Eclipse CD8445 User manual

OWNER'SMANUAL
We appreciate your purchase of this receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
ESN E8 High-Power "Customize" CD/MS Receiver with
MP3/WMA Decoder and Remote
CD8445

2
For your safety in using the
CD8445
Warnings and caution signs, illustrated below, are posted throughout this manual as
well as on the CD8445. They show safe and correct ways to handle the product so
as to prevent personal injury to you, others and to avoid property damage.
Before reading through the manual, take time to read through and learn the
important information listed in this section.
This sign indicates a situation in which incorrect
handling or disregard of this sign might result in
death or serious personal injury.
This sign indicates a situation in which incorrect
handling or disregard of this sign might result in
personal injury or may result solely in damage to
property.
Warning
Caution
CD8445.book 2 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

3
Warning
●Do not modify this system for use other than that specified
herein. Also, do not deviate from the installation procedures
described herein; Eclipse will not be held liable for damages
including, but not limited to serious injury, death or property
damage resulting from installations that enable unintended
operation.
●This equipment requires 12V DC and should only be installed in a
vehicle with a 12V negative ground electrical system. Any other
installation may cause a fire or other severe damage to the
equipment and the vehicle.
●Never install this equipment where it will interfere with safe
operation of the vehicle. Never block the drivers’ view. Do not
install equipment where it may interfere with operation of the
brakes, the steering or any safety equipment, including seat belts
and air bags.
●Before drilling holes in a vehicle for installation, you must confirm
the locations of pipes, tanks, electrical wiring, and other vehicle
systems and components to ensure that there will be no
interference or contact. In addition, you must also apply rust
prevention and leak prevention measures at the drilling area.
Otherwise, fire or electric shock could occur.
●When installing equipment do not remove or alter existing vehicle
fasteners, including nuts, bolts, screws, clips, and fittings. Never
detach, move or alter existing vehicle wiring, including electrical
grounds and straps. Alteration of existing vehicle components
may make vehicle unsafe to operate.
●Before installation, remove the negative (-) battery terminal to
prevent shocks, electrical arcing, fires, and damage to vehicle
wiring and the equipment you are installing.
●Secure wiring with tape or plastic ties so that wires do not
interfere with vehicle operation, including brake pedal, gear
shifter and steering. Position wires so that they will not be
rubbed, abraded, or damaged by moving vehicle components,
including power seats.
CD8445.book 3 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

4
Warning
●To avoid equipment and vehicle damage, including fire, never
supply power to installed equipment in a way which will overload
the capacity of an existing vehicle circuit. Never leave a power
supply wire or connection uninsulated. Always install supplied
fuses, circuit breakers, and relays.
●Air bags are vital safety equipment. Never install equipment in a
way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
●When installation is complete, test all vehicle electrical systems
for proper operation, including lights, horn, brake lights, and
emergency flashers.
●For your protection, never use a power drill without safety
glasses or goggles. Debris or broken drill bits may cause severe
eye injuries, including blindness.
●Use electrical tape to insulate the ends of all wires, even if not
used. Proper insulation prevents arcs, shocks and fires.
●Some equipment uses batteries. Never install equipment where
young children can get access to batteries. If a battery is
swallowed, seek medical attention immediately.
●When vehicle is moving, never take your eyes off the road to
make adjustments to the equipment. You must pay attention to
the road to avoid accidents, do not let the operation or adjustment
of the equipment distract you from proper vehicle operation.
●The driver should not look at the screen while driving. Accidents
may result if you are not paying attention to the forward direction.
●Do not put foreign objects in the loading slot of Memory Stick or
disc. Fires or shocks may result.
●Do not disassemble or alter this equipment. Accidents, fires or
shocks may result.
●Do not let water or foreign objects enter the internal parts of this
equipment. Smoke, fires or shocks may result.
●Pay attention to where the remote control is left. Traffic accidents
or problems with driving may result if the remote control makes
its way under the foot pedals etc. when the vehicle is stopped or
when it goes around a corner.
CD8445.book 4 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

