Echo GT-2000 Type 1E User manual

Grass Trimmer
Operator'sManual
MODELS GT-2000 TYPE 1E
Serial Number 001001 & Up Occasional Use
GT-2400 TYPE 1E
Serial Number 001001 & Up Commercial Use
WARNING DANGER
Readrulesforsafeoperationandinstructionscarefully. ECHOprovidesanOperator's
ManualandaSafetyManual. Bothmustbereadandunderstoodforproperandsafe
operation.
X7532270904 89869544434
03/01

2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-
dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will
find both easy to use and full of helpful operations tips and SAFETY messages.
WARNING DANGER
Readrulesforsafeoperationandinstructionscarefully. ECHOprovidesanOperator'sManualand
aSafetyManual. Bothmustbereadandunderstoodforproperandsafeoperation.
TABLE OF CONTENTS
Introduction ...............................................................2
Manual Safety Symbols and Important Information ..3
Safety .........................................................................3
- Decals .................................................................3
- InternationalSymbols .........................................4
- Equipment ...........................................................4
- Fuel .....................................................................5
- Personal Conditions and Safety Equipment .......5
- SafeOperation ....................................................7
- ExtendedOperation/ExtremeConditions ............8
Description ................................................................9
- EmissionControl.................................................9
- Contents List ......................................................9
Specifications........................................................... 12
Assembly ................................................................. 13
- PlasticShield..................................................... 13
- Nylon Head....................................................... 13
- Front(Loop)Handle ......................................... 13
Pre-Operation ........................................................... 14
- Fuel ................................................................... 14
- EquipmentCheck .............................................. 16
- DetermineOperationArea ................................ 16
Operation ................................................................. 17
- StartingColdEngine ......................................... 17
- StartingWarmEngine....................................... 18
- Stopping Engine ............................................... 18
Maintenance ............................................................ 19
- SkillLevel .......................................................... 19
- Maintenance Intervals ...................................... 19
- AirFilter ............................................................ 20
- FuelFilter........................................................... 20
- Spark plug ......................................................... 21
- Cooling System ................................................. 21
- Exhaust System ................................................. 22
- Carburetor Adjustment Emission Models ......... 23
- Carburetor Adjustment Non Emission Models . 24
- Lubrication ........................................................ 25
- NylonLineReplacement(GT-2000) ................... 25
- NylonLineReplacement(GT-2400) ................... 26
Troubleshooting ...................................................... 28
Storage ..................................................................... 29
ServicingInformation............................................... 32
- Parts.................................................................. 32
- Service .............................................................. 32
- ECHO CustomerAssistance ............................. 32
- Warranty Card .................................................. 32
- Additional or Replacement Manuals ................ 32
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.
THE OPERATOR'SMANUAL
contains specifications and information for operation, starting,
stopping, maintenance, storage and assembly specific to this product.
THE SAFETY MANUAL
explains possible hazards involved with the use of Grass Trimmers and
Brush cutters and what measures you should take to make their use
safer.
CopyRight© 2001 By Echo, Incorporated
All Rights Reserved.

