Echo SRM-2400 Instruction Manual

GRASS TRIMMER
PARTS CATALOG
MODEL SRM-2400
MODEL SRM-2410
SERIAL NUMBER 001001 & UP
ECHO, INCORPORATED
400 OAKWOOD ROAD
LAKE ZURICH, IL 60047
999222025372674
09/99

2
SRM-2400/2410
1
2
3
55
4
6
7
789
10 11
12
13
13
16
14
15
8
ENGINE/EXTERNAL, INTERNAL, CRANKCASE, FAN HOUSING, COVER
17
18
19
20
21
22
23
24
25
26
29
28
27
30
31
32
33
22 21
20
19
17
26
27 28
29
18
18
11
25

3
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
REVISED09/99
1 10101109560 1 CYLINDER S/N001001-161628
1 10101108960 1 CYLINDER S/N 161629 & UP
2 90016205022 2 BOLT,H.S. 5X22
*3 10101044332 1 GASKET,CYLINDERBASE SEE GASKET KIT PAGE 7
4 10000009562 1 PISTONKIT INCLUDESITEMS5-8
5 10001109560 2 RING,PISTON
6 10001311520 1 PIN,PISTON
7 10001504630 2 CIRCLIP,PISTONPIN
8 10001411520 2 SPACER,PISTONPIN
9 10001251230 1 BEARING,NEEDLE
10 ------------------- 1 CRANKCASEKIT INCLUDESITEMS11-15(USESB1027)
11 10021242030 2 OILSEAL
12 10021503930 2 PIN,DOWEL
13 90081036201 2 BEARING,BALL 6201
*14 ------------------ 1 GASKET,CRANKCASE SEE GASKET KIT PAGE 7
15 90016205028 3 BOLT 5X28
16 ------------------- 1 CRANKSHAFT(S/N001001-161628)INCLUDESITEM9(USESB1027)
16 ------------------- 1 CRANKSHAFT(S/N161629&UP) INCLUDESITEM9(USESB1027)
17 10151149230 1 COVER,FAN S/N001001-065999
17 10150352130 1 COVER ASY, FAN S/N066000-117016
17 10150352131 1 COVER ASY, FAN S/N 117017 & UP
18 90016204016 6 BOLT 4X16
19 17500549230 1 DRUM,CLUTCH S/N001001-016000
19 17500548930 1 DRUM,CLUTCH S/N 016001 & UP
20 90070200028 1 CIRCLIP 28
21 90080706001 2 BEARING,BALL 6001
22 90070100012 1 CIRCLIP 12
23 61022349230 1 FLANGE,DRIVESHAFTHOUSING S/N001001-065999
24 90023805016 4 SCREW 5X16
25 61091027832 1 CUSHION S/N001001-117016
25 61091055230 1 CUSHION S/N 117017 & UP
26 61090327432 1 HOLDER KIT(S/N001001-117016) INCLUDESITEMS27-29
26 61090355230 1 HOLDER KIT(S/N117017 & UP) INCLUDESITEMS27-29
27 90014205025 2 BOLT 5X25
28 61092227432 1 HOLDER
29 61092327432 1 HOLDER (S/N001001-117016)
29 61092355230 1 HOLDER (S/N117017& UP)
30 89011552130 1 LABEL,MODEL
31 10151448730 1 COVER,CYLINDER S/N001001-015999
31 10151452630 1 COVER,CYLINDER S/N016000-161628
31 10151448930 1 COVER,CYLINDER S/N 161629 & UP
32 15991254130 1 GUARD,TOP
33 90023805016 1 SCREW 5X16
ENGINEREPOWER
SB1027 1 SHORTBLOCK INCLUDESFACTORYASSEMBLED
CYLINDER,CRANKCASE,PISTON,
CRANKSHAFT,BEARINGS&SEALS
90051 1 REPOWERTUNE-UPKITS/N016001-102000 INCLUDESTHEFOLLOWING
13031052130 1 FILTER,AIR
13120507320 1 STRAINER,FUEL
13130040630 1 VENT ASY
13201013930 1 PIPE, FUEL
15901010630 1 PLUG, SPARK
99988800079M 1 GD OIL,1GAL.MIX
ENGINE/EXTERNAL, INTERNAL, CRANKCASE, FAN HOUSING, COVER

