Echo AIO™
Test Interfaces
Quick Start Guide
Echo Test + Measurement
402 East Carrillo Street, Suite A
Santa Barbara, California 93101
USA
echotm.com
[email protected]
001-805-880-5590

© 2021 Echo Test + Measurement
Safety Instructions
1. Read Instructions –Be sure to read all of the safety and operating instructions before operating this
product.
2. Keep Instructions –The safety instructions and user's manual should be kept for future reference.
3. Warnings –All warnings on your Echo AIO and in the User's Manual should be followed.
4. Follow Instructions –All operating and use instructions should be followed.
5. Moisture –Water and moisture are detrimental to the proper operation of the Echo AIO. Do not
install or operate your Echo AIO near sources of water or moisture such as sinks, damp basements, leaky
roofs, etc.
6. Heat –Your Echo AIO should be situated away from sources of heat such as heaters or radiators.
7. Power Sources –This unit should be operated only from a stable AC power source as indicated in this
documentation or on the Echo AIO. A surge protector is recommended in areas that are subject to
lightning or noise from industrial equipment such as that found on a factory floor.
8. Grounding –Precautions should be taken so that the grounding capabilities of the unit are not
undermined. The Echo AIO is provided with a cord with an equipment grounding conductor and
grounding plug. This plug must be plugged into an outlet that is properly installed and grounded in
accordance with all local rules and ordinances. Do not modify the plug provided with the equipment. If
the plug will not fit into your outlet, have a proper outlet installed by a qualified electrician.
9. Power Cord Protection –Power supply cords should be routed so that they are protected from
damage. Pay particular attention to protecting the plugs, outlets, and the point at which the cord exits
your Echo AIO.
10. Servicing –There are no user serviceable parts inside the Echo AIO. Do not attempt to service this
unit yourself, as opening the case will expose you to hazardous voltage or other dangers, will void the
calibration and void the warranty. All servicing should be referred to qualified service personnel.

© 2021 Echo Test + Measurement
Echo AIO Hardware Installation
Step 1 –Connect the AIO
Plug the supplied USB cable into the AIO and connect to an available USB port on the host computer. For
safety purposes, the USB cable should be properly locked into the AIO socket with the attached
thumbscrews.
Step 2 –Power
Plug the supplied locking power cable into the AIO and connect to a properly grounded outlet. If power
is present you will see the blue LED on the AIO front panel brightly lit.
There is no Power On/Off button on the AIO. Connecting the power cable will automatically power up
the unit.
You are now ready to move on to installing the software.

© 2021 Echo Test + Measurement
Echo AIO Software Installation
Step 1 - Download the AIO Software for PC or Mac
The Echo AIO Software can be found on the Downloads page of the Echo website at
www.echotm.com/downloads/. In order to access the downloads page you will have to register on the
website.
For Windows, download “Echo AIO Windows (ASIO, WASAPI, Control Panel)”.
For Mac, download “Echo AIO Mac (Control Panel, command-line App)”.
Step 2 - Install AIO Software
For Windows PC, run the driver installer. The AIO driver installer includes the ASIO audio driver, the AIO
Control Panel application, and the WASAPI audio driver.
The ASIO driver provides support for 3rd party software that requires ASIO for data acquisition. The
driver will appear in the 3rd party software as “ASIO Echo AIO”.
The AIO Control Panel is an application for setting and monitoring many of the AIO hardware functions.
After the installation is complete, look for a folder in the Windows Start menu named “Echo Test +
Measurement”. Inside that folder is the icon for the Echo AIO Control Panel application.
The WASAPI driver enables the AIO to work as a standard audio device and providing support for 3rd
party test applications that require WASAPI for data acquisition. The WASAPI driver is disabled by
default and can be enabled by the AIO Control Panel.
For macOS, the AIO uses the built-in USB audio driver. Open the “Echo AIO” disk image, and drag the
Control Panel application to your Applications folder.
Step 3 –AIO Control Panel
Run the Echo AIO Control Panel application and set up the hardware to properly interface with 3rd party
test software and your test setup. For more information on this topic, please refer to the Echo AIO
Manual.
Step 4 –Test Software
Install the 3rd party test software that you will be using with the AIO according to the manufacturer’s
instructions.
Note: the 3rd party test software must support WASAPI, ASIO or macOS CoreAudio to be compatible
with the Echo AIO Test System.Run the 3rd party test software and select the audio driver for the AIO.
For applications that support ASIO, choose “ASIO Echo AIO”. For applications that support WASAPI or
macOS Core Audio, choose the audio device with “EchoAIO” in the name.

© 2021 Echo Test + Measurement
At this point, the 3rd party test software should see the AIO driver and allow it to be selected as the
input and output connections.
Some of the 3rd party test software companies have already created setup guides and configuration
files to make this step simple. Please check with the 3rd party test software companies and our website
echotm.com for additional information.
You should now be able to connect microphones, fixtures, and Devices Under Test (DUT’s) and use the
Echo AIO Test System with your chosen 3rd party test software.

© 2021 Echo Test + Measurement
Limited 3 Year Warranty Policy
Echo warrants its products to be free of manufacturing defects for a period of three years from the date
of purchase. Any product covered under a valid Echo new product warranty—where the damage is not
caused by owner misuse or abuse (see Warranty Exclusions, below) —will be repaired or replaced by
Echo free of charge.
Note: Please see the full Echo Warranty Policy for more information on the warranty.

© 2021 Echo Test + Measurement
