Nr 36001001
and after/GT-
2150(SI)
13 150112-42030 1
BUSHING
16 162010-52830 1
LEAD, GROUND
Sr/Nr 004750 and
before
16 162010-52830 1
LEAD, GROUND
Sr/Nr 36001001
and after/GT-
2150(SI)
- 5 -

GT-2150_SI(6digits)( 5)( 6)
. Starter(GT-2150)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
20 177202-44330 1 PAWL ASSY, STARTER
Sus. by 177202-
44331/GT-2150
20 177202-44331 1
PAWL ASM., STARTER
GT-2150
23 + 177234-42030 1
SPRING, RETURN
GT-2150
24 + 177218-44330 1
PAWL, STARTER
BLACK GT-2150
26 177200-54130 1
STARTER ASSY
GT-2150
27 + 177236-44330 1
SCREW
GT-2150
29 + 177215-44430 1
DRUM, STARTER
GT-2150
30 + 177226-10120 1
ROPE, STARTER
3.0*1000 GT-2150
31 + 177227-42030 1
GUIDE, ROPE
GT-2150
32 + 177228-06530 1
GRIP, STARTER
GT-2150
33 + 177220-42030 1
SPRING, REWIND
GT-2150
35 900238-04016 2
SCREW 4*16
4*16 GT-2150
36 890118-49130 1
LABEL, ECHO
GT-2150
- 6 -

GT-2150_SI(6digits)( 5)( 6)
4. Starter(GT-2150SI)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
15 900253-05020 3 SCREW 5*20 5*20 GT-2150SI
18 X502-000031 1
LABEL,ECHO
Sus. by X502-
000032/GT-2150SI
18 X502-000032 1
LABEL,ECHO
GT-2150SI
19 A051-000290 1
STARTER,RECOIL
Sus. by A051-
000292/GT-2150SI
19 A051-000291 1
STARTER,RECOIL
Sus. by A051-
000292/GT-2150SI
19 A051-000292 1
STARTER,RECOIL
GT-2150SI
20 + 177246-11120 1
CLIP, STARTER ROPE
GT-2150SI
21 + 177228-27030 1
GRIP, STARTER
GT-2150SI
22 + P022-004610 2
SPRING, RETURN
GT-2150SI
23 + P022-004620 2
PAWL, STARTER
GT-2150SI
24 + P022-004680 1
SPRING, SPIRAL
GT-2150SI
25 + P022-004600 1
ROPE,STARTER
3.0*920 GT-2150SI
26 + P022-004690 1
REEL,ROPE
GT-2150SI
27 + P022-004660 1
SPRING, RETURN
GT-2150SI
28 + P022-004670 1
PAWL, STARTER
GT-2150SI
29 + P022-004650 1
COMPLETE,SPRING
GT-2150SI
30 + P022-004640 1
PLATE,CAM
GT-2150SI
31 + P022-004630 1
SCREW
GT-2150SI
33 900162-04016 2
BOLT, H.S. 4*16
4*16 W,SW Sus. by 900238-
04016
- 7 -

GT-2150_SI(6digits)( 5)( 6)
4. Starter(GT-2150SI)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
33 900238-04016 2 SCREW 4*16 4*16 GT-2150SI
35 V376-000360 1
SPACER
Sus. by V376-
000361
35 V376-000361 1
SPACER
GT-2150SI
38 X505-000620 1
LABEL,CAUTION
GT-2150SI
40 A052-000130 1
PULLEY,ASM STARTER
GT-2150SI
41 + P022-004740 2
PAWL,STARTER
GT-2150SI
42 + 177234-42030 2
SPRING, RETURN
GT-2150SI
43 + P022-002100 2
E-RING
4 GT-2150SI
- 8 -

