Echo SRM-210U User manual

Grass Trimmer/Brush Cutter
Operator'sManual
MODEL SRM - 210U
WARNING DANGER
Readrulesforsafeoperationandinstructionscarefully. ECHOprovidesanOperator's
ManualandaSafetyManual. Bothmustbereadandunderstoodforproperandsafe
operation.
X7712275002 X771000502
04/06

2
Copyright©2006ByEcho,Incorporated
All Rights Reserved.
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will
find both easy to use and full of helpful operating tips and SAFETY messages.
THE OPERATOR'SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. Contains specifications and information for
operation, starting, stopping, maintenance, storage and assembly
specific to this product.
THE SAFETY MANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. Explains possible hazards involved with the
use of trimmer/brushcutters and the measures you should take to make
their use safer.
TABLE OF CONTENTS
Introduction ........................................................................ 2
- The Operator's Manual .............................................. 2
- The Safety manual ...................................................... 2
Safety.................................................................................. 3
- Manual Safety Symbols and Important Information . 3
- International Symbols................................................. 3
- Personal Condition and Safety Equipment................. 3
- Equipment .................................................................. 6
Emission Control ................................................................ 6
Description ......................................................................... 7
Contents ........................................................................... 10
Assembly.......................................................................... 11
- PlasticShield Installation.......................................... 11
- Nylon Head Installation ........................................... 11
- BladeInstallation ...................................................... 12
- U-Handle Installation ............................................... 13
- Throttle linkage and Ignition Leads .......................... 14
- Balnace and Adjust Unit........................................... 14
- BladeSelection.......................................................... 15
Operation.......................................................................... 17
- Fuel ........................................................................... 17
- StartingColdEngine ................................................. 18
- StartingWarmEngine ............................................... 19
- StoppingEngine........................................................ 20
Maintenance ..................................................................... 20
- SkillLevels................................................................ 20
- Maintenance Intervals .............................................. 21
- Air Filter ................................................................... 22
- Fuel Filter ................................................................. 22
- SparkPlug................................................................. 23
- CoolingSystem......................................................... 23
- Exhaust System ........................................................ 24
- Carburetor Adjustment............................................. 25
- Lubrication................................................................ 26
- Nylon Line Replacement .......................................... 27
- Sharpening Metal Blades .......................................... 28
Troubleshooting................................................................ 29
Storage .............................................................................. 30
Specifications.................................................................... 31
ServicingInformation........................................................ 32
- Parts.......................................................................... 32
- Service ....................................................................... 32
- ECHO Consumer Product Support.......................... 32
- Warranty Card .......................................................... 32
- Additional or Replacement Manuals ........................ 32
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 3
PERSONAL CONDITION AND SAFETY EQUIPMENT
INTERNATIONALSYMBOLS
IMPORTANT
Theenclosedmessageprovides
informationnecessaryfortheprotec-
tionoftheunit.
NOTE
Thisenclosedmessageprovidestips
foruse,careandmaintenanceofthe
unit.
Throughout this manual and on the product itself, you will find safety
alerts and helpful, informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words and what they mean to you.
SAFETY
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead
to serious personal injury to operator and bystanders.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
Hot
Surface
Carburetor
Adjustment
-Idlespeed
Carburetor
Adjustment
- High speed
mixture
DESCRIPTION SYMBOLSYMBOL
"WARNING, SEE
OPERATOR'S
MANUAL
Weareye,ear
and head
protection
Emergency
Stop Fueland oil
mixture
FingerSevering
Carburetor
Adjustment
-Lowspeed
mixture
Primer
Bulb
Ignition
ON/
OFF
Wear hand and
foot protection
Safety/Alert
Keepbystandersandhelpers
away15m(50ft.).
DONOTsmoke
nearfuel.
DONOTallow
flamesorsparks
nearfuel.
DESCRIPTION SYMBOL DESCRIPTION SYMBOL DESCRIPTION
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)
Do not use
blades.String
lineonly
WARNING DANGER
Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions
are not followed. Proper clothing and safety gear must be worn when operating unit.