5
Warning
●Do not use when it is broken (the screen is not lit or no sound
comes out). Accidents, fires or shocks may result.
●Always replace fuses with fuses of identical capacity and
characteristics. Never use a high capacity fuse than the original.
Using the wrong type of fuse may cause a fire or severe damage.
●If foreign objects or water enters the equipment, smoke comes
out, or there is a strange odor, stop using it immediately, and
contact your dealer. Accidents, fires, or shocks may result if you
continue to use it in these conditions.
●The driver should not change the Memory Stick or CD while
driving. As accidents may result if you are not paying attention to
the forward direction, first stop the car at a safe location and then
proceed.
●Plastic bags and wrappings may cause suffocation and death.
Keep away from babies and children. Never put bag over your
head or mouth.
CD8445_00_E.fm 5 ページ ２００４年１２月１６日 木曜日 午後５時２４分

6
Caution
●Wiring and installing this equipment requires expertise and
experience. Professional installation is recommended. Consult
with your dealer or a professional installer. Incorrect wiring may
damage the equipment or interfere with safe vehicle operation.
●Use only the accessory parts as specified. Using other parts may
cause damage to the equipment or cause parts to fall or fly off the
equipment.
●Do not install the unit in places where it may get dew
condensation on (around the air conditioning hose, etc.), come in
contact with water, or in condition of high moisture, dust or oily
smoke. If water, moisture, dust or oily smoke enters this unit,
smoke, fires or malfunctions may result.
●Avoid installing in places where it cannot be fastened securely or
where there are strong vibrations. Also, if you installed the unit
with double-sided tape, first wipe away dirt and wax from the
installation area. Otherwise, the unit may come loose due to
vibration while driving, causing problems for driving and
resulting in traffic accidents or injuries.
●Do not install in places with direct sunlight or where it will be hit
directly by hot air from the heater. This may increase the
temperature of the interior of this equipment, resulting in fires
and malfunctions.
●Do not block the fan, heat sink or vents of this unit. When fan,
heat sink or vent is blocked, the interior overheats, and fires may
result.
●Connect as specified in the installation manual. If not connected
normally, fires or accidents may result.
●When installing in vehicles equipped with air bags, check the
manufacturer's cautions regarding operation before operating.
Airbags may not operate properly.
●Carry out the wiring such that cords are not pinched by movable
parts such as seat rails, and screw parts of the vehicle body.
Accidents, fires and shocks may result from disconnection and
electrical shorts.
●Carry out the wiring such that the cord does not make contact
with metal parts. The cord maybe be damaged by contact with
metal parts, resulting in fire and shocks.
CD8445.book 6 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

7
Caution
●Avoid hot surfaces when wiring equipment. High temperatures
may damage wiring, causing shorts, arcing and fires.
●When changing the installation location for this equipment,
please consult the dealer where you bought it for safety reasons.
Expertise is necessary for removal and installation.
●Keep volume to a reasonable level so that you can hear sounds
from outside the vehicle, including warning sounds, voices, and
sirens. Failure to do so may cause an accident.
●Be careful that hands and fingers are not pinched when adjusting
the tilting angle or closing display. Injuries may result.
●Do not put your hands or fingers into the loading slot of Memory
Stick or disc. Injuries may result.
●Do not touch the heat dissipating part of the amp. Burns may
result from the heat of this part.
●Do not recharge dry batteries. Dry batteries may rupture,
resulting in injuries.
●Do not use batteries other than those specified. Also, do not mix
old and new batteries. Injuries or pollution to the surroundings
may result from battery ruptures and leakage.
●When inserting batteries into the equipment, be careful with the
polarity (positive/negative), and insert them as indicated. If the
battery polarities are incorrect, injuries and pollution to the
surroundings may result from battery ruptures and leakage.
●Replace used batteries as soon as possible; they may leak and
damage equipment. Battery leakage can burn your skin or your
eyes. Wash hands after handling.
●If alkaline solution from alkaline dry batteries makes contact with
your skin or clothes, flush with clean water. If any of the solution
gets in your eyes, also flush clean with water and then seek
medical attention.
●When disposing of lithium dry batteries, affix insulating tape to
the positive and negative terminals, and after they are insulated,
dispose of them according to the "Local municipal ordinances".
Shorts, fires and ruptures may result from disposal when coming
contact with other electrically conductive objects such as metal
parts, etc.
CD8445.book 7 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

