Echo DSRM-2600/U User manual

X7508163900
© 10/21 ECHO Incorporated
Operator’s
Manual
DSRM-2600/U
Grass Trimmer /
Brushcutter
Read and understand all provided literature before use. Failure
to do so could result in serious injury.
Cancer and Reproductive Harm
www.P65Warnings.ca.gov

TABLE OF CONTENTS DSRM-2600/U
2 X7508163900
© 10/21 ECHO Incorporated
TABLE OF CONTENTS
Introduction................................................................................................................. 3
Servicing Information.................................................................................................. 3
Parts and Serial Number.................................................................................... 3
Service ............................................................................................................... 4
ECHO Consumer Product Support .................................................................... 4
Product Registration........................................................................................... 4
Additional Literature ........................................................................................... 4
Safety ......................................................................................................................... 4
For safe use of your product .............................................................................. 4
International Symbols......................................................................................... 5
Handling the Product ......................................................................................... 6
Equipment ........................................................................................................ 12
Description ............................................................................................................... 14
Contents................................................................................................................... 15
Assembly.................................................................................................................. 16
DSRM-2600: .................................................................................................... 16
DSRM-2600U:.................................................................................................. 16
Shield Installation ............................................................................................. 17
Nylon Line Head Installation ............................................................................ 17
To Advance Trimmer Line................................................................................. 18
Balance and Adjust Unit - U model .................................................................. 22
Operation.................................................................................................................. 22
Operation with Blades ...................................................................................... 22
Blade Selection ................................................................................................ 24
Starting Unit .................................................................................................... 25
Stopping Unit.................................................................................................... 26
Applications...................................................................................................... 27
Operating Techniques - Nylon Line Head ........................................................ 27
Operating Techniques - Metal or Plastic Blade ................................................ 28
Reaction Forces ............................................................................................... 29
Blade Cutting Problems ................................................................................... 31
Maintenance............................................................................................................. 32
Skill Levels ....................................................................................................... 32
Maintenance Intervals ...................................................................................... 32
Maintenance and Care..................................................................................... 33
Lubrication........................................................................................................ 34
Nylon Line Replacement .................................................................................. 36
Sharpening Metal Blades ................................................................................. 38
Troubleshooting........................................................................................................ 39
Storage..................................................................................................................... 40
Storage ............................................................................................................ 40
Disposal ........................................................................................................... 41
Specifications ........................................................................................................... 42
Warranty................................................................................................................... 43
Product Registration .................................................................................................44

DSRM-2600/U INTRODUCTION
X7508163900 3
© 10/21 ECHO Incorporated
INTRODUCTION
Specifications, descriptions and illustrative material in this literature are as
accurate as known at the time of publication, but are subject to change
without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
Read and understand all provided literature.
Literature contains specifications and
information for safety, operation,
maintenance, storage, and assembly
specific to this product. Scan QR codes for
more information.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
OR
https://www.shindaiwa-usa.com/manuals
SERVICING INFORMATION
Parts and Serial Number
Genuine ECHO Parts and Assemblies for your ECHO products are
available only from an Authorized ECHO Dealer. When you do need to buy
parts always have the Model Number and Serial Number of the unit with
you. For future reference write them in the space provided below.
Model No. _____________________ Serial No. ____________________

SAFETY DSRM-2600/U
4 X7508163900
© 10/21 ECHO Incorporated
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
ECHO Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer
Product Support Department at 1-800-432-ECHO (3246) from 8:00 a.m. to
5:00 p.m. (Central Standard Time) Monday through Friday. Before calling,
please know the model and serial number of your unit.
Product Registration
Register your ECHO equipment online at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional Literature
In addition to finding information online, information is available from your
Authorized ECHO Service Dealer, or by contacting ECHO Incorporated,
400 Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).
SAFETY
For safe use of your product
Be careful to read this section before using your product.
• The precautions described in this section contain important safety
information. Please observe them carefully.
• You must also read the precautions that appear in the body of the manual
itself.
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.

