Echo GT-222ES(37) Instruction Manual

PARTS CATALOG
GRASS-TRIMMER /
BRUSHCUTTER
GT-222ES(37)
-
P014-002020-12Eb
37000001

GT-222ES(37)
1. CYLINDER, CRANKCASE, PISTON
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A011-000101 1 CRANKSHAFT,ASM
2 A130-002100 1
CYLINDER
3 101010-44332 1
GASKET, CYL. BASE
4 900162-05022 2
BOLT, H.S. 5*22
5*22 W,SW
5 P021-007712 1
PISTON KIT
6 + A101-000090 1
RING,PISTON
7 + 100013-11520 1
PIN, PISTON
8 + 100015-04630 2
CIRCLIP, PISTON PIN
9 + 100014-11520 2
SPACER, PISTON PIN
10 100204-52133 1
CRANKCASE KIT
11 + 900162-05028 3
BOLT, H.S. 5*28
5*28 W,SW
12 + 100215-03930 2
PIN, DOWEL
13 + 94095-36201 2
BEARING BALL
14 + 100212-42031 2
OILSEAL
ISCD 12*22*4.5
15 + 100242-42030 1
GASKET, CRANKCASE
- 1 -

GT-222ES(37)
2. FAN CO ER, CYLINDER CO ER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A172-000320 1 COVER,FAN
2 175313-20430 1
RING, FELT
3 91363-04016 3
SCREW
SMB-4*16/W,SW
4 175005-44331 1
DRUM, CLUTCH
6 X547-002300 1
LABEL,ECHO
7 610922-55931 1
HOLDER, MAIN PIPE
8 660316-55630 1
CLIP
9 V315-000030 1
WASHER,CIRCULAR 30
33.5*41.0*T0.5
10 91118-05028 1
BOLT
CM-5*28
11 A160-000890 1
COVER,CYLINDER
12 V202-000090 2
BOLT,4
4*16
13 X505-002310 1
LABEL,CAUTION
HOT CAUTION
14 A162-000130 1
GUARD,TOP
15 900253-05020 1
SCREW 5*20
5*20
- 2 -

GT-222ES(37)
3. MAGNETO
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A409-000160 1 ROTOR,MAGNETO
2 A411-000140 1
COIL,IGNITION
3 V475-007300 1
TUBE
4 162010-52830 1
LEAD, GROUND
5 900162-04020 2
BOLT, H.S. 4*20
4*20 W,SW
6 156112-40630 1
GROMMET
7 A425-000000 1
SPARKPLUG
BPMR8Y
8 159012-03433 1
CAP, SPARK PLUG
9 159011-03432 1
COIL, SPARK PLUG
10 175000-56831 1
CLUTCH ASSEMBLY
- 3 -

GT-222ES(37)
4. AIR CLEANER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A021-003880 1 CARBURETOR,DIAPHRAGM ZAMA RB-K113
3 V103-001390 1
GASKET,INTAKE
4 130017-44331 1
INSULATOR
5 900500-00005 2
NUT 5
5
6 900238-05022 2
SCREW 5*22
5*22
7 V103-001640 1
GASKET,INTAKE
8 P021-004480 1
CASE, AIR CLEANER
9 890332-52730 1
LABEL, CHOKE
10 129011-52730 1
PLATE, PREVENT
11 900220-05065 2
SCREW 5*65
5*65
12 A226-001410 1
ELEMENT,AIR FILTER
13 130313-05863 1
LID, AIR CLEANER
14 210417-52730 1
BOLT, WING
5*20
- 4 -

GT-222ES(37)
5. FUEL TANK
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A350-000480 1 TANK, FUEL
2 900603-00005 2
WASHER 5
5.5*12*0.8
3 91118-05020 2
BOLT
CM-5*20
4 P021-012210 1
CAP,FUEL ASY
5 + 131016-55830 1
GASKET, FUEL CAP
6 + A365-000060 1
CONNECTOR,CAP
L=123
7 132115-46730 1
GROMMET, FUEL
8 V471-001190 1
PIPE
3*5*180 NBR
9 V471-001200 1
PIPE
3*5*70 NBR
10 132012-56030 1
PIPE
3*6*80 YL
11 A356-000031 1
VALVE,CHECK
12 V490-001240 2
CLIP
13 131205-07320 1
STRAINER, FUEL
- 5 -

