Echo SHC-210 User manual

HEDGE CLIPPER
OPERATOR'SMANUAL 1
Shaft Hedge Clipper
Operator'sManual
MODEL SHC-210
Serial Number 07001001 - 07999999
X750005481
03/03
X7502253801
WARNING DANGER
Readrulesforsafeoperationandinstructionscarefully. ECHOprovidesan
Operator'sManualandaSafetyManual. Bothmustbereadandunderstoodfor
properandsafeoperation.Failuretodosocouldresultinserousinjury.

2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will
find both easy to use and full of helpful operating tips and SAFETY messages.
TABLE OF CONTENTS
Introduction ...............................................................2
- The Operator's Manual........................................2
- The Safety manual...............................................2
Manual Safety Symbols and Important Information ..3
Safety .........................................................................3
- Decals .................................................................3
- InternationalSymbols .........................................4
Safety Instructions ....................................................4
- Personal Conditions and Safety Equipment .......4
- ExtendedOperation/ExtremeConditions ............5
- Equipment ...........................................................5
- SafeOperation ....................................................6
EmissionsControl ......................................................6
Description ................................................................7
- Contents .............................................................7
Specifications.............................................................9
Assembly ................................................................. 10
- Gear Housing Assembly / Drive Shaft .............. 10
Pre-Operation ........................................................... 11
- Fuel.................................................................... 11
Operation ................................................................. 12
- Starting ColdEngine ......................................... 12
- StartingWarmEngine ....................................... 13
Copyright© 2003 By Echo, Incorporated
All Rights Reserved.
- Stopping Engine................................................ 13
Maintenance ............................................................ 14
- SkillLevels ........................................................ 14
- Maintenance Intervals ...................................... 14
- AirFilter ............................................................ 15
- FuelFilter........................................................... 15
- SparkPlug ......................................................... 16
- CoolingSystemCleaning .................................. 16
- Exhaust System ................................................. 17
- Carburetor Adjustment...................................... 18
- Lubrication ........................................................ 19
- Sharpening Blades ............................................ 21
Troubleshooting ...................................................... 22
Storage..................................................................... 23
ServicingInformation............................................... 24
- Parts .................................................................. 24
- Service ............................................................... 24
- ECHO ConsumerProduct Support .................... 24
- Warranty Card ................................................... 24
- Additional or Replacement Manuals ................. 24
Specifications,descriptionsandillustrative material in
this literature are as accurate as known at the time of
publication, but are subject to change without notice.
Illustrations may include optional equipment and
accessories, and may not include all standard equip-
ment.
THE OPERATOR'SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specifications and information for
operation, starting, stopping, maintenance, storage, and assembly
specific to this product.
THE SAFETY MANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It xplains possible hazards involved with the
use of Hedge Clippers and what measures you should take to make their
use safer.

HEDGE CLIPPER
OPERATOR'SMANUAL 3
SAFETY
DECALS
Locate these safety decals on your unit. Make sure the decals are
legible and that you understand and follow the instructions on them.
If a decal cannot be read, a new one can be ordered from your ECHO
dealer. SeePARTSORDERINGinstructionsforspecificinformation.
IMPORTANT Theenclosedmessage
provides information necessary for the
protection of the unit.
NOTE This enclosed message provides tips for
use, care and maintenance of the unit.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
Throughout this manual and on the product itself, you will find safety
alerts and helpful, informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words and what they mean to you.
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead
to serious personal injury to operator and bystanders.
Hand Guard
Hot Surface Decal
P/N 89016006361
P/N 89018721560