G RASS T RIMMER
O PERATOR ' S M ANUAL
3
MANUALSAFETY SYMBOLS AND IMPORTANT INFORMATION
Throughout this manual and on the product itself, you will find safety
alerts and helpful, information messages preceded by symbols or key
words. The following is an explanation of those symbols and key words
and what they mean to you.
This symbol accompanied by the words WARNINGand
DANGER calls attention to an act or condition that can
lead to serious personal injury to operator and bystand-
ers.
The circle with the slash symbol means whatever is
shown within the circle is prohibited.
IMPORTANT The enclosed message
provides information necessary for the
protection of the unit.
NOTE This enclosed message provides
tips for use, care and maintenance of the
unit.
SAFETY
DECALS
Locate these safety decals on your unit. The complete unit illustration,
found in the "DESCRIPTION" section, will help you locate them. Make
sure the decals are legible and that you understand and follow the
instructions on them. If a decal cannot be read, a new one can be
orderedfromyourECHOdealer. SeePARTSORDERINGinstructions
forspecificinformation.
Metal Debris
Shield
•Thisunitcanbedangerousandcauseseriousinjuryifimproperlyused. •Operators,helpersandbystanderscanbeseverelyinjuredby
thrownobjectsandmustwearspecifiedANSIZ87.1eyeprotection.Blindnessorlossofeyecanoccur.Donotrelyoncutterheadshieldto
protecteyes.Ricochetcanoccur.•toavoidaccidentalcontact,keepeveryonebeyondoperatingarea.•Toreducetheriskofinjurytooperator,
helpers& bystanders, readand understandyour operator's andsafety manuals.For a freecopy ofthe safety Manual,write toECHO,
INCORPORATED,400OakwoodRoad,LakeZurich,IL60047.•Keepshieldandothercomponentsinplaceandingoodcondition.Donot
useattachmentsorotherpartsnotapprovedbyECHO.GTstyle(non-bladecapable)unitsmustnotbeconvertedtobladeuseexceptMaxi-
CutsorsimilarECHOapprovedattachments.
WARNING DANGER
SHAFTDECAL

4
INTERNATIONAL SYMBOLS
EQUIPMENT
Before operation a complete check of the unit must be performed;
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks.
DO NOT operate unit if leaks are found.
• Inspect shield for damage and ensure that the cut-off knife issecurely
in place. Replace if either is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe
operating condition.
• Check that front (loop) handle and optional shoulder/waist harness
are adjusted for safe, comfortable operation. See Assembly for proper
adjustment.
• Have repairs done only by an authorized ECHO Service Dealer.
• Do not use any attachment, accessory or replacement part unless it is
recommended in the Operator's Manual.
Spark Arrestor - Catalytic Muffler/Muffler
• The muffler or catalytic muffler controls the exhaust noise and
emissions. The spark arrestor screen prevents hot, glowing particles
of carbon from leaving the muffler. Make sure the spark arrestor
screen is in good repair and properly seated in the muffler. Keep
exhaust area clear of flammable debris. Avoid contact during and
immediatelyafteroperation.
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
"WARNING, SEE
OPERATOR'S
MANUAL
Wear eyes, ears and
head protection
Emergency stop
Fuel and oil mixture
Finger Severing
Primer Bulb
IGNITION
ON/OFF
Wear hand and
foot protection
WARNING
Do not exceed
10,000 RPM.
Beware
- Thrown,
Ricochet
objects
Carburetor adjustment
- Idle speed
Carburetor adjustment
- High speed mixture
Carburetor adjustment
- Low speed mixture Engine choke
control.

G RASS T RIMMER
O PERATOR ' S M ANUAL
5
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Trimmer/Brush Cutter users risk injury to themselves and others if the trimmer/brush cutter is used improperly and or
safety precautions are not followed. Proper clothing and safety gear must be worn when operating a trimmer.
FUEL
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling, otherwise serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallow flamesorsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowlyallowing pressure to equalize.
• NEVERrefuela unitwhenthe engineisHOT!
• NEVERrefuela unitwiththe enginerunning.
• DONOTfillfueltanksindoors.ALWAYSfillfueltanksoutdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
IMPORTANT
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers to
reducefuelspillage.ContactyourECHOdealerfor ordering
information.
After Refueling;
• Wipe any spilled fuel from the unit.
• Move at least 3 m (10 ft.) from refueling location before starting.
After Use;
• DO NOT store a unit with fuel in its tank. Leaks can occur. Return
unused fuel to an approved fuel storage container. 3 m (10 ft.)

6
Physical Condition --
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
•ifyouaretakingmedication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection --
Wear eye protection that meets ANSI Z87.1 or CE requirements
whenever you operate the trimmer.
Hand Protection --
Wear no-slip, heavy duty work gloves to improve your grip on the
Trimmer/Brush Cutter handles. Gloves also reduce the transmission of
machine vibration to your hands.
Hearing Protection --
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing --
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARVES,JEWELRY.
Wear sturdy work shoes with non-skid soles;
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Hot Humid Weather --
Heavy protective clothing can increase operator fatigue which may lead
to heat stroke. Schedule heavy work for early morning or late afternoon
hours when temperatures are cooler.