4
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• ifyouaretakingmedication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your grip on the handle. Gloves also reduce the transmission of
machine vibration to your hands.
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARFS,JEWELRY.
Wear protective hair covering to contain long hair.
Wear sturdy work shoes with nonskid soles;
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue which may lead to heat stroke. Schedule heavy work for early
morning or late afternoon hours when temperatures are cooler.
Extended Operation/Extreme Conditions
It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be
brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning
sensations, followed by loss of color and numbness in the fingers. The following precautions are strongly recom-
mended,becausetheminimumexposure,which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands,
and wrists.
• Maintain good blood circulation by performing vigorous arm exer-
cises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 5
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and
Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animalspreventedfrom coming nearerthan15m (50 ft.)whiletheunit
is in use.
Keep a Firm Grip
• Hold the front and rear handles with both hands, with thumbs and
fingers encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
Avoid Hot Surfaces
• Keep exhaust area clear of flammable debris. Avoid contact during
andimmediatelyafteroperation.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high
riskfordeveloping a RepetitiveStressInjury(RSI). An extremeRSIcondition is CarpalTunnelSyndrome(CTS), which
could occur when your wrist swells and squeezes a vital nerve that runs through the area. Some believe that prolonged
exposure to vibration may contribute to CTS. CTS can cause severe pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead try to maintain a straight wrist position. Also, when grasping,
use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive move-
ment.
• Do exercise to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if
you feel tingling, numbness, or pain in the fingers, hands, wrists, or
arms. The sooner RSI/CTS is diagnosed, the more likely permanent
nerve and muscle damage can be prevented.

6
EQUIPMENT
WARNING DANGER
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which
have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and
safety manual.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed.
• Inspect fuel lines, tank, and area around carburetor for fuel leaks. DO NOT operate unit if leaks are found.
• Inspect shield for damage and ensure that the cut-off knife issecurely in place. Replace ifeither is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe operating condition.
• Check that front loop handle and shoulder strap/ or shoulder/waist harness are adjusted for safe, comfortable opera-
tion. See Assembly Section for proper adjustment.
PRODUCTEMISSIONDURABILITY
The 300 hour emission durability period is the time span selected by the manufacturer certifying the engine emissions
output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed
in the Maintenance Section of this manual.
AnEmissionControlLabelis located on the engine. (This is
anEXAMPLEONLY,informationonlabel variesbyengine
FAMILY).
EMISSION CONTROL
EPA Phase 2
The emission control system for these engines is EM/TWC (Engine Modification and Catalyst).
IMPORTANTENGINEINFORMATION
ENGINE FAMILY: 6EHXS.0214KF DISPLACEMENT: 21.2 cc
EMISSION COMPLIANCE PERIOD: 300 Hours
THIS ENGINE MEETS U.S. EPA PH2 AND 2005 - 2006
CALIFORNIA EMISSION REGULATIONS FOR SORES.
REFER TO OWNER'S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 7
DESCRIPTION
1
2
3
4
5
6
7
8
9
10
14
15
16
17
18
19
20
21
22
12
13
23
11