4
INTERNATIONALSYMBOLS
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Carburetor
adjustment
-Idlespeed
Carburetor
adjustment
- High speed
mixture
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Readand
understand
Operator'sManual.
Weareyes,ears
andhead
protection
Emergencystop
Fueland oil
mixture
FingerSevering
Carburetor
adjustment
-Low speed
mixture
Safety/Alert
Do not operate
closerthan15M
(50 ft.) from
electrical
hazards.
Keepbystanders
atleast15meters
(50feet)away.
Planretreatpath
from falling
objects.
Wearhand
protection.Use
twohanded.
DONOTsmoke
nearfuel.
DONOT allow
flamesorsparks
nearfuel.
Wearslip
resistantfoot
wear.
Ignition
ON/OFF
Primerbulb
Avoidallpower
lines.Thisunitis
notinsulated
againstelectrical
current.
SAFETYINSTRUCTIONS
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Hedge Clipper users risk injury to themselves and others if the hedge clipper is used improperly and or safety
precautions are not followed. Proper clothing and safety gear must be worn when operating a hedge clipper.
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• ifyou are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
EyeprotectionthatmeetsANSIZ87.1orCErequirements
must be worn whenever you operate the unit.
Hand Protection
Wear no-slip, heavy duty work gloves to improve your
grip on the handles. Gloves also reduce the transmission
of machine vibration to your hands.
Hearing Protection
Wearhearingprotection.ECHOrecommendswearing
hearing protection whenever unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARFS,JEWELRY.
Wear protective hair covering to contain long hair.
Wear sturdy work shoes with nonskid soles;
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Wear no-slip, heavy duty work gloves.

HEDGE CLIPPER
OPERATOR'SMANUAL 5
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals, may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations, followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommended,becausetheminimum exposure which mighttriggerthe
ailmentisunknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands,
and wrists.
• Maintain good blood circulation by performing vigorous armexercises
during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms, and shoulders may cause soreness, swelling, numbness,
weakness, and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged exposure
to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the
following:
• Avoid using your wrist in a bent, ex-
tended, or twisted position. Instead try to
maintain a straight wrist position. Also,
when grasping, use your whole hand, not
just the thumb and index finger.
• Takeperiodicbreakstominimizerepetition
and rest your hands.
• Reduce the speed and force with which
you do the repetitive movement.
• Do exercises to strengthen the hand and
armmuscles.
• Immediately stop using all power equip-
ment and consult a doctor if you feel
tingling, numbness, or pain in the fingers,
hands, wrists, or arms. The sooner RSI/
CTSisdiagnosed, themorelikelyperma-
nent nerve and muscle damage can be
prevented.
EQUIPMENT
WARNING DANGER
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories which
have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and
safety manual.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Never adjust blades when the engine is operating.
• Inspect hand guard for damage. Replace if damaged or missing.
• Check that the blade assembly is firmly attached and in safe operating
condition. Dull, loose or damaged blades should not be used.
• Keep exhaust area clear of flammable debris. Avoid contact during
andimmediatelyafteroperation.

6
SAFE OPERATION
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can
cause serious injury or death.
ReadtheManual
• Provide all users of this equipment with the Operator's Manual and
Safety Manual for instructions on Safe Operation.
CleartheWorkArea
• Spectators and fellow workers must be warned, and children and
animalspreventedfromcomingnearerthan15 m (50 ft.) while the unit
is in use.
KeepaFirmGrip
• Hold the front and rear handles with both hands, with thumbs and
fingers tightly encircling the handles.
KeepaSolidStance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
IMPORTANTENGINEINFORMATION
ENGINE FAMILY: 3EHXS.0214EA DISPLACEMENT: 21.2 CC
EMISSION COMPLIANCE PERIOD: 300 Hours
THIS ENGINE MEETS U.S. EPA PHASE 2 EMISSION
REGULATIONS FOR SMALL NONROAD ENGINE.
REFER TO OWNER'S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.
EmissionControlLabel (locatedonEngine) (EXAMPLEONLY,informationonlabelvariesbyFAMILY).
EMISSION CONTROL
EPA Phase 2
The emission control system for this engine is EM (Engine Modification).
PRODUCT EMISSION DURABILITY
The 300 hour emission durability compliance period is the time span selected by the manufacturer certifying the
engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures
are followed as listed in the Maintenance Section of this manual.