G RASS T RIMMER
O PERATOR ' S M ANUAL
7
SAFE OPERATION
Determine Operation Area
• Provide all operators of this equipment with the Operator's Manual
and instructions for safe operation.
• Review the area to be trimmed. Look for hazards that could contribute
to unsafe conditions.
• Spectators and fellow workers must be warned, and children and
animalspreventedfromcomingnearerthan15m(50ft.)while
thetrimmerisin use.
Operation
UseProperClothing&Equipment
• Before starting the unit, equip yourself and any other person
workingwithinthe15 m (50 ft.)SafetyZonewith the required
Protective Equipment and clothing.
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
KeepAFirmGrip
• Hold the front and rear handles with both hands with thumbs and
fingers encircling the handles
KeepASolidStance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
AvoidHotSurfaces
• During operation, the complete unit, especially the drive shaft
housing and the bearing housing may become very hot, too hot to
touch. Avoid contact during and immediately after operation.
15 m (50 ft.)

8
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold --
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommendedbecausethe minimum exposure whichmighttriggerthe
ailmentisunknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands
and wrists.
• Maintain good blood circulation by performing vigorous arm exer-
cises during frequent work breaks and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the trimmer or other hand-held power equipment is not
required.
• If you experience discomfort, redness and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Repetitive Stress Injuries --
It is believed that overusing the muscles and tendons of the fingers,
hands, arms and shoulders may cause soreness, swelling, numbness,
weakness and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged exposure
to vibration may contribute to CTS. CTS can cause severe pain for
months or even years. To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended or twisted position.
Instead try to maintain a straight wrist position. Also, when grasping,
use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed & force in which you do the repetitive movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if
you feel tingling, numbness or pain in the fingers, hands, wrists or
arms. The sooner RSI/CTS is diagnosed, the more likely permanent
nerve and muscle damage can be prevented.

G RASS T RIMMER
O PERATOR ' S M ANUAL
9
DESCRIPTION
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions,
shield installation and positioning of the front handle are necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
IMPORTANT ENGINE INFORMATION
ENGINEFAMILY:TEH021UB24RA
DISPLACEMENT:21.2cc
THISENGINEMEETSU.S.EPAPHIAND1995-1999
CALIFORNIAEMISSIONREGULATIONSFORULGE
ENGINES. REFER TO OWNER’S MANUAL FOR
MAINTENANCESPECIFICATIONSANDADJUSTMENTS.
EMISSION CONTROL --
The emission control system for this engine is EM (Engine
Modification).
EmissionControlLabellocatedonEngine
(EXAMPLEONLY,informationonlabelvariesbyFAMILY).
CONTENTS LIST
____ 1 - TrimmerAssembly
____ - PowerHead
____ - Drive Shaft Assembly
____ 1 - PlasticBag(Co-Pack)
____ - Operator's Manual
____ - Safety Manual
____ - Shield Assembly
____ - HardwareBag
____ -1,1/4-20bolt
____ -1,1/4-20wingnut
____ -1,1/4-20flatwasher
____ - ShoulderStrap,GT-2400only
____ - WarrantyCard &LimitedWarranty
____ - Safety Glasses
____ - Oil2Stroke
IMPORTANT
ThissparkignitionsystemcomplieswithCanadianICES-002