GT-2150_SI(6digits)( 5)( 6)
5. Air Cleaner, Muffler
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 130010-42032 1 GASKET,INTAKE
2 900500-00005 2
NUT 5
5
3 900238-05020 2
SCREW 5*20
5*20
4 130017-42031 1
INSULATOR, INTAKE
5 130016-42031 1
GASKET, INTAKE
6 125200-52431 1
CARBURETOR
C1U-K53 Sus. by 125200-
52433
6 125200-52432 1
CARBURETOR
C1U-K53A Sus. by 125200-
52433
6 125200-52433 1
CARBURETOR
C1U-K53B
7 130319-42030 1
FIXTURE,AIR CLEANER
8 130301-42030 1
CASE, AIR CLEANER
9 + 178810-42030 1
GROMMET, CHOKE
10 178515-46731 1
SHUTTER, CHOKE
φ3.0
11 178516-00830 2
SPACER
5.2*8*0.8T
12 900242-05057 2
SCREW 5*57
5*57
13 130310-46730 1
FILTER, AIR
14 890169-47530 1
LABEL, ADJUSTING
15 P021-000050 1
MUFFLER ASY
Sus. by P021-
000052
15 P021-000051 1
MUFFLER ASY
Sus. by P021-
000052
15 P021-000052 1
MUFFLER ASY
16 + 145510-42031 2
GASKET, MUFFLER
Sus. by V104-
000160
16 + V104-000160 2
GASKET,EXHAUST
- 9 -

GT-2150_SI(6digits)( 5)( 6)
5. Air Cleaner, Muffler
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
17 + 145866-42031 1 GASKET, MUFFLER LID
18 + 145876-42030 1
LID, MUFFLER (B)
19 + 145863-42030 1
HOLDER, SCREEN
20 + 900242-04010 3
SCREW 4*10
4*10
21 145631-42030 1
COVER, MUFFLER
Sus. by A320-
000251
21 A320-000250 1
COVER,MUFFLER
Sus. by A320-
000251
21 A320-000251 1
COVER,MUFFLER
22 900600-00005 2
WASHER 5
5Sus. by 145642-
04930
22 145642-04930 1
WASHER
23 900105-05055 2
BOLT, H.S. 5*55
5*55
- 10 -

GT-2150_SI(6digits)( 5)( 6)
6. Fuel Tank
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 131005-44331 1 TANK, FUEL
Sus. by 131005-
44332
1 131005-44332 1
TANK, FUEL
2 900243-05016 2
SCREW 5*16
5*16
4 131004-55530 1
CAP ASSY, FUEL TANK
5 + 131016-55830 1
GASKET, FUEL CAP
6 + 131051-56030 1
CLIP, FUEL CAP
100L
7 131300-56430 1
VALVE, CHECK
8 130111-00530 1
CLIP
5.5
9 131312-44330 1
PIPE, 3*5*70L
3*5*70L NBR Sus. by V471-
001200
9 V471-001200 1
PIPE
3*5*70 NBR
10 132115-46730 1
GROMMET, FUEL
11 132013-09820 1
CLIP
6MM
12 131205-07320 1
STRAINER, FUEL
13 132010-56330 1
PIPE 3*6*90
3*6*90 YL
14 132010-13930 1
PIPE, FUEL
3*5*180L NBR Sus. by V471-
001190
14 V471-001190 1
PIPE
3*5*180 NBR
18 305110-42030 1
STAND (BL)
GT-2150SI
- 11 -