HEDGE CLIPPER
OPERATOR'SMANUAL 7
DESCRIPTION
The ECHO product you have purchased has been factory pre-assembled for your convenience. Due to packaging
restrictions,someassemblyof SHC-210isrequired.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
CONTENTS LIST
___ 1 - Power Head/Driveshaft Assembly
___ 1 - Hedge Clipper Assembly
___ 1 - Operator's Manual
___ 1 - HedgeClipperSafety Manual
___ 1 - Warranty Statement
___ 1 - Warranty Registration Card
___ 1 - EchoPower BlendTM 2-strokeoilsample
___ 1 - T-Wrench
___ 1 - 4mmHexWrench
___ 1 - Safety Glasses
___ 1 - BladeCover
14
20
10
1
3
789
4
62
5
16
19
18
17
15
11
13
12

8
1. POWERHEAD-IncludestheEngine,Clutch,FuelSystem,IgnitionSystemandRecoilStarter.
2. GRIP,RIGHTHANDREAR-Cushionedgripforrighthand.
3. THROTTLETRIGGERLOCKOUT-Thislevermustbeheldduringstarting.Operationofthethrottletriggeris
prevented unless throttle trigger lockout lever is engaged.
4. STOP SWITCH - mounted on top of the Throttle Trigger Housing. Move switch FORWARD to RUN, BACK to
STOP.
5. DRIVESHAFTASSEMBLY-ContainstheFlexibleDriveCable.
6. FRONTLEFTHANDLOOPHANDLE -Adjustable,loophandleforpropercuttingattitudeandoperatorcomfort.
7. BLADES - Double reciprocating blades mounted to a blade support bar. Double sided blades, are capable of
cutting on either side.
8. GEARHOUSINGASSEMBLY-Gearhousingassemblyfixedstraightextension.
9. THROTTLETRIGGER-Springloadedtoreturntoidlewhenreleased.Duringacceleration,depressgraduallyfor
best operating technique.
10. BLADE COVER - Used to cover blade during transport and storage. Remove blade cover before using unit.
11. SPARKPLUG-Providessparktoignitefuelmixture.
12. TOPGUARD-Protectsarmfromthehotengine.
13. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
14. FUELTANK-Containsfuelandfuelfilter.
15. FUELTANKCAP-Coversandsealsfueltankopening.
16. RECOILSTARTERHANDLE-Pullhandleslowlyuntilstarterengages,thenquicklyandfirmly. Whenengine
starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
17. PRIMERBULB-Pumpingprimerbulbbeforestartingenginedrawsfreshfuelfromthefueltankprimingthe
carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
18. AIRCLEANER-Containsreplaceablefilterelement.
19. CHOKE CONTROL - Located on the air cleaner housing. Move the lever to Cold Start ( ) to close the choke for
Cold Starting. Move lever to Run ( ) position after engine fires.
20. SAFETYVIDEO-(Notincludedwithunit)P/N99922202800Englishversionisavailableatacostof$5.00from
ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating tech-
niques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information
on safe operation.

