Eclipse ESN E3 High-Power CD Receiver with CDC/E-COM/DSP Control and Wireless Remote Model:... User manual

OWNER'S MANUAL
We appreciate your purchase of this receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
MODEL 54420
by FUJITSU TEN
R
ESN E3 High-Power CD Receiver with
CDC/E-COM/DSP Control and Wireless Remote

2
For your safety in using the
54420
Warnings and caution signs, illustrated below, are posted
throughout this manual as well as on the 54420. They show safe
and correct ways to handle the product so as to prevent personal
injury to you and others and avoid damage to property.
Before reading through the manual, take time to read through
and learn the important information listed in this section.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in death or serious personal
injury.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in personal injury or may result
solely in damage to property.
•Do not modify this system for use other than that specified
herein. Also, do not deviate from the installation procedures
described herein; Eclipse will not be held liable for damages
including, but not limited to serious injury, death or property
damage resulting from installations that enable unintended
operation.
•This unit is intended for operation in DC 12-volt, negative-
grounded vehicles only. Never use it in 24-volt vehicles such
as heavy trucks or diesel cars with cold-region specifications.
•Do not change CDs while driving. Doing so may result in an
accident.
Warning
Caution
Warning

3
•Do not place the vinyl storage bag over a person. It may
cause a serious accident or death by suffocation.
•Do not adjust the controls while driving the car. To adjust the
controls, stop the car in a safe location.
•To prevent accidents, store batteries for the remote control
out of the reach of small children.In case a child swallows a
battery, consult a physician immediately.
•Do not disassemble or rebuild this product. Doing so may
cause an accident, fire or electrical shock.
•When it is necessary to replace the fuse, always use a fuse of
the correct rating (number of amperes). Use of fuses with
higher amperage ratings may cause a fire.
•Do not operate the product in a malfunctioning condition, for
instance, when the audio does not play. Doing so may result
in an accident, fire or electrical shock.
•If an abnormal situation occurs, such as foreign matter
entering or liquid splashing on the product, or smoke or a
strange odor emitting from the unit, shut off the product
immediately and consult the dealer from whom you purchased
it. Continued operation may cause an accident, fire or
electrical shock.
•Play the audio at a moderate volume level that permits you to
hear sounds from outside the car. Driving without being able
to hear outside sounds may result in an accident.
•Keep foreign objects out of the disc slot. They may cause fire
or electrical shock. Another possibility is that discs may be
damaged or become stuck.
Caution
Warning

4
•Do not stick your fingers or hands into the disc slot. Doing so
may cause personal injury.
•This product must be operated only as on-board equipment,
or it may cause electrical shock or injury.
•Do not play distorted sounds for long periods of time;
the speakers may overheat and cause a fire.
•This product uses an invisible laser light. In case a problem
develops, be sure to consult the dealer from whom you
purchased the product. Do not disassemble or rebuild the
unit; rebuilding it may expose you and others to a dangerous
laser emission (which would damage eyesight) or cause an
accident.
•Never use batteries other than those specified. Do not mix
new and old cells. Doing so may cause a fire or personal injury
due to a battery explosion or chemical leaks.
•Pay attention to the (+) and (-) polarity of the battery when
installing it in the product. Incorrect installation may cause
personal injury or product damage due to a battery explosion
or chemical leakage.
Caution

5
Table of Contents
Operating Precautions ................................................ 8
Notes on Operation........................................................................ 8
About compact discs .................................................................... 9
About cleaning a CD ................................................................... 11
Names of controls and parts .................................... 12
ESN (Key CD) Security Operating Procedure .......... 13
How to program the Key CD ....................................................... 13
How to cancel the Key CD .......................................................... 14
How to change the Key CD ......................................................... 15
How to resume normal operation (ESN security lock out) ............ 16
What happens if an incorrect CD is inserted? .............................. 17
How to turn the Security indicator on/off .......................................18
How to Read the Electrical Serial Number ................................... 18
Basic operation ......................................................... 19
Turning the power on and off ...................................................... 19
Listening to a CD ......................................................................... 19
Listening to the tuner ................................................................... 20
Adjusting audio volume ............................................................... 21
Displaying the clock ..................................................................... 21
Others ......................................................................................... 22
How to operate the CD player .................................. 26
Listening to CDs .......................................................................... 26
Advancing to the next track or returning to
the beginning of the track being played ....................................... 27
Playing the beginning of tracks (SCAN) ........................................ 27
Repeating the same track (REPEAT) ............................................ 28
Playing tracks in random order (RANDOM) .................................. 28
Switching the display ................................................................... 28
Ejecting the disc .......................................................................... 29
Displaying a genre for a CDs ....................................................... 30
Switching the display ................................................................... 30