8
Caution
●Do not short, disassemble or heat the batteries, or place them in
fire or water. Fire and injuries may result from battery rupture and
leakage.
●Store the remote control in a place away from direct sunlight, high
temperatures, and high moisture levels. The case may change
shape, and the batteries may rupture and leak.
●Do not use this equipment except for in-vehicle use. Shocks or
injuries may result.
●Be careful of the position of the volume when turning the power
source ON. Hearing damage may result if very loud noise is
emitted when the power is turned ON.
●Do not operate under abnormal conditions such as when the
sound is broken or distorted. Fires may result.
●This equipment uses invisible laser light. Do not disassemble or
alter this equipment. If trouble occurs, contact the dealer where
you bought the equipment.
Altering this equipment may cause exposure to laser emissions
(worsening eyesight), or result in accidents, fires or shocks.
●If the equipment is dropped or the cosmetics appear broken, turn
off the power to the main unit and contact your dealer. If used in
this condition, fires or shocks may result.
CD8445.book 8 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

9
Table of Contents
Operating precautions.............................................................................. 16
Names of controls and parts.................................................................... 23
ESN security operating precedure .......................................................... 24
Basic operation ......................................................................................... 41
How to operate the CD player .................................................................. 72
How to operate the MP3/WMA player...................................................... 82
How to operate the Memory Stick player................................................ 91
How to operate the tuner........................................................................ 104
How to operate the Sound Adjustment Mode ...................................... 115
How to operate the AREA SHOT function (U.S.A. only) ...................... 151
How to use the remote control .............................................................. 162
How to operate the receiver with an optional CD changer connected .... 170
How to operate the tuner with an optional HD RADIO tuner
connected (U.S.A. only) ... 174
How to operate the tuner with an optional SIRIUS satellite radio tuner
connected (U.S.A. only) ... 181
Others....................................................................................................... 187
If you have a question: ........................................................................... 190
Specifications.......................................................................................... 195
Before installlation.................................................................................. 197
Mounting instruction .............................................................................. 198
How to contact customer service.......................................................... 209
I
II
III
IV
V
VI
VII
VIII
IX
X
XI
XII
XIII
XIV
XV
XVI
XVII
XVIII
XIX
XX
CD8445.book 9 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

10
Table of Contents
Operating precautions......................................................................... 16
Notes on operation........................................................................................................ 16
About compact discs ..................................................................................................... 17
About cleaning a CD .....................................................................................................19
About Memory Sticks .................................................................................................... 20
About cleaning the Memory Sticks................................................................................22
Names of controls and parts .............................................................. 23
ESN security operating procedure..................................................... 24
About ESN .................................................................................................................... 24
How to switch the security type (Key CD security/Memory Stick security) ................... 25
How to operate the ESN (Key CD) security ..................................................................26
How to program the Key CD................................................................................... 26
How to cancel the Key CD......................................................................................27
How to change the Key CD .................................................................................... 28
How to resume normal operation (ESN security lock out)......................................28
What happens if an incorrect CD is inserted? ........................................................ 29
How to operate the ESN (Memory Stick) security.........................................................30
How to record a security code ................................................................................30
How to cancel the Memory Stick security...............................................................32
How to change the Memory Stick ........................................................................... 34
How to resume normal operation (ESN security lock out)......................................35
What happens if a Memory Stick or security code is incorrect? .............................37
How to operate the ACC security..................................................................................38
How to turn the security indicator on/off........................................................................39
How to read the Electronic Serial Number ....................................................................40
Basic operation .................................................................................... 41
Turning the power on and off ........................................................................................ 41
Listening to CD .............................................................................................................42
Listening to MG Memory Stick ...................................................................................... 43
Listening to the tuner ....................................................................................................44
Adjusting audio volume ................................................................................................. 45
Switching audio control modes ..................................................................................... 46
VOL (VOLUME) Mode ............................................................................................ 46
BASS Mode ............................................................................................................ 46
MID (MIDDLE) Mode .............................................................................................. 47
TREB (TREBLE) Mode........................................................................................... 47
BAL (BALANCE) Mode........................................................................................... 47
FAD (FADER) Mode ............................................................................................... 47
NON-F (NON-FADER) Mode.................................................................................. 47
SVC (Source Volume Control) Mode...................................................................... 48
CD8445.book 10 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

