Echo 99944200553 User manual

ProSweep Attachment
Model 99944200553
Operator's Manual
FOR MODELS: SRM-2400SB
SRM-260SB/261SB
PAS-2400
PAS-230/231
PAS-260/261
PAS-2601
PAS-265
X7702093401 X770001291
03/09
WARNING
Read rules for safe operation and instructions carefully. ECHO provides an Op-
erator's Manual with this attachment and a separate Operator's Manual and Safety
Manual (if available) with the Power Head. All manuals must be read and under-
stood for proper and safe operation. Failure to do so could result in serious injury.
ENGLISH
FRANCAIS
ESPAÑOL

2
Copyright© 2009 By Echo, Incorporated
All Rights Reserved.
In t r o d u c t I o n
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-
dependability. Read and understand this manual included with your attachment. You will nd this manual easy to use and
full of helpful operations tips and SAFETY messages.
ta b l e o f co n t e n t s
Introduction....................................................................2
- The Operator's Manual ...........................................2
- Safety Manual.........................................................2
Safety .............................................................................3
- Manual Safety Symbols and Important Information3
- International Symbols.............................................3
- Personal Condition and Safety Equipment.............3
- Equipment...............................................................6
Description.....................................................................7
Contents .........................................................................8
Assembly........................................................................8
- ProSweep Gear Housing Assembly to
Lower Shaft Assembly............................................8
- Power Head Shaft to ProSweep Attachment ..........9
Operation......................................................................10
Maintenance.................................................................11
- Skill Levels ...........................................................11
- Maintenance Intervals...........................................11
- Lubrication............................................................11
- Brush Replacement..............................................13
Storage .........................................................................14
Specications ...............................................................14
Servicing Information ..................................................16
- Parts/Serial number...............................................16
- Service ..................................................................16
- ECHO Customer Assistance .................................16
- Warranty Card.......................................................16
- Additional or Replacement Manuals ....................16
- Manual Ordering Instructions ..............................16
Specications, descriptions and illustrative material in
this literature are as accurate as known at the time of pub-
lication, but are subject to change without notice. Illustra-
tions may include optional equipment and accessories,
and may not include all standard equipment.
t h e o p e r a t o r 'sm a n u a l
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specications and information
for operation, starting, stopping, maintenance, storage, and assembly
specic to this product.
t h e s a f e t y m a n u a l
(If available for attachment)
Explains possible hazards and what measures you should take to insure
safe operation.

Pr o Sw e e P At t A c h m e n t
oP e r A t o r 'SmA n u A l 3
sa f e t y
m a n u a l s a f e t y s y m b o l s a n d I m p o r t a n t I n f o r m a t I o n
I n t e r n a t I o n a l s y m b o l s
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Read and under-
stand Operator's
Manual.
Fuel and oil
mixture
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Carburetor adjust-
ment
- Idle speed
Carburetor adjust-
ment
- High speed
mixture
Wear eyes, ears
and head protec-
tion
Emergency stop Carburetoradjust-
ment
- Low speed
mixture
Safety/Alert
Wear hand
protection. Use
two handed.
DO NOT smoke
near fuel.
DO NOT allow
ames or sparks
near fuel.
Wear slip resis-
tant foot wear.
Engine choke
control.
Ignition
ON/OFF
Primer bulb
Keep bystanders and helpers
away 15 m (50 ft.).
Keep feet away
from rotaing at-
tachment
Thrown objects
p e r s o n a l c o n d I t I o n a n d s a f e t y e q u I p m e n t
WARNING
ProSweep users risk injury to themselves and others if the ProSweep attachment is used improperly and or safety
precautions are not followed. Proper clothing and safety gear must be worn when operating the ProSweep attach-
ment. Failure to do so can result in serious injury.
Throughout this manual and on the product itself, you will nd safety alerts and helpful, informational messages pre-
ceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to
you.
CAUTION
The safety alert symbol accompanied by the word
“CAUTION” calls attention to an act or condition
which may lead to minor or moderate personal
injury if not avoided.
WARNING
The safety alert symbol accompanied by the word
“WARNING” calls attention to an act or condi-
tion which CAN lead to serious personal injury or
death if not avoided.
CIRCLE AND SLASH SYMBOL
This symbol means the specic action
shown is prohibited. Ignoring these prohi-
bitions can result in serious or fatal injury.
NOTE
This enclosed message provides tips for use, care and
maintenance of the unit.
IMPORTANT
The enclosed message provides information neces-
sary for the protection of the unit.
DANGER
The safety alert symbol accompanied by the word
“DANGER” calls attention to an act or condition
which WILL lead to serious personal injury or
death if not avoided.

4
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE requirements whenever you operate the ProSweep attachment.
Hand Protection
Wear no-slip, heavy duty work gloves to improve your grip on the Pro Attachment Series or Split Boom handles. Gloves
also reduce the transmission of machine vibration to your hands.
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug tting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• Wear hair covering to contain long hair.
• DO NOT WEAR SHORTS,
• DO NOT WEAR TIES, SCARFS, JEWELRY.
Wear sturdy work shoes with non-skid soles;
• DO NOT WEAR OPEN TOED SHOES,
• DO NOT OPERATE UNIT BAREFOOTED.
Keep long hair away from engine and air intake. Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue which may lead to heat stroke. Schedule heavy work for early
morning or late afternoon hours when temperatures are cooler.
Vibration and Cold --
It is believed that a condition called Raynaud’s Phenomenon, which affects the ngers of certain individuals may be
brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sen-
sations followed by loss of color and numbness in the ngers. The following precautions are strongly recommended
because the minimum exposure which might trigger the ailment is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands and wrists.
• Maintain good blood circulation by performing vigorous arm exer-
cises during frequent work breaks and also by not smoking.
• Limit the hours of operation. Try to ll each day with jobs where
operating the unit or other hand-held power equipment is not re-
quired.
• If you experience discomfort, redness, and swelling of the ngers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.

Pr o Sw e e P At t A c h m e n t
oP e r A t o r 'SmA n u A l 5
Repetitive Stress Injuries --
It is believed that overusing the muscles and tendons of the ngers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high
risk for developing a Repetitive Stress Injury (RSI). An extreme RSI condition is Carpal Tunnel Syndrome (CTS), which
could occur when your wrist swells and squeezes a vital nerve that runs through the area. Some believe that prolonged
exposure to vibration may contribute to CTS. CTS can cause severe pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended or twisted position. In-
stead try to maintain a straight wrist position. Also, when grasping,
use your whole hand, not just the thumb and index nger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force in which you do the repetitive move-
ment.
• Do exercises to strengthen the hand and arm muscles.
• See a doctor if you feel tingling, numbness or pain in the ngers,
hands, wrists or arms. The sooner RSI/CTS is diagnosed, the more
likely permanent nerve and muscle damage can be prevented.
DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator's Manual and
Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animals prevented from coming nearer than 15 m (50 ft.) while the
unit is in use.
Keep a Firm Grip
• Hold the front and rear handles with both hands, with thumbs and
ngers tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on lad-
ders. Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft housing, attachment bearing hous-
ing and mufer cover area may become very hot, too hot to touch.
Avoid contact during and immediately after operation.