10
12
13
14
15
16
17
18
19 20
21
22
3
4
5
6
7
8
910
11
12

G RASS T RIMMER
O PERATOR ' S M ANUAL
11
1. OPERATOR'SMANUAL-Included in plasticbag(co-pack).Read before operationandkeepin a safe placefor
future reference, i.e., operation, maintenance, storage and specifications.
2. SAFETYMANUAL- Included inplasticbag(co-pack). Read before operationandkeepin a safeplaceforfuture
reference to learn proper, safe operating techniques.
3. POWERHEAD - Factory Assembled to the Driveshaft assembly. Includes the Engine, Clutch, Fuel System, Ignition
Systemand RecoilStarter.
4. FRONTHANDLE - The Front (loop) handle is factory assembled to the Drive Shaft assembly but must be re-
positioned for proper cutting attitude and operator comfort.
5. DRIVESHAFTASSEMBLY-Factory AssembledtothePowerHead. IncludestheRear(righthand)HandleAssem-
bly, Bearing Housing Assembly, Throttle Trigger, Front (loop, left hand) Handle Assembly, Flexible Drive Cable and
SafetyDecals.
6. NYLONCUTTERHEAD-Containsreplaceablenylontrimminglinethatadvanceswhenthetrimmerheadistapped
against the ground while the head is turning at normal operating speed.
7. DEBRISSHIELDASSEMBLY- Includedin plasticbag (co-pack). MUSTbeinstalledonunitbeforeuse,see
Assembly Instructions. Shield assembly includes the Cut-Off Knife and Safety Decal. Mounts on the Bearing
Housing Assembly just above the cutting attachment. Helps protect the operator by deflecting debris produced
duringthetrimmingoperation.
8. CUT-OFFKNIFE-Trimslinetothecorrectlength(5in.).Iftrimmerisoperatedwithoutacut-offknifethelinewill
become too long - more than (5 in.) - the operating speed will slow, the engine overheat and performance will suffer.
9. THROTTLETRIGGER-Springloadedtoreturntoidlewhenreleased. Duringacceleration,presstriggergradually
for best operating technique.
10. GRIP-Rear(righthand)handle.
11. STOPSWITCH-
GT-2000-"TOGGLESWITCH"mountedontheengine.MoveswitchUPtoRUN,DOWNtoSTOP.
GT-2400-"SLIDESWITCH" mounted on topoftheThrottle Trigger Housing. Move switchFORWARDtoRUN,
BACKtoSTOP.
12. SHOULDERHARNESS-Standard,GT-2400,optional,GT-2000. Anadjustablestrapthatsuspendstheunitfromthe
operator.
13. ARM REST - Provides arm rest during operation and protects arm from hot engine.
14. MUFFLERSPARKARRESTOR-Themufflercontrolstheexhaustnoisewhilethesparkarrestorpreventshot
particles of carbon from leaving leaving the muffler where they could possibly start a fire.
15. FUELTANK-Containsfuelandfuelfilter.
16. RECOILSTARTERHANDLE-Pullhandleslowlyuntilrecoilstarterengages,thenquicklyandfirmly. Whenengine
starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
17. FUELTANKCAP-Coverandsealsfueltankopening.
18. PRIMERBULB-Pumpingprimerbulbbeforestarting enginedrawsfreshfuelfromthefueltankprimingthecarbure-
tor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an
additional4 or5times.
19. AIRCLEANER-Containsreplaceablefilterelement.
20. CHOKE - Located above the air cleaner housing. Controls operation of choke. Move choke to starting position
(Close Choke) and back to run position (Open Choke).
21. SPARKPLUG-Providessparktoignitefuelmixture.
22. SAFETYVIDEO-(Notincludedwithunit)P/N99922202540Englishversiononlyisavailableatacostof$5.00from
ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating tech-
niques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information
on safe operation.