HEDGE CLIPPER
OPERATOR'SMANUAL 9
SPECIFICATIONS
MODEL -----------------------------------------------------SHC-210
Length-------------------------------------------------------1790mm(70.5in.)
Width-------------------------------------------------------- 250mm(9.84in.)
Height -------------------------------------------------------270mm(10.6in.)
Weight (dry)------------------------------------------------5.87kg(12.9lb.)
Engine Type ------------------------------------------------Air cooled, two-stroke, single cylinder gasoline engine
Bore----------------------------------------------------------32.2mm(1.27in.)
Stroke--------------------------------------------------------26.0mm(1.02in.)
Displacement -----------------------------------------------21.2cc(1.29cu.in.)
Exhaust ------------------------------------------------------SparkArrestorMuffler
Carburetor --------------------------------------------------ZamaRBDiaphragmw/PurgePump
Ignition System -------------------------------------------- FlywheelMagneto,CDI(capacitordischargeignition)withESG
SparkPlug --------------------------------------------------NGKBPMR-8Y (Gap0.65mm(0.026in.)
Fuel ----------------------------------------------------------Mixed(GasolineandTwo-strokeOil)
Fuel/OilRatio -----------------------------------------------50:1two-stroke aircooledengine oil
Gasoline -----------------------------------------------------89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
morethan 10%ethylalcohol or15%MTBE.
Oil ------------------------------------------------------------ PowerBlendTM PremiumUniversal2-StrokeOil
FuelTankCapacity ----------------------------------------0.45lit.(15.2USfl.oz.)
RecoilStarterSystem --------------------------------------AutomaticRecoilStarter
Clutch -------------------------------------------------------CentrifugalType
GearCaseRatio --------------------------------------------5.88:1
Cutter --------------------------------------------------------DoubleReciprocatingBlade - Double Edge
Length-----------------------------------------------------490mm(19.3in.)
Pitch -------------------------------------------------------35mm(1.4in.)
Idle Speed---------------------------------------------------2,400-3,200RPM
Wide Open Throttle Speed -------------------------------10,000-12,000RPM
IMPORTANTThissparkignitionsystemcomplieswithCanadianICES-002

10
ASSEMBLY
Tools Required: 4mmhexwrench,screwdriver
Parts Required: Power Head/Drive Shaft Assembly and
Gear Housing Assembly
GEAR HOUSING ASSEMBLY/DRIVE SHAFT
WARNING DANGER
Hedge Clipper Blades are very sharp. Wear gloves to protect
hands.
1. Remove protective cap from drive shaft end.
2. Remove locating screw (A) and align the locating hole in the gear
case with the locating hole (B) in the drive shaft housing.
3. Slide the gear housing assembly on the drive shaft. Be certain the
flex drive shaft engages the hole in driver gear and install locating
screw(A).
4. Tighten screw (A) and clamping bolts (C).

HEDGE CLIPPER
OPERATOR'SMANUAL 11
PRE-OPERATION
FUEL
Fuel Requirements
Gasoline-Use 89 Octane [R + M/2](midgrade or higher) gasoline
known to be good quality. Gasoline may contain up to 15% MTBE
(methyltertiary-butyl ether). Gasohol containing methyl (wood) alcohol
is NOT approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)and J.A.S.O. FC Standards must be used. Echo brandpremium
Power Blend TM Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an ISO-
L-EGDandJ.A.S.O.FCcertifiedoil,suchasEchopremiumPowerBlend
TM, will void the two-stroke engine warranty. (Emission related parts
only are covered for two years, regardless of two-stroke oil used, per
the statement listed in the Emission Defect Warranty Explanation.)
IMPORTANT
EchopremiumPowerBlendTM Universal2-StrokeOilmaybemixed
at 50:1 ratio for application in all Echo engines sold in the past
regardless of ratio specified in those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from container
and surrounding area.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallow flames or sparksnearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuela unit whentheengineisHOT!
• NEVERrefuelaunit with the enginerunning.
• DONOT fill fuel tanks indoors. ALWAYS fill fuel tanks outdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.ContactyourECHOdealerfor
orderinginformation.
After Refueling
• Wipe any spilled fuel from the unit.
• Moveatleast 3 m(10ft.)fromrefueling
location before starting the engine.
After use
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to an
approved fuel storage container.
Storage - Fuel storage laws vary by
locality. Contact your local government for
the laws affecting your area. As a precau-
tion, store fuel in an approved, air tight
container. Store in a well ventilated, unoccu-
pied building, away from sparks and flames.
Do not store fuel longer than 30 days.
IMPORTANT
Storedfuelages.Donotmixmorefuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizeris added.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container thor-
oughly before each use.