4
SRM-2400/2410
1
2
3
4
5
6
7
8
9
13
11
10
4
15 16
17 18 19
20
1
2
3
4
5
6
7
8
10
11 13
20
19
18
17
14
1
2
3
6
7
8
9
10
12
11 13
15 16
17
18 19
20
5
4
15 16
S/N 001001 - 016000
S/N 016001 - 102000
S/N 102001 & UP
INTAKE, AIR CLEANER

5
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
1 13001042032 1 GASKET,INTAKE SEE GASKET KIT PG. 7
2 90050000005 2 NUT 5
3 90023805020 2 SCREW 5X20
4 17851600830 2 WASHER 5
5 17851504560 1 SHUTTER,CHOKE S/N001001-016000
5 17851505060 1 SHUTTER,CHOKE S/N 016001 & UP
6 13041044730 1 BRACKET,AIRCLEANER S/N001001-016000
6 12901151730 1 PLATE,PREVENT S/N016001-102000
6 12901152130 1 PLATE,PREVENT S/N 102001 & UP
7 90024205057 2 SCREW 5X57
8 13030250630 1 COVERASY,AIRCLEANER (S/N001001- 016000)INCLUDESITEMS 9&10
8 13030248930 1 COVERASY, AIRCLEANER (S/N016001 - 102000) INCLUDES ITEMS 9&10
8 13030252130 1 COVERASY,AIRCLEANER (S/N 102001&UP) INCLUDES ITEM10
9 90072000004 1 O-RING 4 S/N001001-016000
9 90072000003 1 O-RING 3 S/N016001-102000
10 13041540630 1 SCREW S/N001001-016000
10 13040616331 1 NUT,THUMB S/N016001-150505
10 13040652130 1 NUT,THUMB S/N 150506 & UP
11 89012148830 1 LABEL,CHOKE S/N001001-016000
11 89012152130 1 LABEL,CHOKE S/N 016001 & UP
12 13033651230 1 PLUG
13 13031004560 1 FILTER,AIR S/N001001-016000
13 13031048930 1 FILTER,AIR S/N016001-037399
13 13031052130 1 FILTER,AIR(H.D.)(S/N037400-102000)INCLUDEDINKIT90009
13 13031051830 1 FILTER,AIR(H.D.)(S/N102001&UP)INCLUDEDINKIT90030
14 90060000005 1 WASHER 5 S/N 102001 & UP
15 13030104560 1 CASE,AIRCLEANER(S/N001001-016000)INCLUDESITEM16
15 13031448930 1 CASE,AIRCLEANER S/N016001-102000
15 13031451730 1 CASE,AIRCLEANER S/N 102001 & UP
16 17881005230 1 GROMMET,CHOKE
17 17851048830 1 ROD,CHOKE S/N001001-016000
17 17851051730 1 KNOB,CHOKE S/N 016001 & UP
*18 12520052131 1 CARBURETOR C1U-K23A S/N001001-161628
18 12300052131 1 CARBURETOR WT-424 S/N 161629 & UP
19 13001642031 1 GASKET,INTAKE(S/N001001-161628) SEE GASKET KIT PG. 7
19 13001005960 1 GASEKT,INTAKE(S/N161629 &UP) SEE GASKET KIT PG. 7
20 13001742031 1 INSULATOR
INTAKE, AIR CLEANER

6
SRM-2400/2410
1
2
2
8
9
12
15
16
14
13
1
2
13
11
9
10
9
8
34
567
1
2
289
12
13
14
15
16
17
11
S/N 001001 - 016000
S/N 016001 - 161628
S/N 161629 & UP
EXHAUST