11
Enabling the loudness control....................................................................................... 49
Making changes with Display Adjustment Mode...........................................................50
Switching the motion picture................................................................................... 51
Switching the brightness......................................................................................... 52
Changing illumination color..................................................................................... 53
Disabling the display...............................................................................................54
Importing DISP screens.......................................................................................... 55
Displaying Amplifier Status (E-AMP DISP).............................................................58
Making changes with Function Mode............................................................................ 59
Disabling the guide tone feature (for button operation) .......................................... 61
Clock display on/off.................................................................................................62
Setting the time.......................................................................................................63
Switching demonstration screen display................................................................. 64
Setting the steering switch function (U.S.A. only)................................................... 65
Others ........................................................................................................................... 69
Operation assist function ........................................................................................ 69
Displaying a memo .................................................................................................70
Setting a memo....................................................................................................... 70
Deleting a memo.....................................................................................................71
How to operate the CD player............................................................. 72
Listening to CDs............................................................................................................72
Advancing to the next track or returning to the beginning of the track being played .... 73
Fast Forward/Rewind.................................................................................................... 73
Playing the beginning of tracks (SCAN)........................................................................ 73
Repeating the same track (REPEAT) ........................................................................... 74
Playing tracks in random order (RANDOM).................................................................. 74
Ejecting the disc............................................................................................................75
Creating a title for a CD ................................................................................................76
Changing a previously set title ...................................................................................... 78
Deleting a previously created title .................................................................................80
Displaying CD text ........................................................................................................81
How to operate the MP3/WMA player................................................. 82
About MP3/WMA .......................................................................................................... 82
What is MP3/WMA?................................................................................................ 82
Playable MP3 file standards ................................................................................... 82
Playable WMA file standards.................................................................................. 82
ID3/WMA tags......................................................................................................... 83
Media......................................................................................................................83
Format of discs ....................................................................................................... 84
File names .............................................................................................................. 85
Multi-sessions ......................................................................................................... 85
Playing MP3/WMA.................................................................................................. 85
MP3/WMA playing time display ..............................................................................85
Display order of MP3/WMA file/folder names .........................................................85
CD8445.book 11 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

12
Listening to MP3/WMA file............................................................................................ 86
Advancing to the next track (file) or returning to the beginning of the track (file)
being played.................................................................................................................. 87
Skipping to the next or previous folder..........................................................................87
Fast Forward/Rewind.................................................................................................... 87
Return to the root directory of the CD ...........................................................................87
Playing the beginning of files (SCAN)...........................................................................88
Repeating the same file (REPEAT) ..............................................................................88
Playing files in random order (RANDOM) .....................................................................89
Displaying title ............................................................................................................... 90
How to operate the Memory Stick player........................................... 91
Listening to MG Memory Stick ...................................................................................... 91
Advancing to the next track or returning to the beginning of the track being played .... 92
Fast Forward/Rewind.................................................................................................... 92
Playing the beginning of tracks (SCAN)........................................................................ 92
Repeating the same track (REPEAT) ........................................................................... 93
Playing tracks in random order (RANDOM).................................................................. 93
Ejecting the Memory Stick ............................................................................................ 94
Recording on Memory Stick .......................................................................................... 95
Selecting tracks to be recorded ....................................................................................97
Setting sound quality.....................................................................................................98
Deleting recorded file ..................................................................................................100
Formatting MG Memory Stick (quick format) ..............................................................102
How to operate the tuner................................................................... 104
Tuning to a station ......................................................................................................104
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................................................105
Manually setting stations into memory ........................................................................106
Preset station scan .....................................................................................................107
Setting a station name ................................................................................................108
Deleting a station name ..............................................................................................110
Changing the reception sensitivity for automatic scanning .........................................111
Changing the radio band location ............................................................................... 112
FM reception characteristics .......................................................................................113
FM reception differs from AM ...............................................................................113
Fading out.............................................................................................................113
Reception area of FM broadcasts.........................................................................114
Multipath ...............................................................................................................114
How to operate the Sound Adjustment Mode ................................. 115
About Sound Adjustment Mode ..................................................................................115
Position selector ...................................................................................................116
SRS Circle Surround II (CS II) ..............................................................................116
DSP ......................................................................................................................116
CD8445.book 12 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