GT-2150_SI(6digits)( 5)( 6)
7. Handle, Tools(Sr/Nr 6006724 and before)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
3 890617-63630 1 LABEL,CAUTION
Sus. by X505-
000140
3 X505-000140 1
LABEL,CAUTION
4 351600-09630 1
HANDLE ASS'Y
5 + 900525-00006 1
NUT, WING 6
BN6
6 + 900600-00006 1
WASHER 6
6
7 + 900100-06040 1
BOLT 6*40
6*40
8 163400-49230 1
SWITCH, IGNITION
Sus. by A440-
001020
9 900500-00005 1
NUT 5
5
10 900560-00005 1
NUT, LOCK 5
5
11 351111-09630 1
GRIP
Sus. by 351111-
09631
11 351111-09631 1
GRIP, HANDLE
13 900502-00006 2
NUT 6 (3N)
3N6
14 178001-56730 1
CABLE, THROTTLE
15 178127-24030 1
TUBE
10*11*160 Sus. by V475-
004020
16 178048-05630 1
HOLDER, THR. WIRE
17 178043-06930 1
SPRING. THR. RETURN
18 178010-48731 1
CONTROL, THROTTLE
19 C470-000000 1
HOLDER,TRIGGER
Sus. by P021-
005550
19 P021-005550 1
HOLDER,TRIGGER SET
20 178110-05330 1
SCREW
21 900242-05028 1
SCREW 5*28
5*28
- 12 -

GT-2150_SI(6digits)( 5)( 6)
7. Handle, Tools(Sr/Nr 6006724 and before)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
24 610281-52730 1 COLLER
25 + 900253-04018 2
SCREW TAPPING 4*18
4*18
26 890157-39130 1
LABEL, SWITCH
28 895410-07630 1
WRENCH, W/S. DRIVER
29 899580-68730 1
SAFETY GLASSES
Sus. by X690-
000030
29 X690-000030 1
GOGGLE
30 895015-26630 1
SPANNER 10
Sus. by 895015-
09631
30 895015-09631 1
SPANNER 10
- 13 -

GT-2150_SI(6digits)( 5)( 6)
8. Handle, Tools(Sr/Nr 6006725 and after)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
3 X505-000140 1 LABEL,CAUTION
4 351600-09630 1
HANDLE ASS'Y
5 + 900525-00006 1
NUT, WING 6
BN6
6 + 900600-00006 1
WASHER 6
6
7 + 900100-06040 1
BOLT 6*40
6*40
8 A440-001020 1
SWITCH, ON OFF
9 900500-00005 1
NUT 5
5
10 900560-00005 1
NUT, LOCK 5
5
11 351111-09631 1
GRIP, HANDLE
13 900502-00006 2
NUT 6 (3N)
3N6
14 178001-56730 1
CABLE, THROTTLE
15 V475-004020 1
TUBE
10*11*215
16 178048-05630 1
HOLDER, THR. WIRE
17 178043-06930 1
SPRING. THR. RETURN
18 178010-48731 1
CONTROL, THROTTLE
19 P021-005550 1
HOLDER,TRIGGER SET
20 178110-05330 1
SCREW
21 900242-05028 1
SCREW 5*28
5*28
24 610281-52730 1
COLLER
25 + 900253-04018 2
SCREW TAPPING 4*18
4*18
26 890157-39130 1
LABEL, SWITCH
28 895410-07630 1
WRENCH, W/S. DRIVER
29 X690-000030 1
GOGGLE
30 895015-09631 1
SPANNER 10
31 159112-22131 1
CLIP
- 14 -

GT-2150_SI(6digits)( 5)( 6)
9. Main Pipe, Shield
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
5 C506-000010 1 SHAFT,FLEXIBLE
Sus. by C506-
000020
5 C506-000020 1
SHAFT,FLEXIBLE
5.15*L1365
8 P021-000140 1
MAIN PIPE ASY
Sus. by P021-
003520
8 P021-003520 1
MAIN PIPE ASY
10 610400-47930 1
HOUSING ASSY, GEAR
11 + 610310-47930 1
SHAFT, P.T.O.
12 + 900802-00608 2
BEARING, BALL 608
608DDU(LLU)
13 + 610315-47930 1
SPACER, DRIVEN SHAFT
Sus. by V355-
000040
13 + V355-000040 1
COLLAR,8
8X5X(T0.9)
14 + 91030-05010 1
BOLT
5*10L
15 + 610410-47930 1
CASE, GEAR
16 + 91032-05030 1
BOLT
5*30L W/SW
17 + 610318-47930 1
WASHER, ADJUSTMENT
18 + 900605-00008 1
WASHER, SPRING 8
8
19 + 610313-47930 1
PLATE, ADAPTER
20 699000-47930 1
SHIELD ASSY
22 + 900100-06045 1
BOLT 6*45
6*45
23 + 900600-00006 1
WASHER 6
6
24 + 900525-00006 1
NUT, WING 6
BN6
25 900242-05014 2
SCREW 5*14
5*14
30 A562-000000 1
STOPPER,PIPE
31 P021-006080 1
KNIFE, CODE KIT
- 15 -

