Echo BRD-280 User manual

Specifications, descriptions and illustrative material in this literature are as accurate as known at the time
of publication, but are subject to change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
Operator’s Manual
X7502314001
© 04/2015 ECHO Inc.
x7722271404 / x772000164
BRD-280
Bed Redefiner
Burn Hazard
The muffler or catalytic muffler and surrounding cover may become extremely hot.
Always keep clear of exhaust and muffler area, otherwise serious personal injury may
occur.
The engine exhaust from this product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Users of this equipment risk injury to themselves and others if the unit is used
improperly and/or safety precautions are not followed. ECHO provides an operator’s
manual and a safety manual. Both must be read and understood for proper and safe
operation. Failure to do so could result in serious injury.

2X7502314001
© 04/2015 ECHO Inc.
TABLE OF CONTENTS BRD-280
TABLE OF CONTENTS
Table of Contents .............................................................................................................................. 2
Introduction ........................................................................................................................................ 3
The Operator’s Manual ................................................................................................................ 3
The Safety Manual....................................................................................................................... 3
Servicing Information ......................................................................................................................... 3
Parts/Serial Number..................................................................................................................... 3
Service......................................................................................................................................... 3
Echo Consumer Product Support ................................................................................................ 3
Product Registration .................................................................................................................... 3
Additional or Replacement Manuals ............................................................................................ 4
Safety................................................................................................................................................. 4
Manual Safety Symbols and Important Information..................................................................... 4
International Symbols .................................................................................................................. 5
Personal Condition and Safety Equipment .................................................................................. 6
Equipment.................................................................................................................................... 9
Emission Control (Exhaust & Evaporative)...................................................................................... 10
EPA 2010 and Later and/or C.A.R.B. TIER III ........................................................................... 10
Description....................................................................................................................................... 11
Contents .......................................................................................................................................... 13
Assembly ......................................................................................................................................... 14
Support Handle.......................................................................................................................... 14
Edger Blade Installation............................................................................................................. 14
Operation ......................................................................................................................................... 15
Fuel............................................................................................................................................ 15
Starting Cold Engine.................................................................................................................. 17
Starting Warm Engine................................................................................................................ 18
Stopping Engine......................................................................................................................... 18
Operation Techniques................................................................................................................ 19
Edging Operation....................................................................................................................... 20
Maintenance .................................................................................................................................... 22
Skill Levels................................................................................................................................. 22
Maintenance Intervals................................................................................................................ 22
Air Filter ..................................................................................................................................... 23
Fuel Filter................................................................................................................................... 24
Cooling System.......................................................................................................................... 25
Exhaust System......................................................................................................................... 26
Carburetor Adjustment............................................................................................................... 27
Drive Shaft Lubrication............................................................................................................... 27
Blade Replacement/Lubrication ................................................................................................. 28
Troubleshooting ............................................................................................................................... 30
Storage ............................................................................................................................................ 31
Long Term Storage (Over 30 Days)........................................................................................... 31
Specifications................................................................................................................................... 32
Warranty Statements ....................................................................................................................... 33
Product Registration ........................................................................................................................ 35
Notes ............................................................................................................................................... 36

BRD-280 INTRODUCTION
© 04/2015 ECHO Inc.
X7502314001 3
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and
on-the-job dependability. Read and understand this manual and the SAFETY MANUAL. You will find both
easy to use and full of helpful operating tips and SAFETY messages.
The Operator’s Manual
Keep it in a safe place for future reference. Contains specifications and information for safety, operation,
maintenance, storage and assembly specific to this product.
The Safety Manual
Keep it in a safe place for future reference. Explains possible hazards and the measures you should take to
insure safe operation.
SERVICING INFORMATION
Parts/Serial Number
Genuine ECHO Parts and ECHO REPOWER™ Parts and
Assemblies for your ECHO products are available only from an
Authorized ECHO Dealer. When you do need to buy parts always
have the Model Number and Serial Number of the unit with you. You
can find these numbers on the engine housing. For future
reference, write them in the space provided below.
Model No. _________________ SN. ___________________
Service
Service of this product during the warranty period must be performed by an Authorized ECHO Service
Dealer. For the name and address of the Authorized ECHO Service Dealer nearest you, ask your retailer or
call: 1-800-432-ECHO (3246). Dealer information is also available on our Web Site. When presenting your
unit for Warranty service/repairs, proof of purchase is required.
Echo Consumer Product Support
If you require assistance or have questions concerning the application, operation or maintenance of this
product you may call the ECHO Consumer Product Support Department at 1-800-673-1558 from 8:00 am to
5:00 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial
number of your unit.
Product Registration
To ensure trouble free warranty coverage it is important that you register your ECHO equipment on-line at
www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your
product confirms your warranty coverage and provides a direct link between you and ECHO if we find it
necessary to contact you.