7
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
EXHAUST
1 14580042031 1 MUFFLER ASY (S/N001001 - 016000) INCLUDES ITEMS 2, 8, 9, 12 & 13
1 14580052130 1 MUFFLER ASY (S/N 016001 - 161628) INCLUDES ITEMS 2 - 11 & 13
1 14580052630 1 MUFFLER ASY (S/N 161629 & UP) INCLUDES ITEMS 2, 8, 9, 11 - 14
2 14551042031 2 GASKET, MUFFLER SEE GASKET KIT BELOW
2 14551051030 1 GASKET, MUFFLER (S/N 016001 - 161628 ONLY) SEE GASKET KIT BELOW
3 90023805010 1 SCREW 5X10
4 14571151030 1 STAY, MUFFLER
5 14581052130 1 MUFFLER
6 14585952130 1 DIFFUSER, MUFFLER
7 90010505018 2 BOLT, H.S. 5X18
8 14586240630 1 SCREEN, MUFFLER
8 14586251030 1 SCREEN, MUFFLER (S/N 016001 - 161628 ONLY)
9 14586642031 1 GASKET, MUFFLER LID SEE GASKET KIT BELOW
9 14586651030 2 GASKET, MUFFLER LID (S/N 016001 - 161628 ONLY) INCLUDED IN KIT BELOW
10 14588052130 1 PLATE,MUFFLER S/N 016001 - 161628
11 14586151030 1 LID, MUFFLER S/N 016001 - 161628
11 14587642030 1 LID, MUFFLER S/N 161629 & UP
12 14586342030 1 HOLDER, SCREEN S/N 001001 - 016000
12 14581852130 1 GUIDE, EXHAUST S/N 161629 & UP
13 90023804010 3 SCREW 4X10
13 90023805016 4 SCREW 5X10 (S/N 016001 - 161628 ONLY)
14 14587144331 1 COVER, MUFFLER
15 90010505055 2 BOLT, H.S. 5X55
16 90060000005 2 WASHER 5
17 90023805014 1 SCREW 5X14
88900044632 1 GASKET KIT (S/N 001001 - 016000)INCLUDES THE FOLLOWING
10101044332 1 GASKET, CYLINDER BASE
------------------ 1 GASKET, CRANKCASE
13001042032 1 GASKET, INTAKE
13001642031 1 GASKET, INTAKE
14551042031 2 GASKET, MUFFLER
14563142030 1 COVER, MUFFLER
14586642031 1 GASKET, MUFFLER LID
88900051030 1 GASKET KIT (S/N 016001 - 161628)INCLUDES THE FOLLOWING
10101044332 1 GASKET, CYLINDER BASE
------------------ 1 GASKET, CRANKCASE
13001042032 1 GASKET, INTAKE
13001642031 1 GASKET, INTAKE
14551051030 1 GASKET, MUFFLER
14586651030 2 GASKET, MUFFLER LID
88900005960 1 GASKET KIT (S/N 161629 & UP) INCLUDES THE FOLLOWING
10101044332 1 GASKET, CYLINDER BASE
------------------ 1 GASKET, CRANKCASE
13001005960 1 GASKET, INTAKE
13001042032 1 GASKET, INTAKE
13001642031 1 GASKET, INTAKE
14551042031 2 GASKET, MUFFLER
14586642031 1 GASKET, MUFFLER LID
61041001260 1 GASKET, GEAR HOUSING

8
SRM-2400/2410 STARTER, IGNITION, CLUTCH, FUEL SYSTEM
4
3
6
5
8
10
11 12 16 17
13
15
14
9
7
18
19
20
21
22 12
23
24
25
26
27
28
29
30
31
32
33
34
35