GT-222ES(37)
6. MUFFLER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 P021-037630 1 MUFFLER ASY
2 + A313-000600 1
GUIDE,EXH
3 + 145862-40630 1
SCREEN, MUFFLER
4 + V104-001760 1
GASKET,EXHAUST
5 + 91367-04010 5
SCREW
4*10/SW(SUS)
6 900105-05055 2
BOLT, H.S. 5*55
5*55
7 V150-000371 1
PLATE,EYE
8 V104-000500 1
GASKET,EXHAUST
9 91121-04008 1
BOLT, FLANGE
M4*8 10.9
- 6 -

GT-222ES(37)
7. RECOIL STARTER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 A051-001401 1 STARTER,RECOIL ASY
2 + P022-034040 1
DRUM, STARTER
3 + P022-034030 1
PLATE, CAM
4 + P022-008270 1
SPRING,DAMPER
5 + P022-019680 1
SPRING, SPIRAL
6 + 177236-61830 1
SCREW
7 + P022-025730 1
ROPE, STARTER
8 + P022-023170 1
GRIP, STARTER
11 V202-000090 2
BOLT,4
4*16
12 A052-000180 1
PULLEY,ASM STARTER
13 + P022-002100 2
E-RING
4
14 + P022-006510 2
SPRING, RETURN
15 + P022-006850 2
PAWL, STARTER
16 X502-000890 1
LABEL,ECHO
- 7 -

GT-222ES(37)
8. MAIN PIPE
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 P021-009461 1 CASE,ASM BEARING
2 + C534-000341 1
SHAFT,GEAR
3 + 94060-06200 1
BEARING BALL
WEPON BB6200
4 + 94061-06200 1
BEARING, BALL
BB6200 LU,DU
5 + 900702-00030 1
CIRCLIP 30
CR-30
6 + C535-000340 1
FIXTURE, BLADE
3/8-24UNF
7 + 900242-04010 1
SCREW 4*10
4*10
8 + 91118-05025 1
BOLT
10 C050-000470 1
PIPE,MAIN
11 C506-000320 1
SHAFT, FLEXIBLE
3263-002A
12 X505-000140 1
LABEL,CAUTION
13 890152-04930 1
LABEL, CAUTION
14 610281-54131 1
COLLER
15 + 900253-04025 2
SCREW 4*25
4*25
16 P021-016090 1
FRONT HANDLE ASY
17 + 900242-05035 4
SCREW 5*35
5*35
- 8 -

GT-222ES(37)
9. THROTTLE LE ER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 178003-52130 1 BRACKET SET,THROTTLE
4 + 900242-05035 1
SCREW 5*35
5*35
5 + 900242-05025 1
SCREW 5*25
5*25
6 + 900500-00005 2
NUT 5
5
2 178010-52130 1
CONTROL, THROTTLE
3 178043-42230 1
SPRING, THR. RETURN
7 301200-29430 1
BAND ASSY
8 + 900242-05014 1
SCREW 5*14
9 C403-000140 1
GRIP, HANDLE
L129.5*28
10 178090-52632 1
LOCKOUT, T. CONTROL
11 178012-52630 1
LOCKOUT, THROTTLE
12 178013-52630 1
SPRING, THR. LOCK
13 A440-000833 1
SWITCH, ON OFF
14 91363-04016 1
SCREW
SMB-4*16/W,SW
15 V430-002290 1
CABLE,BOWDEN
330+61
16 900502-00006 1
NUT 6 (3N)
3N6
17 900518-00006 1
NUT, FLANGE
6
18 P021-014550 1
BAND 25
19 + 900242-05028 1
SCREW 5*28
5*28
6 + 900500-00005 1
NUT 5
5
20 890157-39130 1
LABEL, SWITCH
21 V495-002690 2
BAND
CV-100黒相当
- 9 -

GT-222ES(37)
10. SHIELD
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 P021-009552 1 SHIELD KIT
2 + C554-000021 1
KNIFE, CORD
3 + 900238-05012 2
SCREW 5*12
5*12
4 + 900500-00005 2
NUT 5
5
5 + 900033-00008 1
NUT, WING 1/4-20
1/4-20
6 + 900017-08064 1
BOLT 1/4-20*2A
1/4-20*2A
7 + 910300-27700 1
WASHER,CIRCULAR 6
- 10 -