GT-2150_SI(6digits)( 5)( 6)
9. Main Pipe, Shield
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
32 699016-23231 1 CUTTER
Sus. by P021-
006080
32 + 699016-44330 1
CUTTER
33 699212-23230 1
PROTECTOR
Can not be used
on P021-006080
34 + 900500-00005 2
NUT 5
5
- 16 -

GT-2150_SI(6digits)( 5)( 6)
10. Nylon Line Cutting Head M9 (Sr/Nr 006100and before)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 890093-52730 1 LABEL, CAUTION
Sr/Nr 006100 and
before
2 P022-000070 1
ADAPTER
M8*1.25 RIGHT Sr/Nr 006100 and
before
3 P022-000080 1
HOUSING
Sr/Nr 006100 and
before
4 P022-000090 2
GROMMET
Sr/Nr 006100 and
before
5 696215-08230 1
CORD, NYLON (2.4*5M)
Sr/Nr 006100 and
before
6 P022-000100 1
HOUSING
Sr/Nr 006100 and
before
7 P022-000110 1
SPRING
Sr/Nr 006100 and
before
8 P022-000120 1
KNOB
Sr/Nr 006100 and
before
- 17 -

GT-2150_SI(6digits)( 5)( 6)
11. Nylon Line Cutting Head(Sr/Nr 006101 and after)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
X047-000060 1 CUTTER,ASM LINE DS-3/8 R
Sus. by X047-
000242
X047-000170 1
CUTTER,ASM LINE
F4/8R M8R Sus. by X047-
000242
X047-000171 1
CUTTER,ASM LINE
F4/8R M8R Sus. by X047-
000242
X047-000240 1
CUTTER,ASM LINE
F4/8 M8R ｻｲﾚﾝﾄ Sus. by X047-
000242
X047-000241 1
CUTTER,ASM LINE
F4/8R ｻｲﾚﾝﾄ 2.4 Sus. by X047-
000242
X047-000242 1
CUTTER,ASM LINE
F4/8R Sr/Nr 006101 and
after
41 + X470-000010 1
DRUM,REEL
Sus. by P022-
003320
41 + P022-002900 1
HOUSING
Sus. by P022-
003320
41 + P022-003320 1
HOUSING
Sr/Nr 006101 and
after
42 + P022-001280 1
NUT
DS-3/8R Sr/Nr 006101 and
after
43 + P022-001290 1
SPRING
DS-3/8R Sr/Nr 006101 and
after
44 + P022-001230 1
NYLON CODE
Sus. by P022-
006570
44 + P022-006190 1
NYLON CODE
3.0*2M Sus. by P022-
006570
- 18 -

GT-2150_SI(6digits)( 5)( 6)
11. Nylon Line Cutting Head(Sr/Nr 006101 and after)
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
44 + P022-006570 1 NYLON CODE
ｻｲﾚﾝﾄSﾗｲﾝ
2.4*2M
Sr/Nr 006101 and
after
45 + P022-001300 1
BOBBIN
DS-3/8R Sr/Nr 006101 and
after
46 + P022-001240 1
COVER
DS-3/10 Sus. by P022-
003330
46 + P022-002860 1
COVER
Sus. by P022-
003330
46 + P022-003330 1
COVER
Sr/Nr 006101 and
after
47 + P022-000710 2
EYELET
T4 Sr/Nr 006101 and
after
- 19 -