4X7502314001
© 04/2015 ECHO Inc.
SAFETY BRD-280
Additional or Replacement Manuals
Replacement Operator, Safety Manuals, and Parts Catalogs
are available from your ECHO dealer or at www.echo-usa.com
or by contacting ECHO Inc., 400 Oakwood Road, Lake Zurich,
IL 60047 (800-673-1558). Always check the ECHO Web Site for
updated information.
Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video.
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts and helpful, informational
messages preceded by symbols or key words. The following is an explanation of those symbols and key
words and what they mean to you.
The safety alert symbol accompanied by the word “DANGER” calls attention to an act or condition
which WILL lead to serious personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING” calls attention to an act or condition
which CAN lead to serious personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION” calls attention to an act or condition
which may lead to minor or moderate personal injury if not avoided.
The enclosed message provides information necessary for the protection of the unit.
Note: This enclosed message provides tips for use, care and maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result
in serious or fatal injury.
For more information
scan this QR code.

BRD-280 SAFETY
© 04/2015 ECHO Inc.
X7502314001 5
International Symbols
Symbol Description Symbol Description Symbol Description Symbol Description
Warning, See
Operator’s
Manual
Carburetor
Adjustment -
High Speed
Mixture
DO NOT Allow
Flames or
Sparks Near
Fuel
Ignition
ON / OFF
Wear Eye, Ear
and Head
Protection
Carburetor
Adjustment -
Idle Speed
DO NOT
Smoke Near
Fuel
Primer Bulb
Wear Hand
and Foot
Protection
Carburetor
Adjustment -
Low Speed
Mixture
Choke Control
“RUN” Position
(Choke Open)
Choke Control
“COLD START”
Position (Choke
Closed)
Safety/Alert Emergency
Stop
Keep Feet
Away
From Blade
RotatingCutting
Attachment
Hot Surface Fuel and Oil
Mixture
Keep Bystanders and Helpers
Away 15 m (50 ft.).
A V O I D K I C K O U T .
Keep Bystanders At Least
15 meters (50 feet) Away.
Thrown
Objects
Direction of
Blade
Beware Throw n Objects
Wear Eye Protection

6X7502314001
© 04/2015 ECHO Inc.
SAFETY BRD-280
Personal Condition and Safety Equipment
Users of this product risk injury to themselves and others if the unit is used improperly and/or safety
precautions are not followed. Proper clothing and safety gear must be worn when operating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• If you are tired or sick.
• If you are taking medication.
• If you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
•Eye protection that meets ANSI Z87.1 or CE requirements must be worn whenever you operate the
unit.
•For additional safety, a full-face shield may be worn over safety glasses or goggles to provide
protection from sharp branches or flying debris.
Hand Protection
Wear sturdy, no-slip, rubber work gloves to improve your grip on the handles. Gloves also provide protection
against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your
hands.
Hearing/Ear Protection
ECHO recommends wearing hearing protection whenever unit is used.
Breathing Protection
Operators who are sensitive to dust or other common airborne allergens may need to wear a dust mask to
prevent inhaling these materials while operating unit. Dust masks can provide protection against dust, plant
debris, and other plant matter such as pollen. Make sure the mask does not impair your vision, and replace
the mask as needed to prevent air restrictions.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or hanging items that could become
entangled in moving parts or surrounding growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
Wear sturdy work shoes with nonskid rubber soles:
• DO NOT WEAR OPEN TOED SHOES.