12
LEDOM0002-TG0042-TG
htgneL).ni1.55(mm0041).ni1.95(mm0051
htdiW ).ni0.31(mm033
thgieH ).ni2.41(mm063
daeHrettuC/w)yrd(thgieW).bl3.9(gk2.4).bl9.9(gk5.4
epyTenignE enigneenilosagrednilycelgnis,ekorts-owt,deloocriA
eroB).ni862.1(mm2.23).ni43.1(mm0.43
ekortS ).ni40.1(mm0.62
tnemecalpsiD).ni.uc92.1(cc2.12).ni.uc44.1(cc6.32
tsuahxE relffuMrotserrAkrapS
roterubraCegrup/wU1CledommgarhpaidamaZegrup/wledomTWorblaW
metsySnoitingI egrahcsidroticapac,otengamleehwylF
gulPkrapS).ni620.0(mm56.0(A7-RMPBKGN ).ni620.0(mm56.0(Y7-JCRnoipmahC
leuF )liOekorts-owTdnaenilosaG(dexiM
oitaRliO/leuF lioenignedeloocriaekorts-owt,ecnamrofrePhgiHOHCE1:05
enilosaG ,lohoclalyhtemgniniatnocleufesuTONOD.dedaelnuenatcO98 .EBTM%51rolohoclalyhte%01nahterom
liO lioenignedeloocriaekorts-owt,ecnamrofrePhgiHOHCE1:05
yticapaCknaTleuF ).zo.lfSU5.31(.til4.0
metsySretratSlioceR retratSlioceRcitamotuA
hctulC epyTlagufirtneC
tfahSevirD tfahSxelF"4/1
noitceriDgnitatoR potmorfdeweivesiwkcolC
daeHrettuC ).tf02(m5.6yticapacenil.ni080.htiw)eniL-2(daehenilnolyN
eldnaHtnorF pirG-thgiR,pooL-D-tfeL
ssenraHredluohS10200244999lanoitpOdradnatS
)MPR(deepSeldI MPR0023-0042
deepSelttorhTnepOediW eniLnolyNhtiw).T.O.W( )MPR(daeH MPR0057-0086
SPECIFICATIONS

G RASS T RIMMER
O PERATOR ' S M ANUAL
13
ASSEMBLY
Tools Required: Locking Tool
PLASTICSHIELD
1. Snap the shield over the bearing housing.
2. Install bolt (A), washer (B) and wing nut (C).
NYLON LINE HEAD
1. Align locating hole in locating plate with hole in bearing housing.
2. Insert 1/8" dia. locking tool (D) (not included with unit) and thread
cutting attachment onto shaft clockwise until head is tight.
IMPORTANT
Remembertoremovethelockingtool.
FRONT (LOOP) HANDLE
NOTE
Front handle is pre-installed. Re-positioning and tightening is all
that is required.
1. Position front handle (E) in comfortable operating position and
tighten wing nut (F). The cutting attachment should be 5cm- 7.5cm
(2 in. -3 in.) above the ground and as level as possible.
HARNESS (GT-2400 ONLY)
1. Put on harness and attach unit to harness.
2. Slide harness clamp up or down until unit balances with cutting
head approximately 2"- 3" from the ground.
3. Tighten harness clamp screw.

14
PRE - OPERATION
FUEL
Fuel Requirements
Gasoline - Use 89 Octane [ ] (mid grade or higher) gasoline known
to be good quality. Gasoline may contain up to 15% MTBE (methyl
tertiary-butylether). Gasohol containing methyl (wood) alcohol isNOT
approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)andJ.A.S.O. FCStandards,must beused.Echo brandPremium
50:1 oil meets these standards. Engine problems due to inadequate
lubricationcaused byfailureto useanISO-L-EGD andJ.A.S.O.FC
certifiedoil,suchasEchoPremium50:1Two-strokeOil,willvoidthe
two-stroke engine warranty. (Emission related parts only are covered
for two years, regardless of two-stroke oil used, per the statement listed
intheEPAPhaseI/CaliforniaEmissionDefectWarrantyExplanation.)
IMPORTANT
EchoPremium2-StrokeOilmaybemixedat50:1ratioforapplica-
tion in all Echo engines sold in the past regardless of ratio speci-
fied in those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from container
and surrounding area.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling, or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallow flamesorsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowlyallowing pressure to equalize.
• NEVERrefuela unitwhenthe engineisHOT!
• NEVERrefuela unitwiththe enginerunning.
• DONOTfillfueltanksindoors.ALWAYSfillfueltanksoutdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
R + M
2