GT-222ES(37)
11. NYLON LINE CUTTER
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
10 X047-000450 1 CUTTER,ASM LINE G137
1 + P022-025530 1
CASE
2 + P022-025630 1
COVER
3 + P022-025640 1
REEL
4 + P022-025560 1
BUTTON
5 + P022-025570 1
RETURN SPRING
6 + P022-025580 1
SET SCREW
7 + P022-025590 2
CORD GUIDE
8 + P022-025600 1
NYLON CORD
9 + P022-025660 1
SHAFT
- 11 -

GT-222ES(37)
12. ACCESSORIES
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
1 X690-000050 1 GOGGLE GOGGLE + NOTE
2 X698-000040 1
TOOL,CASE
400*500
3 X606-000080 1
TOOL,BAR
5*120
4 895410-02830 1
WRENCH, W/S. DRIVER
5 898510-07130 1
BAG, TOOL
6 X605-000100 1
TOOL,L WRENCH
4MM M5
8 X772-000820 1
MANUAL,OPERATOR
- 12 -

GT-222ES(37)
13. CARBURETOR
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
A021-003880 1 CARBURETOR,DIAPHRAGM ZAMA RB-K113
2 + P005-000010 1
STRAINER
3 + 125337-08260 1
VALVE, INLET NEEDLE
4 + 125338-13930 1
PIN, METERING ARM
5 + P005-002430 1
SPRING, MET. LEVER
6 + 125323-08260 1
ARM, VALVE
7 + 125339-42030 1
SCREW
8 + P005-002460 1
COVER ASY, ROTOR
9 + P005-000100 1
SCREW,THROTTLEADJUST
10 + 125344-13931 3
SCREW
11 + P005-001240 1
POST
12 + P005-000190 1
E-RING
13 + P005-002230 1
DIAPHRAGM ,METERING
14 + P005-000200 1
GASKET, METERING
15 + 125342-52130 1
COVER, DIAPHRAGM
16 + 125344-52130 3
SCREW
17 + P005-000510 1
DIAPHRAGM, PUMP
18 + P005-000520 1
GASKET, PUMP
19 + P005-001890 1
BASE, ASY PRIMER
20 + 125381-46730 1
PUMP, PRIMING
21 + P005-000250 1
RETAINER
22 + P005-001900 4
SCREW
23 + P005-000270 1
SCREW
24 + P005-000280 1
O-RING
25 + P005-001000 1
ROLLER, GUIDE
26 + P005-001250 1
RETAINER,PLUG BALL
- 13 -

GT-222ES(37)
13. CARBURETOR
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
27 + P005-001260 1 SCREW,MAINN MIXTURE
28 + P005-001270 1
PLUG, H AJUST SCREW
29 + A259-000010 1
CAP,LIMITER
- 14 -