DSRM-2600/U SAFETY
X7508163900 5
© 10/21 ECHO Incorporated
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which might lead to minor
or moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.
International Symbols
Symbol Description Symbol Description
Warning, See
Operator’s Manual Hot Surface
Wear Eye, Ear and
Head Protection Warning, side thrust

SAFETY DSRM-2600/U
6 X7508163900
© 10/21 ECHO Incorporated
Note: Not all symbols will appear on your unit.
Handling the Product
General Power Tool Safety Warnings
Read all safety warnings and all instructions and specifications
provided with this power tool. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
Wear Hand and Foot
Protection Beware of Fire
Safety/Alert Do Not Dispose in
Household Trash
Keep Bystanders and Helpers
Away 15 m (50 ft.)
DO NOT USE LINE
HEADS - Blades Only
DO NOT USE BLADES -
Line Heads Only
Do not expose
to rain / water
Protected Against Splashing Water
Symbol Description Symbol Description
IPX4

DSRM-2600/U SAFETY
X7508163900 7
© 10/21 ECHO Incorporated
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work Area Safety
• Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
• Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety
• Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the risk of electric
shock.
• Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric
shock.
• When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground
fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces
the risk of electric shock.
Personal Safety
• Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired, ill, or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.

SAFETY DSRM-2600/U
8 X7508163900
© 10/21 ECHO Incorporated
• Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery, picking up or carrying
the tool. Carrying power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
• Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or
surrounding growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
• Wear sturdy work shoes with nonskid rubber soles.
• DO NOT WEAR OPEN TOED SHOES.
• DO NOT OPERATE UNIT WITH BARE FEET.

DSRM-2600/U SAFETY
X7508163900 9
© 10/21 ECHO Incorporated
Power Tool Use and Care
• Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
• Disconnect the plug from the power source and/or the battery from the
power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may affect
the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean, and free from oil and
grease. Slippery handles and grasping surfaces to not allow for safe
handling and control of the tool in unexpected situations.
Battery Tool Use and Care
• Recharge only with ECHO eFORCE™ 56V battery series chargers. A
charger that is suitable for one type of battery may create a risk of fire
when used with another battery.
• Use only with ECHO eFORCE™ 56V battery series. Use of any other
battery may create a risk of injury and fire.
• When battery is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.

SAFETY DSRM-2600/U
10 X7508163900
© 10/21 ECHO Incorporated
• Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
• Do not open or destroy the battery. Electrolytes contained within the
battery are corrosive and may cause damage to eyes or skin if released.
It may be toxic if swallowed.
• Exercise care in handling batteries to avoid shorting the battery with
conducting materials such as rings, bracelets, keys, etc. The battery or
conductor may overheat and cause burns if contact with said materials is
made.
• Do not use a battery or tool that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire,
explosion or risk of injury.
• Do not expose a battery or tool to fire or excessive temperature.
Exposure to fire or temperature above 130°C (266°F) may cause
explosion.
• Follow all charging instructions and do not charge the battery or tool
outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage
the battery and increase the risk of fire.
Service
• Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Environmentally Safe Battery Disposal
The toxic and corrosive materials below are in the batteries used in this
machine: Lithium-Ion, a toxic material.
R
E
C
Y
C
L
E
1
.
8
0
0
.
8
2
2
.
8
8
3
R B R C
Li - ion
TM

DSRM-2600/U SAFETY
X7508163900 11
© 10/21 ECHO Incorporated
Discard all toxic materials in a specified manner to prevent
contamination of the environment. Before discarding a
damaged or worn out Li-ion battery, contact your local waste
disposal agency, or the local Environmental Protection Agency
for information and specific instructions. Take the batteries to a
local recycling and/or disposal center, certified for lithium-ion
disposal.
If the battery cracks or breaks, with or without leaks, do not
recharge it and do not use. Discard it and replace with a new
battery. DO NOT TRY TO REPAIR IT! To prevent injury and risk
of fire, explosion, or electric shock, and to avoid damage to
the environment:
• Cover the terminals of the battery with heavy-duty adhesive tape.
• DO NOT try to remove or destroy any of the battery components.
• DO NOT try to open the battery.
• If a leak develops, the released electrolytes are corrosive and toxic. DO
NOT get the solution in the eyes or on skin, and do not swallow it.
• DO NOT put these batteries in your regular household trash.
• DO NOT incinerate.
• DO NOT put them where they will become part of any waste landfill or
municipal solid waste stream.
• Take them to a certified recycling or disposal center.
Read Manuals
• Provide all users of this equipment with literature for instructions on safe
operation.
Clear the Work Area
• Always clear the work area of foreign objects such as rocks, broken
glass, nails, wire, or string, which can be thrown or become entangled in
the cutting attachment, and check for any hidden hazards. Spectators and
fellow workers must be warned, and children and animals prevented from
coming nearer than 50 ft. (15 m) while the unit is in use.