9
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
1 15901201620 1 CAP, SPARK PLUG
2 15901103432 1 COIL, SPARK PLUG CAP
3 99944500071 1 PLUG, SPARK BPM-7Y
3 15901010230 1 PLUG,SPARKBPMR-7A CANADIANMODELSONLY
4 15611240630 1 GROMMET
5 17720244330 1 PAWL ASY, STARTER INCLUDESITEMS6 &7
6 17723442030 1 SPRING,RETURN
7 17721844330 1 PAWL,STARTER
8 17720042033 1 STARTERASY INCLUDESITEMS9-15
9 17723644330 1 SCREW
10 17721544430 1 DRUM,STARTER
11 17722042030 1 SPRING,REWIND
12 17723242032 1 CASE,STARTER
13 17722605530 1 ROPE,STARTER USEBULK ROPE 99944400040
DIA.3MM(.12IN.)X890MM(35.0IN.)
14 17722742030 1 GUIDE,ROPE
15 17722806530 1 GRIP,STARTER
16 90016204016 2 BOLT,H.S. 4X16
17 89011849130 1 LABEL,BRAND
18 15680144731 1 FLYWHEEL S/N001001-208136
18 15680109660 1 FLYWHEEL S/N 208137 & UP
19 17500042031 1 CLUTCHASY
20 90016204022 2 BOLT,H.S. 4X22
21 16202152130 1 LEAD S/N 161629 & UP
22 15660144731 1 COIL,IGNITIONW/LEAD S/N001001-161628
22 15660152130 1 COIL,IGNITIONW/OLEAD S/N161629-208136
22 15662609660 1 COIL,IGNITION S/N 208137 & UP
23 13130040630 1 VENT ASY INCLUDEDINKIT90010
24 13131244330 1 PIPE 3X5X70
25 13211546730 1 GROMMET,FUEL
26 13201309820 1 CLIP
27 13120507320 1 STRAINER,FUEL INCLUDEDINKIT90009OR90030
28 13201251030 1 PIPE 3X5X90
29 13201013930 1 PIPE, FUEL
30 13100544331 1 TANK,FUEL
31 90060300005 2 WASHER 5
32 90023805016 2 SCREW 5X16
33 30511042030 1 STAND
34 13100455830 1 CAP ASY, FUEL TANK INCLUDESITEM35(INCLUDEDINKIT90010
35 13101655830 1 GASKET,FUEL TANK CAP
REVISED09/99
STARTER, IGNITION, CLUTCH, FUEL SYSTEM

10
SRM-2400/2410 DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH
1
2345
67
8
9
10
11
12
13
1415 14
16
17
18
19
24
23
25
26
29
8
33
34
30
31
30
13
32
5
6
7
4
19
20
21
22
24
23
4
25
26
28
27