13
Parametric equalizer.............................................................................................116
Time Alignment.....................................................................................................118
Crossover .............................................................................................................119
Multi-harmonizer...................................................................................................120
Non-fader phase ...................................................................................................121
Non-Fader output..................................................................................................121
E-iSERV sound effect customizations ..................................................................121
Operations during Normal Mode.................................................................................124
DSP Setting ..........................................................................................................125
Position selector setting (POSITION) ...................................................................126
Non-fader phase selection (Non-F Phase) ...........................................................127
Crossover adjustment (X-Over) ............................................................................128
Multi-harmonizer settings (Harmonizer)................................................................129
Non-Fader Output.................................................................................................130
Operations during Advance Mode ..............................................................................131
SRS Circle Surround II (CS II) ..............................................................................132
Parametric equalizer adjustment (PEQ) ............................................................... 133
Selecting an equalizer mode from memory ..........................................................135
Measuring/display frequency characteristic..........................................................136
Simplified time alignment settings (Time Alignment) ............................................139
Crossover adjustment (X-Over) ............................................................................145
Multi-harmonizer settings (Harmonizer)................................................................146
Non-fader phase selection (Non-F Phase) ...........................................................147
Non-Fader Output.................................................................................................148
Importing Sound Data...........................................................................................149
How to operate the AREA SHOT function (U.S.A. only) ................. 151
About the AREA SHOT ...............................................................................................151
To use the AREA SHOT function .........................................................................152
Map data...............................................................................................................153
GPS (Global Positioning System).........................................................................153
Reading the AREA SHOT data ...................................................................................154
Changing the AREA SHOT mode ...............................................................................156
Using the AREA SHOT mode .....................................................................................157
AREA SHOT Screen Configuration ......................................................................157
Switching between guidance points......................................................................158
Re-scrolling through text information .................................................................... 159
Changing AREA SHOT screens ........................................................................... 160
Display Arrows......................................................................................................161
How to use the remote control ......................................................... 162
Precautions in use of the remote control ....................................................................162
Cleaning the remote control........................................................................................162
Turning the power on/off .............................................................................................163
Adjusting the audio volume......................................................................................... 163
Muting the volume ................................................................................................163
CD8445.book 13 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