SAFETY DSRM-2600/U
12 X7508163900
© 10/21 ECHO Incorporated
• Outside the 50 ft. (15 m) zone, there is still a risk of injury from thrown
objects.
• Bystanders should be encouraged to wear eye protection.
• If you are approached, stop the unit and cutting attachment.
• When a bladed unit is used, there is the added risk of injury to bystanders
being struck with the moving blade in the event of a blade thrust or other
unexpected reaction of the blade.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
• Keep cutting attachment below waist.
• Keep all body parts away from rotating cutting attachment.
Equipment
Use only approved attachments. Serious injury may result from
the use of a non-approved attachment combination. ECHO
Incorporated will not be responsible for the failure of cutting
devices, attachments or accessories which have not been
tested and approved by ECHO Incorporated. Read and comply
with all safety instructions.
◆Do not attempt to modify this product. Serious injury can
result from the use of any modified product.
◆Check unit for loose or missing nuts, bolts, and screws.
Tighten or replace as needed.
◆Inspect shield for damage and ensure that shield is
properly installed, and that the cut-off knife is securely in
place. Replace if either is damaged or missing.
◆Check that the cutting attachment is firmly attached and in
safe operating condition.
◆Manufacturer recommended flexible non-metallic line is
installed in the trimmer head.

DSRM-2600/U SAFETY
X7508163900 13
© 10/21 ECHO Incorporated
◆Assure that trigger switch trigger, trigger switch lockout,
and stop switch all work properly.
◆Check that handle and harness (if included) are installed
and adjusted for safe, comfortable operation. See
Assembly Section for proper adjustment.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ALWAYS stop unit and make sure all moving parts have
come to a complete stop before assembling unit, removing
obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and
protective covers are properly assembled to unit.
◆NEVER reach into any opening while the unit is running.
Moving parts may not be visible through openings.
◆Position wiring safely to prevent snagging, separation of
connectors, or breakage during operation. Gather excess
wire, and secure with wiring clamp if provided on
equipment
◆Check wiring and connectors for nicks, cuts, exposed wire,
or other damage, and repair or replace as needed. Exposed
wire or connectors can cause shocks, sparks, and risk of
fire or explosion, resulting in serious injury.
◆Check wire terminals for secure connections.

DESCRIPTION DSRM-2600/U
14 X7508163900
© 10/21 ECHO Incorporated
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible
and that you understand and follow the instructions on it. If a decal cannot
be read, a new one can be ordered from your ECHO dealer. Safety label is
for example only. Your label may appear slightly different.
1. Gear Case
2. Nylon Line Head
3. Debris Shield
4. Cut-off Knife
5. Drive Shaft Assembly
6. Support Handle - For Left Hand
7. U-Handle Assembly
8. Harness Ring
9. Power Indicator LED

DSRM-2600/U CONTENTS
X7508163900 15
© 10/21 ECHO Incorporated
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
DSRM-2600:
DSRM-2600U:
*Not all units include battery and charger.
10. Power Button
11. - Button
12. + Button
13. Trigger Switch Lockout
14. Trigger Switch
15. Power Head
16. Battery Compartment
17. Throttle Handle - For Right Hand
18. Shoulder Harness
1 Power Head / Drive Shaft Assembly
1 Operator’s Manual
1 Battery*
1 Battery Charger*
1 Power Head / Drive Shaft Assembly
1 U-Handle Assembly
1 U-Handle Bolt
1 Shoulder Harness
1 Operator’s Manual
1Battery*
1 Battery Charger*

ASSEMBLY DSRM-2600/U
16 X7508163900
© 10/21 ECHO Incorporated
ASSEMBLY
DSRM-2600:
Note: Label shows minimum
spacing for support
handle location.
1. If necessary, position support
handle for comfortable
operation and securely tighten
screws.
DSRM-2600U:
Parts required: U-Handle assembly, handle bolt
1. Install U-handle clamp (A) to
drive shaft clamp (B). Secure
with U-handle bolt (C).
2. Loosen upper two (2) U-handle
clamp screws (D) and position
U-handle assembly for
comfortable operation.
3. Tighten U-handle clamp
screws.
ABD
C
A
B
C
ABD
C
D
D