6
How to operate the tuner .......................................... 31
Tuning to a station ....................................................................... 31
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................. 32
Manually setting stations into memory ......................................... 33
Preset station scan ...................................................................... 34
Switching the display ................................................................... 34
FM reception characteristics ........................................................ 35
How to use the Card remote control ........................ 38
Precautions in use of the remote control ...................................... 38
Cleaning the remote control ........................................................ 38
Turning the power on/off ............................................................. 39
Adjusting the audio volume .......................................................... 39
Switching playback modes .......................................................... 39
How to play the tuner .................................................................. 40
How to play CDs ......................................................................... 41
Replacing the battery .................................................................. 42
How to use an optional NOB remote control ........... 43
Turning the power on/off ............................................................. 43
Adjusting the audio volume .......................................................... 43
Switching playback modes .......................................................... 44
How to play the tuner .................................................................. 44
How to play CDs ......................................................................... 45
Illuminating the NOB remote control ............................................ 46
Replacing the battery .................................................................. 47
How to operate the receiver with an optional CD
changer connected ................................................... 49
Basic operation ........................................................................... 49
How to operate the receiver with an optional
DSP/EQ unit connected ............................................ 53
How to operate the DSP functions .............................................. 53
How to operate the EQ functions ................................................ 57

7
If you have a question: .............................................. 60
Displaying information (for troubleshooting) .................................. 61
Specifications ............................................................ 64
Before installation .......................................................66
Components ............................................................................... 66
Setting the system-selector switch .............................................. 66
Mounting Instruction...................................................67
Mounting the main unit................................................................. 67
Names of lead wires and destinations ......................................... 69
System ........................................................................................ 70

Operating precautions
8
Notes on Operation
ٟ
Operating Precautions
<Your 54420 will perform well over a long period of time through correct
handling and care.>
•For your safety, play only at volume levels that allow outside sounds to
be heard.
•Use only audio compact discs.
This player can only play compact discs
bearing the logo shown to the left.
•Do not insert anything other than a CD into
the disc slot.
Do not insert any foreign objects, such as
coins or credit cards, into the disc slot. Be
especially watchful of children’s mischief in
this regard.
•Avoid severe mechanical shock.
When the player is subjected to severe
vibration while traveling over a rough
surface, playback may be intermittent.
When a situation like this occurs, resume
playback after returning to a smoother
road.
•About dew condensation
In cold or rainy weather, just as the interior
glass surface gets fogged, dew (water
condensation) may also settle on the deck.
When this occurs, disc playback may
become intermittent or impossible.
Dehumidify the air in the vehick for a while
before resuming playback.
•Cleaning the disc slot
The disc slot tends to get dusty. Clean it
occasionally to prevent accumulated dust
from scratching the discs.

9
Operating precautions
•The signal recorded on a compact disc is read by a laser beam, so
nothing touches the disc surface. A scratch on the recorded surface or
a badly warped disc may cause deteriorated sound quality or
intermittent playback. Observe the following precautions to ensure high
quality sound performance:
•Do not leave an ejected disc in the disc
slot for very long; the disc may warp.
Discs should be stored in their cases and
kept away from high temperature and
humidity.
•Do not stick a piece of paper or tape on,
nor write on or scratch, either side of a
disc .
•Discs spin at a high speed inside the
deck. Keep cracked or warped discs out
of the player to avoid damaging it.
•Avoid touching the recorded surface when
handling a disc; handle discs by their
edges.
About compact discs