12
OPERATION
STARTING COLD ENGINE
WARNING DANGER
The attachment will operate immediately when the engine starts
and could result in loss of control and possible serious injury.
Keep movable parts of the attachment off the ground and away
from objects that could become entangled or thrown.
1. Stop Switch
Move Stop Switch button away from the STOP position.
2. Choke
Move choke (B) to Cold Start ( ) position.
3. Primer
Pump primer bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
4. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts clear
of all obstacles. Firmly grasp right hand grip and throttle trigger
lockout with left hand and fully depress throttle trigger to wide
open position. Rapidly pull recoil starter handle/rope (D) until
enginefires(ormaximumfive[5]pulls).
5. Choke
After engine fires or five (5) pulls, move choke lever back to Run
() position. Hold throttle trigger and throttle trigger lockout
fully depressed, and pull starter handle/rope until engine starts and
runs. Release throttle trigger and allow unit to warm up at idle for
several minutes.
NOTE
If engine does not start with choke in Run position after 5 pulls,
repeat instructions 2 -5.
6. Throttle Trigger
After engine warm up, gradually depress throttle trigger to increase
engine RPM to operating speed.
B
C
A
D

HEDGE CLIPPER
OPERATOR'SMANUAL 13
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke, and do not depress throttle trigger to wide open position.
WARNING DANGER
The attachment should not move at idle, otherwise serious
personal injury may result.
NOTE
If attachment moves, readjust carburetor according to “Carburetor
Adjustment” instructions in this manual or see your ECHO Dealer.
1. Stop Switch
Move Stop Switch button (A) away from the STOP position.
2. Primer
Pump primer bulb (C) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
3. Recoil Starter
Lay the unit on a flat area and keep movable attachment parts clear
of all obstacles. Rapidly pull recoil starter handle/rope (D) until
engine fires.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
STOPPING ENGINE
1. Throttle
Release throttle and allow engine to return to idle before shutting
off engine.
2. Stop Switch
Move stop switch button (A) backward to STOP position.
WARNING DANGER
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using hedge
clipper again or serious personal injury may result.
A
D
C
A

14
MAINTENANCE
Your ECHO product is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your unit to an
ECHOServiceDealerformaintenance. TohelpyoudecidewhetheryouwanttoDO-IT-YOURSELForhavetheECHO
Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs.
SKILL LEVELS
Level1= Easy to do. Most required tools come with unit.
Level2= Moderatedifficulty.Some specialized tools may be required.
Level3= Experiencerequired.Specializedtoolsarerequired.ECHOrecommends
that the unit be returned to your ECHO dealer for service.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Just below each task
heading are listed the various part numbers required for that task. See your ECHO dealer for these parts.
MAINTENANCE INTERVALS
/TNENOPMOC METSYS ECNANETNIAM ERUDECORP
D'QER LLIKS LEVEL ROYLIAD EROFEB ESU
YREVE LEUFER
3SHTNOM 09RO SRUOH 6SHTNOM 072RO SRUOH
YLRAEY 006 SRUOH
serudecorPecnanetniaMrelaeDohcEdednemmoceR
troPtsuahxErednilyCnobraceD/naelC/tcepsnI 3C/I
sedalBneprahSnae
lC/tcepsnI 3)3(I
serudecorPecnanetniaMflesruoY-tI-oD
retliFriAecalpeR/naelC/tcepsnI 1C/I*R
ekohCnaelC/tcepsnI 2C/I
retliFleuFecalpeR/tcepsnI 1I*R
skael,metsySleuFecalpeR/tcepsnI 1*II
metsySgnilooCnaelC/tcepsnI 2C/I
rotserrA
krapSrelffuMecalpeR/tcepsnI 2*R/I
tfahSevirDesaerG 2)1(I
gnisuoHraeGesaerG 2)2(I
sedalBnaelC/tcepsnI 1)3(C/I
epoR
retratSlioceRnaelC/tcepsnI 1*C/I
gulPkrapSnaelC/tcepsnI 2C/I*R
stloB/stuN/swercSecalpeR/nethgiT/tcepsnI 1*R/I
SEDOCRETTELERUDECORPECNANETNIAM NAELC=C,ECALPER=R,TCEPSNI=I:
-ETONTNATROPMI deriuqerfoycneuqerfehtenimretedlliwecneirepxeruoydnaesulaut
cA.mumixameranwohsslavretniemiT
.ecnanetniam :SETONERUDECORPECNANETNIAM)1( OHCEylppA
®
EBUL
MT
.sruoh52yreve
)2( OHCEylppA
®
EBUL
MT
sruoh52-51yreve
)3( .esugnirudyllacidoirepsedalbetacirbuL.dedeensaneprahsdnanaelcdnaedalbtcepsnI
*..noit
cepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA

