Eco Pure ECOP20 User manual

7316151 (Rev. D 2/21/12)
Installation and Operation Manual
System tested and certified by NSF nternational
against NSF/ANS Standards 42 & 53,
for the reduction of the claims specified
on the performance data sheet.
Do not return unit to store
f you have any questions or concerns when
installing, operating or maintaining your
Undersink Drinking Water Filter System,
call our toll free number:
1-800-693-1138
Monday- Friday, 7 AM - 6 PM CST
or visit www.ecopurewaterproducts.com
When you call, please be prepared to provide
the model, date code and serial number of
your product, found on the rating decal,
located inside the cover.
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
How to install, operate
and maintain your Undersink
Drinking Water System
Model ECOP20

2
Questions? Call toll free: 1-800-693-1138
3-1/2"8-3/8"
13"
Filter 1 Filter 2
3-1/2”
13”
8-3/8”
Table of Contents
Parts of the System / Materials and Tools Needed / Typical Undersink nstallation . . . . . . . . . . . . . . . . .3
nstallation Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Filter Cartridge Life / Filter Cartridge Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Faucet Timer / Battery Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Exploded View / Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11
Before You Start
qRead all steps and guides carefully before installing and using your undersink drinking water filter sys-
tem. Follow all steps exactly to correctly install. Reading this manual will also help you to get all the ben-
efits from the undersink drinking water filter system.
qDo not use with water that is microbiologically unsafe or of unknown quality without adequate disinfec-
tion before or after the system. This system is certified for cyst reduction and may be used on disinfected
waters that may contain filterable cysts.
qAll plumbing should be done in accordance with local codes and requirements. n Massachusetts,
plumbing code 248 CMR 3.00 and 10.00 shall be adhered to. Consult with your licensed plumber.
qThe undersink drinking water filter system works on water pressures of 30 psi (minimum) to 125 psi
(maximum). f your house water pressure is over the maximum, install a pressure reducing valve in the
water supply pipe to the filter system.
qDo not install the undersink drinking water filter system outside, or in extreme hot or cold tempera-
tures. Temperature of the water supply to the undersink drinking water filter system must be between
40°F and 100°F. Do not install on hot water.
Min. - Max. Supply Water Pressure 30 - 125 psi (207 - 862 kPa)
Min. - Max. Supply Water Temperature 40 - 100 °F (4 - 38 °C)
nlet - Outlet 3/8" quick connect fittings and tubing included
Specifications and Dimensions

3
Questions? Call toll free: 1-800-693-1138
arts of the System
Materials and Tools Needed
Typical Undersink Installation
•filter system assembly
•water supply fitting
•filtered water faucet for sink or countertop mounting
•3/8" tube bends
•3/8" tubing to make all needed connections
NOTE: Gather the required tools before starting installation. Read and follow
the instructions provided with any tools listed here.
•slotted and Phillips screwdrivers
•pliers and adjustable jaw wrench
•tubing cutter
•electric drill and 1-1/4" drill bit if mounting hole is needed for the faucet
IM ORTANT: To avoid damaging the sink, consult a qualified plumber or
installer for drilling procedures in porcelain or stainless steel.
Locate the water filter housing on the cold water supply pipe, under the kitchen and/or bathroom sink, to
filter the cold drinking water. Refer to the following drawing.
shutoff valve
filtered water
faucet
filter 2
filter 1
Blue
WATER
OUT
Yellow
WATER
IN
supply fitting
S NK
NOTE: f tubing needs to make a sharp
bend, use included tube benders to
prevent kinking.
NOTE: Be sure to allow a minimum space of 1-1/2" under the system
for removing the filter cartridges, in order to change the cartridges.
Fig. 1
4-1/4”
HOT COLD