G RASS T RIMMER
O PERATOR ' S M ANUAL
15
3 m (10 ft.)
IMPORTANT
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers to
reducefuelspillage.ContactyourECHOdealerfor ordering
information.
After refueling;
• Wipe any spilled fuel from the unit.
• Move at least 3 m (10 ft.) from refueling location before starting the
engine.
After use;
• DO NOT store a unit with fuel in its tank. Leaks can occur.
Return unused fuel to an approved fuel storage container.
Storage -
Fuel storage laws vary by locality. Contact your local government for
the laws affecting your area. As a precaution, store fuel in an approved,
air tight container. Store in a well ventilated, unoccupied building, away
from sparks and flames. Do not store fuel longer than 30 days.
IMPORTANT
Stored fuel ages. Do not mix more fuel than you expect to use in
thirty (30) days, ninety (90) days when a fuel stabilizer is added.
IMPORTANT
Stored two-stroke fuel may separate. ALWAYS shake fuel
container thoroughly before each use.
SMTWTFS
1234567
8 9 10 11 12 13 14
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30 31

16
EQUIPMENT CHECK
Before operation a complete check of the unit must be performed;
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel lieaks. DO
NOT operate unit if leaks are found.
• Inspect shield for damage and ensure that the cut-off knife is securely
in place. Replace if either is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe
operating condition.
• Check that front (loop) handle and shoulder strap/ or shoulder/waist
harness are adjusted for safe, comfortable operation. See Assembly
for proper adjustment.
• Have repairs done only by an authorized ECHO Service Dealer.
• Do not use any attachment, accessory or replacement part unless it is
recommended in the Operator's Manual.
DETERMINE OPERATION AREA
• Review the area to be trimmed. Look for hazards that could contribute
to unsafe conditions.
• Spectators and fellow workers must be warned, and children and
animalsprevented fromcomingnearerthan15 m(50ft.) whilethe
trimmerisinuse.
15 m (50 ft.)

G RASS T RIMMER
O PERATOR ' S M ANUAL
17
OPERATION
• Provide all operators of this equipment with the Operator's Manual
and Instructions for safe use.
• Before starting the unit, equip yourself and any other person working
within the 15 m (50 ft.) Safety Zone with the required Protective
Equipment and clothing.
• During operation, the complete unit, especially the drive shaft
housing and the bearing housing may become very hot, too hot to
touch. Avoid contact during and immediately after operation.
STARTING COLD ENGINE
WARNING DANGER
The cutting attachment should not rotate at idle. If attachment
rotates, readjust carburetor according to "Carburetor Adjustment"
instructions in this manual or see your ECHO Dealer, otherwise
serious personal injury may result.
1. Stop Switch -Start/Run.
Move stop switch button (A) away from the STOP position.
2. ChokeLever-ColdStart.
Move choke (B) to “Cold Start” Position.
3. Primer-PumpBulb
Pumpprimerbulb(C)until fuel is visible andflowsfreelyinthe
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
WARNING DANGER
Inspect starting area for hazards such as rocks, glass, debris etc.
which could be thrown by the cutting attachment when starting.
Keep helpers and bystanders at least 15m (50 feet) from starting
area, otherwise serious personal injury may result.
4. Lay thetrimmeron aflatcleararea. Firmlygraspthrottlegrip with
left hand and fully depress throttle trigger to wide open position.
Rapidlypullstarterhandle/rope(D)untilenginefires(maximumfive
[5]pulls). D

18
5. After engine fires or five (5) pulls, move choke lever to “Run”
position. Hold throttle trigger fully depressed and pull starter
handle/rope until engine starts and runs. Release throttle trigger
and allow unit to warm up at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions.
6. After engine warm up, gradually depress throttle trigger to increase
engine RPM to operating speed.
STARTING WARM ENGINE
WARNING DANGER
The cutting attachment should not rotate at idle. If attachment
rotates, readjust carburetor according to "Carburetor Adjustment"
instructions in this manual or see your ECHO Dealer, otherwise
serious personal injury may result.
1. Stop Switch - Start/Run. Move stop switch button (A) away from
the STOP position.
2. Start - Pull Rope. Lay the trimmer on a flat clear area and pull
the starter handle (D) until the engine fires.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
STOPPING ENGINE
1. Release Throttle. Allow engine to idle for a minute.
2. Stop Switch - Stop. Move stop switch button (A) backward to
STOPposition.
WARNING DANGER
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
HaveyourECHOdealerrepairstop switch before using trimmer
again.
NOTE
Refer to the Grass Trimmer / Brush Cutter Safety Manual for proper
and safe trimming techniques.
GT-2000
GT-2400
D