Operating precautions
10
About CD accessories
•Do not use accessories
(stabilizers, protective seals, laser
lens cleaners, etc.) sold for
“improving sound performance”
or “protecting CDs.”The
changes in CD thickness or
outside dimensions made by
these accessories may cause
problems in the player.
About borrowed CDs
•Do not use a CD with glue or
remnants of adhesive tape or
labels. They may cause the CD
to get stuck inside or damage
the deck.
How to remove CDs
•When removing the ejected disc,
pull it straight out along the slot.
Pressing downward in the
process may scratch the
recorded surface of the disc.
OKAY
NO GOOD
About brand new CDs
•You may notice that some brand
new discs are rough around the
center hole or outside edge.
Remove the rough edges with
the side of a ballpoint pen, etc.
Rough edges may prevent
proper loading in the deck.
Flakes from the rough edges
may also stick to the recorded
surface and interfere with
playback.
Rough Edges
Ballpoint
pen
Flakes
Recorded surface
Rough
Edges

11
Operating precautions
About irregularly-shaped CDs
•Specially-shaped CDs, like heart-
shaped or octagonal CDs, cannot
be played. Do not attempt to play
them, even with an adapter, since
they may damage the player.
•Use a commercially available compact disc
cleaner to clean a CD, wiping lightly from
the center to the edge.
•Do not use benzine, thinner, LP record
spray or other cleaners on CDs. They may
damage a CD’s finish.
XXXX
XXXX
XXXX
About cleaning a CD

ٟ
Names of controls and parts
Front View
※NOTE：Double function button→"E-COM"&"MUTE" functions
Names of controls and parts
121212
[CD] button
Buttons [1] to [6]
[PWR] button
[DISC ] buttons
[AUDIO CONTROL] button [ ] buttons
[FUNC] button
[FM･AM] button
[ASM] button [DISP] button
[E-COM] button※
[（EJECT）] button

13
ESN (Key CD) security operating procedure
ٟ
ESN (Key CD) security operating
procedure
عHow to program the Key CD
1 . Turn the vehicle’s ignition on. Press the [PWR]
button or [FM• AM] button to activate the tuner
mode.
The tuner is now turned on.
2 . Press and hold button [1], then the [FM•AM]
button, and hold both for more than one
second.
A [SEC] message appears, then in two seconds it will
change to [DISC].
The 54420 is now ready to accept your Key CD in the
CD slot.
3 . Insert the CD into the slot.
A [SEC] message appears, the Key CD is ejected, then
the tuner mode is activated.
[PWR] button
Button [1]
[FM･AM] button

ESN (Key CD) security operating procedure
14
•If there is a problem with the inserted CD, an [ERR]
message will appear for two seconds and the CD will be
ejected. Reinsert the ejected CD.
•If a CD causes the [ERR] message to appear twice in a
row, a [CHANGE] message will appear for two seconds.
Try another CD.
•The Security indicator will flash whenever the vehicle’s
ignition is switched off.
عHow to cancel the Key CD
1 . Turn the vehicle’s ignition on. Press the [PWR]
button or [FM•AM] button to activate the tuner
mode.
The tuner is now turned on.
2 . Press and hold button [1], then the [FM•AM]
button, and hold both for more than one
second.
A [SEC] message appears, then in two seconds it will
change to [DISC].
The 54420 is now ready to accept your Key CD in the
CD slot.
3 . Insert your Key CD into the slot.
A [CANCEL] message appears, the Key CD is ejected,
then the tuner mode is activated.
The Key CD is cancelled.
[PWR] button
[FM･AM] button Button [1]

15
ESN (Key CD) security operating procedure
• This process cancels the protection for the ESN
deck.
•If power to the 54420 is disconnected, then
reconnected, a key CD will not need to be inserted in
order to return the unit to normal operation.
•Inserting a CD other than the Key CD will not cancel the
protection. Instead, the display will show [ERR] for two
seconds, then the normal CD playback mode will activate.
عHow to change the Key CD
1 . First, cancel the existing Key CD.
Refer to “How to cancel the Key CD.”
2 . Next, program a new Key CD.
Refer to “How to program the Key CD.”