11
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH
1 30120708930 1 HOOK INCLUDES ITEMS 2 & 3
2 90010005018 1 BOLT 5X18
3 69901203330 1 SPACER
4 17802449230 1 BRACKET, THROTTLE S/N 001001 - 016000
4 17800352130 1 BRACKET SET, THROTTLE (S/N S/N 016001 & UP) INCLUDES TIEMS 6, 25, & 26
5 16340049230 1 SWITCH, IGNITION
6 90050000005 1 NUT 5
7 90056000005 1 LOCKNUT 5
8 35120151730 1 HANDLE ASY, LOOP (S/N 001001 - 016000)INCLUDES ITEMS 9 - 12 & 29
8 35120152130 1 HANDLE ASY, LOOP (S/N 016001 & UP) INCLUDES ITEMS 9 - 12 & 29
9 35121351730 1 GRIP, FRONT HANDLE
10 35121051730 1 HANDLE, FRONT
11 90050000005 4 NUT 5
12 90024605030 2 SCREW 5X30
13 61060944730 1 HOUSING ASY, DRIVE SHAFT INCLUDES ITEMS 30 & 31
14 90050200006 2 NUT 6
15 90060000006 2 WASHER 6
16 17800144430 1 WIRE, THROTTLE
17 17812724030 1 TUBE 10X11X160 S/N 001001 - 016000
17 17812750330 1 TUBE S/N 16001 & UP
18 17804805630 1 HOLDER, THROTTLE WIRE S/N 001001 - 016000
19 35101244730 1 GRIP, HANDLE S/N 001001 - 016000
19 35121352130 1 GRIP, FRONT HANDLE S/N 016001 & UP
20 61027252130 1 BAND 25 (S/N 016001 & UP) INCLUDES ITEMS 21 & 22
21 90024205028 1 SCREW 5X28 S/N 016001 & UP
22 90050000005 1 NUT 5 S/N 016001 & UP
23 17801048731 1 CONTROL, THROTTLE S/N 001001 - 016000
23 17801052130 1 CONTROL, THROTTLE S/N 016001 & UP
24 17804306930 1 SPRING, THROTTLE RETURN S/N 001001 - 016000
24 17804342230 1 SPRING, THROTTLE RETURN S/N 016001 & UP
25 17811005330 1 SCREW S/N 001001 - 016000
25 90024205025 1 SCREW 5X25 S/N 016001 & UP
26 90024205030 1 SCREW 5X30 S/N 001001 - 016000
26 90024205035 1 SCREW 5X35 S/N 016001 & UP
27 30120029430 1 BAND (S/N 016001 & UP) INCLUDES ITEM 28
28 90024205014 1 SCREW 5X14 S/N 016001 & UP
29 90024205035 4 SCREW 5X35
30 61024644730 2 FIXTURE, LINER
31 61021744730 1 LINER, FLEXIBLE
32 61001344730 1 SHAFT, FLEXIBLE
33 89016049730 1 LABEL, CAUTION
34 89031744530 1 LABEL, CAUTION
34 89031744730 1 LABEL, CAUTION CANADA

12
SRM-2400/2410
SRM-2410SRM-2410
SRM-2410SRM-2410
SRM-2410
1
2
3
4
5
6
7
8
9
10
11
12 13 14
14
15
16
17
18
17
19
20
21
22
23
24
25
26
27
28
29
30 30
31
33
32
DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH, HARNESS

13
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
SRM-2410SRM-2410
SRM-2410SRM-2410
SRM-2410
1 17811005330 1 SCREW
2 90022005025 1 SCREW 5X25
3 17802441830 1 BRACKET,THROTTLE
4 17801006460 1 CONTROL,THROTTLE
5 90056000005 1 LOCKNUT 5
6 90050000005 1 NUT 5
7 16340149230 1 SWITCH,IGNITION
8 17804305230 1 SPRING,THROTTLERETURN
9 17810605330 1 BAND
10 90022005010 1 SCREW 5X10
11 17811104930 1 CLIP,THROTTLEWIRE
12 17812708030 1 TUBE 10X11X750
13 17800141330 1 WIRE,THROTTLE
14 17802105530 2 LOCKNUT
15 89015204930 1 LABEL,CAUTION
16 61060944730 1 HOUSINGASY,DRIVESHAFT INCLUDESITEMS17&18
17 61024644730 2 FIXTURE,LINER
18 61021744730 1 LINER,FLEXIBLE
19 35101005530 1 HANDLE,FRONTR.H
20 35131522130 1 GRIP,HANDLER.H
21 30120521330 1 HOOK INCLUDESITEM22
22 90010005012 1 BOLT 5X12
23 35121023430 1 HANDLE,FRONTL.H.
24 35131102330 1 GRIP,HANDLEL.H.
25 61001344730 1 SHAFT,FLEXIBLE
26 89037144530 1 LABEL,CAUTION
27 89016049730 1 LABEL,CAUTION
28 35130109230 1 BRACKETASY,HANDLE INCLUDESITEMS29-31
29 90014205025 4 BOLT 5X25
30 35131904130 2 SPACER
31 90014206030 2 BOLT 6X30
32 30100052131 1 HARNESS ASY INCLUDESITEM33
33 30110541830 1 PAD,WAIST
DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH, HARNESS

