Eco Statics VP300ES Instruction manual
This a brief guide to demonstrate the basic ‘Operating Instructions’ and ‘Tips for Spraying’ of the
VP300ES model Please ensure you have read and understood the operations manual before
operating the sprayer
Operating Instructions
Tips for Spraying
1 To start the use of the Electrostatic Sprayer first charge your battery (1 1) by inserting the 16 8-volt battery
into the charger and plugging the charger into a wall socket
2 Next attach the wand (1 2) to the hose (1 3) and then connect it the side of the back pack unit with both the
water and electrical lines via the connectors (1 10)
3 Fill the tank (1 4) by first removing it from the unit via the clip at the top (1 5) and then lift the tank out the
main unit and fill with your desired water based liquid
4 Insert the tank back into the main unit ( TIP - Stand the unit on a flat surface and then place the tank into the
unit ) and secure it via the tank clip
5 Insert the charged battery into the battery socket (1 1 ) and screw on cover
6 Ensure 3 In 1 nozzle (1 6) is on desired setting and before spraying
7 Turn on the back pack sprayer via the power switch on the left hand side (1 7)
8 Lift the back pack onto your back via the straps or attach to trolley accessory
9 Pull the trigger (1 8) and spray on your desired surface When spraying, there is a locking clip which can be
pushed in to allow constant spray (1 9)
10 When you have finished spraying always take the battery out and empty the contents of the tank and flush
through with water Once the battery has been removed, remove hose via the coupler attachment and push
the silver tab to remove the electrical line (1 10 )
11 Never leave the solutions in the sprayer when not in use—pack away sprayer
1 1 Battery /Battery Socket
QUICK USER GUIDE - VP3 ES
16 8v Back Pack Electrostatic Sprayer
CONTINUED
16.8V Battery
•
4 hours spray time
•
2 hours charge time
3 in 1 Nozzle 1 6
Trigger Lock 1 9
Trigger 1 8
Connectors 1 10
1 4 Tank
1 5 Tank Lock
Wand 1 2
Power Switch 1 7
1 3 Hose
•
Stand approximately 5-7 feet away from the surface/area, as the spray travels further than what you think
•
Work in a methodical pattern to ensure an even coverage
•
Angle the sprayer slightly upwards and aim slightly above your target as droplets will drop slightly
•
If you want a longer dwell time
(length of time the solution is wet on the surface)
adjust the nozzle to a higher
micron size
•
Don’t spray directly into sockets or electrical items
•
Always wear the correct PPE equipment for the chemical / solution you are spraying
•
Cleaning the sprayer Empty the contents and refill using water, turn off the electrostatics and spray through
the system for approximately one minute You can turn the nozzles to spray through each one, however
this is not really required
Nozzle Instructions
To remove the 3 in 1 nozzle:
•
Remove the battery from the unit
•
Insert the nozzle wrench around the nozzle piece, fitting it into the grooves
•
Twist the nozzle wrench 1/4 turn anti-clockwise (no pressure required)
•
3 in 1 nozzle should be loose and able to be removed
To insert the 3 in 1 nozzle:
•
Remove the battery from the unit
•
Insert the wrench tool into the nozzle
•
Put the nozzle in the unit, twist until you find the small grooves on the nozzle
•
Twist the wrench 1/4 turn ANTI-CLOCKWISE, the nozzle will move backwards into place
•
Then turn back CLOCKWISE until you hear it click
•
You can then turn it clockwise to your desired nozzle size
If your nozzle is now spraying from the bottom please do the following steps...
•
Insert the wrench tool around the nozzle, fitting it into the grooves
•
Twist the nozzle 1/4 turn anti-clockwise, so it pops out slightly
•
Twist the nozzle 1/4 turn anti-clockwise again, the nozzle should then move back into place
• TIP: o 1 full clockwise rotations of the nozzle to ensure the nozzles are lined up.
Nozzle Diagram
80 Micron (Cone)
40 Micron (Cone)
110 Micron (Fan)
Warranty for your VP3 ES
This is YOUR GUARANTEE for your VP3 ES Details
Quality Control -
Eco Statics (UK) Ltd
1 Amelia Court Business Park,
Retford, Nottinghamshire DN22 7HJ
Web: www ecostatics com
Email: contact@ecostatics com
Tel: +44 (0) 3452 247 582
1 year warranty valid
from date of
purchase please
KEEP SAFE!
One Year Limited Warranty -
Eco Statics UK Ltd will repair or replace, without charge,
any defects due to faulty materials or
workmanship for one year from the date of purchase
This warranty does not cover part failure due to normal
wear or tool abuse For further detail of warranty
coverage and warranty repair information, email us at
contact@ecostatics.com This warranty does not apply to
damage caused where repairs have been made or
attempted by others This warranty gives you specific
legal rights and you may have other rights, which vary in
certain Countries Eco Statics UK Ltd offer refunds within
30 days of payment purchase date After this date
refunds are NOT given & no explanation or reason will
be provided
Free warning label replacement: Please email us if your
warning labels become illegible or are missing
RRP is £1650 plus vat / €1700 By purchasing this
product you agree to NOT advertise this item on the web
below £1650 or any other currency equivalent
Dated - 2 /07/18