4
Questions? Call toll free: 1-800-693-1138
Installation Steps
Step 1 - Cold Water Supply Fitting
Check and comply with local plumbing codes as you plan, then install a cold feed (supply) water fitting.
The fitting must provide a leak-tight connection to the water filter 3/8" tubing. A typical connection using
the included water supply fitting is shown in Figure 2A. An optional connection using standard plumbing
fittings (not included) is shown in Figure 2B.
Cold Water Supply Fitting
1. Close the water shut off valve that is immediately before supply fitting and open faucets to drain water
from the sink cold water pipe.
2. Remove nut that connects the cold water faucet to cold water plumbing.
3. Thread water supply fitting onto pipe and reconnect nut to bottom of fitting.
Optional Pipe Fittings (compression type shown)
NOTE: Be sure to turn off the water supply and open a faucet to drain the pipe.
Complying with plumbing codes, install a fitting on the cold water pipe to adapt 3/8" OD tubing. A typical
connection is shown in Figure 2B. f threaded fittings are used, be sure to use pipe joint compound or
thread sealing tape on outside threads.
Fig. 2
cold water
faucet stud
thread sealing
tape on threads
cold water
pipe
cold water
pipe
A. Water supply connection
(using included water supply fitting)
B. Water supply typical connection
(using compression fitting)
- parts not provided -
cold water
shutoff
cold water
shutoff
water supply fitting
3/8" tubing to
water filter inlet
3/8" compression
fitting
insert
ferrule
3/8" tubing to
Water Filter inlet

5
Questions? Call toll free: 1-800-693-1138
Installation Steps
Step 2 - Make Hole For Filtered Water Faucet
Step 3 - nstall Faucet
IM ORTANT: To avoid damaging the sink, consult a qualified plumber or installer for drilling procedures
in porcelain or stainless steel. Special drill bits are made for this.
1. Select one of the following places to install the faucet. Be sure there's room underneath so you can
make the needed connections.
•n an existing sink spray attachment hole.
•Drill a hole in the sink top.
•Drill a hole in the countertop next to the sink.
2. f drilling is needed make a 1-1/4" dia. (minimum) hole for the faucet.
1. Feed the 3/8" tubing that is attached to the faucet through the mounting hole. Slide the toggle bolts
through the mounting hole. Tighten the screws to secure the base flat on the mounting surface. Do not
overtighten.
2. Move the faucet down onto the base. Turn 1/4 clockwise to attach the faucet to the base.
3. nstall battery in base. See “Battery Change” section for instructions.
Fig. 3
faucet base
1/4 turn to connect
faucet to base
screw
toggle bolt
rubber washer
hole in sink
or countertop
faucet

6
Questions? Call toll free: 1-800-693-1138
Installation Steps
Step 4 - Make Tubing Connections
To Disconnect Tubing:
1. Push the collet inward and hold with a finger while pulling the tubing out.
Fig. 5
tubing
collet (depress to remove tubing)
Fig. 4
NOTE: Remove protective foam plugs before connecting tubes (See Fig. 4). Discard foam plugs.
1. Allowing some slack, measure and cut a length of 3/8" tubing to connect between the supply fitting
and the filter system inlet, Figure 1. Cut the ends of the tubing square.
2. nsert tubing all the way into the supply fitting and inlet fitting. Pull on the tubing to be sure that it's
held firmly in the fittings.
3. Repeat steps 1 and 2 to connect tubing from the faucet to the filter system outlet, Figure 1.
Tubing Connection (all push-in fitting locations):
This system includes push-in fittings for quick tubing connections. f working with the fittings, do the fol-
lowing.
Connect Tubing:
1. Use a sharp cutter or knife to cut the end of tubing square.
2. nspect the end (about 1") of the tubing to be sure there are no nicks, scratches or other rough spots.
f needed cut the tubing again.
3. Push tubing through the collet and all the way into fitting. Full engagement is 3/4" length of tube into
the fitting.
f tubing other than supplied with the system is used, be sure it is of high quality, exact size and round-
ness with a smooth surface.
end of tubing round and smooth,
with no cuts, nicks or flat spots
correct full 3/4" engagement
Tubing correctly cut and connected
Incorrect partial engagement
Remove and discard foam plugs
foam plug
push in fitting