DSRM-2600/U ASSEMBLY
X7508163900 17
© 10/21 ECHO Incorporated
Shield Installation
(Nylon line operation)
Parts required: Shield with cutoff knife, Shield Plate, three screws, line head
plate.
Shield with cutoff knife is for use with the Nylon Line Head only.
Install shield without cutoff knife when using plastic or metal
blades, or serious injury may result.
1. Remove blade, blade
mounting hardware, and shield
without cutoff knife and retain
for future use with blade
conversions.
2. Align holes in shield (H) shield
plate (I) and bottom of the gear
case flange. Install three (3)
screws.
3. Place line head plate (A) on
PTO shaft (F).
Nylon Line Head Installation
Parts Required: Nylon Line Head.
Wear Gloves or personal injury may result:
◆Cutoff knife is sharp.
◆Gearcase and surrounding area may be hot.
I
F
A
H

ASSEMBLY DSRM-2600/U
18 X7508163900
© 10/21 ECHO Incorporated
1. Align notch in edge of shield
and hole in line head plate with
notch in edge of gear housing
and insert head locking tool
(G).
2. Thread line head (J) onto PTO
shaft by turning it
counterclockwise until head is
tight against line head plate.
3. Remove locking tool (G).
Semi-automatic nylon line heads must be used only with debris
shield with cut-off knife. Using nylon line heads with debris shield
without cutoff knife can result in trimmer damage, caused by
operation with excessive line length.
Note: Your nylon line head may appear different than nylon line
head shown.
To Advance Trimmer Line
Note: To advance trimmer line, tap trimmer head against the
ground while the head is turning at normal operating speed.
Battery Charging
Note: See separate operator’s manuals packaged with battery and
charger.
• Use only with ECHO eFORCE™ 56V battery series batteries and
chargers.
• Keep charger and battery away from damp conditions and all liquids.
• Do not operate the charger on an easily combustible surface (e.g. paper,
textiles) or in an environment with a high risk of fire.
J
G

DSRM-2600/U ASSEMBLY
X7508163900 19
© 10/21 ECHO Incorporated
• Do not cover the charger. Covering the charger will prevent it from
cooling.
• Do not operate the charger in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Charger can produce
sparks which may ignite the dust or fumes - there is a risk of explosion.
• Connect the charger only to the mains of voltage and frequency specified
on the rating plate.
• Connect the charger only to an easily accessible wall outlet.
• Never insert objects in the battery's or charger's cooling slots.
• Do not charge or use a defective, damaged or deformed battery and
charger.
• Do not open, damage or drop the battery or the charger.
• Fluid may leak from the battery if it is damaged or not used properly;
avoid contact with the skin. In the event of accidental contact, wash the
affected areas of the skin with plenty of water and soap. If fluid gets in the
eyes, do not rub. Rinse the eyes with plenty of water for at least 15
minutes. Also seek medical assistance.
• Never bridge (short circuit) the battery contacts or the charger's terminals
with metallic objects.
• Protect from direct sunlight, heat and open flames and never throw
battery into fire; there is a risk of explosion.
• In the event of smoke or fire in the charger, disconnect it from the wall
outlet immediately.
• If the connecting cord is damaged, immediately disconnect the plug from
the power supply to avoid the risk of electric shock.
• Do not expose battery to microwaves or high pressure.
• To reduce the risk of stumbling, position and mark the connecting cord in
such a way that it cannot be damaged or endanger others.
The battery comes partially charged from the factory and needs to be
fully charged before first use. Charge the battery when it no longer
produces sufficient power to operate the unit or when battery lights
indicate that the battery is low.

ASSEMBLY DSRM-2600/U
20 X7508163900
© 10/21 ECHO Incorporated
1. Plug charger AC cord in the
wall outlet.
2. Align ridges on battery with
grooves on charger, and slide
battery into charger.
3. During normal charging, the
charger LED (A) will blink
GREEN.
If charger detects a problem, LED will blink RED. Remove battery
from charger, clear obstructions from contacts and reinstall battery
into charger. If battery is outside acceptable temperature range (0°C
to 60°C, 32°F to 140°F) LED will remain RED.
4. When charging is complete,
LED will remain GREEN. See
battery manual for charging
time.
5. Verify battery is fully charged.
Remove battery from charger,
press battery charge status
button (B), and check LED
display.
• One green light indicates that
the battery has 0-25% charge.
• Two green lights indicate that
the battery has 25-50% charge.
• Three green lights indicate that the battery has 50-75% charge.
• Four green lights indicate that the battery has 75-100% charge.
6. Unplug charger AC cord from the wall outlet.
A
B