G RASS T RIMMER
O PERATOR ' S M ANUAL
19
MAINTENANCE
WARNING DANGER
Do not perform maintenance on engine or muffler until engine and muffler are completely cool, otherwise serious
personal injury may result.
Your ECHO trimmer is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your trimmer achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the
ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your Echo dealer for repairs.
SKILL LEVEL
Level1= Easy to do. Most required tools come with unit.
Level2= Moderatedifficulty. Some specialized tools may be required.
Level3= Experiencerequired.Specializedtoolsarerequired.
ECHO offers REPOWER Maintenance Kits and Parts to make your maintenance job easier. Just below each task heading
are listed the various part numbers required for that task. See your ECHO dealer for these parts.
MAINTENANCE INTERVALS
metsyS/tnenopmoCerudecorPecnanetniaM
royliaD erofeB esU
yrevE leufeR
shtnoM3 09ro sruoH shtnoM6 072ro sruoH ylraeY
retliFriAecalpeR/tcepsnI
C/I*R
reniartSleuFecalpeR/tcepsnI
IR
eniLleuFecalpeR/tcepsnI
II
roterubraCecalpeR/naelC/tcepsnI
C/I)1(R
metsySekohCecalpeR/naelC/tcepsnI
C/I
metsySgnilooCnaelC/tcepsnI
C/I
krapSrelffuM rotserrA naelC/tcepsnI
C/I
xelF(tfahSevirD )sledoMelbaC esaerG
)2(I
gnisuoHraeGesaerG
I
epoRretratSnaelC/tcepsnI
I
skaeLleuFriapeR/tcepsnI
II
gulPkrapSecalpeR/naelC
C/I*R
stloB/stuN/swercSecalpeR/nethgiT/tcepsnI
I
naelC=C/ecalpeR=R/tcepsnI=I TNATROPMI deriuqerfoycneuqerfehtenimretedlliwecneirepxeruoydnaesulautcA.mumixameranwohsslavretniemiT .ecnanetniam sishtnom6yrevegninaelc,esuremusnoCroF.ylraeyesulaicremmocrofderiuqereblliwtnemecalpeR)1( .stiKdliubeRsedulcnigninaelC.deriuqer ylppA)2(OHCE
®
EBUL
MT
.esufosruoh52yreve .noitcepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA*

20
AIR FILTER
Level1.
Tools required: Cleaningbrush,25-50mm(1or2in.)mediumbristle
paint brush.
Parts required: AirFilterP/N13031054130
1. Close choke (Cold Start Position). This prevents dirt from entering
the carburetor throat when the air filter is removed. Brush accumu-
lateddirtfromthe air cleaner area.
2. Remove the air cleaner cover. Clean and inspect the element for
damage. If element is fuel soaked and very dirty, replace.
3. If element can be cleaned and reused, be certain it:
-still fits the cavity in the air cleaner cover.
-is installed with the original side out.
NOTE
Carburetor adjustment may be needed after air filter cleaning/
replacement. See Carburetor Adjustment Section.
FUEL FILTER
Level1.
Toolsrequired: Fuellinehook,203-254mm(8-10in.)lengthofwirewith
one end bent into a hook. Clean rag, funnel, and an approved fuel
container.
Partsrequired:FuelFilterP/N13120507320
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and
emptyfueltank.
2. Use the “fuel line hook” to pull the fuel line and filter from the tank.
3. Remove thefilterfromtheline and install thenewfilter.