8
Debris Shield Decal
P/N 89016841031
P/N 89016006361
Hot Decal (near muffler)
P/N 89016054130
Shaft Decal
Spanish Decal
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the
instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER-
INGinstructionsforspecificinformation.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 9
1. POWERHEAD-IncludestheEngine,Clutch,FuelSystem,IgnitionSystem,andRecoilStarter.
2. RIGHTHANDGRIP
3. THROTTLETRIGGERLOCKOUT-Thislevermustbeheldduringacceleration.Operationofthethrottletriggeris
prevented unless throttle trigger lockout lever is engaged.
4. STOPSWITCH - "SLIDE SWITCH" mounted on top of the Throttle Trigger Housing. Move switch FORWARD to
RUN,BACKtoSTOP.
5. THROTTLETRIGGER- Controlsenginespeed. Springloadedtoreturntoidlewhenreleased. Duringacceleration,
press trigger gradually for best operating technique.
6. U-HANDLE-Providessecuretwo-handedcontroloftrimmer/brushcutter. Requiredformetalbladeoperation.
7. LEFTHANDGRIP
8. DRIVESHAFTASSEMBLY-IncludesGearHousingassembly,Bladeattachmentparts,FlexibleDriveCableand
SafetyDecal.
9. NYLONCUTTINGATTACHMENT-Containsreplaceablenylontrimminglinethatadvanceswhenthetrimmerhead
is tapped against the ground while the head is turning at normal operating speed.
10. CUT-OFFKNIFE- Automatically trimslineto the correctlength(5in.) afterheadistapped on thegroundwhile nylon
cutting attachment is turning. If trimmer is operated without a cut-off knife, the line will become too long, the engine
will overheat and engine damage may occur.
11. PLASTICDEBRISSHIELDASSEMBLY- Deflectsdebris. MUSTbeinstalledonunitbeforeNylonLineHeaduse
(See Assembly Instructions). Shield assembly includes the Cut-Off Knife and Safety Decal. Mounts on the Gear
Housing Assembly just above the cutting attachment. Helps protect the operator by deflecting debris produced
during the trimming operation. This shield must be replaced with the steel shield for blade use.
12. BLADES - Circular steel blades for grass, weeds, or brush cutting applications. (Harness, metal shield, and U-handle
required for blade operation.)
13. METALBLADESHIELD-Requiredwhenunitisequipped withblades. Donotoperateunitwithoutshield.
14. SHOULDERHARNESSWITHHIP PAD - An adjustable shoulderstrapthatsuspendsthe unit from the operator’s
shoulder. Using the strap reduces operator fatigue and enhances safety. Hip pad helps protect hip/leg and clothing
when using U-handle equipped units.
15. TOPGUARD-Protectsoperator's arm from the hotengineduringnormal operation.
16. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
17. FUELTANK-Holdsfuelandcontainsthefuelfilter.
18. FUELTANKCAP-Coversandsealsfueltankopening.
19. RECOILSTARTERHANDLE-Startsengine. Pullhandleslowlyuntilstarterengages,thenquicklyandfirmly.
When engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
20. PURGE BULB -Pumping purge bulb before starting engine draws freshfuelfromthefueltank,purging air from the
carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump purge bulb
an additional 4 or 5 times.
21. CHOKE - Adjusts Fuel/Air ratio for starting or running engine. The choke control is located at the top of the air filter
case. Move choke lever to "Cold Start" ( ) to close choke for cold starting. Move choke lever to "Run" ( )
position to open choke.
22. AIRCLEANER-Filtersoutdirtanddebrisinair. Containsreplaceablefilterelement.
23. SPARKPLUG-Providessparktoignitefuelmixture.

10
____ 1 - PowerHead
____ 1 - Drive Shaft Assembly w/Gear Housing
____ 1 - NylonTrimmerHead
____ 1 - PlasticDebrisShield
____ 1 - ShieldPlate
____ 3 - 5mmx16mmscrews(ShieldPlate-GearCase)
____ 1 - MetalShield
____ 1 - MetalShieldBracket
____ 2 - 5mmx8mmscrews(Bracket-Shield)
____ 4 - 5mmnuts(Bracket-Shield&GearCase)
____ 4 - 5mmlockwashers(Bracket-Shield&GearCase)
____ 1 - 8 Tooth Weed/Grass Blade
____ 1 - Shoulder Harness With Hip Pad
____ 1 - U-Handle Assembly
____ 1 - 8 mmhexhead bolt
____ 1 - 8mmflatwasher
___ 10 - 2mmx25mmCotterpins
____ 2 - Plastic cable clips
____ 1 - CombinationSocket/ScrewdriverTool(Scrench)
____ 1 - LockingTool
____ 1 - 3mm”L” hexwrench
____ 1 - 4mm”L” hexwrench
____ 1 - Operator’s Manual
____ 1 - Safety Manual
____ 1 - Warranty Registration Card
____ 1 - LimitedWarrantyStatement
____ 1 - Safety Glasses
_____ 1 - EchoPowerBlend TM 2-strokeoilsample
CONTENTS
Your new Echo product has been factory pre-assembled for your convenience. Due to packaging restrictions, shield
installation and other final assembly may be necessary.
Check the contents carefully, and notify your retailer or ECHO Dealer immediately if any parts are missing or damaged.
Use the contents list below to check for missing parts.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 11
ASSEMBLY
PLASTIC SHIELD INSTALLATION
Tools Required: Screwdriver,LockingTool,17x19mmT-Wrench,
8x10mmOpen-endWrench,3and4mmHex
Wrench,Pliers
Parts Required: PlasticDebrisShield,ShieldPlate,
three(3) 5x16mmscrews
WARNING DANGER
The plastic shield is for use with the Nylon Line Head only. Install
Metal Shield when using plastic or metal blades, or serious injury
mayresult.
1. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool to prevent splined shaft from turning. Arrow on
gear housing flange points to notch location.
2. Remove cotterpin(A), L.H.bladenut (B),lowerplate (C),and
upper plate (D) from PTO shaft. Turn blade nut clockwise to
remove.
3. Remove locking tool. Retain lower plate, blade nut, and cotter pin
for future use with blade conversions.
4. Align plastic debris shield (F) with the drive shaft, and install on
the bottom of the gear housing flange.
5. Place shield plate (E) on shield, align holes and install three (3)
screws.
6. Replace upper plate (D) on PTO shaft.
NYLON HEAD INSTALLATION
Parts Required: NylonLineHead.
1. Make sure plastic debris shield (F) is properly aligned, and upper
plate (D) is installed on splined PTO shaft.
2. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool (H) to prevent splined shaft from turning.
3. Thread line head (I) onto PTO shaft by turning it counter-clock-
wise until head is tight against upper plate (D).
4. Removelockingtool.
CBA
D
G
E
D
H
F
F
I