BRD-280 SAFETY
© 04/2015 ECHO Inc.
X7502314001 7
• DO NOT OPERATE UNIT BAREFOOTED.
Keep long hair away from engine and air intake. Retain hair with cap or net.
Heavy protective clothing can increase operator fatigue, which may lead to heat stroke. Schedule heavy
work for early morning or late afternoon hours when temperatures are cooler.
The components of this machine generate an electromagnetic field during operation, which may
interfere with some pacemakers.To reduce the risk of serious or fatal injury, persons with
pacemakers should consult with their physician and the pacemaker manufacturer before operating
this machine.In the absence of such information, ECHO does not recommend the use of this
machine by anyone who has a pacemaker.
Extended Operation / Extreme Conditions
Prolonged exposure to cold and/or vibration may result in injury. Read and follow all safety and
operation instructions to minimize risk of injury. Failure to follow instructions may result in painful
wrist/hand/arm injuries.
It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals,
may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling
and burning sensations, followed by loss of color and numbness in the fingers. The following precautions are
strongly recommended, because the minimum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not
smoking.
• Limit the hours of operation. Try to fill each day with jobs
where operating the unit or other hand-held power equipment
is not required.
• If you experience discomfort, redness, and swelling of the
fingers followed by whitening and loss of feeling, consult your physician before further exposing yourself to
cold and vibration.

8X7502314001
© 04/2015 ECHO Inc.
SAFETY BRD-280
Repetitive Stress Injuries (RSI)
It is believed that overusing the muscles and tendons of the fingers,
hands, arms, and shoulders may cause soreness, swelling,
numbness, weakness, and extreme pain in those areas. Certain
repetitive hand activities may put you at a high risk for developing a
Repetitive Stress Injury (RSI). An extreme RSI condition is Carpal
Tunnel Syndrome (CTS), which could occur when your wrist swells
and squeezes a vital nerve that runs through the area. Some believe
that prolonged exposure to vibration may contribute to CTS. CTS
can cause severe pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead try to maintain a straight wrist position. Also, when
grasping, use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive movement.
• Do exercise to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if you feel tingling, numbness, or pain in
the fingers, hands, wrists, or arms. The sooner RSI/CTS is diagnosed, the more likely permanent nerve
and muscle damage can be prevented.
All over head electrical conductors and communications wires can have electricity flow with high
voltages. This unit is not insulated against electrical current. Never touch wires directly or indirectly,
otherwise serious injury or death may result.
Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains
poisonous emissions and can cause serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and Safety Manual for instructions on Safe
Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals prevented from coming nearer
than 15 m (50 ft.) while the unit is in use.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery, uneven or unstable surfaces. Do not
work in odd positions or on ladders. Do not over reach.

BRD-280 SAFETY
© 04/2015 ECHO Inc.
X7502314001 9
Avoid Hot Surfaces
• Keep exhaust area clear of flammable debris. Avoid contact
during and immediately after operation.
Equipment
Use only ECHO attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or
accessories which have not been tested and approved by ECHO. Read and comply with all safety
instructions listed in this manual and safety manual.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed.
• Inspect shield for damage and that shield is securely in place. Replace if shield is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe operating condition.
• Check that support handle is adjusted for safe, comfortable operation. See Assembly Section for proper
adjustment.
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects
away from all openings.
◆ALWAYS stop engine, disconnect spark plug, and make sure all moving parts have come to a complete
stop before removing obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and protective covers are properly assembled to unit.
◆NEVER reach into any opening while the engine is running. Moving parts may not be visible through
openings.
Check fuel system for leaks due to fuel tank damage, especially if the unit is dropped. If damage or
leaks are found, do not use unit, otherwise serious personal injury or property damage may occur.
Have unit repaired by an authorized servicing dealer before using.

10 X7502314001
© 04/2015 ECHO Inc.
EMISSION CONTROL (EXHAUST & EVAPORATIVE) BRD-280
EMISSION CONTROL (EXHAUST & EVAPORATIVE)
EPA 2010 and Later and/or C.A.R.B. TIER III
The emission control system for the engine is EM (engine modification)
and, if the second to last character of the Engine Family on the Emission
Control Information label (sample below) is “C”, “K”, or “T”, the emission
control system is EM and TWC (3-way catalyst). The fuel tank/fuel line
emission control system is EVAP (evaporative emissions). Evaporative
emissions for California models are only applicable to fuel tanks.
An Emission Control Label is located on the engine. (This is an
EXAMPLE ONLY, information on label varies by engine FAMILY).
Product Emission Durability (Emission Compliance Period)
The 50 or 300 hour emission compliance period is the time span
selected by the manufacturer certifying the engine emissions output
meets applicable emissions regulations, provided that approved
maintenance procedures are followed as listed in the Maintenance Section of this manual.

