ecoey FJ128 User manual

PRODUCT SPECIFICATIONS
PRODUCT OVERVIEW
User Manual
Model: FJ128
Carbon Monoxide Alarm
• Power Supply: DC 3V(AA 1.5V*2) battery operated
• Sensitivity Setting:
50PPM Between 60 to 90 minutes
100PPM Between 10 to 40 minutes
300PPM Less than 3 minutes
• Standby Current: <20μA (average)
• Alarm Current: <50mA (average)
• Storage/Transport Ambient Condition:
-20~+50℃,10~95% non-condensing
• Sensor Type: electrochemical
• Alarm sound:
≥85dB at 100cm @3.2±0.5KHz pulsing alarm
MADE IN CHINA
• POWER indicator
The POWER indicator (green LED) is used to indicate power
status of the CO alarm.
The POWER indicator will flash every 33 seconds.
• FAULT indicator
The FAULT indicator (yellow LED) is used to indicate fault or
warning status of the CO alarm.
• ALARM indicator
The ALARM indicator (red LED) is used to indicate alarm
status of the CO alarm.
• TEST/SILENCE button
The TEST/SILECNE button is used to test the unit. Press and
hold to enable TEST function.
• Alarm sounder
The alarm sounder is used to send out CO alarm warning
and fault warning information.
• LCD screen
Indicates CO concentration and alarm status.
TEST
SILENCE
7 YEARS LIFE TIME

UNDERSTANDING YOUR CO ALARM
GENERAL MAINTENANCE
To keep your CO alarm in good working order, please follow these simple steps:
1.
Verify the unit's alarm sound and indictors operation by enable the TEST/SILENCE button once a week.
2. Remove the unit from the wall and clean the alarm cover and vents with a soft brush
attachment once a month to remove dust and dirt.
3. Never use detergents or other solvents to clean the unit.
4. Avoid spraying air fresheners, hair spray, or other aerosols near the CO alarm.
5. Do not paint the unit. Paint will seal the vents and interfere with the sensor's ability to detect
CO. Never attempt to disassemble the unit or clean inside. This action will void your warranty.
6. As soon as possible, place the CO alarm back in its proper location to assure continuous
protection from carbon monoxide poisoning.
7.
When household cleaning supplies or similar contaminants are used, the area should be ventilated.
WARNING! –The following substances can affect the sensor and may cause false actions:
methane, propane, isobutene, isopropanol, ethylene, benzene, toluene, ethyl acetate,
hydrogen sulfide, sulfur dioxides, alcohol based products, paints, thinner, solvents, adhesives,
hair sprays, after shaves ,perfumes and some cleaning agents.
WARNING! –Your CO alarm will not be operational and will not monitor for CO levels without
battery.
WARNING! –This apparatus is designed to protect individuals from the acute effects of carbon
monoxide exposure. It will not fully safeguard individuals with specific medical conditions. If in
doubt consult a medical practitioner.
• Start up
After connecting the battery, all three LEDs light up briefly and the CO alarm confirms start-up
with a beep. After power on, 40 seconds before the green LED flash every 3 seconds, This is
preheated state, 40 seconds later the green LED flashing every 33 seconds indicates the unit is
functioning properly. The LCD will active for 40 seconds, as follow:
• Low battery voltage warning silence
When the alarm is under the low battery warmning, pressing the TEST/SILENCE button, it
willcome into silence status for about 9 hours, and FAULT indicator (yellow LED) still keep
flashing. The LCD will active for 1 seconds every 33 seconds, as follow:
NOTE: When alarm under the low battery warning, please replace the battery in time to ensure
the normal working.
• End of life warning
lf the alarm chirps 3 tines every 33 seconds with FAULT indicator (yellow LED) flash.
lt indicates end of life of the CO alarm. You need to immediately replace the CO alarm.
the LCD will active for 4 seconds every 33 seconds, as follow:
• CO alarm warning
When the alarm detects a dangerous level of CO, the alarm will emit a loud alarm pattern. The
alarm signal pattern is 4 quick beeps followed by 5 seconds of silence. This cycle repeats as
long as a dangerous CO condition exists. The red alarm LED will flash the same pattern.
This signal will repeated until the alarm resets after dissipation of CO.
When CO concentration is >=30ppm, the LCD will active for 4 seconds every 33 seconds, and
alarm is positive, the LCD will always active, display CO concentration as follow:
• Human alarm sounds
lf the alarm come into the status of CO alarm waining, the alarm willstart in a lower alarm
volume (<85dB) for around 10 seconds, then issuing a normal alarm volume (>85dB).
It will avoid people to be scared suddenly by a loudness alarm sound.
• Test the unit
To test the alarm, press and hold TEST/SILENCE button, you should hear alarm sound patterns
and with a corresponding ALARM indicator (red LED) flash. The alarm sound patterns will stop
when release TEST/SILENCE button.
The test alarm sound pattern includes: 4 short beeps, 5 seconds pause, repeat the pattern until
release TEST/SILENCE button. the LCD will activate for 100 seconds, as follow:
NOTE: After theTEST/SILENCE button is enabled, the alarm sounds and the red alarm light
flashes. This does not indicate that CO is present.
NOTE: Test the unit weeklyl lf at any time your unit does not perform as described, replace it
immediately.
• Normal operation
The POWER indicator (green LED) flashing every 33 seconds.
• Low battery voltage warning
lf the alarm chirps once every 33 seconds, with FAULT indictor (yellow LED) will be flash.
lt indicates the battery is low. The LCD will active for 1 seconds every 33 seconds, as follow:
NOTE: You need to replace the batteries immediately when the alarm enters this status.
NOTE: The alarm will not protect against the risk of carbon monoxide poisoning when the
battery has drained.
• Fault warning
lf the unit chirps twice every 38 seconds, with FAULT indicator (yellow LED) will be flash. lt
indicates the CO alarm is in malfunction condition. That means your CO alarm has no detecting
function and no respond CO.
The LCD will active for 4 seconds every 38 seconds, as follow:
Replace battery, if condition continues, the CO alarm has malfunctioned. Replace immediately.
Please contact us to more service.