14
SRM-2400/2410
1
2
3
45678
9
16
19
20
21
22
23
24
25
26
30
31
29
28
27
4
3
18
13
15
10 17
9
10
11
12
36
37
42
11
10
39
38
40
38
41
32 33 35
34
14
9
16
GEARCASE, SHIELDS, TOOLS

15
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
1 90010008008 1 BOLT 8X8 S/N001001-102000
1 61043450030 1 BOLT S/N 102001 & UP
2 90010005035 2 BOLT 5X35
3 90060000005 2 WASHER 5
4 61030044830 1 GEAR SET, BEVEL
5 90085506900 1 BEARING,BALL 6900
6 90085806900 1 BEARING,BALL 6900
7 90070200022 1 CIRCLIP 22
8 90070600012 1 CIRCLIP 12
9 90060500005 5 WASHER, SPRING 5
10 90050000005 6 NUT 5
11 89011848830 1 LABEL,ECHO
12 89016841031 1 LABEL,CAUTION
13 69901023531 1 SHIELD,BLADE
14 69900023431 1 SHIELDASY(BL) INCLUDES ITEMS 9, 10, 13, 15 - 17
15 90022005008 2 SCREW 5X8
16 90024205010 4 SCREW 5X10
17 69901523431 1 BRACKET,SHIELD
18 61023904130 2 WASHER,SHIM
19 61040240930 1 HOUSINGASY,GEAR INCLUDES ITEMS 1 - 9, 16, 18, 20 - 31
20 90030020022 1 PIN,SPLIT 2X22
21 90051100010 1 NUT 10 (L-H)
22 61031404131 1 PLATE,ADAPTER (L)
23 61033808930 1 PLATE,ADAPTER (U)
24 61041307130 1 OILSEAL
25 61031507130 1 SPACER
26 90070200032 1 CIRCLIP 32
27 90081036201 1 BEARING,BALL 6201
28 61036008931 1 SHAFT,P.T.O.
29 90070600010 1 CIRCLIP 10
30 90080000609 1 BEARING, BALL 609
31 61046027430 1 HOUSING,GEAR
32 89850201130 1 PIN 2X22 (W/POUCH)
33 89751801131 1 LOCKINGTOOL
34 89511200330 1 SPANNER 8X10
35 89541008030 1 WRENCH,W/SCREWDRIVER
36 89561203430 1 ALLANWRENCH
37 69900440931 1 SHIELDASY INCLUDESITEMS10,38-41
38 90024205016 5 SCREW 5X16
39 69901840830 1 BRACKET,SHIELD
40 69901644330 1 KNIFE,CORD
41 69901027231 1 SHIELD,BLADE
42 89016844330 1 LABEL,CAUTION
GEARCASE, SHIELDS, TOOLS

16
SRM-2400/2410
1
2
3
4
5
6
7
8
9
10
11 12 13
14 15
14
16
10
17
18
19
20
21
22
23
24
25
26
27
28
29
CARBURETOR S/N 001001 - 161628

17
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
12520052131 1 CARBURETOR C1U-K23A INCLUDESTHEFOLLOWINGITEMS
1 12534413931 2 SCREW
2 12534215130 1 COVER,DIAPHRAGM
3 A B 1 DIAPHRAGM
4 A B 1 GASKET,DIAPHRAGM
5 12533942030 1 SCREW
6 A 1 PIN
7 A 1 ARM, VALVE
8 A 1 SPRING,COIL
9 A 1 VALVE, NEEDLE
10 12532715130 2 CLIP
11 A 1 PLUG,WELCH
12 12531651230 1 VALVE,THROTTLE
13 12531451230 1 SCREW
14 12531942030 2 SPRING,COIL
15 12531851330 1 NEEDLE,IDLE
16 12532051230 1 NEEDLE,HIGHSPEED
17 12537242030 1 SWIVEL
18 12531742030 1 SHAFT,THROTTLE
19 12531342030 1 SPRING,THROTTLERETURN
20 12537813930 1 PIECE,FRICTION
21 12533413930 1 SCREW,IDLEADJUST
22 12531011610 2 SCREW
23 12536311610 1 RING
24 12538146730 1 PUMP,PURGE
25 12532411610 1 COVER,PUMP
26 A B 1 GASKET, FUEL PUMP
27 A B 1 DIAPHRAGM,FUELPUMP
28 A 1 STRAINER
29 12537651030 1 NOZZLE,CHECKVALVE
A 12530051330 1 REBUILDKIT
B 12530351030 1 GASKET/DIAPHRAGMKIT
CARBURETOR S/N 001001 - 161628