7
Questions? Call toll free: 1-800-693-1138
Filter Cartridges
Filter Cartridge Life
Filter Cartridge Replacement
Taste and Odor Cartridges: A taste and odor cartridge contains activated carbon, a black powder.
When new, open the filtered water faucet and allow fine, carbon particles to purge from the cartridge.
Close the faucet when you no longer see the “fines” (carbon particulates) in the filtered water, or approxi-
mately 10 minutes. t is recommended to replace the battery and filter cartridges every six months of
use. There are several variables that determine how long a cartridge will last. These include:
1. How much water you use, and
2. How much sediment, taste and/or odor, or other unwanted substance, is in the water.
Use the following information as a guide. However, no matter which type of cartridge you are using, you
will know it is time to replace it when you first notice the return of the unwanted substance in your water.
Ecopure Undersink Drinking Water Filter system model ECOP20 with replacement element pack
ECODWF conforms to NSF/ANS 42 and 53 for the specific performance claims as verified and substan-
tiated by test data. The rated capacity for this system is 280 gallons (1060 liters) at a rated service flow
of 0.5 gpm (gallons per minute).
1. Turn filter cartridge to the left to remove cartridges from the filter heads.
2. Dispose of the cartridges in a proper manner.
3. nstall new cartridges. Turn cartridges to the right to re-attach to the filter heads.
4. Remove and replace the timer battery. See “Battery Change” section for instructions.
Taste and Odor Cartridges: A taste and odor cartridge contains activated carbon, a black powder.
When new, open the filtered water faucet and allow the fine carbon particles to purge from the cartridge.
Close the faucet when you no longer see the “fines” in the filtered water, or approximately 10 minutes.
Filter 1 Filter 2
Fig. 6
filter cartridge
head
Turn filter cartridge to the left
to remove from head
Turn filter cartridge to the right
to attach to head

8
Questions? Call toll free: 1-800-693-1138
Faucet Electronics
Troubleshooting the System
Battery Change
Faucet Timer
To change the battery, complete the following steps.
1. Loosen the screw on the right side of the faucet base.
2. Press the battery housing upwards from faucet base until it releases from the base.
3. Replace the battery (CR 2032 or equivalent). Place battery into the holder with the positive (+) side
facing the back of the holder.
4. When the battery is first replaced the light in the base will flash six times and turn off. This indicates
the battery is fully charged. After the six flashes the timer enters the 6 month time cycle. f it repeatedly
flashes two times, the battery is weak and needs to be replaced.
5. Re-install the battery housing and firmly tighten the mounting screw.
nside the faucet base is a battery operated 6 month timer.
An amber LED indicator is also located in the front of the faucet base. This LED will flash continuously
after 6 months have passed. This indicates that it is time to replace the battery and filters.
Problem: Taste and/or Odor.
Cause: Filter 1 and 2 expended. Correction: Replace the filter cartridges.
Cause: System contaminated. Correction: Sanitize system. Call 1-800-693-1138 for
instructions.
Problem: Faucet LED indicator light does not function after batter change.
Cause: Battery dead. Correction: Replace with new battery.
Cause: Battery installed incorrectly. Correction: nstall battery correctly.
Problem: Water leaks at push connect fittings.
Cause: Tubing not pushed in all the way. Correction: Push tubing in all the way into fittings.
Cause: Tubing not cut square. Correction: Cut tubing square.
Cause: Tubing nicked. Correction: Remove nicked portion, reinsert tubing into fit-
ting.
Cause: Outer tubing surface not smooth. Correction: Remove rough portion, reinsert tubing into fit-
ting.
battery housing
battery,
negative (-) side
facing the front screw
Fig. 7