BRD-280 DESCRIPTION
© 04/2015 ECHO Inc.
X7502314001 11
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow
the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See
PARTS ORDERING instructions for specific information.
1
2
3
4
5
6
7
8
9
10
12
11
19
18
17
15
16
14 13
Hot Label
Shaft Label

12 X7502314001
© 04/2015 ECHO Inc.
DESCRIPTION BRD-280
1. POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter.
2. THROTTLE HANDLE - FOR RIGHT HAND - Contains the Stop Switch, Throttle Lockout, and Throttle
Trigger.
3. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle
trigger is prevented unless throttle trigger lockout lever is engaged.
4. STOP SWITCH - “SLIDE SWITCH” mounted on top of the throttle handle. Move switch FORWARD to
RUN, BACK to STOP.
5. SUPPORT HANDLE - FOR LEFT HAND - The support handle can be repositioned for comfortable
operation by loosening the screws and moving the handle.
6. DRIVE SHAFT ASSEMBLY - Contains a specially designed liner and the flexible drive shaft.
7. DEBRIS SHIELD/FLAP - Mounted over the cutting attachment. Helps protect operator by deflecting
debris produced during the redefining operation.
8. BLADE - Rotates to provide cutting action.
9. WHEEL - Adjustable up/down, sets depth of blade.
10. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration, press trigger
gradually for best operating technique.
11. TOP GUARD - Protects arm from the hot engine.
12. SPARK ARRESTOR MUFFLER OR SPARK ARRESTOR MUFFLER WITH CATALYST - The muffler or
catalytic muffler controls exhaust noise and emission. The spark arrestor screen prevents hot, glowing
particles of carbon from leaving the muffler. Keep exhaust area clear of flammable debris.
13. FUEL TANK - Contains fuel and fuel filter.
14. FUEL TANK CAP - Covers and seals fuel tank opening.
15. RECOIL STARTER/HANDLE - Pull handle slowly until starter engages, then quickly and firmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
16. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging
air from the carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return
line. Pump purge bulb an additional 4 or 5 times.
17. AIR CLEANER - Contains replaceable filter element.
18. CHOKE - The choke control is located at the rear of the air cleaner housing. Move choke lever to COLD
START ( ) to close choke for cold start. Move choke lever to RUN ( ) position to open choke.
19. SPARK PLUG -Provides spark to ignite fuel mixture.

BRD-280 CONTENTS
© 04/2015 ECHO Inc.
X7502314001 13
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging
restrictions, shield installation and other assembly may be necessary. After opening the carton, check for
damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list
to check for missing parts.
____ 1 - Power Head / Drive Shaft Assembly
____ 1 - Operator’s Manual
____ 1 - Emission Control Warranty Statement
____ 1 - Safety Manual
____ 1 - Safety Glasses
____ 1 - Support Handle
____ 1 - Lower Bracket, Support Handle
____ 4 - 5 x 35 mm Screws
____ 2 - Split Pins
____ Assembly Tool(s)
Specifications,descr iptionsand illustrativematerial in thisliterature are as accurateas known at the time
of publication, but are subject to change withoutnotice. Illustrationsmay include optional equipment and
accessories, and may not include all standardequipment.
Operator’s Manual
X7722271404 / X772000164
© 4/2011 ECHO Inc.
X7722271404 / X772000164
BRD-280
BedRedefiner
Burn Hazard
The muffler or catalyticmuffler and surrounding cover may become extremelyhot.
Alwayskeep clearof exhaust and muffler area, otherwise seriouspersonal injury mayoccur.
The engine exhaust from thisproductcontainschemicalsknown to the State of Californiatocause cancer.
birth defectsor other reproductive harm.
Read rulesfor safe oper ationand instructionscarefully.E CHO providesanOperator’s Manual
and aSafety Manual. Both must be read and understood for properand safe o peration.

14 X7502314001
© 04/2015 ECHO Inc.
ASSEMBLY BRD-280
ASSEMBLY
Support Handle
1. If necessary, position support handle for comfortable
operation and securely tighten screws.
Note: Label shows minimum spacing for support handle
location.
Edger Blade Installation
1. Remove bed redefining blade as shown in “Blade
Replacement” Section. Discard used split pin.
2. Do not remove inner blade adapter (A) or locking tool (B).
3. Install and center edger blade (C) on inner adapter.
4. Install outer adapter (D) and nut (E).
5. Tighten nut (E) firmly, counterclockwise.
6. Remove locking tool (B).
7. Install new split pin (F) to secure nut (E).
MIN
SPACING
A
B
C
D
E
F