12
CBA
D
G
BLADEINSTALLATION
WARNING DANGER
You must install the U-Handle and all Blade Conversion parts shown in the following instructions before operat-
ing this unit with metal blades, otherwise serious injury may result.
K
J
G
NOTE
Model SRM-210U includes U-Handle, 8-tooth blade, and neces-
sary blade conversion parts. Blades must be selected for type of
cutting being performed. See page 16, "Blade Selection."
Install Metal Shield
Parts Required: MetalShield,ShieldBracket,
3-5 x 16 mmscrewsw/captivatedflat and lock-
washer, (metal shield to gear housing).
2-5x8mmscrews,2-5mmnuts,2-5mmlock-
washers, (bracket to shield).
2- 5mm nuts,2-5mmlockwashers
(bracket to gear housing)
1. If installed, remove nylon line head, upper plate and plastic shield,
and set upper plate aside for use with blade installation. Retain
plastic shield, shield plate, and plastic shield hardware for conver-
sion back to nylon line operation.
2. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool to prevent splined shaft from turning. Arrow on
gear housing flange points to notch location.
3. Remove splitpin(A),L.H. blade nut(B),lowerplate (C), and upper
plate (D) from PTO shaft. Turn blade nut clockwise to remove.
4. Removelockingtool.
5. Loosely attach bracket (J) to shield (K) and attach shield to bottom
of gear housing (G) with hardware provided.
6. Tighten all shield hardware.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 13
Install Blade
Parts Required: UpperPlatew/20mmpilot,LowerPlate,10mmNutw/
L.H.threads,2x25mmCotterPin,Blade.
1. Install upper plate (D) on splined PTO shaft, pilot side down. Blade
installationrequiresUpperPlate(D)with20mmpilot.
2. Install Blade (L) on upper plate pilot. Blades must be installed so
that rotation arrow on blade matches rotation of unit: teeth toward
direction of rotation (See debris shield decal). Secure blade with
LowerPlate(C),and10mmL.H.nut(B).Turnnutcounter-clockwise
on PTO shaft to tighten.
3. Align hole in upper plate with notch in gear housing, and insert
Locking Tool (H) to prevent splined shaft from turning. Arrow on
gear housing points to notch. Tighten 10 mm nut securely.
4. Insert Split Pin (A) in hole in PTO shaft, and bend pin legs around
shaft counterclockwise to retain 10 mm nut.
IMPORTANT
Never reuse a cotter pin - install a new cotter pin each time a blade is
installed or replaced.
5. Tri-CutBlade(M)isinstalledwithGlideCup(N).
6. Removelockingtool.
D
20
H
L
BA
C
D
L
C
B
A
HM
N
U-HANDLEINSTALLATION
Parts Required: U-Handle,Clampw/screws,8mm x55mmhexbolt,
8mmflatwasher
1. Install upper U-Handle and bracket on lower bracket with one (1)
8mmx55mmbolt(A)and(1)largecircularwasher. Donot tighten
bolt securely until final adjustments are completed.
2. Loosen upper (2) U-handle clamp screws (B), and position U-
handle as shown.
3. Lightly tighten 8mm bolt (A) and clamp screws (B) to hold U-handle
in position until final adjustments are completed.
4. Route throttle linkage and ignition lead assembly along shaft and
clip as shown.
A
B