9
Questions? Call toll free: 1-800-693-1138
Warranty
ONE YEAR LIMITED WARRANTY ON UNDERSINK DRINKING WATER FILTER SYSTEM
(except filter cartridges)
Warrantor: Ecodyne Water Systems, 1890 Woodlane Drive, Woodbury, MN 55125
Warrantor guarantees, to the original owner, that the Undersink Drinking Water Filter System, when installed and
maintained in accordance with the instructions, will be free from defects in materials and workmanship for a
period of one (1) year from the date of purchase. f, within the first year, a part proves, after inspection, to be
defective, Warrantor will, at its sole option, either replace or repair the part without charge except installation
charges. Labor to maintain the equipment is not part of the warranty. Filters, which are expendable, are not cov-
ered by the warranty.
TO OBTA N WARRANTY PARTS, S MPLY CALL 1-800-693-1138, Monday - Friday, 7 am - 6 pm CST, for assis-
tance. This warranty applies only while this product is in use in the United States.
General rovisions
The above warranties are effective provided the Undersink Drinking Water Filter System is operated at water
pressures not exceeding 125 psi, and at water temperatures not exceeding 100°F; provided further that the
Undersink Drinking Water Filter System is not subject to abuse, misuse, alteration, neglect, freezing, accident or
negligence; and provided further that the Undersink Drinking Water Filter System is not damaged as the result of
any unusual force of nature such as, but not limited to, flood, hurricane, tornado or earthquake.
Warrantor is excused if failure to perform its warranty obligations is the result of strikes, government regulation,
materials shortages, or other circumstances beyond its control.
*THERE ARE NO WARRANTIES ON THE UNDERSINK DRINKING WATER FILTER SYSTEM BEYOND THOSE
S ECIFICALLY DESCRIBED ABOVE. ALL IM LIED WARRANTIES, INCLUDING ANY IM LIED WARRANTY
OF MERCHANTABILITY OR OF FITNESS FOR A ARTICULAR UR OSE, ARE DISCLAIMED TO THE
EXTENT THEY MIGHT EXTEND BEYOND THE ABOVE ERIODS. THE SOLE OBLIGATION OF WARRANTOR
UNDER THESE WARRANTIES IS TO RE LACE OR RE AIR THE COM ONENT OR ART WHICH ROVES
TO BE DEFECTIVE WITHIN THE S ECIFIED TIME ERIOD, AND WARRANTOR IS NOT LIABLE FOR CON-
SEQUENTIAL OR INCIDENTAL DAMAGES. NO WARRANTOR DEALER, AGENT, RE RESENTATIVE, OR
OTHER ERSON IS AUTHORIZED TO EXTEND OR EX AND THE WARRANTIES EX RESSLY DESCRIBED
ABOVE.
Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of inciden-
tal or consequential damage, so the limitations and exclusions in this warranty may not apply to you. This warran-
ty gives you specific legal rights, and you may have other rights which vary from state to state. This warranty applies
to consumer-owned installations only.

10
Questions? Call toll free: 1-800-693-1138
Exploded View
1
2
3
5
7
6
9
8
10
4
4

11
Questions? Call toll free: 1-800-693-1138
Repair arts List
Key No. art No. Description
1 7292674 Faucet, with base & electronics
2 7268382 Cover (2 req’d)
3 7228536 Tee, Feed Adaptor
4 7273565 Flow Bend, 3/8” (2 req’d)
5 7208057 Tubing, 3/8” x 72” long, Yellow
6 7207962 Tubing, 3/8” x 72” long, Blue
7 7280106 Head Assembly
8 ECODWF Rep’l Filter Cartridge (2 pack) Ù
– 7333129 Mounting Hardware Kit
(includes 2 ea. of Key Nos. 9 & 10)
9áHanger Washer (2 req’d)
10 áScrew (2 req’d)
¢7316151 Owner’s Manual
ÙPlease purchase replacement cartridges from the retailer
where you bought your drinking water system.
¢Not illustrated.
For repair parts call 1-800-693-1138, Monday - Friday, 7 am - 6 pm CST.