BRD-280 OPERATION
© 04/2015 ECHO Inc.
X7502314001 15
OPERATION
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects
away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts
have come to a complete stop before removing obstructions, clearing debris, or servicing unit.
Operation of this equipment may create sparks that can start fires. This unit is equipped with a spark
arrestor to prevent discharge of hot particles from the engine. Metal cutters can create sparks if the
cutter strikes rocks, metal, or other hard objects. Contact local fire authorities for laws or
regulations regarding fire prevention requirements.
Fuel
Alternative fuels, such as E-15 (15% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO
requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels
may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended
machine operation, including, but not limited to, improper clutch engagement. Alternative fuels may
also cause premature deterioration of fuel lines, gaskets, carburetors and other engine components.
Fuel Requirements
Gasoline - Use 89 Octane [R+M/2] (mid grade or higher) gasoline known to be good quality. Gasoline may
contain up to 10% Ethanol (grain alcohol) or 15% MTBE (methyl tertiary-butyl ether). Gasoline containing
methanol (wood alcohol) is NOT approved. ECHO brand Power Fuel™is 93 octane, ethanol-free fuel
premixed with ECHO Red Armor®engine oil at 50:1 ratio. Use of ECHO Power Fuel™is recommended to
extend engine life in all air-cooled 2-stroke and 2/4-stroke hybrid engines.
Two Stroke Oil - A two-stroke engine oil meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards
must be used. Echo brand premium Power Blend X™Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an ISO-L-EGD (ISO/CD 13738) and
J.A.S.O. M345-FD certified oil, such as Echo premium Power Blend X™, will void the two-stroke engine
warranty.
Echo premium Power Blend X™Universal 2-Stroke Oil may be mixed at 50:1 ratio for application in all Echo
engines sold in the past regardless of ratio specified in those manuals.
Handling Fuel
Fuel is VERY flammable. Use extreme care when mixing, storing or handling, or serious personal
injury may result.
•Use an approved fuel container.
•DO NOT smoke near fuel.

16 X7502314001
© 04/2015 ECHO Inc.
OPERATION BRD-280
•DO NOT allow flames or sparks near fuel.
•Fuel tanks/cans may be under pressure. Always loosen fuel caps slowly allowing pressure to
equalize.
•NEVER refuel a unit when the engine is HOT or RUNNING!
•DO NOT fill fuel tanks indoors. ALWAYS fill fuel tanks outdoors over bare ground.
•DO NOT overfill fuel tank. Wipe up spills immediately.
•Securely tighten fuel tank cap and close fuel container after refueling.
•Inspect for fuel leakage. If fuel leakage is found, do not start or operate unit until leakage is
repaired.
•Move at least 3 m (10 ft.) from refueling location before starting the engine.
Mixing Instructions
1. Fill an approved fuel container with half of the required
amount of gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Add remaining gasoline, close fuel container, and remix.
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers
to reduce fuel spillage.
After use
• DO NOT store a unit with fuel in its tank. Leaks can occur.
Return unused fuel to an approved fuel storage container.
Storage - Fuel storage laws vary by locality. Contact your local government for the laws affecting your area.
As a precaution, store fuel in an approved, airtight container. Store in a well-ventilated, unoccupied building,
away from sparks and flames.
Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days, ninety (90) days when a
fuel stabilizer is added.
Stored two-stroke fuel may separate. ALWAYS shake fuel container thoroughly before each use.
For more information
scan this QR code.

BRD-280 OPERATION
© 04/2015 ECHO Inc.
X7502314001 17
Starting Cold Engine
The attachment will operate immediately when the engine
starts, and could result in possible serious injury.Keep
movable parts of the attachment away from objects that
could become entangled or thrown, and surfaces that
could cause loss of control.
1. Stop Switch
Move stop switch button (A) forward, away from the STOP
position.
2. Choke
Move choke lever (B) to COLD START ( ) position.
3. Purge Bulb
Pump purge bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5
times.
4. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts
clear of all obstacles. Firmly grasp throttle handle and throttle
trigger lockout with left hand and fully depress throttle trigger to wide open position. Rapidly pull recoil
starter handle/rope (D) until engine fires (or maximum five [5] pulls).
5. Choke
After engine fires (or 5 pulls), move choke lever back to RUN
( ) position. Firmly grasp throttle handle and throttle trigger
lockout with left hand and fully depress throttle trigger to wide
open position. Pull recoil starter handle/rope until engine
starts and runs. Release throttle trigger, and allow unit to
warm up at idle for several minutes.
Note: If engine does not start with choke in “RUN” position after
5 pulls, repeat instructions 2 - 5.
6. Throttle Trigger
After engine warm-up, grip throttle handle and support handle. Depress the throttle trigger lockout, and
gradually depress throttle trigger to increase engine RPM to operating speed.
A
B
C
D