ESN (Key CD) security operating procedure
16
عHow to resume normal operation
(ESN security lock out)
If power to the 54420 is disconnected while ESN security is
active (a Key CD was programmed), operation is disabled
until power is restored and the unit unlocked. Follow this
procedure to resume normal operation.
1 . When the power is turned on after
disconnecting the battery power, a [SEC]
message will appear for two seconds.
Thereafter, the message changes to [DISC]
and the 54420 is ready to accept your Key CD
into the slot.
2 . Insert your Key CD.
If the correct CD is inserted, an [OK] message will
appear for two seconds and the CD will begin playing.
•If an incorrect CD is inserted, an [ERR] message will
appear for two seconds, after which the CD will be
ejected.
•You must use the same CD used for Key CD
programming; a duplicate CD may not work properly.

17
ESN (Key CD) security operating procedure
عWhat happens if an incorrect CD is
inserted?
1 . An [ERR_] message will be appear, then
change to a flashing [DISC], then the CD will
be ejected.
You will have five uninterrupted attempts to insert the
correct CD.
2 . After the 5th incorrect attempt, the display
reads [CALL800] and the security indicator
lights steadily.
• Number of errors: Numbers indicated at _ show the
number of errors that occurred.
٨Note٨
If after 5 tries the correct Key CD is not insereted, the
display reads [CALL 800]; the unit must be returned to
Eclipse to be reset. In this case, please contact your
Eclipse dealer for assistance or call Eclipse directly at
[phone]
Your key CD can be easily forgotten. Write
the album name in a reminder note (Pg.75).

ESN (key CD) security operating procedure
18
ع
How to turn the Security indicator on/off
Once ESN security is activated, the indicator flashes
whenever the vehicle’s ignition is turned off, warning
potential thieves that the unit is protected. However, if you
do not want this visible deterrent, it may be turned off.
1 . With the tuner mode ON, press the [DISP]
button, then [FM•AM] button and hold both for
more than a second.
2 . [INDICATOR flash] or [INDICATOR OFF] appears
on the display.
[IND FLASH] means the security indicator will flash when
the vehicle’s ignition is off, and [IND ---] means it will
not. Repeat the above steps to reactivate the flash
mode.
ع
How to Read the Electronic Serial Number
1 . Turn the vehicle’s ignition on; press the [PWR]
button or [FM•AM] button to activate the tuner
mode.
2 . Press button [4], then the [FM•AM] button, and
hold both for more than a second.
[ESN] appears on the display, followed by an eight-digit
number; this number is your electronic serial number (ESN).
You may use this number to identify your Eclipse 54420 in
the event it is recovered after being stolen.
[PWR] button
[FM･AM] button
[DISP] button
Button [4]

19
Basic operation
[FM･AM] button [ ] buttons
[PWR] button
ٟ
Basic operation
This section covers basic operating procedures.For
additional details, please refer to the sections on specific
functions.
عTurning the power on and off
1 . Press the [PWR] button.
Pressing the button turns the power on and off.
Less than two seconds Stand by
More than two seconds Off
• If a car is not eguipped with an ACC position (for example,
a European car), keep the [PWR] button depessed for more
than two seconds.
You may also press the [FM• AM] button to turn on the
power. (When there is a disc loaded, you may press the
[CD] button to turn on the power.)
عListening to a CD
1 . Insert a CD into the disc slot, label side up.
The CD will immediately start playing.
•When a CD is already loaded, pressing the [CD] button
starts playing the disc.
[CD] button
Buttons [1] to [6]

Basic operation
20
عListening to the tuner
1 . Press the [FM• AM] button.
This will turn the tuner on.
To turn the tuner off, either press the [PWR] button or
select another mode.
2 . Tap the [FM•AM] button to switch to the
desired FM or AM bands.
Each additional tap of the button switches the preset
station sets from FM1 to FM2, FM3, then AM in
sequence.
3 . Press the [ ] button to tune to a station.
A tap on either the [ ] or [ ] button for less than one
button second will enable manual station tuning. Hold
one button down for more than two seconds to start the
automatic station search.
[ ] button: Starts searching toward higher frequencies.
[ ] button: Starts searching toward lower frequencies.
•If stations have been stored in memory, pressing a button
from [1] to [6] will directly select a station. (Refer to the
section “Manually setting stations into memory”on page
33.)