14
DE
THROTTLE LINKAGE AND IGNITION LEADS
1. Place throttle linkage cable (C) through adjustmentfixture(D)and
installwireendintolargecarburetor throttle swivel hole (E). Check
throttle for freedom of movement and that wide open throttle / low
idle extremes are adjusted properly. The throttle linkage can be
adjusted by turning the adjustment fixture (D). Consult with your
Echo Dealer for correct adjustment procedure.
2. Connect ignition leads (F) and one ring terminal (G) which attaches
under fan housing screw.
3. Install throttle linkage into bracket clamp (H) and pinch snug with
pliers. Bend bracket up and flush against drive shaft.
C
F
G
H
I
J
BALANCE AND ADJUST UNIT
1. Loosen harness clamp screw.
2. Put on harness and attach unit to harness.
3. Slide harness clamp up (I) or down until unit balances with head
approximately50-75mm(2-3in.)fromtheground.
4. Tighten harness clamp screw.
5. Loosen upper U-Handle clamp screws (J), and position U-Handle
forcomfortableoperation.
6. Tighten U-Handle clampscrewsand8mm clamp bolt securely.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 15
BLADE SELECTION
WARNING DANGER
The type of Blade used MUST be matched to the type and size of material cut. An improper or dull blade can cause
serious personal injury. Blades MUST be sharp. Dull blades increase the chance of kick out, and injury to yourself
and bystanders.
Plastic/Nylon Blades may be used where ever the nylon line head is
used. DO NOT use this blade for heavy weeds or brush!
8 Tooth Weed/Grass Blade is designed for grass, garden debris and
thick weeds. DO NOT use this blade for brush or heavy woody growth,
19mm(3/4in.)diameterorlarger.
SRM-210SeriesP/N69600120331
80ToothBrushBlade(P/N69500120331)isdesignedforcuttingbrush
andwoodygrowth up to64mm (2-1/2in.) diameter.
22ToothClearingBlade(99944200130)isdesignedfordensethickets
andsaplings upto 64mm(2-1/2in.)diameter.

16
Shoulder/WaistHarness(P/N30100052131)Useofthe Shoulder/Waist
Harnessis recommendedforALLTrimmer/BrushCutter use.The
Shoulder/Waist Harness suspends the trimmer from the operator's
shoulder and reduces operator fatigue.
The restrictive harness enhances operator safety by reducing the
possibility of blade contact with the operator's hands and feet.
NOTE
In case of Emergency, the trimmer/brushcutter can be released from
the harness by pulling up on the quick-release collar.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 17
oitaR1:05-xiMliOotleuF
.S.UCIRTEM
SAGLIOSAGLIO
snollaG.zo.lFretiL.cc
1
2
5
6.2
2.5
31
4
8
02
08
061
004
Mixing Instructions
1. Fill an approved fuel container with half
of the required amount of gasoline.
2. Add the proper amount of 2-stroke oil
to gasoline.
3. Close container and shake to mix oil
with gasoline.
4. Add remaining gasoline, close fuel
container,andremix.
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.
Afteruse
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to an
approved fuel storage container.
Storage - Fuel storage laws vary by locality.
Contact your local government for the laws
affecting your area. As a precaution, store
fuel in an approved, airtight container. Store
in a well-ventilated, unoccupied building,
away from sparks and flames.
IMPORTANT
Storedfuelages. Do notmixmorefuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizerisadded.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container thor-
oughly before each use.
OPERATION
NOTICE:Useofunmixed,improperlymixed,orfuelolderthan90
days, (stale fuel), may cause hard starting, poor performance, or
severe engine damage and void the product warranty. Read and
follow instructions in the Storage section of this manual.
FUEL
Fuel Requirements
Gasoline-Use 89Octane[R+M/2](mid gradeorhigher) gasoline known
to be good quality. Gasoline may contain up to 15% MTBE (methyl
tertiary-butylether).Gasoholcontainingmethyl(wood)alcoholisNOT
approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)andJ.A.S.O.FCStandards must be used.Echobrandpremium
Power Blend TM Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an ISO-
L-EGDandJ.A.S.O.FCcertifiedoil,suchasEchopremiumPowerBlend
TM, will void the two-stroke engine warranty. (Emission related parts
only are covered for two years, regardless of two-stroke oil used, per
the statement listed in the Emission Defect Warranty Explanation.)
IMPORTANT
EchopremiumPowerBlendTM Universal2-StrokeOilmaybemixed
at 50:1 ratio for application in all Echo engines sold in the past
regardless of ratio specified in those manuals.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallow flamesorsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhentheengineisHOTorRUNNING!
• DONOTfillfueltanksindoors.ALWAYS fill fuel tanks outdoors
over bare ground.
•DONOToverfillfueltank. Wipeupspillsimmediately.
• Securely tighten fuel tank cap and close fuel container after
refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
• Move at least 3m (10 ft.) from refueling location before starting
the engine.