18 X7502314001
© 04/2015 ECHO Inc.
OPERATION BRD-280
Starting Warm Engine
The starting procedure is the same as Cold Start except DO
NOT close the choke, and do not depress throttle trigger to wide
open position.
The attachment should not move at idle, otherwise serious
personal injury may result.
Note: If attachment moves, readjust carburetor according to
“Carburetor Adjustment” instructions in this manual or
see your ECHO Dealer.
1. Stop Switch
Move stop switch button (A) forward away from the STOP
position.
2. Purge Bulb
Pump purge bulb (C) until fuel is visible in the “Clear” fuel
return line.
3. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts
clear of all obstacles. Firmly grip throttle handle and throttle
trigger lockout with left hand. Rapidly pull recoil starter
handle/rope (D) until engine fires.
Note: If engine does not start after 5 pulls, use Cold Start
Procedure.
Stopping Engine
1. Throttle
Release throttle trigger and allow engine to return to idle
before shutting off engine.
2. Stop Switch
Move stop switch button (A) backward to STOP position.
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall
engine. Have your ECHO dealer repair stop switch before using unit again.
A
C
D
A

BRD-280 OPERATION
© 04/2015 ECHO Inc.
X7502314001 19
Operation Techniques
Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas. Breathing CO can cause
unconsciousness, serious injury, or death. Exhaust can cause serious burns. ALWAYS position
unit so that exhaust is directed away from your face and body.
Before operating unit, be sure to read and understand the entire Operator’s Manual to avoid the
chance of serious personal injury.
Note: For best results, use BRD redefining blade (provided with
unit) ONLY for redefining existing bed edges. For edging
next to curbs, sidewalks, or other hard surfaces, remove
redefining blade and install ECHO Approved Premium
Power Edger blade. Use of redefining blade next to hard
surfaces, can lead to premature blade wear.
1. Always grip throttle handle with right hand, and support
handle with left hand.
2. Before using Redefiner, check the area and remove objects
that could be thrown.
3. Carefully plan your direction of travel. Walk outside of bed.
Be aware of curbs or other obstacles.
4. Work with body turned toward engine as shown. Travel in
direction of arrow, pulling rather than pushing unit. Carefully
watch bed edge and direction of travel. Do NOT walk
backwards.
Do not walk towards gear case while operating unit with redefining blade installed, otherwise poor
performance or damage to unit could occur.
5. When starting to work, run the engine at full throttle, and
lower the blade gently into the ground. Travel around
perimeter of bed, allowing the Redefiner to improve bed's
edge.
6. Do not force the blade. Move only as quickly as conditions
will allow. If performance suffers or engine RPM drops,
reduce walking speed or decrease blade depth and allow
engine RPM to return to normal before continuing.
Note: Blade height may need to be adjusted due to differences
in height between the bed and the top of the grass.
Never adjust blade height while engine is running, otherwise serious personal injury may result.
For more information
scan this QR code.

20 X7502314001
© 04/2015 ECHO Inc.
OPERATION BRD-280
7. Loosen adjustment knob (A) and adjust the blade’s depth of
cut. Tighten adjustment knob (A) when desired blade height
is achieved.
8. If shield clogs with mud or debris, do not hit unit against
hard surfaces to clean, or damage to unit may occur. Stop
engine and unclog shield with a suitable tool.
Be sure blade has completely stopped spinning before setting
unit on concrete or other hard surface. Never allow spinning blade
to contact hard surfaces. Carbide teeth on blade can break, or
damage to surface can occur.
The complete unit, specifically the drive shaft assembly
and muffler exhaust area may become very hot during use.
Avoid contact during and immediately after operation,
otherwise serious personal injury may result.
Edging Operation
Before edging, be sure to read and understand the entire Operator’s Manual and Safety Manual to
avoid the chance of serious personal injury.
1. Before edging, water the area to soften the ground to make edging easier.
2. Before edging, check the area and remove all obstacles and objects that could be thrown.
3. Plan to edge regularly to make it easier to keep a neat edge and to avoid having to make more than one
pass.
Never adjust blade height or clear debris from shield with engine running, otherwise serious
personal injury may result.
Note: Blade depth may have to be adjusted due to differences in height between the hard surface and the
top of the grass.