14
Switching playback modes..........................................................................................164
How to play the tuner ..................................................................................................164
Selecting the FM/AM band ...................................................................................164
Selecting a station (manually or automatically) ....................................................165
Selecting preset stations.......................................................................................165
How to play CDs .........................................................................................................165
Switching disc modes ...........................................................................................165
Advancing to the next track or returning to the beginning of the track being
played ...................................................................................................................166
Skipping to the next or previous disc ....................................................................166
How to play MP3/WMA ...............................................................................................167
Switching disc modes ...........................................................................................167
Advancing to the next file or returning to the beginning of the file being played...167
Skipping to the next or previous folder .................................................................167
Replacing the battery ..................................................................................................168
How to operate the receiver with an optional CD changer
connected ........................................................................................... 170
Listening to a CD ........................................................................................................170
Advancing to the next track or returning to the beginning of the track being played .. 170
Fast Forward/Rewind..................................................................................................171
Playing the beginning of tracks (SCAN)...................................................................... 171
Repeating the same track (REPEAT) .........................................................................172
Playing tracks in random order (RANDOM)................................................................172
Skipping to the next or previous CD ...........................................................................173
Specifying a CD to play...............................................................................................173
How to operate the tuner with an optional HD Radio tuner
connected (U.S.A. only)..................................................................... 174
About HD Radio ..........................................................................................................174
Tuning to a station ......................................................................................................175
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................................................176
Manually setting stations into memory ........................................................................177
Preset station scan .....................................................................................................178
Switching between displays when receiving HD Radio...............................................179
HD Radio reception settings .......................................................................................179
How to operate the tuner with an optional SIRIUS satellite
radio tuner connected (U.S.A. only)................................................. 181
About SIRIUS satellite radio .......................................................................................181
Selecting the radio mode ............................................................................................182
Selecting a channel.....................................................................................................182
Category selection ...................................................................................................... 183
Direct channel selection..............................................................................................183
CD8445.book 14 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

15
Manually setting channels into memory ......................................................................185
Preset channel scan ................................................................................................... 186
Switching displays when using the SIRIUS satellite radio ..........................................186
Others ................................................................................................. 187
Connecting portable audio players to the AUX jack.................................................... 187
Changing auxiliary input sensitivity....................................................................... 188
User Registration Key display.....................................................................................189
If you have a question: ...................................................................... 190
Displayed information (for troubleshooting) ................................................................ 191
Specifications..................................................................................... 195
Before installation.............................................................................. 197
Components................................................................................................................ 197
Installation angle ......................................................................................................... 197
Mounting instruction ......................................................................... 198
Mounting the main unit................................................................................................ 198
Names of lead wires and destinations ....................................................................... 201
System ........................................................................................................................203
How to contact customer service..................................................... 209
CD8445TOC.fm 15 ページ ２００４年１２月１６日 木曜日 午後５時３２分

16
Operating precautions
Operating precautions
<Your CD8445 will perform well over a long period of time through correct handling
and care.>
Notes on operation
●For your safety, play only at volume levels that allow outside sounds to be heard.
●We recommend using with this player a disc with the
logo shown to the left.
●You can play music CDs(CD-R/CD-RW) on this player.
Be sure to use discs that have been properly processed.
Depending on the editing equipment used, some discs
may not play properly.
●Do not insert anything other than a CD and a Memory
Stick into the head unit.
Do not insert any foreign objects, such as coins or credit
cards, into the disc slot. Be especially watchful of
children’s mischief in this regard.
●Avoid severe mechanical shock.
When the player is subjected to severe vibration while
traveling over a rough surface, playback may be
intermittent. When a situation like this occurs, resume
playback after returning to a smoother road.
●About dew condensation.
In cold or rainy weather, just as the interior glass surface
gets fogged, dew (water condensation) may also settle
on the deck. When this occurs, disc playback may
become intermittent or impossible. Dehumidify the air in
the vehicle for a while before resuming playback.
TEXT
ATE
ATE
M
AGIC
AGIC
G
TICK
TICK
M
EMORY
EMORY
S
CD8445.book 16 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

17
Operating precautions
I
About compact discs
●The signal recorded on a compact disc is read by a laser beam, so nothing
touches the disc surface. A scratch on the recorded surface or a badly warped
disc may cause deteriorated sound quality or intermittent playback. Observe the
following precautions to ensure high quality sound performance:
●Cleaning the disc slot.
The disc slot tends to get dusty. Clean it occasionally to
prevent accumulated dust from scratching the discs.
●With the front panel open, many functions will not
operate, therefore, the front panel will need to be closed
during operation.
●Do not leave an ejected disc in the disc slot for very long;
the disc may warp. Discs should be stored in their cases
and kept away from high temperature and humidity.
●Do not stick a piece of paper or tape. Do not write on or
scratch either side of a disc.
●Discs spin at a high speed inside the deck. Keep
cracked or warped discs out of the player to avoid
damage it.
●Avoid touching the recorded surface when handling a
disc; handle discs by their edges.
ATE
ATE
M
AGIC
AGIC
G
TICK
TICK
M
EMORY
EMORY
S
ATE
ATE
M
AGIC
AGIC
G
TICK
TICK
M
EMORY
EMORY
S
CD8445.book 17 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