18
STARTING COLD ENGINE
WARNING DANGER
The attachment will operate immediately when the engine starts
and could result in loss of control and possible serious injury.
Keep movable parts of the attachment off the ground and away
from objects that could become entangled or thrown.
1. Stop Switch
Move stop switch button (A) forward away from the STOP
position.
2. Choke
Move choke lever (B) to Cold Start Position ( ).
3. Purge Bulb
Pump purger bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
NOTE
Lightly place knee on drive shaft to stabilize unit during starting. Do
not apply excessive downward force or damage to unit can occur.
4. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts clear
of all obstacles. Firmly grasp right hand grip and throttle trigger
lockout with left hand and fully depress throttle trigger to wide
open position. Rapidly pull recoil starter handle/rope (D) until
enginefires(ormaximumfive[5]pulls).
5. Choke
After engine fires (or 5 pulls), move choke lever back to Run ( )
position. Hold throttle trigger and throttle trigger lockout fully
depressed, and pull recoil starter starter handle/rope until engine
starts and runs. Release throttle trigger, and allow unit to warm up
at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions 2 - 5.
6. Throttle Trigger
After engine warm-up, gradually depress throttle trigger to increase
engine RPM to operating speed.
B
C
A
D

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 19
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke, and do not hold throttle trigger fully depressed.
WARNING DANGER
The attachment should not move at idle, otherwise serious
personal injury may result.
NOTE
If attachment moves, readjust carburetor according to “Carburetor
Adjustment” instructions in this manual or see your ECHO Dealer.
1. Stop Switch
Move stop switch button (A) forward away from the STOP
position.
2. Purge Bulb
Pump purgerbulb (C)untilfuelis visiblein the "Clear" fuel return
line.
NOTE
Lightly place knee on drive shaft to stabilize unit during starting. Do
not apply excessive downward force or damage to unit can occur.
3. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts clear
of all obstacles. Rapidly pull the recoil starter handle (D) until the
enginefires.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
C
A
D

20
STOPPING ENGINE
1. Release Throttle.
Allow engine to return to idle before shutting off engine.
2. Stop Switch.
Move stop switch button backward to STOP position.
WARNING DANGER
If engine does not stop when stop switch is moved to "STOP"
position, move choke lever to closed "Cold Start" position to stall
engine. Have your ECHO dealer repair stop switch before using
trimmeragain.
A
MAINTENANCE
Your ECHO trimmer is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your trimmer achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the
ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs
SKILL LEVELS
Level1= Easy to do. Most required tools come with unit.
Level2= Moderate difficulty. Some specialized tools may be required.
Level3= Experiencerequired.Specializedtoolsarerequired.ECHOrecommendsthat
the unit be returned to your ECHO dealer for servicing.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Below each task heading
are listed the various part numbers required for that task. See your ECHO dealer for these parts.