18
SRM-2400/2410
1
2
3
4
5
67
8
9
10
11 12
13
14
15
16
16
25
26
27
28
29 17
17
18
19
20
21
22
23
24
30
A
A
CARBURETOR S/N 161629 & UP

19
SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
12300052131 1 CARBURETOR WT-424A INCLUDESTHEFOLLOWINGITEMS
1 12311043130 2 SCREW
2 12314209560 1 COVER, PURGE PUMP
3 12318109560 1 PUMP, PURGE
4 12317135630 1 VALVE, CHECK PURGE
5 12312443230 1 COVER, FUEL PUMP
6 12313304260 1 SPRING,IDLEADJUST
7 12313404260 1 SCREW,IDLEADJUST
8 A B 1 GASKET, FUEL PUMP
9 A B 1 DIAPHRAGM,FUELPUMP
10 A 1 SCREEN,INLET
11 12311352130 1 SPRING,THROTTLESHAFT
12 12311752130 1 SHAFT,THROTTLE
13 12317307930 1 CLIP
14 12314926030 1 WASHER
15 12317226030 1 SWIVEL
16 12312052130 2 NEEDLE,MIXTURE
17 12315139230 2 CAP,LIMITER
18 A 1 PLUG, WELCH
19 A 1 VALVE, INLET NEEDLE
20 A 1 SPRING,METERINGLEVER
21 A 1 LEVER,METERING
22 A 1 PIN,METERINGLEVER
23 A 1 SCREW, METERING LEVER PIN
24 A B 1 GASKET,METERINGDIAPHRAGM
25 A B 1 DIAPHRAGM,METERING
26 12314203930 1 COVER,METERINGDIAPHRAGM
27 A 4 SCREW
28 12311652130 1 VALVE,THROTTLE
29 12311403930 1 SCREW
30 12312715030 1 CLIP
A 12310052130 1 REBUILDKIT
B 12310152130 1 GASKET/DIAPHRAGMKIT
CARBURETOR S/N 161629 & UP

20
SRM-2400/2410
696001 20330696001 20330
696001 20330696001 20330
696001 20330
8" 8 CUTTER BLADE8" 8 CUTTER BLADE
8" 8 CUTTER BLADE8" 8 CUTTER BLADE
8" 8 CUTTER BLADE
695001 20330695001 20330
695001 20330695001 20330
695001 20330
8" BRUSH BLADE8" BRUSH BLADE
8" BRUSH BLADE8" BRUSH BLADE
8" BRUSH BLADE
99442 00130 CLEARING99442 00130 CLEARING
99442 00130 CLEARING99442 00130 CLEARING
99442 00130 CLEARING
SAW BLADESAW BLADE
SAW BLADESAW BLADE
SAW BLADE
351304 49230 U-HANDLE KIT351304 49230 U-HANDLE KIT
351304 49230 U-HANDLE KIT351304 49230 U-HANDLE KIT
351304 49230 U-HANDLE KIT
999442 00200 SHOULDER STRAP KIT999442 00200 SHOULDER STRAP KIT
999442 00200 SHOULDER STRAP KIT999442 00200 SHOULDER STRAP KIT
999442 00200 SHOULDER STRAP KIT