18
Operating precautions
●You may notice that some brand new
discs are rough around the center
hole or outside edge. Remove the
rough edges with the side of a
ballpoint pen, etc. Rough edges may
prevent proper loading in the deck.
Flakes from the rough edges may
also stick to the recorded surface and
interfere with playback.
●Do not use accessories
(stabilizers, protective seals, laser
lens cleaners, etc.) sold for
"improving sound performance" or
"protecting CDs." The changes in CD
thickness or outside dimensions
made by these accessories may
cause problems in the player.
● Please be sure NOT to attach any ring-
shape protector (or other accessory) to
your discs. Those protectors are
commercially available and said to
protect disc and to improve sound
quality (and antivibration effect), but
they can do more harm than good in
regular uses. The most common
problems are disc insertion, disc
ejections, and won't play problems due
to the protector ring that came off in the
disc mechanism.
About brand new CDs
Rough Edges
Ballpoint
pen
Flakes
Recorded surface
Rough
Edges
About CD accessories
CD8445.book 18 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

19
Operating precautions
I
●Do not use a CD with glue or remnants
of adhesive tape or labels. They may
cause the CD to get stuck inside or
damage the deck.
●When removing the ejected disc, pull
it straight out along the slot. Pressing
downward in the process may scratch
the recorded surface of the disc.
●Specially-shaped CDs, like heart-
shaped or octagonal CDs, cannot be
played. Do not attempt to play them,
even with an adapter, since they may
damage the player.
About cleaning a CD
About borrowed CDs
How to remove CDs
OKA
Y
NO GOOD
About irregularly-shaped CDs
●Use a commercially available compact disc cleaner to
clean a CD, wiping gently from the center to the edge.
●Do not use benzine, thinner, LP record spray or other
cleaners on CDs. They may damage a CD’s finish.
XXXX
XXXX
XXXX
CD8445.book 19 ページ ２００４年１２月１３日 月曜日 午前１１時３０分

20
Operating precautions
About Memory Sticks
●Do not store Memory Sticks in places that are subject to
static electricity and electrical interference, otherwise the
data they contain may become corrupted.
●In order to protect the player, the player's functions will
be stopped automatically if a problem occurs. If the
player cannot be operated even after following the
instructions that appear on the screen, the unit is
malfunctioning, and you should ask the place of
purchase for further advice.
●If using a Memory Stick Duo, you will need to use it with
a Memory Stick Duo adapter.
●Only Memory Sticks with a capacity of up to 128 MB can
be used in the unit.
●Memory Stick PRO types of Memory Stick cannot be
used.
●If MG Memory Stick is not being used for prolonged time,
remove it from the unit.
●MG Memory Sticks bearing one of the marks at the left
can be used.
●Memory Sticks bearing one of the marks at left can be
used for writing and reading data other than music data.
MagicGate Memory Stick and Memory Stick are
trademarks of Sony Corporation.
●If the write protection switch on a MG Memory Stick or
Memory Stick is at the lock position, audio recordings
and other data cannot be saved onto it.
●Do not remove a MG Memory Stick while it is being
accessed for playback or recording, otherwise the data
on the MG Memory Stick may become corrupted. If the
data becomes corrupted, it can no longer be retrieved.
●Please format the MG Memory Stick on this deck. A MG
Memory Stick formatted by another deck may not be
playback or record data.
●When a Memory Stick is formatted, all data on that
Memory Stick will be erased. (Includes Memory Stick
security recorded data and sound quality data)
CD8445.book 20 ページ ２００４年１２月１３日 月曜日 午前１１時３０分