Index
Patrs Number Key No. Patrs Number Key No. Patrs Number Key No.
100013-11520 1 - 7 900033-00008 10 - 5 A356-000031 5 - 11
100014-11520 1 - 9 900105-05055 6 - 6 A365-000060 5 - 6
100015-04630 1 - 8 900162-04020 3 - 5 A409-000160 3 - 1
100204-52133 1 - 10 900162-05022 1 - 4 A411-000140 3 - 2
100212-42031 1 - 14 900162-05028 1 - 11 A425-000000 3 - 7
100215-03930 1 - 12 900220-05065 4 - 11 A440-000833 9 - 13
100242-42030 1 - 15 900238-05012 10 - 3 C050-000470 8 - 10
101010-44332 1 - 3 900238-05022 4 - 6 C403-000140 9 - 9
125323-08260 13 - 6 900242-04010 8 - 7 C506-000320 8 - 11
125337-08260 13 - 3 900242-05014 9 - 8 C534-000341 8 - 2
125338-13930 13 - 4 900242-05025 9 - 5 C535-000340 8 - 6
125339-42030 13 - 7 900242-05028 9 - 19 C554-000021 10 - 2
125342-52130 13 - 15 900242-05035 8 - 17 P005-000010 13 - 2
125344-13931 13 - 10 900242-05035 9 - 4 P005-000100 13 - 9
125344-52130 13 - 16 900253-04025 8 - 15 P005-000190 13 - 12
125381-46730 13 - 20 900253-05020 2 - 15 P005-000200 13 - 14
129011-52730 4 - 10 900500-00005 4 - 5 P005-000250 13 - 21
130017-44331 4 - 4 900500-00005 9 - 6 P005-000270 13 - 23
130313-05863 4 - 13 900500-00005 9 - 6 P005-000280 13 - 24
131016-55830 5 - 5 900500-00005 10 - 4 P005-000510 13 - 17
131205-07320 5 - 13 900502-00006 9 - 16 P005-000520 13 - 18
132012-56030 5 - 10 900518-00006 9 - 17 P005-001000 13 - 25
132115-46730 5 - 7 900603-00005 5 - 2 P005-001240 13 - 11
145862-40630 6 - 3 900702-00030 8 - 5 P005-001250 13 - 26
156112-40630 3 - 6 910300-27700 10 - 7 P005-001260 13 - 27
159011-03432 3 - 9 91118-05020 5 - 3 P005-001270 13 - 28
159012-03433 3 - 8 91118-05025 8 - 8 P005-001890 13 - 19
162010-52830 3 - 4 91118-05028 2 - 10 P005-001900 13 - 22
175000-56831 3 - 10 91121-04008 6 - 9 P005-002230 13 - 13
175005-44331 2 - 4 91363-04016 2 - 3 P005-002430 13 - 5
175313-20430 2 - 2 91363-04016 9 - 14 P005-002460 13 - 8
177236-61830 7 - 6 91367-04010 6 - 5 P021-004480 4 - 8
178003-52130 9 - 1 94060-06200 8 - 3 P021-007712 1 - 5
178010-52130 9 - 2 94061-06200 8 - 4 P021-009461 8 - 1
178012-52630 9 - 11 94095-36201 1 - 13 P021-009552 10 - 1
178013-52630 9 - 12 A011-000101 1 - 1 P021-012210 5 - 4
178043-42230 9 - 3 A021-003880 4 - 1 P021-014550 9 - 18
178090-52632 9 - 10 A021-003880 13 - P021-016090 8 - 16
210417-52730 4 - 14 A051-001401 7 - 1 P021-037630 6 - 1
301200-29430 9 - 7 A052-000180 7 - 12 P022-002100 7 - 13
610281-54131 8 - 14 A101-000090 1 - 6 P022-006510 7 - 14
610922-55931 2 - 7 A130-002100 1 - 2 P022-006850 7 - 15
660316-55630 2 - 8 A160-000890 2 - 11 P022-008270 7 - 4
890152-04930 8 - 13 A162-000130 2 - 14 P022-019680 7 - 5
890157-39130 9 - 20 A172-000320 2 - 1 P022-023170 7 - 8
890332-52730 4 - 9 A226-001410 4 - 12 P022-025530 11 - 1
895410-02830 12 - 4 A259-000010 13 - 29 P022-025560 11 - 4
898510-07130 12 - 5 A313-000600 6 - 2 P022-025570 11 - 5
900017-08064 10 - 6 A350-000480 5 - 1 P022-025580 11 - 6
- 15 -

Index
Patrs Number Key No. Patrs Number Key No. Patrs Number Key No.
P022-025590 11 - 7
P022-025600 11 - 8
P022-025630 11 - 2
P022-025640 11 - 3
P022-025660 11 - 9
P022-025730 7 - 7
P022-034030 7 - 3
P022-034040 7 - 2
V103-001390 4 - 3
V103-001640 4 - 7
V104-000500 6 - 8
V104-001760 6 - 4
V150-000371 6 - 7
V202-000090 2 - 12
V202-000090 7 - 11
V315-000030 2 - 9
V430-002290 9 - 15
V471-001190 5 - 8
V471-001200 5 - 9
V475-007300 3 - 3
V490-001240 5 - 12
V495-002690 9 - 21
X047-000450 11 - 10
X502-000890 7 - 16
X505-000140 8 - 12
X505-002310 2 - 13
X547-002300 2 - 6
X605-000100 12 - 6
X606-000080 12 - 3
X690-000050 12 - 1
X698-000040 12 - 2
X772-000820 12 - 8
- 16 -

12Eb
No. 04-400
©2012