HEDGE CLIPPER
OPERATOR'SMANUAL 15
AIR FILTER
Level1.
Tools required: 25or 50mm(1or2in.)cleaningbrush
Parts required: 90008REPOWERTM Air&FuelFilterKit
1. Close choke (Cold Start Position [ ]). This prevents dirt from
entering the carburetor throat when the air filter is removed. Brush
accumulateddirtfrom the air cleanerarea.
2. Remove the air cleaner cover. Clean and inspect the element for
damage. If element is fuel soaked and very dirty, replace.
3. If element can be cleaned and reused, be certain it:
• properly fits the cavity in the air cleaner cover.
• is installed with the original side out.
NOTE
Carburetor adjustment may be needed after air filter cleaning/
replacement. See Carburetor Adjustment Section.
FUEL FILTER
Level1.
Tools required: 200-250mm (8-10in.)lengthofwirewithoneend
bent into a hook, clean rag, funnel, and an approved
fuel container
Parts required: 90008REPOWERTM Air&FuelFilterKit
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
1. Use a clean rag to remove loose dirt from around fuel cap and empty
fueltank.
2. Use the “fuel line hook” to pull the fuel line and filter from the tank.
3. Remove the filter from the line and install the new filter.

16
SPARK PLUG
Level2.
Tools Required: T-Wrench, feeler gauge, soft metal brush
Parts Required: SparkPlug,NGKBPMR-8YP/NA425000000
1. Remove spark plug and check for fouling, worn and rounded center
electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean.Remainingsandwilldamageengine.
3. Adjust spark plug gap by bending outer electrode.
4. Tightensparkplugto145-155kg/cm(125-135in.lb.).
COOLING SYSTEM CLEANING
Level2.
Tools required: Crosshead screwdriver,3mm,4mm hex wrench,
25or50mm(1or 2 in.) cleaning brush
Parts Required: None.
IMPORTANT
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder fin area. This flow of air carries
combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes are blocked, preventing cooling air from reaching the
cylinder.
• Dust and grass build up on the outside of the cylinder. This build-
up insulates the engine, and prevents the heat from escaping.
Removal of cooling passage blockages or cleaning of cooling fins is
considered “Normal Maintenance.” Any failure attributed to lack of
maintenance is not warranted.
0.65 mm
(0.026 in.)

HEDGE CLIPPER
OPERATOR'SMANUAL 17
1. Disconnect spark plug lead from spark plug.
2. Remove (1) screw from top guard, and remove guard.
3. Remove(4)screwsfromengine/mufflercover,and removecover.
4. Use the brush to remove dirt form cylinder fins.
5. Remove grass and leaves from the grid between the recoil starter
and fuel tank.
6. Assemble components in reverse order.
NOTE
When installing the engine/muffler cover, be certain the tabs of the
metal deflector shield are in the slots of the cover.
EXHAUST SYSTEM
Spark Arrestor Screen
Level2.
Tools Required: Cross head screwdriver, soft metal brush.
Parts Required: SparkArrestorScreenP/N14586240630,
GasketP/N14586642031
1. Remove engine/muffler cover (A). See "Cleaning Cooling System"
pages 16 and 17 for step by step instructions.
2. Place piston at Top Dead Center (TDC) to prevent carbon/dirt from
entering cylinder.
3. Remove spark arrestor screen cover (B), gasket (C), and screen (D)
frommufflerbody.
4. Clean carbon deposits from muffler components.
5. Replace screen if it is cracked, plugged or has holes burned
through.
B
C
D
A

18
6. Assemble components in reverse order.
NOTE
When installing the engine/muffler cover, be certain the tabs of the
metal deflector shield are in the slots of the cover.
Cylinder Exhaust Port
Level3.
IMPORTANT
The cylinder exhaust port must be inspected and cleaned of excess
carbon every 3 months or 90 hours of operation in order to maintain
this engine within the emissions durability period. ECHO strongly
recommends that you return your unit to your ECHO dealer for this
importantmaintenanceservice.
CARBURETORADJUSTMENT
Engine Break-In
New engines must be operated for a minimum of two tanks of fuel before
carburetor adjustments can be made. During the break-in period, your
engineperformancewillincreaseandexhaustemissionswillstabilize.
Idle speed can be adjusted as required.
High Altitude Adjustment
High altitude adjustment is not required for proper operation of this
engine.
Idle Speed Adjustment
Idle speed adjustment may be required periodically to comply with
specifications for this unit. See page 9, "Specifications," for correct idle
speed.
Level2.
Tools required: Screwdriver,tachometer(ECHOP/N99051130017)
NOTE
Every unit is run at the factory and the carburetor is set in compli-
ance with emission regulations. This carburetor does not have
acceleration and high speed adjustment needles.
1. Check idle speed using a tachometer, and reset if necessary. Turn
idle screw (A) clockwise to increase idle speed; counter clockwise
to decrease idle speed.
WARNING DANGER
When carburetor adjustment is completed, blades should not move
at idle, otherwise serious personal injury may result.
A

HEDGE CLIPPER
OPERATOR'SMANUAL 19
LUBRICATION
Blades
Level1.
Tools Required: Clean rag, cleaning brush , oil can
Parts Required: 20WEngineOil(lubrication),50-50mixtureof
kerosene and 20W oil (cleaning)
WARNING DANGER
Blades are very sharp. Wear gloves to protect hands, otherwise
serious personal injury may result.
1. Brush loose debris from blade and coat both sides of blade with the
50-50cleaningmixture.
2. Allow cleaning mixture to soften the remaining gummy residue then
wipe it from the blade.
3. Apply clean oil to the entire length of the blade. Be certain the
blade bolts are lubricated.
4. Wipe excess oil from the blade before putting the unit back in
service.
Gear Case
Level2.
Tools required: GreasegunwithLithiumGrease,cleanrag
Parts required: ECHO®LUBETM14oz.cartridgeP/N91015or
LithiumBasedGrease
1. Clean dirt from grease fitting.
2. Carefully pump grease in fitting (A). DO NOT force grease.
Too much pressure will force grease past seals and cause damage.
Apply1-2pumpsofgreaseevery15-25hoursofoperation.
A

20
Drive Shaft Assembly
Level1.
NOTE
Hedge Clipper drive shaft should be greased every 25 hours of
operation.
Tools required: 4mmHexwrench,screwdriver,cleanrag,small
brush
Parts required: ECHO®LUBETM14oz.cartridgeP/N91015or
LithiumBasedGrease
WARNING DANGER
Blades are very sharp. Wear gloves to protect hands, otherwise
serious personal injury may result.
1. Loosen gear housing assembly locating screw (A) and mounting
screws (C). Remove the gear box from the drive shaft housing.
2. Pull the drive shaft (B) from the housing, wipe clean and re-coat
withathin coating [1/2 oz. (15 ml)] of grease.
3. Slide the drive shaft back in the drive housing being careful not to
get dirt on the flex shaft.
4. Install the gear housing assembly.
